3. Clean out the inside of enclosure before remounting circuit board.

4. Mounting NEMA4/4X rated enclosure (Enclosure Dimensions, pgs. 11-12):

Wall mount: Mount unit in desired location. Mark and drill holes to line up with the top and bottom holes of the enclosure flange. Secure enclosure with appropriate fasteners

(e. g. screws and anchors; bolts and locking nuts, etc.) that are compatible with mounting surface and are of sufficient length/construction to ensure a secure mount (Fig. 5, pg. 8).

Pole Mount: Refer to Figs. 6 - 11, pg. 8. Note: All inlets for conduit fittings should be on the bottom of the enclosure.

5. Mount backplane in enclosure with hardware.

6. To facilitate wire entry utilize weather-tight NEMA rated connectors (supplied), bushings, and cable.

NetWaySP8X Enclosure Mounting and Installation:

1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the enclosure. Install two (2) upper fasteners and screws in the wall

with the screw heads protruding. Place the enclosure's upper keyholes over the two (2) upper screws; level and secure. Mark the position of the lower two (2) holes. Remove the

enclosure. Drill the lower holes and install two fasteners. Place the enclosure's upper keyholes over the two (2) upper screws. Install the two (2) lower screws and make sure to

tighten all screws (Enclosure Dimensions, pg. 9). Secure enclosure to earth ground.

NetWaySP8B/SP8PL Mounting and Installation:

1. Mount board/backplane in the desired location/enclosure with hardware supplied.

2. NetWaySP8B: Connect 56VDC/120W max power source to terminal marked [+ and --- ].

1. For NetWaySP8WP, NetWaySP8WPX, NetWaySP8X, and NetWaySP8PL:

Before powering unit, set input voltage selection switch to proper Input Voltage position (Fig. 3a, pg. 6) Units are factory set for 115VAC.

2. Secure cabinet to earth ground. Connect AC power from overcurrent protective device circuit breaker (20A @ 115VAC, 60Hz, 16A @ 230VAC, 50/60Hz)

to the terminals marked [L, N] on power supply board (Fig. 3, pg. 6).

Use 14AWG or larger for all power connections (Battery, DC output, AC input). Connect ground lug

Note: For NetWaySP8WPN use external 48-55V UL Listed ITE power supply, carefully observing correct polarity (Fig. 4, pg. 7).

Keep power-limited wiring separate from non power-limited wiring by utilizing separate knockouts/inlets. Minimum 0.25" spacing must be provided.

CAUTION: Do not touch exposed metal parts. Shut branch circuit power before installing or servicing equipment.

There are no user serviceable parts inside. Refer installation and servicing to qualified service personnel.

3. Port Configurations (Fig. 1, pg. 3; Fig. 3b, pg. 6):

Jumper

Position

30W and

PORT 4

30W

Data

PORT 6

30W

-----

PORT 4

60W

Data Only

PORT 6

60W

-----

4. Connect structured cables from port marked [Port 1] to [Port 8] on NetWay unit to PoE-compliant cameras/edge devices (Fig. 3, pg. 6).

Note: All interconnected devices must be UL Listed.

5. Insert SFP module(s) into port(s) marked [SFP], then connect one end of fiber cable to the SFP module(s) on NetWaySP8B and the other end to the corresponding input of an

SFP switch (Fig. 3, pg. 6).

6. Battery Backup (if desired): Connect four (4) 12VDC batteries wired in series to terminals marked [+ BAT --- ] (Fig. 3, pg. 6), carefully observing polarity.

When use of stand-by batteries is desired, they must be lead acid or gel type.

Note: When batteries are not used, a loss of AC will result in the loss of output voltage.

7. Please ensure that the cover is secured with: key lock and screws for NetWaySP8X, security bolt for NetWaySP8WP/NetWaySP8WPN, screw lock down for NetWaySP8WPX.
