Web-based manager pages

Lists

Icons

30
Antivirus Configure antivirus protection.
Web Filter Configure web filtering.
Spam Filter Configure email spam filtering.
Log & Report Configure logging. View log messages.
Many of the web-based manager pages are lists. There are lists of network interfaces,
firewall policies, administrators, users, and so on.
Figure 6: Example of a web-based manager list
The list shows some information about each item and the icons in the rightmost
column enable you to take action on the item. In this example, you can select Delete
to remove the item or select Edit to modify the item.
To add another item to the list, you select Create New. This opens a dialog box in
which you define the new item. The dialog box for creating a new item is similar to the
one for editing an existing item.
The web-based manager has icons in addition to buttons to enable you to interact with
the system. There are tooltips to assist you in understanding the function of the icon.
Pause the mouse pointer over the icon to view the tooltip. The following table
describes the icons that you will see in the web-based manager.
Icon Name
Change
Password
Clear
Column
Settings
Delete
01-28008-0013-20050204
Description
Change the administrator password. This icon appears in the
Administrators list if your access profile enables write permission
on Admin Users.
Clear a log file.
Select log columns to display.
Delete an item. This icon appears in lists where the item is
deletable and you have write permission on the page.
Web-based manager
Delete
Edit
