PARTS LISTING WITH
MOUNTING AND OPERATING
INSTRUCTIONS
KUBOTA M6-131
TWIN ROTARY
Current as of 09/11/2020
Tiger Corporation
3301 N. Louise Ave.
Sioux Falls, SD 57107
1-800-843-6849
1-605-336-7900
www.tigermowers.com
06070022

Advertisement

loading
Need help?

Need help?

Do you have a question about the M6-131 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tiger M6-131

  • Page 1 KUBOTA M6-131 TWIN ROTARY Current as of 09/11/2020 PARTS LISTING WITH MOUNTING AND OPERATING INSTRUCTIONS Tiger Corporation 3301 N. Louise Ave. Sioux Falls, SD 57107 1-800-843-6849 1-605-336-7900 www.tigermowers.com 06070022...
  • Page 2 TO THE OWNER / OPERATOR / DEALER All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
  • Page 3 • Classify the problem • Hydraulic, electrical or mechanical - Read the trouble shooting section • Tractor or Truck chassis - Contact vehicle dealer • If unable to correct the problem yourself, contact your local Tiger Dealer after gathering: • Machine model _______________________ •...
  • Page 5: Table Of Contents

    PARTS SECTION______________________________________ COMMON PARTS SECTION____________________________ WARRANTY INFORMATION_____________________________ This symbol means: CAUTION – YOUR SAFETY IS AT RISK! When you see this symbol, read and follow the associated instructions carefully or personal injury or damage may result. Tiger is a registered trademark.
  • Page 7: Safety Section

    SAFETY SAFETY SECTION Bengal Boom Safety Section 1-1...
  • Page 8 SAFETY General Safety Instructions and Practices A safe and careful operator is the best operator. Safety is of primary importance to the manufacturer and should be to the owner / operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and observing certain precautions. The first section of this manual includes a list of Safety Messages that, if followed, will help protect the operator and bystanders from injury or death.
  • Page 9 SAFETY PELIGRO! Si no lee Ingles, pida ayuda a alguien que LEA EL si lo lea para que le traduzca las medidas INSTRUCTIVO! de seguridad. (SG-3) Never operate the Tractor or Implement until you have read and DANGER! completely understand this Manual, the Tractor Operator’s Manual, and each of the Safety Messages found in the Manual or on the Tractor and Implement.
  • Page 10 SAFETY DANGER! Never allow children or other persons to ride on the Tractor or Implement. Falling off can result in serious injury or death. (SG-10) DANGER! Never allow children to operate or ride on the Tractor or Implement. (SG-11) WARNING! Do not mount the Tractor while the tractor is moving.
  • Page 11 SAFETY WARNING! The operator and all support personnel should wear hard hats, safety shoes, safety glasses, and proper hearing protection at all times for protection from injury including injury from items thrown by the equipment. (SG-16) CAUTION! PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE PERMA- NENT HEARING LOSS! Tractors with or without an Implement at- tached can often be noisy enough to cause permanent hearing loss.
  • Page 12 SAFETY WARNING! Never attempt to lubricate, adjust, or remove material from the Implement while it is in motion or while tractor engine is running. Make sure the tractor engine is off before working on the Implement. (SG-20) WARNING! Periodically inspect all moving parts for wear and replace when necessary with authorized service parts.
  • Page 13 SAFETY DANGER! NEVER use drugs or alcohol immediately before or while operating the Tractor and Implement. Drugs and alcohol will affect an operator’s alertness and coordination and therefore affect the operator’s ability to operate the equipment safely. Before operating the Tractor or Imple- ment, an operator on prescription or over-the-counter medication must consult a medical professional regarding any side effects of the medi- cation that would hinder their ability to operate the Equipment safely.
  • Page 14 SAFETY DANGER! The rotating parts of this machine have been designed and tested for rugged use. However, the blades could fail upon impact with heavy, solid objects such as metal guard rails and concrete structures. Such impact could cause the broken objects to be thrown outward at very high velocities.
  • Page 15 SAFETY WARNING! Do not mow with two machines in the same area except with Cab tractors with the windows closed. (SGM-11) Rotary and Flail Mowers are capable under adverse conditions of DANGER! throwing objects for great distances (100 yards or more) and causing serious injury or death.
  • Page 16 SAFETY Relieve hydraulic pressure prior to doing any maintenance or repair work on the Implement. Place the Mower Head on the ground or securely supported on blocks or stands, disengage the PTO, and turn off the engine. Push and pull the control Levers or Joystick several times to relieve pressure prior to starting any maintenance or repair work.
  • Page 17 These parts are made and tested to Tiger specifications. Non-genuine “will fit” parts do not consistently meet these specifications. The use of “will fit” parts may reduce mower performance, void mower warranties and present a safety hazard.
  • Page 18 SAFETY PART NO. LOCATION 002369 HYDRAULIC TANK 00725746 INSIDE OF CAB 00769737 MOWER DECK Bengal Boom Safety Section 1-12...
  • Page 19 SAFETY PART NO. LOCATION 00758194 MOWER DECK 02962764 MAIN BOOM, SECONDARY BOOM, MAIN FRAME 02962765 MAIN FRAME 02965262 HYDRAULIC TANK Bengal Boom Safety Section 1-13...
  • Page 20 SAFETY PART NO. LOCATION 02967668 MOWER DECK 02971123 HYDRAULIC TANK 03200285 OUTSIDE OF CAB 22645 INSIDE OF CAB 22839 MOWER DECK Bengal Boom Safety Section 1-14...
  • Page 21 SAFETY PART NO. LOCATION 22840 INSIDE OF CAB 24028 MOWER DECK 25387 INSIDE OF CAB 10” x 5.5” 31522 MOWER DECK, MAIN BOOM 18.25” x 10” 31523 HYDRAULIC TANK Bengal Boom Safety Section 1-15...
  • Page 22 SAFETY PART NO. LOCATION 27001 INSIDE OF CAB 31935 INSIDE OF CAB 32707 HYDRAULIC TANK 42350 MOWER DECK Bengal Boom Safety Section 1-16...
  • Page 23 SAFETY PART NO. LOCATION 32708 HYDRAULIC TANK 32709 INSIDE OF CAB 33224 MOWER DECK 33438 MAIN BOOM Bengal Boom Safety Section 1-17...
  • Page 24 SAFETY PART NO. LOCATION 33302 INSIDE OF CAB 33743 INSIDE OF CAB Bengal Boom Safety Section 1-18...
  • Page 25 SAFETY PART NO. LOCATION 42399 REFLECTIVE TAPE MOWER DECK AMBER 42400 REFLECTIVE TAPE MOWER DECK 6T3217 MOWER DECK 6T3219 INSIDE OF CAB 6T3220 FRONT PUMP MOUNT Bengal Boom Safety Section 1-19...
  • Page 26 SAFETY PART NO. LOCATION 6T3221 INSIDE OF CAB 6T3222 INSIDE OF CAB 6T3224 MOWER DECK 6T3225 INSIDE OF CAB Bengal Boom Safety Section 1-20...
  • Page 27 SAFETY PART NO. LOCATION 6T3230 INSIDE OF CAB 6T3231 INSIDE OF CAB 6T3233 HYDRAULIC TANK 6T3234 INSIDE OF CAB 6T3236 MOWER DECK Bengal Boom Safety Section 1-21...
  • Page 28 SAFETY PART NO. LOCATION 6T3237 INSIDE OF CAB 6T3241 INSIDE OF CAB 34206 INSIDE OF CAB 6T3243 INSIDE OF CAB 6T3249A MOWER DECK 6T3261 MOWER DECK Bengal Boom Safety Section 1-22...
  • Page 29 SAFETY TB1011 MOWER DECK 34852 HYDRAULIC TANK Bengal Boom Safety Section 1-23...
  • Page 30 SAFETY ITEM PART NO. QTY. DESCRIPTION 50023 AVAIL MANUAL CANISTER COMPLETE 00776031 ROUND MANUAL CANISTER 33997 DECAL, SHEET, MANUAL CANISTER DECAL DECAL DECAL AVAIL SPECIFIC PRODUCT MANUAL 33753 E M I SAFETY MANUAL 34296 FRONT ADHESIVE PAD 34297 REAR ADHESIVE PAD 6T1823 ZIP TIE 14”...
