Tiger NEW HOLLAND T6000 Mounting And Operating Instructions

For new holland t6000

Table of Contents

Quick Links

SABER

MOWER

NEW HOLLAND T6000

Current as of 01/18/2012

PARTS LISTING WITH

MOUNTING AND OPERATING

INSTRUCTIONS

Tiger Corporation

3301 N. Louise Ave.

Sioux Falls, SD 57107

1-800-843-6849

1-605-336-7900

www.tiger-mowers.com

06022005

Table of Contents

Chapters

Table of Contents

Troubleshooting

Summary of Contents for Tiger NEW HOLLAND T6000

Page 1 SABER MOWER NEW HOLLAND T6000 Current as of 01/18/2012 PARTS LISTING WITH MOUNTING AND OPERATING INSTRUCTIONS Tiger Corporation 3301 N. Louise Ave. Sioux Falls, SD 57107 1-800-843-6849 1-605-336-7900 www.tiger-mowers.com 06022005...
Page 2 TO THE OWNER / OPERATOR / DEALER All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
Page 3 • Classify the problem • Hydraulic, electrical or mechanical - Read the trouble shooting section • Tractor or Truck chassis - Contact vehicle dealer • If unable to correct the problem yourself, contact your local Tiger Dealer after gathering: • Machine model _______________________ •...
Page 5: Table Of Contents
PARTS SECTION______________________________________ COMMON PARTS SECTION____________________________ WARRANTY INFORMATION_____________________________ This symbol means: CAUTION – YOUR SAFETY IS AT RISK! When you see this symbol, read and follow the associated instructions carefully or personal injury or damage may result. Tiger is a registered trademark.
Page 7: Safety Section
SAFETY SAFETY SECTION Saber Safety Section 1-1...
Page 8: General Safety Instructions And Practices
General Safety Instructions and Practices A safe and careful operator is the best operator. Safety is of primary importance to the manufacturer and should be to the owner / operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and observing certain precautions. The first section of this manual includes a list of Safety Messages that, if followed, will help protect the operator and bystanders from injury or death.
Page 9 PELIGRO! Si no lee Ingles, pida ayuda a alguien que si lo lea para que le traduzca las medidas de seguridad. (SG-3) Never operate the Tractor or Implement until you have read and DANGER! completely understand this Manual, the Tractor Operator’s Manual, and each of the Safety Messages found in the Manual or on the Tractor and Implement.
Page 10 DANGER! Never allow children or other persons to ride on the Tractor or Implement. Falling off can result in serious injury or death. DANGER! Never allow children to operate or ride on the Tractor or Implement. WARNING! Do not mount the tractor while the tractor is moving. Mount the tractor only when the tractor and all moving parts are completely stopped.
Page 11 WARNING! The operator and all support personnel should wear hard hats, safety shoes, safety glasses, and proper hearing protection at all times for protection from injury including injury from items thrown by the equipment. CAUTION! PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE PERMA- NENT HEARING LOSS! Tractors with or without an Implement at- tached can often be noisy enough to cause permanent hearing loss.
Page 12 WARNING! Never attempt to lubricate, adjust, or remove material from the Implement while it is in motion or while tractor engine is running. Make sure the tractor engine is OFF before working on the Implement. WARNING! Periodically inspect all moving parts for wear and replace when necessary with authorized service parts.
Page 13 DANGER! NEVER use drugs or alcohol immediately before or while operating the Tractor and Implement. alertness and coordination and therefore affect the operator’s ability to operate the equipment safely. Before operating the Tractor or Imple- ment, an operator on prescription or over-the-counter medication must consult a medical professional regarding any side effects of the medi- cation that would hinder their ability to operate the Equipment safely.
Page 14 DANGER! The rotating parts of this machine have been designed and tested for rugged use. However, the blades could fail upon impact with heavy, solid objects such as metal guard rails and concrete structures. Such impact could cause the broken objects to be thrown outward at very high velocities.
Page 15 WARNING! Do not mow with two machines in the same area except with Cab tractors with the windows closed. Rotary and Flail Mowers are capable under adverse conditions of DANGER! throwing objects for great distances (100 yards or more) and causing serious injury or death.
Page 16 Relieve hydraulic pressure prior to doing any maintenance or repair work on the Implement. Place the Mower Head on the ground or securely supported on blocks or stands, disengage the PTO, and turn off the engine. Push and pull the control Levers or Joystick several times to relieve pressure prior to starting any maintenance or repair work.
Page 17 These parts are made and tested to Tiger specifications. Non-genuine “will fit” parts do not consistently meet these specifications. The use of “will fit” parts may reduce mower performance, void mower warranties and present a safety hazard.
Page 18 SAFETY PART NO. LOCATION 002369 HYDRAULIC TANK 00725746 INSIDE OF CAB 00769737 MOWER DECK Saber Safety Section 1-12...
Page 19 SAFETY PART NO. LOCATION 00758194 MOWER DECK 02962764 MAIN BOOM, SECONDARY BOOM, MAIN FRAME 02962765 MAIN FRAME 02965262 HYDRAULIC TANK Saber Safety Section 1-13...
Page 20 SAFETY Saber Safety Section 1-14 PART NO. LOCATION 02967668 MOWER DECK 02971123 HYDRAULIC TANK 03200285 OUTSIDE OF CAB 22645 INSIDE OF CAB 22839 MOWER DECK...
Page 21 SAFETY Saber Safety Section 1-15 PART NO. LOCATION 22840 INSIDE OF CAB 24028 MOWER DECK 25387 INSIDE OF CAB 10” x 5.5” 31522 MOWER DECK, MAIN BOOM 18.25” x 10” 31523 HYDRAULIC TANK...
Page 22 SAFETY PART NO. LOCATION 32428 MAIN BOOM 32449 HYDRAULIC TANK Saber Safety Section 1-16...
Page 23 SAFETY PART NO. LOCATION 32707 HYDRAULIC TANK 32708 HYDRAULIC TANK 32709 INSIDE OF CAB Saber Safety Section 1-17...
Page 24 SAFETY Saber Safety Section 1-18 PART NO. LOCATION 33224 MOWER DECK 33302 INSIDE OF CAB 35284 INSIDE OF CAB 33438 MAIN BOOM...
Page 25 SAFETY Saber Safety Section 1-19 PART NO. LOCATION 33512 INSIDE OF CAB 33743 INSIDE OF CAB 42350 MOWER DECK...
Page 26 SAFETY Saber Safety Section 1-20 PART NO. LOCATION 42399 REFLECTIVE TAPE MOWER DECK AMBER 42400 REFLECTIVE TAPE MOWER DECK 6T3217 MOWER DECK 6T3219 INSIDE OF CAB 6T3220 FRONT PUMP MOUNT...
Page 27 SAFETY Saber Safety Section 1-21 PART NO. LOCATION 6T3222 INSIDE OF CAB 6T3224 MOWER DECK 6T3225 INSIDE OF CAB 6T3230 INSIDE OF CAB...
Page 28 SAFETY Saber Safety Section 1-22 PART NO. LOCATION 6T3233 HYDRAULIC TANK 6T3234 INSIDE OF CAB 6T3236 MOWER DECK 6T3243 INSIDE OF CAB 6T3249A MOWER DECK...
Page 29 SAFETY Saber Safety Section 1-23 PART NO. LOCATION 6T3261 MOWER DECK TB1011 MOWER DECK 34852 HYDRAULIC TANK...
Page 30 ITEM PART NO. QTY. 50023 AVAIL 00776031 33997 AVAIL 33753 34296 34297 6T1823 NOTE: The manual canister can be bolted, zip tied or adhered to a variety of surfaces. Locate a protected area within the view of the operator. Then select an installation method and attach the canister.
Page 31: Federal Laws And Regulations
FEDERAL LAWS AND REGULATIONS This section is intended to explain in broad terms the concept and effect of federal laws and regulations concerning employer and employee equipment operators. This section is not intended as a legal interpretation of the law and should not be considered as such. Employer-Employee Operator Regulations U.S.
Page 32 SAFETY Saber Safety Section 1-26...
Page 33: Assembly / Mounting Section
CNH T6000 - SABER ASSEMBLY SECTION Assembly Section 2-1...
Page 34: Tractor Preparation
Always use a floor jack, hoist or fork lift to lift and raise heavy parts. Read and understand the entire assembly section instructions before attempting to mount your Tiger mower. Refer to the parts section of this manual for detailed illustrations to locate all parts.
Page 35 FRONT PUMP MOUNTING Install the pump mounting bracket on the front of the tractor with cap-screws and lock-washers as shown in the parts section illustration. DO NOT tighten fasteners at this time. Slide the pump drive shaft into the crankshaft adapter. The end with the shorter splines should be inserted into the adapter (if applicable).
