Christie Roadie HD+35K Setup Manual
  1. Manuals
  2. Brands
  3. Christie Manuals
  4. Projector
  5. Roadie HD+35K
  6. Setup manual

Christie Roadie HD+35K Setup Manual

Hide thumbs Also See for Roadie HD+35K:
Table of Contents

Advertisement

Quick Links

Download this manual
Roadie HD+35K
S E T U P G U I D E
020-100394-02

Advertisement

Table of Contents
loading

Related Manuals for Christie Roadie HD+35K

Summary of Contents for Christie Roadie HD+35K

  • Page 1 Roadie HD+35K S E T U P G U I D E 020-100394-02...
  • Page 3 Roadie HD+35K S E T U P G U I D E 020-100394-02...
  • Page 4 Christie makes no warranty of any kind with regard to this material, including, but not limited to, implied warranties of fitness for a particular purpose. Christie will not be liable for errors contained herein or for incidental or consequential damages in connection with the performance or use of this material.

  • Page 5: Table Of Contents

    3.2 Using the Built-In Keypad or Remotes ..................3-3 3.2.1 Built-in Keypad........................3-3 3.2.2 Standard IR Remote and Transmission ................3-4 3.2.3 Wired IR Remote .........................3-4 3.3 Power-up Procedure/Checklist ....................3-5 3.4 Power-down Procedure........................3-6 3.4.1 System Warnings/Errors ......................3-6 Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)
  • Page 6 5.3 Inputs ............................5-2 5.4 Control ............................5-2 5.4.1 Wired Remote (Converted from IR Remote) ..............5-2 5.4.2 IR Remote ..........................5-2 5.4.3 Ethernet ..........................5-3 5.4.4 RS-232 Serial Input......................5-3 5.4.5 RS-422 Serial Input......................5-3 5.4.6 GPIO Input ..........................5-3 Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)
  • Page 7 5.10 Operating Environment ......................5-5 5.11 Non-Operating Environment .....................5-6 5.12 Weight & Size ..........................5-6 5.12.1 Standard Dimensions ......................5-6 5.13 Standard and Optional Components ..................5-7 5.13.1 Standard (Sold with Product).....................5-7 5.13.2 Optional (Sold Separately)....................5-7 Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)

  • Page 9: Safety Warnings And Guidelines

    The serial number can be found on the license label located on the back of the projector. Only personnel trained specifically by Christie on lamp replacement and lamp safety may handle the NOTES: 1) lamp.

  • Page 10: Ac / Power Precautions

    Do not overload power outlets and extension cords as this can result in fire or shock hazards. Only a Christie accredited service technician is permitted to open any enclosure on the product, and only NOTE: if the AC has been fully disconnected from the projection head and Ballast.

  • Page 11: 2: Installation And Setup

    See Section 2.2 Projector Position and Mounting, the Roadie HD+35K Throw Distance Tech- nical document available on the Christie Website, PN 020-100395-XX, and Section 5.2 Lenses. • Ensure the projector is level from side-to-side, and not inverted. The projector’s front-to-back and side- to-side tilt can be no more than 15°...
  • Page 12 1) Connect all four cables to the projection head prior to turning the breaker/power switch ON. 2) Follow all labeling exactly. Head to Ballast Connect all four ballast cables (Figure 2-3): • 2 DC power cables • 2 communication/control cables Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)
  • Page 13 Refer to Figure 2-4. Before connecting the ballast to the AC, a Christie accredited service technician must ensure the ballast's NOTE: plug type and Input Power Range Switch matches the line voltage available at the site. Remove the Ballast cover to access the breaker/power switch and determine it's setting. Toggle LEFT for 200 VAC supplies and RIGHT for 400 VAC supplies (factory default=200 VAC).
  • Page 14 (Modify plug as necessary) Figure 2-4 Ballast Connection and Breaker/Power Switch ON Head-to-AC Connect the Christie-supplied IEC 320 (220V) 15-amp line cord to AC (Figure 2-5). Do not substitute other cords. Input power required is 200 - 240 VAC (nominal), 50/60 Hz @ 3A for 208V.
  • Page 15 IR remote  Or standard Christie service password. Figure 2-6 Setting Lamp Size Once the Status Display shows the correct lamp type, the projector and lamp can be switched ON. Lamp size can also be changed in the Service menu (Service password required) if the projector is NOTE: running, but it will not take effect until the next power-u p.

  • Page 16: Projector Position And Mounting

    Ensure the room can accommodate the required location of the projector for the chosen screen size. For more information about the Roadie HD+35K lens throw ratio calculations, refer to the Roadie HD+35K Throw Distance Technical Document available on the Christie Website, PN 020-100395-XX.