  • Page 31 SAFETY FEDERAL LAWS AND REGULATIONS This section is intended to explain in broad terms the concept and effect of federal laws and regulations concerning employer and employee equipment operators. This section is not intended as a legal interpretation of the law and should not be considered as such. Employer-Employee Operator Regulations U.S.
  • Page 32 SAFETY Bengal Boom Safety Section 1-26...
  • Page 33: Assembly / Mounting Section

    KUB M6 101-131 - TWIN ROTARY ASSEMBLY SECTION Assembly Section 2-1...
  • Page 34 Always use a floor jack, hoist or fork lift to lift and raise heavy parts. Read and understand the entire Assembly Section instructions before attempting to mount your Tiger mower. Refer to the Parts Section of this manual for detailed illustrations to locate all parts.
  • Page 35 ASSEMBLY ADJUSTING REAR WHEELS Raise rear of tractor onto jack-stands. Follow the instructions in the tractor owner’s manual for adjusting tires and rims. The back wheels MUST be adjusted to the widest setting. NOTE: This may require switching the wheels to opposite sides of tractor. Also take note of any width restrictions when transporting by trailer.
  • Page 36 ASSEMBLY APPLICATION OF LOCTITE 2047 MOWER MAINFRAME MOUNTING BOLTS All mower mainframe mounting bolts shall be secured utilizing Loctite 2047 and torqued per the Torque Chart in the maintenance section. Shake bottle for 60 seconds before use. To prevent clogging of nozzle, do not allow tip to touch metal surfaces during application.
  • Page 37 ASSEMBLY MAINFRAME INSTALLATION With an overhead hoist and / or jack-stands, raise one side of the frame up to the correctly matching mounting holes. Install capscrews and other hardware to secure the sides of the mainframe to the tractor casting, as shown on the tractor mount kit page in the Parts Section. DO NOT tighten at this time.
  • Page 38 ASSEMBLY LIFT VALVE LINE INSTALLATION The Tiger lift valve used needs to access the pressure, return and power beyond ports of the tractor. To access the ports, 1/2” adapters are used. The return port is located above the PTO. The return hose runs from the return port on the lift valve to the return port on the tractor.
  • Page 39 ASSEMBLY CABLE CONTROL MOUNTING BRACKET Assemble the cable control mount as shown in the Parts Section. Use the image below for positioning the cable control bracket. Position the support bracket on the floor as a template. Mark the holes on top of the floor mat. Be sure that the location of the stand will allow clearance between the cable control bracket and all existing interior levers, etc.
  • Page 40 ASSEMBLY SWITCHBOX WIRING Power for the switchbox is accessed through the auxiliary plug located on the right rear of the cab. A John Deere plug is used, part number RE67651. DO NOT connect the plug to the cab port until the wiring is completed. The wires in the plug are colored RED, BLACK and ORANGE. Either the RED or ORANGE wire will always be hot, so it needs to be capped.
  • Page 41 ASSEMBLY VALVE MOUNTING The valve mounting bracket is fastened above the rear remotes. The slots closest to the remotes use the existing hardware. The existing hardware is to be loosened until the bracket can slide under the hardware. Next, align the holes of the bracket to the holes in the tractor.
  • Page 42 ASSEMBLY SWITCHBOX AND CABLE CONTROL MOUNT The switchbox is to be secured to the operator’s side of the control handles, or valve stand. A bracket is installed between the cable controls and the tractor’s console to provide additional stability. Refer to the Parts Section for assembly and components needed. (ASM-C-0053 KUB M6 111) Assembly Section 2-10...
  • Page 43 ASSEMBLY *NOTE ON HUSCO CONTROL VALVES* Manual, cable controlled (Husco control valve) boom mowers require check valves with integral restricting orifice (#06502036) installed in the control valve work ports that are connected to the gland ends of the main and secondary boom cylinders. This check valve allows oil to free flow into the gland end of the main and secondary boom cylinders, but restricts flow out of the cylinder, thereby providing proper boom control.
  • Page 44 ASSEMBLY HOSE ROUTING Drill holes in the right rear wheel well and use clamps and zip ties to secure and route lift valve hoses. Place as many hoses in the clamp as will fit without compromising pressure. The hoses that don’t fit into the clamp are to be secured to the others with zip ties.
  • Page 45 (ASM-C-0103) FILLING HYDRAULIC RESERVOIR Refer to the Maintenance Section for filling specifications and hydraulic oil requirements. NOTE: Starting or running your Tiger mower before filling reservoir will cause serious damage to the hydraulic pump. (ASM-C-0004hydro resrv) Assembly Section 2-13...
  • Page 46 ASSEMBLY INSTALLING O-RING FITTINGS Installing straight, 45º and 90º O-rings requires that the O-ring and washer be up against the swivel body. Insert the swivel and turn in until the swivel is pointed in the desired direction and O- ring contact is made. Hold swivel in set direction with a wrench and turn the O-ring nut away from the swivel body and carefully tighten.
  • Page 47 ASSEMBLY FINAL PREPARATION FOR OPERATION Place operator’s safety and operation decals on the steering column and side console where they are clearly visible to the operator. These decals should be understood by each operator of the machine in conjunction with the Safety and Operation Sections of this book. The decals are to be maintained in good condition as a reminder to the operator, and should be replaced if damaged.
  • Page 48 ASSEMBLY Assembly Section 2-16...
  • Page 49: Operation Section

    OPERATION SECTION Operation Section 3-1 ©2013 Alamo Group Inc.
  • Page 50 TIGER BOOM MOWER OPERATING INSTRUCTIONS Tiger Booms are manufactured with quality material by skilled workers. The Boom is designed to attach to a tractor and operate various heads for a wide range of vegetative maintenance applications. The boom and heads are equipped with safety warning decals, protective deflectors, shields, and other safety features to provide operator and passerby protection, however, no shielding is 100% accurate.
  • Page 51 OPERATION 1.OPERATOR REQUIREMENTS Safe operation of the unit is the responsibility of a qualified operator. A qualified operator has read and understands the implement and tractor Operator’s Manuals and is experienced in implement and tractor operation and all associated safety practices. In addition to the safety messages contained in this manual, safety signs are affixed to the implement and tractor.
  • Page 52 OPERATION 2.TRACTOR REQUIREMENTS In addition to tractor horsepower and size required to operate the boom unit, the tractor must also be properly equipped to provide operator protection, to alert approaching vehicle drivers of the tractor’s presence, and to ensure tractor stability when mowing with the boom fully extended. Tractor Requirements and Capabilities •...
  • Page 53 OPERATION Never operate the Tractor and Mower Unit without an OPS (Operators Protective Structure) or Cab to prevent injury from objects thrown from ground or from overhead trimming. Stop mowing if workers or passersby are within 300 feet. (SBM-9) 2.3 Tractor Lighting and SMV Emblem If the tractor will be operated near or traveled on a public roadway it must be equipped with proper warning lighting and a Slow Moving Vehicle (SMV)
  • Page 54 OPERATION 2.4 Tractor Ballast To ensure tractor stability when operating on flat surfaces the left rear tractor tire MUST exert a minimum down force (weight) of 1500 lbs. on the ground when the tractor is on level ground, its boom is fully extended and the mower head is horizontal and two feet above the ground.
  • Page 55 OPERATION 3.1 Boarding the Tractor Use both hands and equipped handrails and steps for support when boarding the tractor. Never use control levers for support when mounting the tractor. Seat yourself in the operator’s seat and secure the seat belt around you.
  • Page 56 OPERATION 4.STARTING THE TRACTOR The operator must have a complete understanding of the placement, function, and operational use of all tractor controls before starting the tractor. Review the tractor operator’s manual and consult an authorized dealer for tractor operation instructions if needed. Essential Tractor Controls: •...
  • Page 57 OPERATION 5.CONNECTING ATTACHING HEADS TO THE BOOM 1. Start by attaching the pivot bracket(3) to the boom(1) using pin(5) and hardware. Next attach the cylinder to the pivot bracket(3) using pin(8) and roll pins. 2. Then attach the dogleg(4) to the mower(2) using pin(7) and hardware.