Page 36 ASSEMBLY POLYCARBONATE SAFETY WINDOW NOTE: Installing a boom mower requires that all of the right side windows be replaced, or protected with a polycarbonate window. This should be done before mounting the main frame. 1. Disconnect gas shock at door. Remove the right side cab door/window glass from tractor cab by removing hinge pins.
Page 37 Remove the existing mirror bracket and mirror from the cab. Remove the mirror and knob from existing bracket. Install the supplied bracket (using supplied hardware) on the cab as shown below. Install the mirror with the knob on the supplied bracket as shown below. Refer to the Parts section for details.
Page 38 4 CYLINDER EXHAUST MOUNT NOTE: This should be done after mounting the main frame. Cut the tractor hood as shown in Pic. #1 to accomodate modified exhaust turbo tube. Remove the muffler from existing turbo tube. Remove existing turbo tube from tractor turbo. Install the exhust mounting bracket and supporting brace.
Page 39 ASSEMBLY 4 CYLINDER EXHAUST MOUNT (continued) (ASM-NH-0056) Picture #4 Picture #5 Assembly Section 2-7...
Page 40 6 CYLINDER EXHAUST MOUNT NOTE: This should be done after mounting the main frame. Cut the tractor hood as shown in below to accomodate modified exhaust turbo tube. Remove the muffler from existing turbo tube. Remove existing turbo tube from tractor turbo. Install the exhust mounting bracket and supporting brace.
Page 41 ASSEMBLY SWITCH BOX WIRING Refer to the Parts Section for wiring diagrams. Remove top instrument panel (tach, and hour meter) for access to the wires. Route the red and green switch box wires from the switch box to the bottom right corner of the instrument panel near window.
Page 42 ASSEMBLY WEATHER-PACK/METRI-PACK ASSEMBLY These instructions apply to both Weather-Pack and Metri-pack connectors. NOTE: Use the specific tool for the type of connector you are assembling. (ASM-C-0009) Assembly Section 2-10...
Page 43 ASSEMBLY IDENTIFYING TRACTOR HYDRAULIC SYSTEM The lift valve uses the Pressure, Return and Load Sense on the tractors rear remotes. Depending on what tractor hydraulic system you have determines how the lift valve is plumbed The Closed Center system is shown below. For more information refer to the Parts Section page for a complete diagram of the tractor lift valve hookup.
Page 44 ASSEMBLY For Open Center hydraulic systems, the lift valve will need additional pressure. This pressure is taken from the Power Steering Return line which is located behind the battery box. Assembly Section 2-12...
Page 45 LOAD SENSE HOSE ROUTING - OPEN CENTER On a tractor with an Open Center system with Closed Center remotes, the lift valve uses the Pressure, Return and Load Sense on the tractors rear remotes. The ports used are directly under the valve mounting plate as shown below. The Pressure hose is routed from the tractor remotes to the inlet port of the HP filter on the valve mounting bracket.
Page 46 LOAD SENSE HOSE ROUTING - OPEN CENTER On a tractor with an Open Center system with Open Center ports, the lift valve uses the Pressure, Return and Power Beyond ports on the tractors rear remotes. The ports used are directly under the valve mounting plate as shown below. NH-0062A) The Pressure and Return lines are routed the same as stated above, however, the Load Sense line is routed differently.
Page 47 LIFT VALVE MOUNTING Drill a Ø9/16” hole in the fender frame tube of the tractor 3/4” back of the existing hole (away from cab). Install the valve mounting bracket to the inside of the right and left rear fender frame tube as shown below and attach it with hardware listed in the Parts Section of this manual.
Page 48 CABLE CONTROL LEVER STAND Place the front edge of the support bracket 2-3/4” back from the lower right front window. Rotate stand to be 2-1/4” from the right door frame as shown below. Be sure that the location of the stand will allow clearance between the cable control handles and all existing interior levers, etc.
Page 49 ELECTRONIC LIFT VALVE PORTS (ASM-C-0089) HIGH PRESSURE FILTER The high pressure filter is mounted to the right valve mounting bracket with hardware, as shown in the parts section. Attach the two adapters to the filter. The pressure line from the trac- tor is plumbed to the left (Inlet) side of the filter.
Page 50 NEW HOLLAND PRIORITY VALVE USED ON DELTA & VALUE UNITS (DANFOSS) The DanFoss lift valve needs a priority valve and the Delta and Value style tractor units need a NH priority valve plug in the tractor rear remotes for the proper hydraulic flow. Torque the body of the plug first to 94Nm and then the small end to 15Nm.
Page 51 LIFT VALVE MOUNTING Drill a Ø9/16” hole in the fender frame tube of the tractor 3/4” back of the existing hole (away from cab). Install the valve mounting bracket to the inside of the right and left rear fender frame tube as shown below and attach it with hardware listed in the Parts Section of this manual.
Page 52 LIFT VALVE HOSE & CABLE ROUTING Attach two clamps to the right rear wheel well for proper hose/cable routing. Drill one hole for each clamp. Use the lower rear corner of the wheel well as an origin for measuring. The holes should be Ø10mm or Ø3/8”...
Page 53 ASSEMBLY BOOM JOYSTICK CONTROL CALIBRATION (FOR SABER) SUB-D This Danfoss PVG32 control valve is now equipped with higher-resolution actuators on Main Boom, Secondary Boom, Deck Roll, and Swivel functions. These actuators have “active fault monitoring”. The Deck Shield section does not have “active fault monitoring”. The joystick is unchanged and provides a ratio-metric voltage signal.
Page 54 ASSEMBLY Run tractor at normal operating RPM to adjust the settings as follows. Set the dead band compensation potentiometer first. Set the dead band compensation potentiometer at 50%, or halfway between full clockwise and full counter-clockwise. Setting Signal Adaptation Potentiometers: Disconnect the Deutsch connectors from the actuators of the valve.
Page 55 MAIN BOOM: “A” Port, Boom UP: (Note: Extend secondary boom completely; roll deck to be level with ground, and lower main boom until deck is on ground. Now index main boom “up” function and determine the time required for main boom to rise completely.) “B”...
Page 56 ASSEMBLY (ASM-DF CALIBRATION SBR-0001) Assembly Section 2-24...
Page 57 ASSEMBLY SABER HOSE ROUTING WARNING NOTE: The sudden release of hydraulic pressure could cause the sudden movement of very heavy parts. Anyone in the way of these parts could be severely hurt or killed. DO NOT ALLOW these hydraulic hoses to BREAK or BURST in order to prevent hydraulic failure Make sure the hoses do not pinch or stretch as boom moves.
Page 58 SABER HOSE ROUTING Arrange the hoses in the clamp that attaches to the boom mounting bracket as shown above, with the 1” motor hoses closest to the main frame. Pull the hoses snug from the swivel to the main frame clamps, when main boom is fully forward, and tighten the hoses in the clamp. Make sure the 1”...
Page 59 (ASM-C-0023) SIDE HYDRAULIC TANK INSTALLATION Install all fittings and tubes into tank and tank filter as shown in the Parts Section illustration. Insert tank sight glass into front side of tank. Place the tank in the mounting bracket on the main frame as shown in the Parts Section. Secure the tank with the tank channel mount by placing the channel mount on top of the tank and the washers over the holes.
Page 60 FILLING HYDRAULIC RESERVOIR Refer to the maintenance section for filling specifications and hydraulic oil requirements. NOTE: Starting or running your Tiger mower before filling reservoir will cause serious damage to hydraulic pump. (ASM-C-0004hydro resrv) INSTALLING O-RING FITTINGS Installing straight, 45º and 90º O-rings requires that the O-ring and washer be up against the swivel body.
Page 61 SOLENOID BRAKE VALVE Install a solenoid valve on the mounting bracket with the supplied hardware as shown in the Parts Section in this manual. While installing the fittings to the brake valve, the electical coil on the spool may have to be removed to make room. When reinstalling the coil, it is important to use no more than 5 ft.
Page 62 COOLER MOUNTING - SIDE TANK Mount the cooler mounting brackets on the top rear side of the side hydraulic tank. Locate the bolt plates on the top of the tank and secure the appropriate cooler bracket to the tank with the hardware provided. Attach the screen and cooler to the brackets. Refer to the Parts Section to attach the hoses and adapters to the cooler.
Page 63 AXLE BRACE MOUNTING The axle braces are to be mounted under the rear axle of the tractor with spacers. The other end of the right axle brace mounts to the outside of the lower rear corner of the main frame. After attaching the boom rest, it should fit tightly and level under the tractor.
