Power Supply Board Terminal Identification:

Terminal Legend
L, N
+ DC –
Trigger EOL
Supervised
NO, GND RESET
+ AUX –
AC FAIL
NC, C, NO
BAT FAIL
NC, C, NO
+ BAT –

Access Power Controller Terminal Identification:

Terminal Legend
– Power +
– Control +
TRIGGER INPUT
1-INPUT 8 IN, GND
OUTPUT 1-
OUTPUT 8
NC, C, NO, COM
FACP INTERFACE
T, + INPUT –
FACP INTERFACE
NC, C, NO
eFlowNA8DV Series Installation Guide
Function/Description
Connect 220VAC 50/60Hz to these terminals: L to hot, N to neutral.
Do not use terminal marked [G]
Factory connected to ACM8CB board.
Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally
open, normally closed from an FACP output circuit (power-limited input) (Fig. 3, pg. 9).
FACP interface latching or non-latching (power-limited) (Fig. 3, pg. 9).
Auxiliary power-limited output rated @ 1A (unswitched) (Fig. 3, pg. 9).
Indicates loss of AC power, e.g. connect to audible device or alarm panel.
Relay normally energized when AC power is present.
Contact rating 1A @ 30VDC (power-limited) (Fig. 3, pg. 9).
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized
when DC power is present. Contact rating 1A @ 30VDC.
A removed battery is reported within 5 minutes.
Battery reconnection is reported within 1 minute (power-limited) (Fig. 3, pg. 9).
Stand-by battery connections.
Maximum charge current 1.54A (non power-limited) (Fig. 3, pg. 9).
Function/Description
12VDC or 24VDC from power supply/charger (factory connected).
These terminals are paralleled to the [– Control +] terminals.
These terminals are paralleled to the [– Power +] terminals.
These terminals can be connected to an external Listed power-limited access control
power supply to provide isolated operating power for the devices.
Jumpers J1 and J2 must be removed.
From normally open and/or open collector sink trigger inputs
(request to exit buttons, exit pir's, etc.)
12VDC to 24VDC trigger controlled outputs:
eFlow4NA8DV - 9.8-13.2VDC @ 3.3A or 19.9-26.4VDC @ 3.6A (power-limited).
eFlow6NA8DV - 9.7-13.2VDC @ 5.3A or 19.8-26.4VDC @ 5.6A (power-limited).
eFlow102NA8DV - 9.7-13.2VDC @ 9.3A (power-limited).
eFlow104NA8DV - 19.8-26.4VDC @ 9.6A (power-limited).
Fail-Safe [NC positive (+) & COM Negative (–)],
Fail-Secure [NO positive (+) & COM Negative (–)],
Auxiliary output [C positive (+) & COM Negative (–)] (When using AC power supplies
polarity needs not to be observed). Contacts shown in a non-triggered state.
Fire Alarm Interface trigger input from FACP. Trigger inputs can be normally open,
normally closed from an FACP signaling circuit output (Figs. 5-10, pg. 11-12).
Form "C" relay contact rated @ 1A 28VDC for alarm reporting.