  • Page 58 OPERATION Periodically inspect all moving parts for wear and replace when necessary with authorized service parts. Look for loose fasteners, worn or broken parts, and leaky or loose fittings. Make sure all pins have attaching hardware. Serious injury may occur from not maintaining this machine in good working order.
  • Page 59 OPERATION 6.2 Boom Unit Pre-Operation Inspection and Service Inspect and service the boom arm and head prior to operation. Damaged and/or broken parts should be repaired and/or replaced immediately. To ensure the unit is ready for operation, conduct the following: OPS-B- 0020 Periodically inspect all moving parts for wear and replace when necessary with authorized service parts.
  • Page 60 OPERATION Relieve hydraulic pressure prior to doing any maintenance or repair work on the Implement. Place the Mower Head on the ground or securely supported on blocks or stands, disengage the PTO, and turn off the engine. Push and pull the control Levers or Joystick several times to relieve pressure prior to starting any maintenance or repair work.
  • Page 61 OPERATION Do not operate this Equipment with hydraulic oil or fuel leaking. Oil and fuel are explosive and their presence could present a hazard. Do not check for leaks with your hand! High-pressure oil streams from breaks in the line could penetrate the skin and cause tissue damage including gangrene.
  • Page 62 OPERATION ROTARY HEAD INSPECTION • Inspect blades and blade bolts for looseness and excessive wear. Rotate to 90° to make for checking easier. Replace damaged, worn, and missing blades as complete sets to maintain rotary balance. • Ensure motor bolts and nuts are tightened to the appropriate torque.
  • Page 63 OPERATION FLAIL HEAD INSPECTION • Inspect blades and blade bolts for looseness and excessive wear. Rotate to 90° to make for checking easier. Replace damaged, worn, and missing blades as complete sets to maintain cuttershaft balance. • Ensure rubber deflectors are in position and not damaged.
  • Page 64 OPERATION 6.3 Cutting Component Inspection Inspect blade pan and blade assembly for the following: OPS-U-0031 Inspect the Blades daily for abnormal wear. REPLACE BOTH BLADES on that carrier IMMEDIATELY if either blade has: • Become bent or deformed from it’s original shape or •...
  • Page 65 OPERATION Tractor PRE-OPERATION Inspection Mower ID#________________ Make ____________________ Date: ________________ Shift ____________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
  • Page 66 OPERATION Boom PRE-OPERATION Inspection Mower ID#________________ Make ____________________ Date: ________________ Shift ____________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
  • Page 67 A control lever decal similar to the one shown below should be near the control valve to remind the operator of the lever functions. The main control valve on the Tiger Boom Mower has four sections with tapered spools, located near the right side of the steering wheel.
  • Page 68 OPERATION 6.4 Switchbox The Safety Shield lever opens and closes the shield located on the front of the cutter head. When moving at or near the ground, always have the shield in th closed position. When mowing in the brush or in trees above ground level the shield may be opened for easier cutting.
  • Page 69 OPERATION LEVER #1 MAIN BOOM LEVER #2 SECONDARY BOOM LEVER #3 DECK ROLL Boom Operation Section 3-21 ©2013 Alamo Group Inc.
  • Page 70 OPERATION LEVER #4 BOOM SWIVEL LEVER #5 BOOM SHIELD Boom Operation Section 3-22 ©2013 Alamo Group Inc.
  • Page 71 Install the manual valve handle onto valve and operate the functions individually to stow boom. After boom is stowed in rest, transport the unit to the maintenance facility and contact your Tiger dealer for assistance. DO NOT attempt to operate the valve manually for mowing operations! Note: Pushing manual valve handles “out”...
  • Page 72 OPERATION 7.1 Switch Box and Joystick Control The diagrams below and on the next page show the functions that are performed through the use of the joystick controller. The Safety Shield switch opens and closes the shield located on the front of the cutter head. When moving at or near the ground, always have the shield in the closed position.
  • Page 73 OPERATION Joystick Control JOYSTICK FWD/BACK MOVES MAIN BOOM Boom Operation Section 3-25 ©2013 Alamo Group Inc.
  • Page 74 OPERATION JOYSTICK LEFT/RIGHT MOVES SECONDARY BOOM LEFT JOYSTICK ROLLER MOVES DECK ROLL RIGHT JOYSTICK ROLLER MOVES BOOM SWIVEL Boom Operation Section 3-26 ©2013 Alamo Group Inc.
  • Page 75 OPERATION RIGHT JOYSTICK ROLLER WHILE PRESSING BUTTON MOVES BOOM KNUCKLE ON A LEGAL REAR STOW BOOM SHIELD SWITCH(on switch box) OPERATES SAFETY SHIELD 8.DRIVING THE TRACTOR AND IMPLEMENT Safe tractor transport requires the operator to possess a thorough knowledge of the model being operated and precautions to take while driving with an attached implement.
  • Page 76 OPERATION Never operate the Tractor or Implement until you have read and completely understand this Manual, the Tractor Operator’s Manual, and each of the Safety Messages found in the Manual or on the Tractor and Implement. Learn how to stop the tractor engine suddenly in an emergency.
  • Page 77 OPERATION Transport only at speeds where you can maintain control of the equipment. Serious accidents and injuries can result from operating this equipment at high speeds. Understand the Tractor and Implement and how it handles before transporting on streets and highways. Make sure the Tractor steering and brakes are in good condition and operate properly.
  • Page 78 OPERATION 8.2 Brake and Differential Lock Setting Make sure the tractor brakes are in good operating condition. Tractor brakes can be set to operate independently allowing single rear wheel braking action or locked together to provide simultaneous rear wheel braking. FOR MOST DRIVING AND OPERATING CONDITIONS, THE BRAKE PEDALS SHOULD BE LOCKED TOGETHER TO PROVIDE THE MOST EFFECTIVE BRAKING ACTION.
  • Page 79 OPERATION 8.3 Driving the Tractor and Boom Start off driving at a slow speed and gradually increase your speed while maintaining complete control of the tractor. Never operate the tractor at speeds that cannot be safely handled or which will prevent the operator from stopping quickly during an emergency.
  • Page 80 OPERATION Never Leave the mower unattended while the head is in the raised position. The mower could fall causing serious injury to anyone who might inadvertently be under the mower . (SBM-4) Always keep a careful lookout and use extreme care when working around overhead obstructions.
  • Page 81 OPERATION Avoid mowing in reverse direction when possible. Check to make sure there are no persons behind the mower and use extreme care when mowing in reverse. Mow only at a slow ground speed where you can safely operate and control the tractor and mower. Never mow an area that you have not inspected and removed debris or foreign material.
  • Page 82 OPERATION Mow at the speed that you can safely operate and control the tractor and mower. The correct mowing speed depends on terrain condition and grass type, density, and height of cut. Normal ground speed range is from 2 to 5 mph(3-8 kph). Use slow mowing speeds when operating on or near steep slopes, ditches, drop-offs, overhead obstructions, power lines, or when debris and foreign objects are to be avoided.
  • Page 83 OPERATION 9.4 Mower Operation The rotating parts in this machine have been designed and tested for rugged use. However, they could fail upon impact with heavy solid objects-such as steel guard rails, concrete abutments,etc., causing them to be thrown at a very high velocity. Never allow cutter head to contact such objects. Inspecting the cutting area for such objects and removing them prior to mowing can help eliminate these potiential hazards.
  • Page 84 OPERATION For cutting brush, it is usually best to stop the tractor and swivel the boom and mower into foilage. The horizontal positioning action of the boom is designed to position the cutting head and provide a limited pressure relief when excessive pressure is applied to the boom. DO NOT use excessive force when positioning cutting head into heavy branches or stumps.
  • Page 85 OPERATION When cutting trees and brush approach material to be cut with the head perpendicular to material. The cutting edge of the blades should be the only elements in contact with material. The blade bar should not contact with material. The mower head blades should...
  • Page 86 OPERATION Do not allow knives to cut down to the ground. Position ground roller to maintain knife arc at a minimum of 2 inches above the ground. Knife contact or lug contact with ground will cause permanent damage to cutter shaft, knives, and knife attachment parts. 9.7 63”...