Page 64 Attach the head to the secondary boom using the pins and hardware shown in the Parts Section. Install the deck pivot cylinder using the pins and hardware also shown in the Parts Section. Connect the fittings and hoses from the pivot cylinder to the small preformed tubes on the boom arm.
Page 65 4WD tractor with wheels larger than 13.6 X R24 will have to be limited. On each side of the front axle the following procedure must be followed. The existing spacer and capscrews will need to be removed and a new Tiger Spacer (p/n 06401546) will need to be added. Sandwich the Tiger Spacer between the tractor and the existing spacer.
Page 66 FINAL PREPARATION FOR OPERATION Place operators safety and operation decals on the steering column and side counsel where they are clearly visible to the operator. These decals should be understood by each operator of the machine in conjunction with the safety and operation section of this book. The decals are to be maintaned in good condition as a reminder to the operator, and should be replaced if damaged.
Page 68 TIGER SABER BOOM MOWER OPERATING INSTRUCTIONS Safety is of primary importance to the owner/operator and to the manufacurer. Tiger Saber Booms are manufactured with quality material by skilled workers. The first section of this manual includes a list of Safety Messages, that, if followed, will help protect the operator and bystanders from injury or death.
Page 69: Operator Requirements
1.OPERATOR REQUIREMENTS Safe operation of the unit is the responsibility of a qualified operator. A qualified operator has read and understands the implement and tractor Operator’s Manuals and is experienced in implement and tractor operation and all associated safety practices. In addition to the safety messages contained in this manual, safety signs are affixed to the implement and tractor.
Page 70: Tractor Requirements
2.TRACTOR REQUIREMENTS In addition to tractor horsepower and size required to operate the boom unit, the tractor must also be properly equipped to provide operator protection, to alert approaching vehicle drivers of the tractor’s presence, and to ensure tractor stability when mowing with the boom fully extended. Tractor Requirements and Capabilities •...
Page 71 2.3 Tractor Lighting and SMV Emblem If the tractor will be operated near or traveled on a public roadway it must be equipped with proper warning lighting and a Slow Moving Vehicle (SMV) emblem which are clearly visible from the rear of the unit.
Page 72: Getting On And Off The Tractor
3.GETTING ON AND OFF THE TRACTOR Before getting onto the tractor, the operator must read and completely understand the implement and tractor operator manuals. If any part of either manual is not completely understood, consult an authorized dealer for a complete explanation. OPS-U- 0007 Do not mount or dismount the Tractor while the tractor is moving.
Page 73: Starting The Tractor
BEFORE leaving the tractor seat, always set the parking brake and/or set the tractor transmission in parking gear, disengage the PTO, stop the engine, remove the key, and wait for all moving parts to stop. Place the tractor shift lever into a low range or parking gear to prevent the tractor from rolling.
Page 74 Start tractor only when properly seated in the Tractor seat. Starting a tractor in gear can result in injury or death. Read the Tractor operators manual for proper starting instructions. When rotating parts are in motion, serious injury may occur if caution is not used or danger is not recognized.
Page 75 5.1 Tractor Pre-Operation Inspection/Service Refer to the tractor operator’s manual to ensure a complete pre-operation inspection and scheduled service performed according manufacturers recommendations. are some of the items that require daily service and inspection: • Tire condition/air pressure • Wheel lug bolts •...
Page 76 The operator’s manual and safety signs affixed on the unit contain important instructions on the safe and proper use of the equipment. Maintain these important safety features on the implement in good condition to ensure the information is available to the operator at all times.
Page 77 BOOM ARM ASSEMBLY • Inspect condition of each arm section weldment • Ensure all pins are in place. • Ensure all bolts, nuts and rollpins are properly installed. • Check condition of bushings at boom pivot points and hydraulic cylinder tangs. •...
Page 78 HYDRAULIC PUMP/OIL RESERVOIR • Check oil reservoir level and oil condition. (Add specific type oil if low) • Change hydraulic oil filter and hydraulic oil according to maintenance schedule. • Ensure there are no oil leaks and fitting are properly connected •...
Page 79 ROTARY HEAD INSPECTION • Inspect blades and blade bolts for looseness and excessive wear. Rotate to 90° to make for checking easier. Replace damaged, worn, and missing blades as complete sets to maintain rotary balance. • Ensure motor bolts and nuts are tightened to the appropriate torque.
Page 80 Boom PRE-OPERATION Inspection Mower ID#________________ Date: Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 81 Tractor PRE-OPERATION Inspection Mower ID#________________ Date: Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 82 5.3 Cutting Component Inspection Inspect blade pan and blade assembly for the following: Inspect the Blades daily for abnormal wear. REPLACE BOTH BLADES on that carrier IMMEDIATELY if either blade has: • Become bent or deformed from it’s original shape or •...
Page 83 5.4 Blade Bolt Inspection Inspect Blade Bolt Head daily for wear as followed: Inspect the Blade Bolt Heads daily for abnormal wear. REPLACE BOTH BLADE BOLTS on the Blades IMMEDIATELY if either blade bolts has: • Visible cracks or • If the recessed area on blade bolt is worn off or •...
Page 85 OPERATION JOYSTICK FW/BACK MOVES MAIN BOOM JOYSTICK LEFT/RIGHT MOVES SECONDARY BOOM LEFT JOYSTICK ROLLER MOVES DECK ROLL Saber Operation Section 3-19 ©2011 Alamo Group Inc.
Page 86 OPERATION RIGHT JOYSTICK ROLLER MOVES BOOM SWIVEL SHIELD SWITCH(on switch box) OPERATES SAFETY SHIELD 6.1 Switchbox The Safety Shield lever opens and closes the shield located on the front of the cutter head. When moving at or near the ground, always have the shield in the closed position.
Page 87 If mowing for the first time with a Tiger Saber Boom Mower, we recommend choosing a ditch or area relatively flat with a minimum of sign posts, guard rails, etc. As always, you should inspect the area for other objects that can cause potential hazards.
Page 88 Upon starting the tractor the “mower run” indicator light may flash briefly, and may flash briefly again when the tractor is shut down. If tractor starts with switch on, turn off tractor and contact your local Tiger dealership for assistance.
Page 89 The Master Switch also provides power to the “Deck Float”, “Shield” and “Travel Lock” Functions of the mower deck. The Deck Float function allows the ground roller of the flail mower head to follow the contour of the ground. To operate the deck float function, the Master switch must be in the “ON”...
Page 90: Driving The Tractor And Implement
7.DRIVING THE TRACTOR AND IMPLEMENT Safe tractor transport requires the operator to possess a thorough knowledge of the model being operated and precautions to take while driving with an attached implement. Ensure the tractor has the capacity to handle the weight of the boom and the tractor operating controls are set for safe transport. To ensure safety while driving the tractor with a boom, review the following.
Page 91 Transport only at speeds where you can maintain control of the equipment. Serious accidents and injuries can result from operating this equipment at high speeds. Understand the Tractor and Implement and how it handles before transporting on streets and highways. Make sure the Tractor steering and brakes are in good condition and operate properly.
Page 92 7.2 Brake and Differential Lock Setting Make sure the tractor brakes are in good operating condition. Tractor brakes can be set to operate independently allowing single rear wheel braking action or locked together to provide simultaneous rear wheel braking. FOR MOST DRIVING AND OPERATING CONDITIONS, THE BRAKE PEDALS SHOULD BE LOCKED TOGETHER TO PROVIDE THE MOST EFFECTIVE BRAKING ACTION.
