5 . 1 3 . 4
REPLACEMENT
Place the diskette drive in the housing and s l ide it into position.
1 .
Secure the diskette drive to the housing with the two screws .
2 .
Figure 5 - 23 .
3 .
both diskette drives were removed , repeat Steps
I f
s econd diskette driv e .
Notch
Power Supply
Power Supply
Cover
Cover Mounting
(4)
Screws
Figure 5 - 24 .
5-!" Diskette Drive Connections
4 .
Reconnect the power connector , ground c l ip , and r ibbon connector to
the rear of the diskette drive . Make sure the connectors to the other
diskette drive are also attached.
5 .
Place the cover on the diskette drive assembly .
with the four screws . See Figure 5 - 23 .
Ribbon Connectors
See Figure 5 - 2 4 .
Removal and Repl acement Procedures 5 - 3 6
See
1
and 2 for the
Power Supply
Circuit Board
AC Power Input
Connector At This
Location-Far Side
Ground Wire And
Screw At This
Location-Far Side
Secure the cover