  • Page 87 OPERATION 9.8 Shutting Down the Attached Head- For Standard Equipment To shut down attached mower head, first bring the tractor to a complete stop. Decrease engine RPM to idle then disengage cutterhead. The mower head will come to a complete stop within a suitable amount of time.
  • Page 88 OPERATION 10.TRACTOR, BOOM, AND ATTACHED HEAD STORAGE Properly preparing and storing the unit at the end of the season is critical to maintaining its appearance and to help ensure years of dependable service. The following are suggested storage procedures: • Thoroughly clean all debris from boom and head to prevent damage from rotting grass and standing water.
  • Page 89 OPERATION 11.1 Placing Boom Arm on Boom Arm Rest - For Standard Equipment Before transporting tractor between locations, idle the tractor engine, disengage the attached head, and wait for all head motion to come to a complete stop. Place the boom in its storage cradle rest support and then turn the joystick master switch to the OFF position.
  • Page 90 OPERATION 11.2 Transporting on Public Roadways Extreme caution should be used when transporting the tractor and mower on public roadways. The tractor must be equipped with all required safety warning features including a SMV emblem and flashing warning lights to alert drivers of the tractor’s presence. Remember that roadways are primarily designed for automotive drivers and most drivers will not be looking out for you, therefore, you must look out for them.
  • Page 91 OPERATION When operating public roads, have consideration for other road users. Pull to the side of the road occasionally to allow all following traffic to pass. Do not exceed the legal speed limit set in your state or municipality for agricultural tractors. Always stay alert when transporting the tractor and mower on public roads.
  • Page 92 OPERATION 11.3 Hauling the Tractor and Implement Before transporting a loaded tractor and implement, measure the height and width dimensions and gross weight of the complete loaded unit. Ensure that the load will be in compliance with the legal limits set for the areas that will be traveled through.
  • Page 93 The tractor and the mower head should now be chained down securely to the trailer bed. If any part of this operating section, or any other section of this manual is not completely understood, contact your Tiger dealer or the address on the cover of this manual for assistance! Boom Operation Section 3-45 ©2013 Alamo Group Inc.
  • Page 94 OPERATION Boom Operation Section 3-46 ©2013 Alamo Group Inc.
  • Page 95: Maintenance Section

    MAINTENANCE SECTION Maintenance Section 4-1 ©2020 Alamo Group Inc.
  • Page 96 Regular maintenance at the intervals mentioned will result in the maximum efficency and long life of the Tiger Mower. When you purchase a Tiger Mower you also acquire another valuable asset, Tiger’s parts organization. Our rapid and efficent service has guaranteed the customer satisfaction for many years.
  • Page 97 MAINTENANCE Do not modify or alter this Implement. Do not permit anyone to modify or alter this Implement, any of its components or any Implement function. (SG-8) Relieve hydraulic pressure prior to doing any maintenance or repair work on the Implement. Place the Mower Head on the ground or securely supported on blocks or stands, disengage the PTO, and turn off the engine.
  • Page 98 MAINTENANCE Regular Maintenance The intervals at which regular servicing should be done are based on hours of operation. Use the tractors hour meter to determine when regular servicing is required. Refer to the Detailed Maintenance section for futher instructions on greasing. Copy and use the Daily Maintenance sheet located at the end of this section.
  • Page 99 MAINTENANCE Ground Roller detailed maintenance section WEEKLY OR EVERY 40 HOURS ITEM SERVICE COMMENTS Rotary Spindle Lubricate Every 40 hours or weekly WEEKLY OR EVERY 50 HOURS ITEM SERVICE COMMENTS In Tank Hyd. Fluid Change Change after first 50 Filter hours only, then every 10 micron filter) 500 hours or yearly...
  • Page 100 MAINTENANCE TROUBLESHOOTING SYMPTOMS CAUSE REMEDY Vibration 1. Loose bolts 1. Check all bolts and tighten to recommended torque specs. 2. Cutter assembly 2a. Check for damaged blades, disc unbalanced or cuttershaft. Replace if needed. 2b. Check for wire, rope, etc. entangled in the cutter assembly Mower will not lift 1.
  • Page 101 MAINTENANCE Clean parts or replace if scratched. TROUBLESHOOTING (CONTINUED) SYMPTOMS CAUSE REMEDY Motor runs but 1. Belts Inspect belts and pulleys. Replace will not cut. belts and repair as needed. 2. Tensioner Adjust tensioner nut flatwasher washer is flush with top of guide. Mower turns slowly 1.
  • Page 102 MAINTENANCE Boom Maintenance Section 4-8 ©2020 Alamo Group Inc.
  • Page 103 Deck Boom Pivot & Grease Lithium Complex Mobilgrease CM-S Deck Stop Adjustment Gun Extreme Pressure Rotary & Flail) NLGI-ISO 320 Deck Spindle(Rotary) Grease Tiger Spindle Lubricant Mobilith SHC 220 part number 06540000 Boom Maintenance Section 4-9 ©2020 Alamo Group Inc.
  • Page 104 The proprietry UV and Abrasion Resistant Surface coating on SHIELDS SUPERCOATED polycarbonate significantly improves performance. Periodic cleaning using proper procedures and compatible cleaners are recommended to prolong service life. Tiger Corp. polycarbonate is SUPERCOATED on both sides. CLEANING THE SUPERCOAT HARD-COAT Wash with a mild solution of soap or detergent and lukewarm water.
  • Page 105 MAINTENANCE RECOMMENDED FILLING INSTRUCTIONS FOR HYDRAULIC RESERVIORS When filling or checking the oil level, the unit should be parked on a level surface., shut OFF, and allow sufficient time to cool to ambient temperature. Use caution when removing the pressurized breather. Do not place face over opening when removing breather.
  • Page 106 MAINTENANCE GREASING CUTTERSHAFT -- FLAIL MOWERS Locate grease zerks on each end of cuttershaft(s), these are located on the bearing cover. Normal conditions require one or two pumps in each bearing, using Lithium-Complex Extreme Pressure grease confirming to NLGI2-ISO 320 specifications. This is to be done with a standard grease gun daily or at 8 hour intervals.
  • Page 107 MAINTENANCE GREASING GROUND ROLLER SHAFT-- FLAIL Locate grease zerks on eack end of roller tube at lower end of head. Normal conditions require one or two pumps in each bearing, using Lithium-Complex Extreme Pressure grease conforming to NLGI2-ISO 320 specifications. This is to be done with a standard grease gun daily or at 8 hour intervals.
  • Page 108 Adjust bolt out until the head just touches the boom, and tighten lock nut. NOTE: Bolt should not hit boom before cylinder reaches full travel. GREASING SPINDLE Locate grease fitting on inside of deck housing. Inject Tiger Spindle Lubricant, part number 06540000 into spindle housing. Fill with lubricant until lubricant weeps out of top spindle seal.
  • Page 109 MAINTENANCE TIGHTENING SPINDLE BOLTS The spindle mounting bolts should be checked and retorqued daily or every 8 hours of service. Torque the (6) bolts shown below to 357 dry or 315 ft. lbs. lubricated. GREASING PUMP DRIVE SHAFT COUPLER With engine stopped, ensure driveshaft alignment by grasping coupler and sliding back and forth.
  • Page 110 MAINTENANCE DRIVESHAFT YOKE, U-JOINT STUB SHAFT WIth engine stopped, inject Lithium-Complex extreme pressure grease conforming to NLGI2-ISO 320 specifications into universal joints and slip yoke until grease appears at the seal. Grease them daily or every 8 hours. GREASING THE BOOM SWIVEL Locate the zerks on the main swivel boss (if applicable), main boom pivot boss (if applicable) and on both ends of the boom swivel cylinder.
  • Page 111 MAINTENANCE GREASING BOOM CYLINDER(S) PIVOT POINTS Locate the zerk on the butt end tang of cylinder and on rod end tang. Inject Lithium-Complex Extreme Pressure grease conforming to NLGI2-ISO 320 specifications until grease begins to protrude from ends. This procedure is to be used on the main boom cylinder, secondary boom cylinder, deck pivot, and swivel cylinders daily or at 8 hour intervals.