Page 93 7.3 Driving the Tractor and Boom Start off driving at a slow speed and gradually increase your speed while maintaining complete control of the tractor. Never operate the tractor at speeds that cannot be safely handled or which will prevent the operator from stopping quickly during an emergency.
Page 94: Operating The Boom Unit And Attached Head
8.OPERATING THE BOOM UNIT AND ATTACHED HEAD THE OPERATOR MUST COMPLETELY UNDERSTAND HOW TO OPERATE THE TRACTOR AND MOWER AND ALL CONTROLS BEFORE ATTEMPTING TO MOW. The operator must read and understand the Safety and Operation Sections of this manual and the tractor operator’s manuals. These manuals must be read and explained to any operator who cannot read.
Page 95 8.1 Foreign Debris Hazards/Overhead Obstructions An area to be cut must first be inspected for objects that could be thrown or that could damage the machine. Walk through the area looking for fences, boulders, rocks, culverts, stumps or metal objects. Mark the inspected area with flags.
Page 96 8.2 Operating Speed and Ground Speed Ground speed for mowing will depend upon the height, type, and density of vegetation to be cut. Do Not exceed 5 MPH while operating. Operate the mower at its full rated RPM to maintain blade speed for a clean cut.
Page 97 A flail mower deck should be carried so that the part of the deck weight is carried by the boom and part carried by the ground roller, when moving on the ground. When the flail mower is carried this way, the ground roller follows the contour of the ground more easily during mowing operations.
Page 98 disengage the mower, and return boom to a safe travel position. Return to starting point and make next pass, etc. After the first day of operation, all bolts should be checked and tightened securely. This should be done periodically to ensure the bolts do not become loose and cause damage to the tractor or mower, or injury to the operator.
Page 99 8.6 50” Boom Flail The 50” boom flail mower was designed for cutting brush and foliage up to 2 inches in diameter or multiple branches that have a total cross section area equivalent to one 2 inch branch. Cutting multiple limbs at the same time may overload the mower causing it to slow down or stall completely.
Page 100 All Safety Shields, Guards and Safety devices including (but not limited to) - the Deflectors, Chain Guards, Steel Guards, Gearbox Shields, PTO integral shields, and Retractable Door Shields should be used and maintained in good working condition. devices should be inspected carefully at least daily for missing or broken components. Missing, broken, or worn items must be replaced at once to reduce the possibility of injury or death from thrown objects, entanglement, or blade contact.
Page 101 8.10 Shutting Down the Attached Head- For Standard Equipment To shut down attached mower head, first bring the tractor to a complete stop. Decrease engine RPM to idle then disengage cutterhead. The mower head will come to a complete stop within a suitable amount of time.
Page 102: Transporting The Tractor And Implement
9.TRANSPORTING THE TRACTOR AND IMPLEMENT Inherent hazards of operating the tractor and implement and the possibility of accidents are not left behind when you finish working in an area. Therefore, the operator must employ good judgement and safe operation practices when transporting the tractor and implement between locations. By using good judgement and following safe transport procedures, the possibility of accidents while moving between locations can be substantially minimized.
Page 103 9.3 Transporting on Public Roadways Extreme caution should be used when transporting the tractor and mower on public roadways. The tractor must be equipped with all required safety warning features including a SMV emblem and flashing warning lights to alert drivers of the tractor’s presence. Remember that roadways are primarily designed for automotive drivers and most drivers will not be looking for you, therefore, you must look out for them.
Page 104 When operating public consideration for other road users. Pull to the side of the road occasionally to allow all following traffic to pass. Do not exceed the legal speed limit set in your state or municipality for agricultural tractors. Always stay alert when transporting the tractor and mower on public roads.
Page 105 If any part of this operating section, or any other section of this manual is not completely understood, contact your Tiger dealer or the address on the cover of this manual for assistance! 9.5 Hauling the Tractor and Implement...
Page 106 Arrange the chains so that when tightened, the chains pulling downward themselves. Carefully tighten the securing chains or other fasteners using boomers or binders to apply maximum tension. Use extreme care when attaching and removing the securing devices as the extreme tension involved when released has the potential to inflict serious injury.
Page 107 BEFORE leaving the tractor seat, always set the parking brake and/or set the tractor transmission in parking gear, disengage the PTO, stop the engine, remove the key, and wait for all moving parts to stop. Place the tractor shift lever into a low range or parking gear to prevent the tractor from rolling.
Page 110: General Instructions
Regular maintenance at the intervals mentioned will result in the maximum efficiency and long life of the Tiger Mower. When you purchase a Tiger Mower you also acquire another valuable asset, Tiger’s parts organization. Our rapid and efficient service has guaranteed the customer satisfaction for many years.
Page 111: Regular Maintenance
Never work under the Implement, the framework, or any lifted component unless the Implement is securely supported or blocked up to prevent sudden or inadvertent falling which could cause serious injury or even death. Do not modify or alter this Implement. Implement, any of its components or any Implement function.
Page 112 ITEM SERVICE Hydraulic Fittings Check for leaks Knives Check Spindle mounting bolts Check (spindle to deck) Knife mounting bolts Check (knife to disk or blade bar) Disk or blade bar mntg bolts Check (disk or blade bar to spindle) Belts Check/Adjust Main Frame and Check...
Page 113 WEEKLY OR EVERY 40 HOURS ITEM SERVICE Rotary Spindle Lubricate WEEKLY OR EVERY 50 HOURS ITEM SERVICE In Tank Hyd. Fluid Change Filter 10 micron filter) In-Line High Pressure Change Filter (10 micron filter) MONTHLY OR EVERY 150 HOURS ITEM SERVICE Hydraulic Fluid Level Check...
Page 114: Troubleshooting
SYMPTOMS CAUSE Vibration 1. Loose Bolts 2. Cutter assembly Mower will not lift 1. Hyd. Fluid Low 2. Leaks in line 3. Faulty relief valve 4. Kinked or blocked 5. Faulty cylinder Mower will not start 1. Blown fuse or run 2.
Page 115 TROUBLESHOOTING (Continued) SYMPTOMS CAUSE Motor runs but 1. Belts will not cut. 2. Tensioner Mower turns slowly 1. Contaminants or not at all. 2. Suction lines 3. Low oil level Pump will not work 1. Excessive wear Motor will not work 1.
Page 116 Delvac Synthetic Gear Oil 75W-90 Mobil Delvac® Xtreme Grease Mobilgrease CM-S Mobil Delvac® Xtreme Grease Mobilgrease CM-S Mobil Delvac® Xtreme Grease Mobilgrease CM-S Mobil Delvac® Xtreme Grease Mobilgrease CM-S Mobil Delvac® Xtreme Grease Mobilgrease CM-S Mobilith SHC 220, Tiger Part #06540000...
Page 117: Torque Specifications
MAINTENANCE TORQUE SPECIFICATIONS *These are general specifications. Check your tractor operators or service manual for exact specifications. Saber Maintenance Section 4-9 ©2011 Alamo Group Inc.
Page 118 The proprietary UV and Abrasion Resistant Surface coating on SHIELDS® SUPERCOATED™ polycarbonate significantly improves performance. Periodic cleaning using proper procedures and compatible cleaners are recommended to prolong service life. Tiger Corp. polycarbonate is SUPERCOATED™ on both sides. CLEANING THE SUPERCOAT™ HARD-COAT Wash with a mild solution of soap or detergent and lukewarm water.
Page 119 MAINTENANCE RECOMMENDED FILLING INSTRUCTIONS FOR HYDRAULIC RESERVIORS When filling or checking the oil level, the unit should be parked on a level surface., shut ”OFF”, and allow sufficient time to cool to ambient temperature. Use caution when removing the pressurized breather. Do not place face over opening when removing breather.
Page 120 MAINTENANCE DETAILED MAINTENANCE REPLACEING HIGH PRESSURE HYDRAULIC FILTER ELEMENT: Assure system has been shut down and de- pressurized. Locate High Pressure Filter housing. Confirm that the element that is about to be installed matches the element p/n on the filter model tag.