  • Page 17: Tilting And Special Orientations

    ± 15° max. ± 15° max. Figure 2-8 Tilt only as shown in Figure 2-9 Figure 2-8 Front End Tilt Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)

  • Page 18: Hoisting And Stacking

    Never exceed the load rating specified. Use the projector’s handles for hoisting/rigging ONE projector only. Never try to carry more than one projector. Remove the projection lens before hoisting/rigging. Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)
  • Page 19 When hoisting/rigging a single projector using its handles, do the following: 1. Remove the projection lens. Refer to Section 4.5, Replacing a Lens in the Roadie HD+35K User Manual. 2. Clamp the 4 rigging clamps to the projector's handles staying within the assigned rigging zones. Refer to...
  • Page 20 Route safety straps though both eyebolts Route safety strap around outside of handles. BOTTOM VIEW Route a safety strap through both eyebolts on crossbeam. Figure 2-12 Using Safety Straps 2-10 Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)

  • Page 21: Installing Lens, Lamp, And Cooling

    Ensure that the lens is fully back to seat properly within the lens mount. The following steps are IMPORTANT! and necessary to ensure your safety and that the lens does not fall out. Roadie HD+35K Setup Guide 2-11 020-100394-02 Rev. 1 (01-2010)
  • Page 22 2-14. For more information, refer to Section 3, to Projector Operation in the Roadie HD+35K User Manual. Lens calibration must be performed each time a new lens is inserted or after performing manual lens mount adjustments. This is critical to the projector functioning properly.

  • Page 23: Install First Lamp

    2.3.2 Install First Lamp Explosion Hazard. Wear authorized protective clothing whenever the lamp door is open! Never apply a twisting or bending force to the quartz lamp body. A Christie accredited service technician is required. 1. Open the lamp door and remove lamp cooling compartment door.

  • Page 24: Liquid Cooling

    2. Install lamp. Lamp Cradle Refer to Section 4.2 Replacing the Lamp & Filter in the Roadie HD+35K User Manual. Observe all warnings, and wear protective clothing NOTES: 1) and shielding. Do Not forget to properly mark the “Lamp Installed” label on the lamp door to indicate current lamp size.
  • Page 25 RS422 GPIO Input 6 (Opt. 2) Control ports RS232 RS232 Figure 2-17 Roadie HD+35K Input Panel Section 5 Specifications Refer to for details regarding compatible inputs. Use only high-quality NOTES: 1) shielded cables for all connections. Roadie HD+35K Setup Guide 2-15 020-100394-02 Rev.

  • Page 26: Rgb Signals

    1, use the red, green and blue BNCs as described in YPbPr Signals (below). This input does not route to Figure 2-18 Connecting an RGB Source the decoder and cannot be used for Composite Video or S-Video. 2-16 Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)

  • Page 27: Ypbpr Signals (Component Video)

    Image Settings menu. Refer to Hor / Comp Section 3.6.3 Image Settings Menu in the Roadie HD+35K User Manual. Do not Blue connect digital component signals (known as YCbCr) to INPUT 1 or INPUT 2. Use the...

  • Page 28: Dual Sd/Hd-Sdi

    Section 2: Installation and Setup 2.4.4 Dual SD/HD-SDI Christie's Dual SD/HD-SDI module is standard with Input 1 this projector and factory-installed in the first option Vert slot (labeled INPUT 5). Its loop-through capability Sync enables incoming serial digital data (HD format) to...

  • Page 29: Extra Video

    ” optional HDTV Input Module used in earlier projectors is not needed or recommended. See Appendix D: Optional Input Modules in the Roadie HD+35K User Manual for a brief description of each interface. Connecting the Ballast DO NOT connect the ballast to AC until the projection head and ballast are connected to each other.

  • Page 30: Configuring The Ballast For Incoming Ac

    DMDs are parallel to and well-centered with both the lens and screen. It should be completed before adjusting the lens boresight. Before you begin: Properly position the projector relative to the screen (refer back to Section 2.2 Projector Position and Mounting). 2-20 Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)
  • Page 31 2. Course focus. Do a quick preliminary (center) focus and (if available) zoom adjustment with the primary lens only. Refer to Section 3.14 Working with the Lenses in the Roadie HD+35K User Manual. 3. Center the image in the lens. Holding a piece of paper (full white field) at the lens surface, adjust offsets until the image on the paper is centered within the lens perimeter.

  • Page 33: Projector Basics

    Intake air flows through the filter before circulating in the front compartment to cool main electronics. Replace the air filter whenever the lamp is replaced, or sooner in dusty/dirty environments. Refer to Section 4.2 Replacing the Lamp & Filter in the Roadie HD+35K User Manual for complete instructions. IMPORTANT! Check condition monthly.

  • Page 34: Breaker/Power Switch (On/Off)

    2) It protects against over-current conditions of 50A or more. The breaker/power switch must be ON in order to enable normal Roadie HD+35K system power-up and operation. If faulty or major excessive AC is detected, the breaker “trips” to OFF in order to prevent damage.

  • Page 35: Handles

    FredFrame™. 3.1.5 Channels for FredFrame™ An adjustment mechanism (part of Christie's FredFrame™) that is inserted and secured into the channels located under the projector, enables the projector to be hoisted, flown, and/or stacked. Consult complete installation instructions supplied with the FredFrame™...