  • Page 112 MAINTENANCE Blades Check the Blades for cracks and wear and Blade Bolts for tightness, daily. Blades should be replaced when they are worn excessively, bent, deformed, or out of balance. Blades should always be replaced in pairs. Blades of different weights can cause serious imbalance and damage to the machine and personnel.
  • Page 113 MAINTENANCE ROTARY KNIFE REPLACEMENT Be sure you have a complete matching set of new knives for replacement. Remove knives and inspect holes for damage. Also watch for cracks in the disk (if applicable) around the holes. Lube threads with anti-seize. Install bolts through knife and disk from bottom side of disk/blade bar. Install new self-locking nuts and torque them to 800 ft.
  • Page 114 MAINTENANCE Flail Blades Inspection Inspect the Blades daily for abnormal wear. REPLACE ALL BLADES on the carrier IMMEDIATELY if any blades have: • Become bent or deformed from its original shape, or • Wear inside the blade bolt hole, or •...
  • Page 115 MAINTENANCE Blade Pins and D-Ring Inspection Inspect Blade Pins and D-Rings daily for wear or damage as follows: Inspect the Blade pins and D-Rings daily for abnormal wear. Make sure the cotter pins are in place and properly spread. REPLACE BLADE Pins and D-Rings IMMEDIATELY if they have: •...
  • Page 116 MAINTENANCE Flail Axe Blades Inspection Inspect the Blades daily for abnormal wear. REPLACE ALL BLADES on the carrier IMMEDIATELY if any blades have: • Become bent or deformed from its original shape, or • Oval shape wear inside the blade bolt hole, or •...
  • Page 117 MAINTENANCE Flail Axe Blade Bolt Inspection Inspect Blade Bolts daily for wear or damage as follows: Inspect the Blade Bolt daily for abnormal wear. REPLACE ALL BLADE BOLTS on the carrier IMMEDIATELY if any bolts have: • Visible cracks or •...
  • Page 118 MAINTENANCE 50” FLAIL KNIFE BLADE REPLACEMENT (Light Brush Grass) If knives are damaged or badly worn, they will need to be replaced as a set. Replacing a single knife can cause severe knife can cause severe vibration and possible damage to the mower. The knife should not be welded on for any reason.
  • Page 119 MAINTENANCE 63” BOOM FLAIL KNIFE REPLACEMENT If knives are damaged or badly worn, they will need to be replaced as a set. Replacing a single knife can cause severe vibration and possible damage to the mower. Assemble knives, clevis, bolts and nuts as shown in part section of manual. Install locking hex nut so that the flat face of nut is towards the knife.
  • Page 120 MAINTENANCE THE SPINDLE ASSEMBLY See the diagram below for identification of spindle parts, while servicing. Boom Maintenance Section 4-26 ©2020 Alamo Group Inc.
  • Page 121 Position the spindle housing horizontally with the drain hole oriented “up”. Grease through the zerk with Tiger Spindle Lubricant (part number 06540000) until the grease purges from the drain hole. Install the plug into the drain hole. BEARING ADJUSTMENT...
  • Page 122 MAINTENANCE Boom Cylinder Removal and Replacement Instructions Clear the area of all personnel before lowering the boom mower head. From the tractor seat with your seat belt fastened around you, lower the boom mower head to the ground. Extend the boom to the furthest reach and lower the mower head flat on the ground. DO NOT attempt to replace the cylinders with the boom in the raised or transport position.
  • Page 123 MAINTENANCE CUTTERSHAFT BEARING REPLACEMENT Remove existing cuttershaft, bearings and string guards. Make sure that the end knives on each end of the cuttershaft are oriented as shown. Apply anti-seize on cuttershaft as shown on next page. Install non-drive side bearing first. Install the top of the string guard on the non-drive side first.
  • Page 124 MAINTENANCE Boom Maintenance Section 4-30 ©2020 Alamo Group Inc.
  • Page 125 MAINTENANCE DAILY MAINTENANCE SCHEDULE The following services should be performed daily or every 8 hours of service, following the detailed maintenance instructions in the operator’s manual. _______ Pump driveshaft: If required with drive shaft/coupler check for end play and lubricate at zerks. _______ Crankshaft adapter: If equipped with rubber grommets check condition, replace if missing or damaged.
  • Page 126 MAINTENANCE Boom Maintenance Section 4-32 ©2020 Alamo Group Inc.
  • Page 127: Parts Section

    KUBOTA M6-131 TWIN ROTARY PARTS SECTION...
  • Page 128 CABLE (MANUAL) LIFT VALVE - 3 SPOOL............................8 3 SPOOL CABLE CONTROL MOUNT..............................10 COOLER ASSEMBLY....................................12 COOLER MOUNT...................................... 14 TILT CYLINDER......................................16 TM REAR MOWER HYDRAULICS................................. 18 TSR REAR MOWER HYDRAULICS................................ 20 NOTES......................................... 22 KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -2...
  • Page 129 PARTS ORDERING GUIDE KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -3...
  • Page 130 TRACTOR MOUNT KIT KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -4...
  • Page 131 TRACTOR MOUNT KIT Continued... ITEM PART NO. QTY. DESCRIPTION 06300380 MAINFRAME, KUBOTA M6-131 06300399 ALXE BRACE, LH, KUBOTA M6-131 06300378 MAINFRAME, TM, TSF, KUBOTA M6101/111 06380078 TANK, RES, WW, TS6.1XX, T4B 06380090 MOUNT, TANK, REAR, KUB M6-101/111 06510083 BRAKE VALVE, SOL, 3000PSI 06530237 CAPSCREW, 3/4"...
  • Page 132 TRACTOR MOUNT KIT - HYDRAULICS KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -6...
  • Page 133 HOSE, 1" X 68" 06501341 HOSE, 1" X 170" 06501342 HOSE, 1" X 166" 06500918 HOSE, 1-1/2" X 114" 06500624 HOSE, 1" X 156" 06501343 HOSE, 1" X 215" KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -7...
  • Page 134 CABLE (MANUAL) LIFT VALVE - 3 SPOOL KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -8...
  • Page 135 HOSE, 1/2" X 42" 33649 HOSE, 1/2" X 50" 06503072 ADAPTER, 1/2"MJ X 1/2"BSPP 06503073 ADAPTER, 1/2"MJ X 1/2"BSPP W/SEAL 06510050 TRAVEL LOCK, METRIPACK COIL 33382 ELBOW, 1/2"MB X 1/2"MJ KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -9...
  • Page 136 3 SPOOL CABLE CONTROL MOUNT KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -10...
  • Page 137 STABILIZING BRACKET 06530525 CAPSCREW, 6MM X 40MM 1.0P 21545 CAPSCREW, 1/4" X 6" NC 34532 SWITCH, TRAVEL LOCK 34874 BRACKET, SWITCH 21525 HEX NUT, 1/4" NC 22014 FLATWASHER, 1/4" KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -11...
  • Page 138 COOLER ASSEMBLY KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -12...
  • Page 139 MOUNT, COOLER, BUMPER TANK, LH 06510350 COOLER, ADAMS, LEGACY 21629 CAPSCREW, 3/8" X 3/4" NC 21988 LOCKWASHER, 3/8" 22016 FLATWASHER, 3/8" 34117 ELBOW, 1"MOR X 1"MJ90, FORGED 06370060 SCREEN, COOLER, REAR, (OPTIONAL) KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -13...
  • Page 140 COOLER MOUNT KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -14...
  • Page 141 COOLER,ELEC TERM,ASSY 21631 CAPSCREW,3/8"X1 1/4", NC,GR8 22016 FLATWASHER,3/8",GR8 21627 NYLOCK NUT,3/8" NC 21833 CAPSCREW,3/4" X 2-1/4" NC 33880 FLATWASHER,3/4",GR 8,SAE 21825 HEX NUT,3/4" NC 06380096 PUMP MOUNT 06380072 MNT,CLR,FRNT,UNI KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -15...
  • Page 142 TILT CYLINDER KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -16...
  • Page 143 ROLL PIN, 5MM X 50MM, SS 30481 CYLINDER, 3" X 8" 31208 SPACER, 1/2" 30184C CLEVIS, TRR, LOWER 6T2272 SETSCREW, 3/8" X 1/2" NC 06500142 HOSE, 1/4" X 49" KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -17...
  • Page 144 TM REAR MOWER HYDRAULICS KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -18...