Page 121 MAINTENANCE GREASING GROUND ROLLER SHAFT-FLAIL Locate grease zerks on each end of roller tube at lower end of head. Normal conditions require one or two pump in each bearing, using Lithium-Complex Extreme Pressure grease conforming to NLGI2-ISO 320 specifications. This is to be done with a standard grease gun daily or at 8 hour intervals. CAUTION: Over greasing may cause premature seal failure.
Page 122 MAINTENANCE BALL VALVES The ball valve at the hydraulic reservoir may need to be closed during certain maintenance or repair procedures. THE BALL VALVES MUST BE OPEN (handle parallel with valve) WHEN TRACTOR IS RE-STARTED OR PUMP IS COUPLED TO MOTOR OR P.T.O.! Failure to do so will result in component failure! TIGHTENING KNIFE BOLTS AND DISK BOLTS:...
Page 123 MAINTENANCE GREASING POINTS ON BOOM AND PIVOT Locate grease zerks (8) on deck pivot assembly, (2) on the deck end of secondary boom, (2) at main/ secondary boom joint, and (2) at swivel end of main boom. Inject Lithium-Complex Extreme Pressure grease conforming to NLGI2-ISO 320 specifications until grease begins to protrude from ends.
Page 124 MAINTENANCE GREASING SPINDLE Locate grease fitting on inside of deck housing. Inject Tiger Spindle Lubricant, part number 06540000 into spindle housing. Fill with lubricant until lubricant weeps out of top spindle seal. Lubricate spindle weekly or every 40 hours of use.
Page 125 MAINTENANCE GREASING PUMP DRIVE SHAFT COUPLER With engine stopped, ensure drive shaft alignment by grasping coupler and sliding back and forth. Coupler should slide freely with approximately 1/8” of end play. If coupler does not slide freely, inspect for loose pump mount bolts, or damaged or loose crank shaft adapter.
Page 126 MAINTENANCE GREASING THE BOOM SWIVEL Locate the zerks on the main swivel boss (2), main boom pivot boss (2) and on both ends of the boom swivel cylinder. Inject Lithium-Complex Extreme Pressure grease conforming to NLGI2-ISO 320 specification until grease begins to protrude from ends every 8 hours.
Page 127 Blades Check the Blades for cracks and wear and Blade Bolts for tightness, daily. Blades should be replaced when they are worn excessively, bent, deformed, or out of balance. Blades should always be replaced in pairs. Blades of different weights can cause serious imbalance and damage to the machine and personnel.
Page 128: Rotary Knife Replacement
ROTARY KNIFE REPLACEMENT Be sure you have a complete matching set of new knives for replacement. Remove knives and inspect holes for damage. Also watch for cracks in the disk around the holes. Lube threads with anti-seize, motor oil or grease. Install bolts through knife and disk from bottom side of disk.
Page 129 Flail Blades Inspection Inspect the Blades daily for abnormal wear. REPLACE ALL BLADES on the carrier IMMEDIATELY if any blades have: • Become bent or deformed from its original shape, or • Wear inside the blade bolt hole, or • Any cracks are visible, or •...
Page 130 Blade Pins and D-Ring Inspection Blade Pins and D-Rings daily for wear or damage as follows: Inspect the Blade pins and D-Rings daily for abnormal wear. Make sure the cotter pins are in place and properly spread. REPLACE BLADE Pins and D-Rings IMMEDIATELY if they have: •...
Page 131: Flail Axe Blades Inspection
Flail Axe Blades Inspection Inspect the Blades daily for abnormal wear. REPLACE ALL BLADES on the carrier IMMEDIATELY if any blades have: • Become bent or deformed from its original shape, or • Oval shape wear inside the blade bolt hole, or •...
Page 132 Flail Axe Blade Bolt Inspection Inspect Blade Bolts daily for wear or damage as follows: Inspect the Blade Bolt daily for abnormal wear. REPLACE ALL BLADE BOLTS on the carrier IMMEDIATELY if any bolts have: • Visible cracks or • If the blade bolt is worn or any recessed area is visible on the bolt, or •...
Page 133 DO NOT re-use the locking hex nuts for mounting the knives. If hex nut becomes loose, or required removal for knife replacement or any other reason, they must be discarded and replaced with new nuts. Knives should not be welded on for any reason. 63”...
Page 134 MAINTENANCE HEAVY DUTY SPINDLE ASSEMBLY INSTALLATION AND BEARING ADJUSTMENT A press MUST be used to install bearing cups, bearing cones, and seals. DO NOT use a hammer to install races, bearings, or seals. The parts of assembly may be damaged. NOTE: The grease zerk and gussets are located on the top side of the spindle housing.
Page 135 Turn the spindle housing over (up position) and fill with Tiger Spindle Lubricant (part number 06540000) to the top edge of the upper bearing cup. Support the bottom of the spindle and press the upper bearing cone and bearing adjustment sleeve onto the spindle.
Page 136: Boom Cylinder Removal And Replacement Instructions
Boom Cylinder Removal and Replacement Instructions Clear the area of all personnel before lowering the boom mower head. From the tractor seat with your seat belt fastened around you, Lower the boom mower head to the ground. Extend the boom to the furthest reach and lower the mower head flat on the ground. DO NOT attempt to replace the cylinders with the boom in the raised or transport position.
Page 137 CUTTERSHAFT BEARING REPLACEMENT FOR FLAIL MOWERS Remove existing cuttershaft, bearings and string guards. Make sure that the end knives on each end of the cuttershaft are orientated as shown. Apply anti-seize on cuttershaft as shown on next page. Install non-drive side bearing first. Install the top of the string guard on the non-drive side first.
Page 139 DAILY MAINTENANCE SCHEDULE The following services should be performed daily or every 8 hours of service, following the detailed maintenance instructions in the operators manual. _______ Pump Drive Shaft: If required with drive shaft/coupler check for end play and lubricate at zerks. _______ Crankshaft adapter: If equipped with rubber grommets check condition, replace if missing or damaged.
Page 141: Parts Section
NH T6000 SABER BOOM PARTS SECTION...
Page 142 NOTES...
Page 143 PART NAME INDEX PARTS ORDERING GUIDE ... 4 NOTES... 5 TRACTOR MOUNT KIT... 6 TRACTOR MOUNT KIT - HYDRAULICS... 8 AXLE BRACE AND BATTERY BOX ... 10 MID-MOUNT VALVE RELOCATION... 12 JOYSTICK AND SWITCH BOX MOUNT... 14 ELECTRONIC PROPORTIONAL LIFT VALVE - LOAD SENSE... 16 ELECTRONIC PROPORTIONAL LIFT VALVE - TERRAGLIDE...
Page 147 Continued... ITEM PART NO. QTY. DESCRIPTION 06300076 FRM,LH,SBR 06300075 MNFRM,SBR 06300080 MNT,TANK 06380012 TANK,RESERVOIR 06505077 CAP,BREATHER 21725 HEX NUT,1/2",NC 22018 FLATWASHER,1/2",WIDE 06505067 SIGHT GAUGE 06505044 FLTR ASSY,IN-TANK CPLT 21627 NYLOCK NUT,3/8",NC TF4888 STREET ELBOW,1/8" X 90º 6T0649 FILTER GAUGE 06380014 TIE BOLT,SIDE TANK,HYDRO 06410352 CHANNEL,MNT,TANK,TIE-BOLT...
Page 149 Continued... ITEM PART NO. QTY. DESCRIPTION 06300076 FRM,LH,SBR 06300075 MNFRM,SBR 06300080 MNT,TANK 06700090 TANK,ASSY 23152 PUMP TF4852 KIT,FLANGE,#20 06400114 MNT,BRAKE VALVE 33880 FLATWASHER,3/4",SAE 25341 CAPSCREW,20MM X 70MM,2.5P 24849 SPACER,7/8"ID X 1-1/4"OD X 5/8" 06510084 VALVE,BRAKE,3500PSI 32382 BRACKET,HOSE 24860 CAPSCREW,20MM X 40MM,2.5P 21644 CAPSCREW,3/8"...
Page 151 Continued... ITEM PART NO. QTY. DESCRIPTION ------ MAIN FRAME *REFER TO TRACTOR MNT KIT PAGE 06300032 AXLE BRC,LH 06300031 AXLE BRC,RH 21825 HEX NUT,3/4",NC 33880 FLATWASHER,3/4",SAE 21833 CAPSCREW,3/4" X 2-1/4",NC 22016 FLATWASHER,3/8" 21627 NYLOCK NUT,3/8",NC 06410145 COVER,TOP,BATT 21530 CAPSCREW,1/4" X 1",NC 21986 LOCKWASHER,1/4"...
Page 153 Continued... ITEM PART NO. QTY. DESCRIPTION ------ CAPSCREW (EXISTING HARDWARE) ------ HEX NUT (EXISTING HARDWARE) ------ VALVE MOUNTING PLATE,TOP (EXISTING) 06411134 STRAP,VLV,RELOCATE ------ VALVE MOUNTING PLATE,BOTTOM (EXISTING) 21581 CAPSCREW,5/16" X 1-1/4",NC 21577 NYLOCK NUT,5/16",NC 06401528 PLATE,VLV,RELOCATE ------ FLATWASHER (EXISTING HARDWARE) NH T6000 SABER ©2011 Alamo Group Inc.
Page 155 Continued... ITEM PART NO. QTY. DESCRIPTION 06520041 MOUNT,RAM,BALL,1-1/2",NPT 06520042 MOUNT,RAM,ARM,1.5" X 2.75" 35033 CAN,JYSTK,CPLT,DF 35205 SETSCREW,3/8" X 2",NC,KNURLED PT 35206 HEX NUT,JAMB,3/8",NC 35204 KNOB,3/8",NC,INSERT 33691 JOYST,4AXIS,RH 32829 SCREW,MACHINE,10-32 X 3/4",FLTHD 35256 BUSHING,NYLON,1"OD,3/4"ID 21636 CAPSCREW,3/8" X 2-1/2",NC 21627 NYLOCK NUT,3/8",NC 06340011 MNT,STND,JYSTK 06340010 ROD,1/2"NPT X 7",JYSTK...
Page 157: Electronic Proportional Lift Valve - Load Sense
ELECTRONIC PROPORTIONAL LIFT VALVE - LOAD SENSE Continued... ITEM PART NO. QTY. DESCRIPTION 06340008 VLV MNT,RH 06340009 VLV MNT,LH 34622 PLATE,VALVE,REAR MNT 21631 CAPSCREW,3/8” X 1-1/4”,NC 21988 LOCKWASHER,3/8" 21625 HEX NUT,3/8",NC 22016 FLATWASHER,3/8" 06505029 FILTER,HP,3/4"SAE,VIS IND 06505039 ELEMENT,FILTER 06505081 INDICATOR,VIS,HP FILTER 21579 CAPSCREW,5/16"...