  • Page 36: Standard Ir Remote And Transmission

    Section 3: Operation 3.2.2 Standard IR Remote and Transmission The Roadie HD+35K comes with a standard IR remote which controls the projector by way of wireless communication from a battery-powered infrared (IR) transmitter. Use the standard IR remote the same way you would use any remote supplied with a TV or DVD player.

  • Page 37: Power-Up Procedure/Checklist

    8. In the Lamp menu, set the “Cable Length (m)” to match the length of the DC cables currently connected between your ballast and projection head. For more information, see Section 2.1.1 Quick Setup. Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)

  • Page 38: Power-Down Procedure

    LCD Status Display window. A system malfunction can be cleared by pressing E twice from the presentation level, but may indicate the need for service by a Christie accredited service technician. System messages appear on-screen only if Display Error Messages has been set to...

  • Page 39: Power

    If the projector does not appear to be operating properly, note the symptoms and use this section as a guide. If the problem cannot be resolved, contact your dealer for assistance. A Christie accredited service technician is required when opening an enclosure to diagnose any "probable NOTE: cause".

  • Page 40: Flicker, Shadows Or Dimness

    • Increase lamp power, if possible. Lamps which are near end of life may not operate reliably at lowest power range. • Fold mirror misalignment (a Christie accredited service technician is required to resolve the issue). 4.2.4 LampLOC™ Does Not Seem to Work Check for the following: •...

  • Page 41: Calibrating The Lens Mount

    IS NOT 4.5.2 Severe Motion Artifacts Most likely there is a synchronization problem with reversed 3-2 drop-down in 60Hz-to-24Hz film-to-digital conversion in your source. The display file needs correction. Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)

  • Page 42: Image Appears Vertically Stretched Or 'Squeezed' Into Center Of Screen

    4.5.3 Image Appears Vertically Stretched or ‘Squeezed’ into Center of Screen Source data converted from film and “pre-squeezed” for Roadie HD+35K display format may require use of an anamorphic lens (or resizing) to regain full “scope” image width and proper proportions.

  • Page 43: Data Is Cropped From Edges

    • If the distance between the input source device and the projector is greater than 25 feet, signal amplification/ conditioning may be required. • If the source is a VCR or off-air broadcast, detail may be set too high. Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)

  • Page 45: Display

    5 Specifications This section provides detailed Roadie HD+35K specifications. Due to continuing research, specifications are subject to change without notice. Display 5.1.1 Panel Resolution and Refresh Rate Pixel format (H x V) on 3 DMDs 2048 x 1080 Refresh rate, 2D displays 23.97 - 65 Hz...

  • Page 46: Lenses

    For proper placement in any installation, use the lens and screen size to calculate the precise throw distance using the tables provided in the Dealer Section of the Christie Website, PN 020-100395-xx. In addition, please keep in mind that due to lens manufacturing tolerances for lens focal length, actual throw distance can vary ±5% or...

  • Page 47: Ethernet

    Connector type 9-pin subminiature D (female) Number and type of outputs 1 – lamp enable (low = enable lamp) 4 – safety interlocks (high = disable lamp) 1 – +5VDC for opto-isolated interface Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)

  • Page 48: Power

    Operating voltage range 18-46 VDC Start-up voltage (open current) 125-155 VDC Operating current range 50-180 A Ripple 1% max @ 25°C Control ports 5.4.7 Control Port (From Ballast) 5.4.8 Ballast Ports on previous page. Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)

  • Page 49: Lamps

    • CISPR 24/ EN55024: All parts for immunity characteristics for Information Technology Equipment (ITE) 5.10 Operating Environment Temperature 10°C to 35°C (50°F to 95°F) Humidity (non-condensing) 20% to 80% Altitude 0 – 3000 meters Tilt, any angle 15° max. Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)

  • Page 50: Non-Operating Environment

    460 lb (209.1 kg) Ballast 145 lb (66 kg) FredFrame™ 166 lb (76 kg) Installed Weight Projection Head 435 lb (197.3 kg) Ballast 110 lb (50 kg) FredFrame™ 110 lb (50 kg) Roadie HD+35K Setup Guide 020-100394-02 Rev. 1 (01-2010)

  • Page 51: Standard And Optional Components

    • Line Cord, 10-foot, 15 amp, North American 220V • Face shield (required for lamp handling) • Dual SD/HD-SDI input module (38-804656-xx) • Roadie HD+35K User Manual • Misc. hardware, including Allen Keys 5.13.2 Optional (Sold Separately) Projection Lenses The projection head is compatible with the following optional lenses: 0.8:1 fixed throw ratio lens...
  • Page 52 38-814006-XX Other Remote IR Sensor - communication cables Ethernet, RS-232, and RS-422 Compact/Lite remote 03-900566-XX Christie TWIST Module for arbitrary image warping and edge blending 108-103001-XX FredFrame™ Rigging Frame 38-814007-XX Rigging Clamps for flying projection head by handles 113-102101-XX 10-Bit KoRE Librarian Setup Software...