  • Page 145 HEX NUT,3/8",NC 06503074 UNION,1"MOR X 1"MOR 33554 ELBOW 1"MOR X 1"MJ 45º 06501292 HOSE,1" X 65" 34865 HOSE,1" X 57" 34183 ADAPTER,BULKHEAD,1"MJ X 1"MJ 21725 HEX NUT,1/2",NC 22018 FLATWASHER,1/2",WIDE KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -19...
  • Page 146 TSR REAR MOWER HYDRAULICS KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -20...
  • Page 147 PUMP *REFER TO TRACTOR MOUNT KIT PAGE 33554 ELBOW 1"MOR X 1"MJ 45º 06510083 VALVE,BRAKE 06500104 HOSE,1" X 64" 34865 HOSE,1" X 57" 34183 ADAPTER,BULKHEAD,1"MJ X 1"MJ 21725 HEX NUT,1/2",NC 22018 FLATWASHER,1/2",WIDE KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -21...
  • Page 148 NOTES KUBOTA M6-131 TWIN ROTARY ©2020 Alamo Group Inc. Parts Section -22...
  • Page 149 COMMON TWIN ROTARY PARTS SECTION...
  • Page 150 NOTES...
  • Page 151 PART NAME INDEX PARTS ORDERING GUIDE ..................................5 CABLE DRAFT BEAM ASSEMBLY................................6 COMBO DRAFT BEAM ASSEMBLY................................ 8 60IN SIDE CABLE TM ROTARY MOWER............................. 10 72IN SIDE CABLE TM ROTARY MOWER............................. 12 60IN SIDE COMBO TM ROTARY MOWER ............................14 72IN SIDE COMBO TM ROTARY MOWER ............................
  • Page 152 PART NAME INDEX SWITCH BOX......................................72 SWITCH BOX SCHEMATIC..................................73 NOTES 1........................................74 COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-4...
  • Page 153 PARTS ORDERING GUIDE COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-5...
  • Page 154 CABLE DRAFT BEAM ASSEMBLY COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-6...
  • Page 155 CABLE DRAFT BEAM ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 6T0105 DRAFT BEAM (STD WITH TRAVEL LOCK) 27241 DRAFT BEAM (EXTENDED 6”) 6T0150 CYLINDER 3” X 18” 6T0151R HYD. CYLINDER 3” X 10” 6T0100 LOWER SHEAVE BRACKET 6T0101 UPPER SHEAVE BRACKET 33768 SHEAVE 6T0110...
  • Page 156 COMBO DRAFT BEAM ASSEMBLY COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-8...
  • Page 157 COMBO DRAFT BEAM ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 06350001 COMBO DRAFT BEAM - STD DTY ROTARY 31063 COMBO DRAFT BEAM - HVY DTY ROTARY 6T0151R HYD. CYLINDER 3” X 10” 32215 HYD. CYLINDER 3” X 12” - STD DTY 25343 HYD.
  • Page 158 60IN SIDE CABLE TM ROTARY MOWER COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-10...
  • Page 159 60IN SIDE CABLE TM ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 32099 RTRY, 60" DECK, CABLE 31773 GAURD,CHAIN,FRONT,SR60 6T1001 BRKT, MOTOR MTG, 60"SIDE RTRY 6T0820H SKID SHOE, TM60 22592 FLAP, DEFLECTOR, TM60 6T0823 BAR, FLAP, TM60 6T1024H5 SPINDLE ASSY,CPLT,HD,5/8" HOLES 21223 SPROCKET, 1-1/4"...
  • Page 160 72IN SIDE CABLE TM ROTARY MOWER COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-12...
  • Page 161 72IN SIDE CABLE TM ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 21225B RTRY,72" DECK, CABLE 31931 GUARD,CHAIN,FRONT,SR72 6T1001 BRKT, MOTOR MTG, 60"SIDE RTRY 21248 SKID SHOE, TM72 21295B FLAP, DEFLECTOR, TM72 21242A BAR, FLAP, TM72 6T1024H5 SPINDLE ASSY,CPLT,HD,5/8" HOLES 21223 SPROCKET, 1-1/4"...
  • Page 162 60IN SIDE COMBO TM ROTARY MOWER COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-14...
  • Page 163 60IN SIDE COMBO TM ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 30087D RTRY, 60" DECK, COMBO - STD DUTY 32617 RTRY, 60" DECK, COMBO - HVY DUTY 31773 GAURD,CHAIN,FRONT,SR60 6T1001 BRKT, MOTOR MTG, 60"SIDE RTRY 6T0820H SKID SHOE, TM60 22592 FLAP, DEFLECTOR, TM60 6T0823...
  • Page 164 72IN SIDE COMBO TM ROTARY MOWER COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-16...
  • Page 165 72IN SIDE COMBO TM ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 34260 RTRY, 72" DECK, COMBO - STD DUTY 31408A RTRY, 72” DECK, COMBO - HEAVY DUTY 31931 GUARD,CHAIN,FRONT,SR72 6T1001 BRKT, MOTOR MTG, 60"SIDE RTRY 21248 SKID SHOE, TM72 21295B FLAP, DEFLECTOR, TM72 21242A...
  • Page 166 60IN SIDE TSR ROTARY MOWER COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-18...
  • Page 167 60IN SIDE TSR ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 34975 HEAVY DUTY GRASSKAT COMBO 06320005 STD DUTY GRASSKAT COMBO ---- 06320008 HEAVY DUTY GRASSKAT CABLE 34980 SPINDLE ASSY,TM 60" 06504016 CURRENT MOTOR,(M365-1 1/4" 14-SPLINE) 06410254 SKID,OUTBOARD,TM60 22992 CHAIN,10 LINK 6T2270 PLOW BOLT,3/8"...
  • Page 168 60IN REAR TM ROTARY MOWER COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-20...
  • Page 169 60IN REAR TM ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 23003 REAR RTRY, 60” W/REAR CHAINS 32616 RTRY, 60" DECK, TRR 6T1024H5 SPINDLE ASSY,CPLT,HD,5/8 HOLES 6T2277 CAPSCREW, 3/4" X 2" NF 21993 LOCKWASHER,3/4",GR 8 6T2413 HEX NUT,3/4",NF,GR 8 ------ DISK *REFER TO DISK &...
  • Page 170 60IN REAR TSR ROTARY MOWER ITEM PART NO. QTY. DESCRIPTION 06741023 60IN TSR REAR MOWER ASSY 06320002 TRAILKAT®,60,WLDMNT 6T0112 SHACKLE,W/PIN,CPLT 22051 CABLE,LIFT,TRR,60 COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-22...
  • Page 171 60IN REAR TSR ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 06520425 06537021 ROLLPIN,5MM X 50MM,SS 21474A HITCH,3PT,TRR 28511 STAND,SAFETY SUPPORT W/PAD 23329 CASTER WHL,SOLID TIRE W/SPIND 22057 SPINDLE,CASTER AXLE,ASSY 22018 FLATWASHER,1/2,WIDE 21725 HEX NUT,1/2,NC 6T3211 GREASE ZERK,1/8 06370003 CASTER ADJ,TRAILKAT 06504016 MOTOR,M365-1 1/4”,SPLINE,SEALED 6T1025...
  • Page 172 REAR ROTARY HYDRAULICS COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-24...
  • Page 173 REAR ROTARY HYDRAULICS Continued... ITEM PART NO. QTY. DESCRIPTION ------ REAR ROTARY MOWER 06510083 VALVE,BRAKE,SOL,3000PSI,METRI 33555 ADAPTER,1MORB X 1MJIC (3 FOR TSR) 33554 ELBOW,1MORB X 1MJIC,45 (TSR PRESSURE TO MOTOR) TF4852 KIT, FLANGE, #20 34198 HOSE, 1" X 40" (TM MOWER RETURN) 06500087 HOSE, 1"...
  • Page 174 60IN SIDE TM CHAIN GUARDS COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-26...