Page 159: Electronic Proportional Lift Valve - Terraglide
ELECTRONIC PROPORTIONAL LIFT VALVE - TERRAGLIDE Continued... ITEM PART NO. QTY. DESCRIPTION 06340008 VLV MNT,RH 06340009 VLV MNT,LH 34622 PLATE,VALVE,REAR MNT 21631 CAPSCREW,3/8” X 1-1/4”,NC 21988 LOCKWASHER,3/8" 21625 HEX NUT,3/8",NC 22016 FLATWASHER,3/8" 06505029 FILTER,HP,3/4"SAE,VIS IND 06505039 ELEMENT,FILTER 06505081 INDICATOR,VIS,HP FILTER 21579 CAPSCREW,5/16"...
Page 160 ELECTRONIC PROPORTIONAL LIFT VALVE - POWER BEYOND ITEM PART NO. QTY. DESCRIPTION 06340008 VLV MNT,RH 06340009 VLV MNT,LH 34622 PLATE,VALVE,REAR MNT 21631 CAPSCREW,3/8” X 1-1/4”,NC NH T6000 SABER ©2011 Alamo Group Inc. Parts Section 5-20...
Page 161 ELECTRONIC PROPORTIONAL LIFT VALVE - POWER BEYOND Continued... ITEM PART NO. QTY. DESCRIPTION 21988 LOCKWASHER,3/8" 21625 HEX NUT,3/8",NC 22016 FLATWASHER,3/8" 06505029 FILTER,HP,3/4"SAE,VIS IND 06505039 ELEMENT,FILTER 06505081 INDICATOR,VIS,HP FILTER 21579 CAPSCREW,5/16" X 3/4",NC 33294 ELBOW,3/4"MOR X 1/2"MJ 21729 CAPSCREW,1/2" X 1",NC 21990 LOCKWASHER,1/2"...
Page 163: Electronic Proportional Lift Valve - Open Center
ELECTRONIC PROPORTIONAL LIFT VALVE - OPEN CENTER Continued... ITEM PART NO. QTY. DESCRIPTION 06340008 VLV MNT,RH 06340009 VLV MNT,LH 34622 PLATE,VALVE,REAR MNT 21631 CAPSCREW,3/8” X 1-1/4”,NC 21988 LOCKWASHER,3/8" 21625 HEX NUT,3/8",NC 22016 FLATWASHER,3/8" 06505029 FILTER,HP,3/4"SAE,VIS IND 06505039 ELEMENT,FILTER 06505081 INDICATOR,VIS,HP FILTER 21579 CAPSCREW,5/16"...
Page 165: Tractor Remote Plumbing - Open Center
TRACTOR REMOTE PLUMBING - OPEN CENTER Continued... ITEM PART NO. QTY. DESCRIPTION 06410171 PLATE,MOUNT 21986 LOCKWASHER,1/4" 21525 HEX NUT,1/4",NC 28583 CAPSCREW,8MM X 25MM,1.25P 6T2619 LOCKWASHER,8MM 34948 FLATWASHER,8MM 06503002 ADAPTER,12MM MOR X 5/16"MJ 06500092 HOSE,1/4" X 12" 06503012 ADAPTER,27MM MOR X 3/4"MJ 33463 ADAPTER,22MM MOR X 1/2"MJ 06500091...
Page 167 Continued... ITEM PART NO. QTY. DESCRIPTION ------ WORK LIGHT ------ KNOB T6010 ------ MIRROR ------ EXHAUST 06370008 MNT,MIRROR/LIGHT 06410633 MNT,MIRROR 06410141 COLLAR,EXHAUST 06410142 COLLAR,CLAMP,EXHAUST 21530 CAPSCREW,1/4" X 1",NC 21525 HEX NUT,1/4",NC 22014 FLATWASHER,1/4" 21529 CAPSCREW,1/4" X 3/4",NC 21580 CAPSCREW,5/16 X 1,NC 21577 NYLOCK NUT,5/16",NC 21585...
Page 169 Continued... ITEM PART NO. QTY. DESCRIPTION 06490037 POLYCARBONATE,DOOR,RH 31965 TRIM SEAL,3/8"CLIP X 3/4"OD BULB (IN FEET) 06530502 CAPSCREW,8MM X 40MM,1.25P,GR8 ------ EXISTING HARDWARE 06530501 CAPSCREW,6MM X 25MM,1.0P,GR8 06537006 THREADED INSERT,1/4" X 1/2",NC 21532 CAPSCREW,1/4" X 1-1/2",NC 06537001 WASHER RUBBERIZED 35234 GROMET,RIBBED,1/2"OD X 1/4"ID X 1/2"...
Page 170: Exhaust Mount - 6 Cylinder
ITEM PART NO. QTY. DESCRIPTION 06410113 MNT,EXHAUST 06410121 MNT,EXHAUST,SUPPORT 06520023 TUBE,EXHAUST RELOCATE,6CYL 32986 CLAMP,EXHAUST,3-1/2" 21630 CAPSCREW,3/8" X 1",NC 21988 LOCKWASHER,3/8" 21625 HEX NUT,3/8",NC ------ EXISTING MAINFRAME HARDWARE NH T6000 SABER ©2011 Alamo Group Inc. EXHAUST MOUNT - 6 CYLINDER Parts Section 5-30...
Page 171: Boomrest Assembly - Saber
ITEM PART NO. QTY. DESCRIPTION 06310071 BMRST,ASSY,SABER 06310090 STOP,UPPER,SBR 06310091 STOP,LOWER,SBR 06520078 BUMPER,PAD,SHORT 32686 BUMPER,PAD,LONG 28734 CAPSCREW,3/8" X 1",NC 6T1027 CAPSCREW,1/2" X 1-3/4",NC 06533004 FLATWASHER,1/2",NC 31580 HEX NUT,1/2",NC 21782 CAPSCREW,5/8" X 1-3/4",NC 33764 FLATWASHER,5/8",SAE 21777 NYLOCK NUT,5/8",NC NH T6000 SABER ©2011 Alamo Group Inc.
Page 172: Boomrest Assembly - Saber Mb
ITEM PART NO. QTY. DESCRIPTION 06310092 BMRST,ASSY,SABER MB 06310090 STOP,UPPER,SBR 06310060 STOP,LOWER,SBR MB 06520078 BUMPER,PAD,SHORT 32686 BUMPER,PAD,LONG 28734 CAPSCREW,3/8" X 1",NC 6T1027 CAPSCREW,1/2" X 1-3/4",NC 06533004 FLATWASHER,1/2",NC 31580 HEX NUT,1/2",NC 21782 CAPSCREW,5/8" X 1-3/4",NC 33764 FLATWASHER,5/8",SAE 21777 NYLOCK NUT,5/8",NC NH T6000 SABER ©2011 Alamo Group Inc.
Page 173: Boomrest Assembly - Saber Xb
ITEM PART NO. QTY. DESCRIPTION 06310035 BOOMREST,BASE 06310053 BOOMREST,UPPER 06310054 BOOMREST,LOWER 06520078 WEARPAD,SHORT,BOOMREST 32686 WEARPAD,LONG,BOOMREST 06410587 CHANNEL,TIE DOWN 21747 CAPSCREW,1/2" X 9",NC 22004 FLATWASHER,1/2",NARROW 21727 NYLOCK NUT,1/2",NC 28734 CAPSCREW,FLT/SKT HD,3/8" X 1",NC 21731 CAPSCREW,1/2" X 1-1/2",NC 21782 CAPSCREW,5/8" X 1-3/4",NC 33764 FLATWASHER,5/8",SAE 21777...
Page 175 Continued... ITEM PART NO. QTY. DESCRIPTION 32615 1700# WEIGHT 32518 850# WEIGHT 21846 CAPSCREW,3/4" X 9",NC 33626 FLATWASHER,3/4",USS 06530200 CAPSCREW,7/8" X 14",NC 06533000 FLATWASHER,7/8" 06531000 HEX NUT,7/8",NC 06401332 LOCK,BOLT,WHL WHT 06530219 CAPSCREW,7/8" X 19-1/2",NC 06533000 FLATWASHER,7/8" 06499010 3400# WEIGHT 06531000 HEX NUT,7/8",NC NH T6000 SABER ©2011 Alamo Group Inc.
Page 177 Continued... ITEM PART NO. QTY. DESCRIPTION 06770045 1700# WEIGHT,TAPPED 32518 850# WEIGHT 21846 CAPSCREW,3/4" X 9",NC 33626 FLATWASHER,3/4",USS 06530200 CAPSCREW,7/8" X 14",NC 06533000 FLATWASHER,7/8" 06531000 HEX NUT,7/8",NC 06401332 LOCK,BOLT,WHL WHT 21842 CAPSCREW,3/4" X 5",NC 33626 FLATWASHER,3/4",USS 32518 850# WEIGHT 06370167 SPACER,WHEEL WEIGHT 06530219 CAPSCREW,7/8"...
Page 179 COMMON SABER BOOM PARTS SECTION...
Page 181 PART NAME INDEX PARTS ORDERING GUIDE ... 5 BOOM SWIVEL ASSEMBLY ... 6 QUICK COUPLERS... 8 SABER BOOM ASSEMBLY... 10 SABER MB BOOM ASSEMBLY ... 12 SABER XB BOOM ASSEMBLY... 14 50IN FLAIL ASSEMBLY... 16 50IN FLAIL ASSEMBLY, PASS-THROUGH KNIVES... 18 50IN FLAIL DRIVE ASSEMBLY...
Page 182 PART NAME INDEX LEFT HAND JOYSTICK SWITCHBOX SCHEMATIC... 71 TROUBLESHOOTING... 72 TROUBLESHOOTING - CONTINUED ... 73 HYDRAULIC TROUBLESHOOTING GUIDE... 74 ELECTRICAL TROUBLESHOOTING GUIDE... 75 NOTES 1... 76 CLEAN CUTTER HEAD... 77 CLEAN CUTTER ASSEMBLY... 78 CLEAN CUTTER OPERATION ... 79 CLEAN CUTTER OPERATION - CONTINUED...
Page 185 Continued... ITEM PART NO. QTY. DESCRIPTION 32742 SWIVEL W/BUSHINGS,BOOM,SABER 32376 SWIVEL,BOOM,SABER,W/O BUSHING 33705 CYLINDER,3X17 1/2,WELDED 32381 PIN,2 1/2,SWIVEL,SABER 33710 PIN,CYLINDER,1,SWIVEL,SABER 32380 PIN,CYL,1,SWIVEL,SABER 32372 PIN,CYLINDER,STAGE,2ND 32378 PIN,BOOM TO SWIVEL,SABER 32322 BEARING,DX,2 1/2X2 1/2LONG, 6T3211 GREASE ZERK,1/8 21782 CAPSCREW,5/8 X 1-3/4 NC 21992 LOCKWASHER,5/8 21775...
Page 187 Continued... ITEM PART NO. QTY. DESCRIPTION 34392 ADAPTER,1ORBX1FJX 06503028 QUICK COUPLER,1”SAE,MALE,FLAT 06503027 QUICK COUPLER,1”SAE,FEM,FLAT 33555 ADAPTER,1MORBX1MJIC ------ PREFORMED TUBES - REFER TO BOOM ARM PARTS ------ #16 HOSE - REFER TO HYDRAULICS PARTS COMMON SABER ©2011 Alamo Group Inc. QUICK COUPLERS Parts Section 6-9...
Page 188 ITEM PART NO. QTY. DESCRIPTION 32743 MAIN BOOM W/BEARING 32744 SECONDARY BOOM W/BEARING 32311 MOUNT,SWIVEL HEAD 32309 MOUNT HEAD PLATE 32316 LINKAGE,BOOM TO CYLINDER 32745 LINKAGE W/BEARING,CYLINDER TO SWIVEL COMMON SABER ©2011 Alamo Group Inc. SABER BOOM ASSEMBLY Parts Section 6-10...
Page 189 Continued... ITEM PART NO. QTY. DESCRIPTION 32363 CYLINDER,5" X 25" 32364 CYLINDER,4-1/2" X 26-1/2" 32365 CYLINDER,4" X 15" 33542 PREFORMED TUBE,1” 32627 PREFORMED TUBE,3/8” 32628 PREFORMED TUBE,3/8” 32629 PREFORMED TUBE,3/8” 33541 PREFORMED TUBE,1” (ROTARY RETURN) 33540 PREFORMED TUBE,1” (ROTARY PRESSURE) 33215 TUBE CLAMP KIT 32313...
Page 190 ITEM PART NO. QTY. DESCRIPTION 06310075 BOOM,MB,PRIMARY,SABER 06310076 BOOM,MB,SECONDARY,SABER 21688 CAPSCREW,7/16" X 3-1/4,NC 32375 PIN,1-1/2" X 3-13/16",W/HOLE 21677 NYLOCK NUT,7/16",NC 32363 CYLINDER,5" X 25" COMMON SABER ©2011 Alamo Group Inc. SABER MB BOOM ASSEMBLY Parts Section 6-12...
Page 191 Continued... ITEM PART NO. QTY. DESCRIPTION 32362 BEARING,DX,2" X 2" LONG 6T3211 GREASE ZERK,1/8" X STR 06506042 PRFRMD,1,MAIN,SABER MB 06506043 PRFRMD,2,MAIN,SABER MB 33215 TUBE CLAMP KIT 06506045 PRFRMD,4,MAIN,SABER MB (ROTARY RETURN) 06506044 PRFRMD,3,MAIN,SABER MB (ROTARY PRESSURE) 06500488 HOSE,3"/8 X 39" 32818 HOSE,3/8"...
Page 192 ITEM PART NO. QTY. DESCRIPTION 06310031 BOOM,LONG,PRIMARY,SABER 06310032 BOOM,LONG,SECONDARY,SABER 21688 CAPSCREW,7/16" X 3-1/4",NC 32375 PIN,1-1/2" X 3-13/16",W/HOLE 21677 NYLOCK NUT,7/16",NC 32363 CYLINDER,5" X 25" COMMON SABER ©2011 Alamo Group Inc. SABER XB BOOM ASSEMBLY Parts Section 6-14...
Page 193 Continued... ITEM PART NO. QTY. DESCRIPTION 32362 BEARING,DX,2" X 2" LONG 6T3211 GREASE ZERK,1/8" X STR 06506029 PRFRMD,1,MAIN,SABER XB 06506030 PRFRMD,2,MAIN,SABER XB 33215 TUBE CLAMP KIT 06506032 PRFRMD,4,MAIN,SABER XB (ROTARY RETURN) 06506031 PRFRMD,3,MAIN,SABER XB (ROTARY PRESSURE) 32818 HOSE,3/8" X 24" 32680 HOSE,3/8"...
Page 195 Continued... ITEM PART NO. QTY. DESCRIPTION ---- 06742138 FLAIL,BOOM,50,MD GRASS,CPLT ASSY (MEDIUM BRUSH/GRASS) 06320145 CUTTER HEAD BONNET TF3004 FRONT SHIELD 06700115 TBF50 (MEDIUM BRUSH/GRASS KNIFE ASSY) 6T2419 HEX NUT,9/16”,NC,STOVER 41725.01 BUSHING,1"OD X 5/8"ID 06430122 SPACER (MEDIUM BRUSH/GRASS KNIVES) 34786 CAPSCREW,9/16” X 3-1/2”,NC 06521007 KNIFE (MEDIUM BRUSH/GRASS CUTTING) 31204...
Page 197: In Flail Assembly, Pass-Through Knives
50IN FLAIL ASSEMBLY, PASS-THROUGH KNIVES Continued... ITEM PART NO. QTY. DESCRIPTION 06742135 FLAIL,BOOM,50,CPLT ASSY 06320145 CUTTER HEAD BONNET TF3004 FRONT SHIELD 33717 TBF50,CUTTERSHAFT,PASS THRU KNIVES TF3405 GROUND ROLLER TF3406 GROUND ROLLER TIE ROD TB1006A DEFLECTOR FLAP TB1008 FLAP RETAINING BAR TF3001 SKID SHOE TF3407...
Page 199 Continued... ITEM PART NO. QTY. DESCRIPTION 06504013 MOTOR TF3006 BELT GUARD TF3043 SHEAVE TF3013 BUSHING TF3011 BUSHING TF3034 IDLER PULLEY TF3205 IDLER ARM TF3206 IDLER PULLEY SPACER TF3605 IDLER ARM PIN WITH ZERK 6T3004 R - CLIP PT3611A CLEVIS 32481 THREADED ROD TF3620 COMPRESSION SPRING...
Page 200 ITEM PART NO. QTY. DESCRIPTION 06742086 BONNET,SBF50,DD,ASSY (LIGHT BRUSH) ---- 06742142 BONNET,SBF50,DD,ASSY (MEDIUM BRUSH) COMMON SABER ©2011 Alamo Group Inc. SABER DIRECT DRIVE FLAIL ASSY Parts Section 6-22...
Page 201 Continued... ITEM PART NO. QTY. DESCRIPTION 06320112 BONNET TF3007A COVER PLATE 06410794 GUARD 06533006 FLATWASHER,1/2",GR 9 21727 NYLOCK NUT,1/2",NC 06530404 CAPSCREW,SKT/BUT HD,1/2" X 1-1/2",NC 06530401 CAPSCREW,SKT/BUT HD,1/2" X 1",NC 06320127 DOOR,SBF50 DD 06530218 CAPSCREW,1/2" X 1-3/4",NC,L9 06520211 BEARING W/ HOUSING 31204 STRING GUARD 06700123...
Page 203 Continued... ITEM PART NO. QTY. DESCRIPTION ------ BONNET *REFER TO BONNET ASSY 06506040 PREFORMED TUBE TF4852 FLANGE KIT 06530401 CAPSCREW,SKT/BUT HD,1/2" X 1",NC 06320126 MOTOR GUARD 06504003 MOTOR,DD 06500539 HOSE,1" X 82" 06530223 CAPSCREW,9/16" X 1-3/4",NC,GR8 06533003 FLATWASHER,9/16",GR9,SAE 06505014 CLAMP KIT 06500386 HOSE,1"...
Page 205 Continued... ITEM PART NO. QTY. DESCRIPTION ------ 06200658 FLAIL,BOOM,63",GRASS,CPLT ASSY 06320110 CUTTER HEAD BONNET 28743 CUTTER SHAFT / KNIFE ASSY STANDARD GRASS ------ 28642C CUTTER SHAFT,63",STD TF1021B FLAIL KNIFE MOUNTING BOLT TF1020 FLAIL KNIFE MOUNTING CLEVIS 33713 FLAIL KNIFE - STANDARD 21677 NYLOCK NUT 28086A...
Page 207 Continued... ITEM PART NO. QTY. DESCRIPTION 06504013 MOTOR (M350-1 3/4 GEAR) 28703B BELT GUARD TF3044 UPPER SHEAVE TF3040 LOWER SHEAVE TF3013 BUSHING 28723 BUSHING 28679B MOTOR CHANNEL PT3611A CLEVIS 40496 THREADED ROD 28702 BELT TF3620A TENSIONER SPRING 28572 SQUARE KEY TF1025 SQUARE KEY TF4852...
Page 208 ITEM PART NO. QTY. DESCRIPTION 33304 ROTARY,SABER 50",ASSY 32914 ROTARY,SABER 50",DECK 32915 SHIELD,50" ROTARY,SABER 06504012 MOTOR 33198 MOTOR MOUNTING BRACKET 34479 SPROCKET,MOTOR 34482 CHAIN COUPLING 34483 COVER COUPLING TF4852 FLANGE KIT TF1124 KEY,WOODRUFF 33185 CYLINDER COMMON SABER ©2011 Alamo Group Inc. 50IN SABER ROTARY MOWER Parts Section 6-30...
Page 209 Continued... ITEM PART NO. QTY. DESCRIPTION 32952 DEFLECTOR FLAP 33211 RETAINING BAR,FLAP 32951 HINGE PIN,SHIELD 33924 ROLLPIN,HINGE PIN 32936 SKID SHOE 34509 BAR,KNIVE MOUNTING 33203 KNIVES,SET OF 2,ROTARY,3/4” 34883 BOLT,KNIFE 6T0822 SHIM,MOTOR MOUNT,THIN 6T0822A SHIM,MOTOR MOUNT,THICK TB1033 CLEVIS PIN 06537021 ROLL PIN,CLEVIS 3334306 ELBOW,3/8MP X 3/8MJ90...
Page 210 ITEM PART NO. QTY. DESCRIPTION 06741036 ROTARY,SABER XB,ASSY 06320009 ROTARY,SABER XB,DECK 06410439 COVER,MOTOR MNT 22014 FLATWASHER,1/4" 21530 CAPSCREW,1/4" X 1",NC 33879 CAPSCREW,3/4" X 2-1/4",NF,GR 8 33880 FLATWASHER,3/4",GR 8,SAE 33984 PIN,SHIELD,50" RD1032 PIN,LYNCH,1/4" X 2" 06500291 HOSE,3/8" X 74" 32810 ELBOW,1/2" X 3/8" 06500292 HOSE,3/8"...
Page 211 Continued... ITEM PART NO. QTY. DESCRIPTION 33785 CYL,1-1/2 X 8" 33778 HINGE PIN,50" RTRY 6T3017 ROLLPIN,3/16" X 1" 33754 SHIELD,50" RTRY 33777 SKID SHOE,50" RTRY 21993 LOCKWASHER,3/4",GR 8 6T2413 HEX NUT,3/4",NF,GR 8 6T1023R KNIFE MTG NUT,1-1/8",NF,GR8 06533002 FLATWASHER,1-1/8",GR8 06521001 KNIFE,TRB 50,5/8" 06538000 KNIFE MTG BOLT,5/8",SHOULDER 6T2259...
Page 212 ITEM PART NO. QTY. DESCRIPTION 06741072 ROTARY,SABER 60",ASSY 06320169 ROTARY,SABER 60",DECK 33879 CAPSCREW, 3/4" X 2-1/4",NF GR 8 33880 FLATWASHER,3/4",GR 8,SAE 06410439 COVER,MOTOR MNT 22014 FLATWASHER,1/4” 21530 CAPSCREW,1/4" X 1",NC RD1032 PIN,LYNCH,1/4" X 2" 33984 PIN,SHIELD 33785 CYL,1-1/2" X 8" 06500292 HOSE,3/8"...
Page 213 Continued... ITEM PART NO. QTY. DESCRIPTION 06420139 HINGE PIN,60" RTRY 06320162 SHIELD,60" RTRY 6T1024H5 SPINDLE 21993 LOCKWASHER,3/4",GR 8 6T2413 HEX NUT,3/4",NF,GR 8 06400690 BAR,BLADE,60” RTRY 33764 FLATWASHER,5/8",GR 8,SAE 6T2259 CAPSCREW,5/8" X 1-3/4",NF,GR 8 06538000 KNIFE MTG BOLT,5/8" SHOULDER 06521001 KNIFE,TRB50,5/8” 06533002 FLATWASHER,1-1/8",GR 8 6T1023R...
Page 215: In Rotary Knife And Dish Option
Continued... ITEM PART NO. QTY. DESCRIPTION 34876 BLADE MOUNTING DISK 6T1023R NYLOCK NUT,1-1/8” 34878 SPACER 34497 KNIFE MOUNTING BOLT 34684 GRASS KNIFE 33764 FLATWASHER 6T2259 CAPSCREW 27167 BOLT KIT (INCLUDES ITEMS 6 & 7) ---- 6T1825 LOCTITE - USED ON ALL DISK MOUNTING BOLTS 33893 KNIFE KIT (INCLUDES ITEMS 2, 4 &...
Page 217 Continued... ITEM PART NO. QTY. DESCRIPTION 33219 SPINDLE ASSY,ROTARY 34480 TAPERLOCK SPROCKET 21530 CAPSCREW,1/4” X 1”,NC 6T1015 BEARING LOCK NUT,THIN 22596 JAMWASHER 6T1014 BEARING ADJUST SLEEVE 6T1011 UPPER SEAL,SMALL 6T1012 BEARING CONE,SMALL 6T1013 BEARING CUP,SMALL 6T3210 GREASE ZERK 32953 SPINDLE HOUSING,SABER 33200 BEARING CUP,LARGE 33199...
Page 219 Continued... ITEM PART NO. QTY. DESCRIPTION 6T1024H5 SPINDLE ASSEMBLY 6T1031 SPROCKET 6T1016 BEARING LOCK NUT,THICK 22596 JAM WASHER 6T1015 BEARING ADJUSTMENT NUT,THIN 6T1014 BEARING ADJUSTMENT SLEEVE 6T1011 UPPER SEAL (SET OF 2) 6T1012 BEARING CONE 6T1013 BEARING CUP 6T1010H SPINDLE HOUSING 30570 FITTING,STREET ELBOW 33990...
Page 220: In X 17-1/2In Welded Cylinder Breakdown
3IN X 17-1/2IN WELDED CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION 33705 CYLINDER,WELDED,3" X 17-1/2" 34571 PISTON ROD ASSY 34572 BUTT & TUBE ASSY 34573 PISTON 34574 GLAND 34575 LOCK NUT,1"-14 UNS (TORQUE TO 315 FT.LB.) 34576 SPACER 34577 CHECK VALVE,KEPNER 34578 ORIFICE 33761...
Page 221: In X 15In Welded Cylinder Breakdown
ITEM PART NO. QTY. DESCRIPTION 32365 CYLINDER,WELDED,4" X 15" 34580 PISTON ROD ASSY 34581 BUTT & TUBE ASSY 34582 PISTON 34583 GLAND 34584 LOCK NUT,1-1/4"-12 UNF (TORQUE TO 510 FT.LB.) 33757 SEAL KIT,PACKING (ITEMS 12 THRU 19) ------ GREASE ZERK ------ O - RING ------...
Page 222 4-1/2IN X 26-1/2IN WELDED CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION 32364 CYLINDER,WELDED,4-1/2" X 26-1/2" 34586 PISTON ROD ASSY 34587 BUTT & TUBE ASSY 34588 PISTON 34589 GLAND 34590 LOCK NUT,1-1/4"-12 UNF (TORQUE TO 510 FT.LB.) 33758 SEAL KIT,PACKING (ITEMS 12 THRU 19) ------ GREASE ZERK ------...
Page 223: In X 25In Welded Cylinder Breakdown
ITEM PART NO. QTY. DESCRIPTION 32363 CYLINDER,WELDED,5" X 25" 34592 PISTON ROD ASSY 34593 BUTT & TUBE ASSY 34594 PISTON 34595 GLAND 34596 LOCK NUT,1-3/4"-12 UNF (TORQUE TO 1800 - 2000 FT.LB.) 34597 CHECK VALVE,KEPNER 34598 ORIFICE 33759 SEAL KIT,PACKING (ITEMS 12 THRU 19) ------ GREASE ZERK ------...
Page 224: Pump And Grill Guard Options
ITEM PART NO. QTY. DESCRIPTION 32430 UNIVERSAL PUMP GUARD 32737 UNIVERSAL GRILL GUARD 21833 CAPSCREW,3/4" X 2-1/4",NC 22021 FLATWASHER,3/4" 21993 LOCKWASHER,3/4" 21825 HEX NUT,3/4",NC COMMON SABER ©2011 Alamo Group Inc. PUMP AND GRILL GUARD OPTIONS Parts Section 6-46...
Page 225: Reservoir Tank Filter Assembly
ITEM PART NO. QTY. DESCRIPTION ------ 06505044 FILTER ASSY SAE 10 MICRON 28583 CAPSCREW,8MM X 25MM(1.25 PITCH) 06505045 COVER 06505046 SEAL KIT 06505047 SPRING 06505048 BYPASS 35259 FILTER,10 MIC,RETURN LINE 06505049 CAN/BODY COMMON SABER ©2011 Alamo Group Inc. RESERVOIR TANK FILTER ASSEMBLY Parts Section 6-47...
Page 227: Front Hydraulic Pump
Continued... ITEM PART NO. QTY. DESCRIPTION 23152 PUMP ASSEMBLY,1-3/4”,COMPLETE 22766 SHAFT END COVER 22779 PORT END COVER 22774 GEAR HOUSING,1-3/4” 22771 GEAR SET 23824 CAPSCREW 06504078 SCREW,DRIVE 22773 DOWEL PINS 06504077 NAMEPLATE 02965611 THRUST PLATE 22767 PLUG 06504075 SEAL,BK-UP 06504074 SEAL,CHAN 22765 SEAL,LIP...
Page 229: In And 63In Flail Motor Breakdown