  • Page 175 60IN SIDE TM CHAIN GUARDS Continued... ITEM PART NO. QTY. DESCRIPTION 31773 GUARD,CHAIN,TM60,FRONT,ASSY 31762 GUARD,CHAIN,TM60,FRONT 28407 CABLE,5/16",BULK (QTY IN FEET) 22993 CHAIN,5/16",GR30,9 LINK 28408 U-BOLT,CABLE,5/16" (NOT SHOWN) 31774 GUARD,CHAIN,TM60,REAR,ASSY 31763 GUARD,CHAIN,TM60,REAR 31879 ROD,SHORT,TM60 31878 ROD,LONG,TM60 22016 FLATWASHER,3/8",GR8 6T3028 COTTER PIN,1/8" X 1" 22992 CHAIN,5/16",GR30,10 LINK COMMON TWIN...
  • Page 176 72IN SIDE TM CHAIN GUARDS COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-28...
  • Page 177 72IN SIDE TM CHAIN GUARDS Continued... ITEM PART NO. QTY. DESCRIPTION 31931 GUARD,CHAIN,TM72,FRONT,ASSY 31863 GUARD,CHAIN,TM72,FRONT 28407 CABLE,5/16",BULK (QTY IN FEET) 22993 CHAIN,5/16",GR30,9 LINK 28408 U-BOLT,CABLE,5/16" (NOT SHOWN) 31932 GUARD,CHAIN,TM60,REAR,ASSY 31864 GUARD,CHAIN,TM60,REAR 31934 ROD,LONG,TM72 31933 ROD,SHORT,TM72 22016 FLATWASHER,3/8",GR8 6T3028 COTTER PIN,1/8" X 1" 22992 CHAIN,5/16",GR30,10 LINK COMMON TWIN...
  • Page 178 60IN TSR REAR GUARDS COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-30...
  • Page 179 60IN TSR REAR GUARDS Continued... ITEM PART NO. QTY. DESCRIPTION 34973 ROD,CHAIN,OUTER,TM60 34974 ROD,CHAIN,INNER,TM60 21631 CAPSCREW, 3/8 X 1-1/4,NC 34972 PLATE,CAP,CHAIN 21625 HEX NUT,3/8",NC 21988 LOCKWASHER, 3/8" 22992 CHAIN,10 LINK 06410947 MNT,FLAP,RH,EXT,TSR 06401184 STRAP,FLAP,EXT,TSR 06410948 COVER,FLAP,EXT,TSR 21632 CAPSCREW,3/8" X 1-1/2" NC 22016 FLATWASHER,3/8",GR8 06410946...
  • Page 180 TM MOWER SPINDLE ASSEMBLY COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-32...
  • Page 181 TM MOWER SPINDLE ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 6T1024H5 SPINDLE ASSEMBLY COMPLETE 6T1031 SPROCKET 6T1016 BEARING LOCK NUT - THICK 22596 JAM WASHER 6T1015 BEARING ADJUSTMENT NUT - THIN 6T1014 BEARING ADJUSTMENT SLEEVE 6T1011 UPPER SEAL - SET OF 2 6T1012 BEARING CONE 6T1013...
  • Page 182 TSR MOWER SPINDLE ASSEMBLY COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-34...
  • Page 183 TSR MOWER SPINDLE ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 34980 SPINDLE ASSEMBLY COMPLETE 34978 SPINDLE MOUNT 34979 SPINDLE,TM60 6T1013 BEARING CUP 6T1012 BEARING CONE 6T1011 UPPER SEAL - SET OF 2 6T1014 BEARING ADJUSTMENT SLEEVE 6T1013H BEARING,CUP,HD 6T1012H BEARING CONE,HD 6T1011H SEAL,LOWER,HD 34985...
  • Page 184 ROTARY DISK AND KNIVES ITEM PART NO. QTY. DESCRIPTION 34876 BLADE MOUNTING DISK 6T1023R NYLOCK NUT,1-1/8” 34878 SPACER 34497 KNIFE MOUNTING BOLT 34685 KNIFE,60" HIGH SUCTION - STANDARD 34684 KNIFE,60" - OPTIONAL 34682 KNIFE 72” (MOUNT ON 72” MOWER ONLY) 25270 FLATWASHER,5/8",USS,GR8 6T2259...
  • Page 185 NOTES COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-37...
  • Page 186 SIDE ROTARY CASTER WHEEL ASSEMBLY COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-38...
  • Page 187 SIDE ROTARY CASTER WHEEL ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 25214C FRAME,CASTER,WHL (TM60) 28297A FRAME,CASTER WHL (TM72) 22057 SPINDLE,CASTER AXLE,ASSY 6T2617 BUSHING,MACH,1-1/2IDX 2-1/4OD 28548 CASTER WHEEL,SOLID TIRE 22065 HUB,ASSY,CASTER ---- 22066 HUB,CASTER 22070 DUST CAP ---- 22071 HUB STUD 22073 HEX NUT,1”,NF (SLOTTED) ----...
  • Page 188 60IN TM REAR CASTER WHEEL & 3PT ASSY COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-40...
  • Page 189 60IN TM REAR CASTER WHEEL & 3PT ASSY Continued... ITEM PART NO. QTY. DESCRIPTION ------ MOWER,REAR,60IN,TM 21474A HITCH, 3PT, TRR 22059B ADJ ROD, TRR 25095A FRAME, CASTER WHEEL, TRR 60" 22057 SPINDLE, CASTER AXLE, ASSY 21925 HEX NUT,1" NC 22023 FLATWASHER,1"...
  • Page 190 CASTER WHEEL ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 22057 SPINDLE,CASTER AXLE,ASSY 21987 LOCKWASHER,5/16” 21575 HEX NUT,5/16” 28548 CAPSCREW,5/16” X 3/4”,NC 22697 RIM,OUTER,CASTER ASSY 21416 TIRE,SOLID 22696 RIM,CASTER WHEEL 22070 DUST CAP 22533 COTTER PIN,3/16” X 2” 6T0836 CUP,CASTER WHEEL 22073 HEX NUT,1",NF (SLOTTED JAM NUT) 22071 HUB STUD...
  • Page 191 SAFETY STAND ITEM PART NO. QTY. DESCRIPTION ------ REAR RTRY - REFER TO REAR RTRY DECK ASSY 28511 REAR RTRY STAND 06520425 6T3014 ROLL PIN, 1/4" X 2" 6T3004 R-CLIP (HAIRPIN COTTER, 3/16") COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-43...
  • Page 192 3IN X 10IN HYDRAULIC CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION 6T0151R HYD. CYLINDER 3" X 10" 6T0167 CYLINDER BUTT 6T0170 CYLINDER GLAND 6T0178 CLEVIS END 6T0164 CYLINDER TUBE 6T0161 PISTON ROD 6T0173 PISTON 6T0179 LOCKNUT 6T0176 TIE ROD ASY 6T0187 SEAL KIT ------...
  • Page 193 3IN X 12IN HYDRAULIC CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION ---- 32215 HYD. CYLINDER 3" X 12" (STD DUTY) 25343 HYD. CYLINDER 3" X 12" (HVY DUTY) 6T0167 CYLINDER BUTT 6T0170 CYLINDER GLAND 6T0178 CLEVIS END 6T0204 CYLINDER TUBE 6T0203 PISTON ROD 6T0173...
  • Page 194 3IN X 18IN HYDRAULIC CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION 6T0150 CYLINDER 3" X 18" 6T0167 CYLINDER BUTT 6T0170 CYLINDER GLAND 6T0178 CLEVIS END 6T0165 CYLINDER TUBE 6T0162 PISTON ROD 6T0173 PISTON 6T0179 LOCKNUT 6T0177 TIE ROD ASY 6T0187 SEAL KIT ------ O - RING...
  • Page 195 RESERVOIR TANK FILTER ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 06505044 FILTER ASSY SAE 10 MICRON 28583 CAPSCREW,8MM X 25MM(1.25 PITCH) 06505045 COVER 06505046 SEAL KIT 06505047 SPRING 06505048 BYPASS 35259 FILTER,10 MIC,RETURN LINE 06505049 CAN/BODY COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-47...
  • Page 196 ROTARY MOTOR BREAKDOWN COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-48...