Continued... ITEM PART NO. QTY. DESCRIPTION ------ 06504013 MOTOR ASSEMBLY 350 06504039 SHAFT END COVER 06504040 PORT END COVER 06504041 GEAR HOUSING 06504042 MATCHED GEAR SET TF4402 BALL BEARING 06504043 CAP SCREW 06504044 SET SCREW 06504028 06504045 DOWEL PIN ------ NAMEPLATE 763759 THRUSTPLATE...
Page 231: In Flail Direct Drive Motor Breakdown
50IN FLAIL DIRECT DRIVE MOTOR BREAKDOWN Continued... ITEM PART NO. QTY. DESCRIPTION 06504003 MOTOR ASSEMBLY,DIRECT DRIVE 06504039 HOUSING,SEC 06504040 HOUSING,PEC 06504041 HOUSING,GEAR 06504117 GEAR,SET 06504118 SHAFT,CONTINENTAL TF4402 BRG,BALL 06504043 CAPSCREW 06504044 SCREW,DRIVE 06504045 PIN,DOWEL 06504077 NAME PLATE 763759 THRPL 02961940 PLUG,ODT 06504119 RING,SNAP...
Page 233: In And 60In Rotary Motor Breakdown
Continued... ITEM PART NO. QTY. DESCRIPTION 06504011 MOTOR ASSEMBLY,TRB60 06504012 MOTOR ASSEMBLY,TRB50 22790 HOUSING, SEC 06504088 HOUSING, PEC 06504062 HOUSING, GEAR,TRB60 ------ 06504089 HOUSING, GEAR,TRB50 06504090 SET, GEAR SHAFT 06504104 CAP SCREW,TRB60 ------ 06504091 CAP SCREW,TRB50 06504078 SCREW, DRIVE 06504092 06504093 PIN, DOWEL 06504094...
Page 235: Cooler Assembly
Continued... ITEM PART NO. QTY. DESCRIPTION 21530 CAPSCREW,1/4 X1 NC 21986 LOCKWASHER,1/4 22014 FLATWASHER,1/4 35176 1/4 U-NUT 06370015 SCREEN,COOLER,FRNT 06380006 MNT,COOLER,BUMPER TANK,RH 06380007 MNT,COOLER,BUMPER TANK,LH 06510026 COOLER,FRONT MNT 21629 CAPSCREW,3/8 X 3/4 NC 21988 LOCKWASHER,3/8 22016 FLATWASHER,3/8 34117 ELBOW,1MOR X 1MJ90,FORGED COMMON SABER ©2011 Alamo Group Inc.
Page 237: Cable (Manual) Lift Valve, 4 Spool
CABLE (MANUAL) LIFT VALVE, 4 SPOOL - 06502104 Continued... ITEM PART NO. QTY. DESCRIPTION 06502104 VALVE,MANUAL,4 SPOOL,LOAD SENSE 31595 INLET END COVER 31594 END COVER, LOAD SENSE 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31600 VALVE SECTION (DOUBLE ACTING, DETENT-FLOAT) 31598...
Page 239: Cable (Manual) Lift Valve, 5 Spool
CABLE (MANUAL) LIFT VALVE, 5 SPOOL - 06502103 Continued... ITEM PART NO. QTY. DESCRIPTION 06502103 VALVE,MANUAL,5 SPOOL,LOAD SENSE 31595 INLET END COVER 31594 END COVER, LOAD SENSE 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31597 VALVE SECTION (DOUBLE ACTING, CENTER SPRING) 31598...
Page 240 ITEM PART NO. QTY. DESCRIPTION ------ 06502096 VLV,5SP,32PVG,SIDE STOW 06502074 END PLATE 06505013 END PLATE SEAL KIT ------ BONNET 06505042 BONNET SEAL KIT 42197 MAIN BOOM BONNET 42197 SECONDARY BOOM BONNET 42197 DECK ROLL BONNET 42197 BOOM SWIVEL BONNET 42197 DECK SHIELD BONNET COMMON SABER ©2011 Alamo Group Inc.
Page 241 Continued... ITEM PART NO. QTY. DESCRIPTION 34308 INLET SECTION 06505013 INLET SECTION SEAL KIT ------ ELECTRONIC ACCUATOR 06502101 MAIN BOOM ELECTRONIC ACCUATOR 06502101 SECONDARY BOOM ELECTRONIC ACCUATOR 06502100 DECK ROLL ELECTRONIC ACCUATOR 06502101 BOOM SWIVEL ELECTRONIC ACCUATOR 06502099 DECK SHIELD ELECTRONIC ACCUATOR 42202 TIE-BOLT KIT ------...
Page 242: Brake Valve Assembly
ITEM PART NO. QTY. DESCRIPTION 06510084 BRAKE VALVE, ASSY 34092 BRAKE VALVE, BLANK 34094 LOGIC ELEMENT 34090 RELIEF VALVE, 3500 PSI 06510095 METRI PAK COIL 34093 CARTRIDGE, 2 POSITION, 3 WAY (WITH NUT & WASHER) 34091 RELIEF VALVE, 2600 PSI COMMON SABER ©2011 Alamo Group Inc.
Page 244: Solenoid Switch Box And Wiring
ITEM PART NO. QTY. DESCRIPTION ------ SWITCH BOX RE37651 PLUG,AUX PWR 24204 FUSE HOLDER,IN-LINE (OPTION) 6T3965 FUSE,3AMP (OPTION) 6T3934 TEMPERATURE GAUGE (OPTION) 6T3931 TEMPERATURE SENSOR (OPTION) COMMON SABER ©2011 Alamo Group Inc. SOLENOID SWITCH BOX AND WIRING Parts Section 6-66...
Page 245: Manual Lift Valve Switch Box
ITEM PART NO. QTY. DESCRIPTION 06514012 SWBX,ALUM,BLK,06510100 35226 SWITCH,MOWER,COLEHERSEE 33811 SWITCH,MASTER/DECK FLOAT 34532 SWITCH,TRVL LCK 06514014 BREAKER,10A,SWBX 6T3923 INDICTATOR LIGHT,ON,RED 34540 STRAIN RELIEF,3/4,BLACK,NYLON 06550019 DECAL,SWTCHBX,BOOM,CG 02964063 KNOB,RED 35227 RELAY,DP,DT,12V,LY2F,35226 COMMON SABER ©2011 Alamo Group Inc. MANUAL LIFT VALVE SWITCH BOX Parts Section 6-67...
Page 246: Manual Lift Valve Schematic
MANUAL LIFT VALVE SCHEMATIC COMMON SABER ©2011 Alamo Group Inc. Parts Section 6-68...
Page 247: Electronic Lift Valve Switch Box
ITEM PART NO. QTY. DESCRIPTION 06510196 SWBX,ASSY 33811 SWITCH,MASTER/DECK FLOAT 33813 SWITCH,SFTY SHIELD 34532 SWITCH,TRVL LCK 34540 STRAIN RELIEF,3/4",BLACK,NYLON 6T3923 INDICTATOR LIGHT,ON,RED 06514006 BREAKER,15A,SWBX 06550044 DECAL,SWBX,06510047 35226 SWITCH,MOWER,COLEHERSEE 02964063 KNOB,RED 35227 RELAY,DP,DT,12V,LY2F,35226 COMMON SABER ©2011 Alamo Group Inc. ELECTRONIC LIFT VALVE SWITCH BOX Parts Section 6-69...
Page 251: Troubleshooting - Continued
TROUBLESHOOTING - CONTINUED COMMON SABER ©2011 Alamo Group Inc. Parts Section 6-73...
Page 260: Clean Cutter Blade And Teeth Parts
ITEM PART NO. QTY. DESCRIPTION 06420025 ADAPTER,SAW,SABER,RNFRCD 06520224 BLADE, 48” SAW WITH TEETH 06420038 COLLAR,SAW,SABER 33380 FLATWASHER,3/4",GR8,SAE 06530210 CAPSCREW,5/8" X 3-3/4",NF,GR 8 06520225 TOOTH WITH RIVET, SAW BLADE 34703 TOOTH RIVET, SAW BLADE 34704 RIVET REMOVER TOOL (NOT SHOWN) 34702 TOOTH TIP, SAW, CARBIDE 34705 SHARPENING TOOL (NOT SHOWN)
Page 265 Continued... ITEM PART NO. QTY. DESCRIPTION 06520357 TANK,FIRE SUPRESS SYS,RAILKUT 06520358 MNT,TANK,FIRE KIT,RAILKUT 06520359 PUMP,FIRE SUPRESS SYS,RAILKUT 6T2181 CAPSCREW,SKT HD,10/24 X 3/4 24890 HEX NUT,10-24 NYLOCK 06520360 HOSE REEL,FIRE KIT,RAILKUT 21630 CAPSCREW, 3/8 X 1,NC 21627 NYLOCK NUT,3/8",NC 06520361 FILTER,FIRE KIT,RAILKUT ------ 06520365 FILTER ELEMENT (AVAILABLE)
Page 268: Wetcut 50 Gallon Tank Mount
ITEM PART NO. QTY. DESCRIPTION 06370128 MNT,3PNT,UNI 06370136 MNT,TANK,50GAL,WETCUT 06520342 TANK,50GA.,WETCUT RD1032 PIN,LYNCH 1/4" X 2" TB1036 PIN,SEC BOOM SWIV 1X4-11/16" 06520343 ANCHOR,STRAP,WETCUT 06520344 BOLT,STRAP,TANK,WETCUT 06520345 STRAP,TANK,WETCUT COMMON SABER ©2011 Alamo Group Inc. WETCUT 50 GALLON TANK MOUNT Parts Section 6-90...
Page 269: Wetcut 100 Or 150 Gallon Tank Mount
ITEM PART NO. QTY. DESCRIPTION 06370128 MNT,3PNT,UNI 06370138 MNT,TANK,100GAL,WETCUT ------ 06370139 MNT,TANK,150GAL,WETCUT 06520372 TANK,100GA.,WETCUT ------ 06520373 TANK,150GA.,WETCUT 21527 HEX NUT,NYLOCK,1/4" NC 21530 CAPSCREW,1/4" X 1" NC RD1032 PIN,LYNCH 1/4" X 2" TB1036 PIN,SEC BOOM SWIV 1X4-11/16" 06520345 STRAP,TANK,WETCUT 06520344 BOLT,STRAP,TANK,WETCUT 06520343 ANCHOR,STRAP,WETCUT COMMON SABER...
Page 271 Continued... ITEM PART NO. QTY. DESCRIPTION 06370128 MNT,3PNT,UNI 06520336 CNTRLR,SENSOR,06520333 06520341 PUMP,WETCUT 06520346 FITTING,BULKHEAD,WETCUT 06520347 FITTING,ELBOW,WETCUT 06520348 VLV,BALL,WETCUT 06520349 FITTING,BARB,HOSE,WETCUT 06520352 FITTING,NIPPLE,1/2X3/8,WETCUT 06520353 FITTING,TEE,WETCUT 06520367 ELBOW,1/2MPX1/2BARB,POLY 06520361 FILTER,FIRE KIT,RAILKUT 06520400 QUIK CPLR,MALE,1/2,WETCUT 06520401 QUIK CPLR,FEM,1/2,WETCUT 27329 U-BOLT,1/4" X 1" X 2" 35176 U-NUT,1/4,3/4 TO CENTER 35091...
Page 273 Continued... ITEM PART NO. QTY. DESCRIPTION 06370105 HOOD,SPRAYER 06370106 HINGE,LH,SPRAYER 06370107 HINGE,RH,SPRAYER 06370108 HINGE,CNTR,SPRAYER 06410668 GUARD,SPRAYER,WETCUT 06410753 MNT,RH,WET CUT 06410754 MNT,LH,WET CUT 06410796 GUARD,HOSE,WETCUT 06420069 PIN,HINGE,WET CUT 06497003 TUBE,LG,SPRAYER 06499012 SKIRT,ANTI SPRAY,50 06499013 SKIRT,ANTI SPRAY,7 06520314 TUBE,CAP,SPRAYER 06520316 HOSE,SPRAYER 06520317 NOZZLE,SPRAYER 06520319 TIP,NOZZLE,SPRAYER...
Page 275 WARRANTY SECTION Warranty Section 7-1...
Page 277: Warranty Information
All Tiger obligation under this warranty shall be terminated if the equipment is modified or altered in ways not approved in writing by Tiger, if repair parts other than genuine Tiger repair parts have been used, or if the equipment has been subject to misuse, neglect, accident, improper maintenance or improper operation.
Page 278 . Common sense should play a large role in the operation of this machine. Since we at Tiger Corporation are constantly striving to improve out products, we reserve the right to change specifications or design at any time.
Page 279 TO THE OWNER / OPERATOR / DEALER To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this manual and on the machine. The table of contents clearly identifies each section where you can easily find the information you need. The Occupational Safety and Health Act (OSHA 1928.51 subpart C) makes the following minimum requirements for tractor operators.

This manual is also suitable for:

Saber mower

Tiger NEW HOLLAND T6000 Mounting And Operating Instructions

Table of Contents

Section 1

Section 2

Quick Links

Chapters

Troubleshooting

Related Manuals for Tiger NEW HOLLAND T6000

Summary of Contents for Tiger NEW HOLLAND T6000

This manual is also suitable for:

Table of Contents