  • Page 197 ROTARY MOTOR BREAKDOWN Continued... ITEM PART NO. QTY. DESCRIPTION 06504011 MOTOR ASSEMBLY 22790 END,COVER 06504088 HOUSING, PEC 06504111 HOUSING, GEAR 06504026 SET, GEAR SHAFT 06504104 CAPSCREW 06504078 SCREW, DRIVE 06504092 06504093 PIN, DOWEL 06504094 NAME PLATE 06504095 THRPL 2961940 PLUG, ODT 2962200 RING, SNAP 06504096...
  • Page 198 60IN TSR ROTARY MOTOR BREAKDOWN COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-50...
  • Page 199 60IN TSR ROTARY MOTOR BREAKDOWN Continued... ITEM PART NO. QTY. DESCRIPTION 06504016 MOTOR(M365-1 1/4SPLINE),SEALED 22790 COVER,END 06504088 HOUSING,PEC 06504111 HOUSING,GEAR 06504110 SET,GEAR SHAFT 06504104 CAP SCREW 06504078 SCREW,DRIVE 06504093 PIN,DOWEL 06504094 NAME PLATE 06504095 THRPL 02961940 PLUG,ODT (0.25) 6T5200 RING,SNAP 06504097 SEAL,LIP 22797...
  • Page 200 FRONT HYDRAULIC PUMP BREAKDOWN COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-52...
  • Page 201 FRONT HYDRAULIC PUMP BREAKDOWN Continued... ITEM PART NO. QTY. DESCRIPTION 06504002 PUMP,ASSY 22766 HOUSING,SEC 06504068 HOUSING,PEC 02965092 HOUSING,GEAR 06504069 HOUSING,BEARING CARRIER 06504070 SET,GEARSHAFT 06504071 GEAR,SET 02961917 WASHER 06504072 STUD 06504073 NUT,HEX 22765 SEAL,LIP 6T5121 PLUG 02979970 SPACER 02979971 RING,SNAP 02965611 THRPL 06504074 SEAL,CHAN...
  • Page 202 COOLER ASSEMBLY COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-54...
  • Page 203 COOLER ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 21530 CAPSCREW,1/4 X1 NC 21986 LOCKWASHER,1/4 22014 FLATWASHER,1/4 35176 1/4 U-NUT 06370015 SCREEN,COOLER,FRNT 06380006 MNT,COOLER,BUMPER TANK,RH 06380007 MNT,COOLER,BUMPER TANK,LH 06510350 COOLER,FRONT MNT 06510029 FAN ASSY ONLY 21629 CAPSCREW,3/8 X 3/4 NC 21988 LOCKWASHER,3/8 22016 FLATWASHER,3/8...
  • Page 204 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 31320 COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-56...
  • Page 205 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 31320 Continued... ITEM PART NO. QTY. DESCRIPTION 31595 INLET END COVER 31594 END COVER, LOAD SENSE 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 06503067 RELIEF PLUG 06503067 RELIEF PLUG 6T4209 RELIEF PLUG...
  • Page 206 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 31321 COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-58...
  • Page 207 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 31321 Continued... ITEM PART NO. QTY. DESCRIPTION 31595 INLET END COVER 31594 END COVER, LOAD SENSE 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 06503067 RELIEF PLUG 31861 RELIEF VALVE, 360 PSI 6T4209 RELIEF PLUG...
  • Page 208 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 06502043 COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-60...
  • Page 209 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 06502043 Continued... ITEM PART NO. QTY. DESCRIPTION 31595 INLET END COVER 31594 END COVER, LOAD SENSE 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) (REMOVE SHUTTLE DISC) 06503067 RELIEF PLUG 06503067...
  • Page 210 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 06502044 COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-62...
  • Page 211 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 06502044 Continued... ITEM PART NO. QTY. DESCRIPTION 31595 INLET END COVER 31594 END COVER, LOAD SENSE 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) (REMOVE SHUTTLE DISC) 06503067 RELIEF PLUG 31861...
  • Page 212 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 06502087 COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-64...
  • Page 213 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 06502087 Continued... ITEM PART NO. QTY. DESCRIPTION TB1017S INLET END COVER TB1702 END COVER, POWER BEYOND TB1017P VALVE SECTION (SINGLE ACTING, SPRING DETENT) TB1017P VALVE SECTION (SINGLE ACTING, SPRING DETENT) TB1017N VALVE SECTION (DOUBLE ACTING, CENTER SPRING) ------ ------ 28816...
  • Page 214 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 06502088 COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-66...
  • Page 215 CABLE (MANUAL) LIFT VALVE BREAKDOWN - 06502088 Continued... ITEM PART NO. QTY. DESCRIPTION TB1017S INLET END COVER TB1702 END COVER, POWER BEYOND TB1017P VALVE SECTION (SINGLE ACTING, SPRING DETENT) TB1017N VALVE SECTION (DOUBLE ACTING, CENTER SPRING) TB1017N VALVE SECTION (DOUBLE ACTING, CENTER SPRING) ------ 31861 RELIEF VALVE, 360 PSI...
  • Page 216 BRAKE VALVE ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 06510083 BRAKE VALVE, ASSY 34092 BRAKE VALVE, BLANK 34094 LOGIC ELEMENT 34095 RELIEF VALVE, 3000 PSI 06510095 METRI PAK COIL 34093 CARTRIDGE, 2 POSITION, 3 WAY (WITH NUT & WASHER) 34091 RELIEF VALVE, 2600 PSI 34096 RELIEF SEAL KIT ----...
  • Page 217 BRAKE VALVE HYDRAULIC SCHEMATIC COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-69...
  • Page 218 CABLE DRAFT BEAM TRAVEL LOCK ITEM PART NO. QTY. DESCRIPTION ------ CABLE DRAFT BEAM 6T0106 TRAVEL LOCK BRACKET 6T0107 TRAVEL LOCK PINS 3/4” X 3 1/4” 6T3020 R - CLIP 5/32” 21833 CAPSCREW 3/4” X 2 1/4” 21825 HEX NUT 3/4” 21993 LOCK WASHER 3/4”...
  • Page 219 COMBO DRAFT BEAM TRAVEL LOCK ITEM PART NO. QTY. DESCRIPTION ------ COMBO DRAFT BEAM 6T0106 TRAVEL LOCK BRACKET 21833 CAPSCREW 3/4” X 2 1/4” ------ MAIN FRAME *REFER TO PARTS SECTION 33856 BRKT,PIN HOLDER 21988 LOCK WASHER 3/8” 21629 CAPSCREW 3/8” X 3/4” 6T3020 R - CLIP 5/32”...
  • Page 220 SWITCH BOX ITEM PART NO. QTY. DESCRIPTION 06514011 SWBX,ALUM,BLK,06510097 35226 SWITCH,MOWER,COLEHERSEE 06510028 SWITCH,FORWARD/BRAKE/REV 33811 SWITCH,MASTER/DECK FLOAT 6T3923 INDICTATOR LIGHT,ON,RED 34540 STRAIN RELIEF,3/4,BLACK,NYLON 06514006 BREAKER,15A,SWBX 06514015 ALARM,SWBX,REVERSER 06550002 DECAL,SWTCHBX,TWIN/T3F,REV FAN 35227 RELAY,DP,DT,12V,LY2F,35226 COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-72...
  • Page 221 SWITCH BOX SCHEMATIC COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-73...
  • Page 222 NOTES 1 COMMON TWIN ©2014 Alamo Group Inc. Parts Section 6-74...
  • Page 223 WARRANTY SECTION Warranty Section 7-1...
  • Page 225: Warranty Information

    All Tiger obligation under this warranty shall be terminated if the equipment is modified or altered in ways not approved in writing by Tiger, if repair parts other than genuine Tiger repair parts have been used, or if the equipment has been subject to misuse, neglect, accident, improper maintenance or improper operation.
  • Page 226 . Common sense should play a large role in the operation of this machine. Since we at Tiger Corporation are constantly striving to improve out products, we reserve the right to change specifications or design at any time.
  • Page 227 TO THE OWNER / OPERATOR / DEALER To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this manual and on the machine. The table of contents clearly identifies each section where you can easily find the information you need. The Occupational Safety and Health Act (OSHA 1928.51 subpart C) makes the following minimum requirements for tractor operators.
  • Page 228 Printed in USA © Tiger Corporation...
