  • Page 1: User Guide

    ™ ThinkCentre User Guide Types 9212 and 9213...
  • Page 3 ™ ThinkCentre User Guide Types 9212 and 9213...
  • Page 4 Before using this information and the product it supports, be sure to read the “Important safety information” on page v and Appendix D, “Notices,” on page 43. Second Edition (April 2005) © Copyright International Business Machines Corporation 2005. All rights reserved. US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.

  • Page 5: Table Of Contents

    . 44 Identifying security locks . . 22 Integrated cable lock . . 23 Index ....45 Padlock . . 24 © Copyright IBM Corp. 2005...
  • Page 6 User Guide...

  • Page 7: Important Safety Information

    Follow and retain all information included with your IBM computer. The information in this document does not alter the terms of your purchase agreement or the IBM Statement of Limited Warranty. Customer safety is important to IBM. Our products are developed to be safe and effective.

  • Page 8: General Safety Guidelines

    Always observe the following precautions to reduce the risk of injury and property damage. Service Do not attempt to service a product yourself unless instructed to do so by the IBM Support Center. Use only an IBM authorized service provider who is approved to repair your particular product.

  • Page 9: Extension Cords And Related Devices

    In addition many mobile products such as Thinkpad notebook PCs utilize a rechargeable battery pack to provide system power when in portable mode. Batteries supplied by IBM for use with your product have been tested for compatibility and should only be replaced with IBM approved parts.

  • Page 10: Heat And Product Ventilation

    Battery abuse or mishandling can cause the battery to overheat, which can cause gasses or flame to “vent” from the battery pack or coin cell. If your battery is damaged, or if you notice any discharge from your battery or the buildup of foreign materials on the battery leads, stop using the battery and obtain a replacement from the battery manufacturer.

  • Page 11: Additional Safety Information

    CAUTION: Danger of explosion if battery is incorrectly replaced. When replacing the battery, use only IBM Part Number 33F8354 or an equivalent type battery recommended by the manufacturer. The battery contains lithium and can explode if not properly used, handled, or disposed of.

  • Page 12: Laser Compliance Statement

    Do not use the telephone to report a gas leak in the vicinity of the leak. Laser compliance statement Some IBM Personal Computer models are equipped from the factory with a CD-ROM drive or a DVD-ROM drive. CD-ROM drives and DVD-ROM drives are also sold separately as options.
  • Page 13 Hazardous voltage, current, and energy levels are present inside any component that has this label attached. There are no serviceable parts inside these components. If you suspect a problem with one of these parts, contact a service technician. Important safety information...
  • Page 14 User Guide...

  • Page 15: Overview

    It also includes basic troubleshooting information, software recovery procedures, help and service information, and warranty information. Access IBM, on your desktop, provides a link to more information about your computer. If you have Internet access, the most up-to-date information for your computer is available from the World Wide Web.
  • Page 16 User Guide...

  • Page 17: Chapter 1. Installing Options

    Before you install or remove any option, read “Important safety information” on page v. These precautions and guidelines will help you work safely. Note: Use only the parts provided by IBM. Features This section provides an overview of the computer features and preinstalled software.
  • Page 18 Memory v Support for four double data rate dual inline memory modules (DIMMs) v 512 KB flash memory for system programs Internal drives v 3.5-inch, slim, 1.44 MB diskette drive v Serial Advanced Technology Attachment (SATA) internal hard disk drive v Optical drive (some models) Video subsystem v An integrated graphics controller for a Video Graphics Array (VGA) monitor...
  • Page 19 Expansion v Five drive bays v Two standard peripheral component interconnect (PCI) adapter connectors v One PCI Express x1 adapter connector v One PCI Express x16 graphics adapter connector (some models) Power v 310 W power supply with manual voltage selection switch v Automatic 50/60 Hz input frequency switching v Advanced Power Management support v Advanced Configuration and Power Interface (ACPI) support...

  • Page 20: Available Options

    You can also obtain information by calling the following telephone numbers: v Within the United States, call 1-800-IBM-2YOU (1-800-426-2968), your reseller, or marketing representative. v Within Canada, call 1-800-565-3344 or 1-800-IBM-4YOU. v Outside the United States and Canada, contact your reseller or marketing representative.

  • Page 21: Specifications

    Specifications This section lists the physical specifications for your computer. Dimensions Heat output (approximate) in British thermal units (Btu) per hour: Height: 492 mm (19.4 in.) Minimum configuration: 256 Btu/hr (75 watts) Width: 175 mm (6.9 in.) Maximum configuration: 1058 Btu/hr (310 watts) Depth: 450 mm (17.7 in.) Airflow Weight...

  • Page 22: Handling Static-Sensitive Devices

    Handling static-sensitive devices Static electricity, although harmless to you, can seriously damage computer components and options. When you add an option, do not open the static-protective package containing the option until you are instructed to do so. When you handle options and other computer components, take these precautions to avoid static electricity damage: v Limit your movement.

  • Page 23: Locating The Connectors On The Front Of Your Computer

    Locating the connectors on the front of your computer The following illustration shows the locations of the connectors on the front of the computer. Note: Not all computer models will have the following connectors. IEEE 1394 connector Microphone connector USB connector Headphone connector USB connector Chapter 1.

  • Page 24: Locating The Connectors On The Rear Of Your Computer

    Locating the connectors on the rear of your computer The following illustration shows the locations of the connectors on the rear of the computer. Diagnostic LEDs USB connectors Voltage selection switch Keyboard connector Power connector PCI Express x16 adapter connector (some models) Audio line in connector PCI adapter connector...

  • Page 25: Obtaining Device Drivers

    Category 5 Ethernet cable. Obtaining device drivers You can obtain device drivers for operating systems that are not preinstalled at http://www.ibm.com/pc/support/ on the World Wide Web. Installation instructions are provided in README files with the device-driver files. Chapter 1. Installing options...

  • Page 26: Removing The Cover

    Removing the cover Important Read “Important safety information” on page v and “Handling static-sensitive devices” on page 6 before removing the computer cover. To remove the computer cover: 1. Shut down your operating system, remove any media (diskettes, CDs, or tapes) from the drives, and turn off all attached devices and the computer.

  • Page 27: Locating Components

    Locating components The following illustration will help you locate the various components in your computer. Optical drive Optional PCI adapter Memory modules System board Power supply Speaker Hard disk drive Diskette drive PCI adapter connector Identifying parts on the system board The system board (sometimes called the planar or motherboard) is the main circuit board in your computer.

  • Page 28: Installing Memory Modules

    The following illustration shows the locations of parts on the system board. Speaker connector PCI adapter connector 1 Memory connector 4 PCI adapter connector 2 Memory connector 3 Serial connector 2 Memory connector 2 PCI Express x1 adapter connector Memory connector 1 Clear CMOS/Recovery jumper Front panel connector Battery...

  • Page 29: Installing Adapters

    2. Locate the memory connectors. See “Identifying parts on the system board” on page 11. 3. Open the retaining clips. 4. Position the memory module over the memory connector. Make sure that the notch 1 on the memory module aligns correctly with the connector key 2 on the system board.
  • Page 30 2. Push the blue adapter latch as shown and pivot it to the open position. 3. Remove the connector cover from the appropriate expansion connector. 4. Remove the adapter from its static-protective package. 5. Install the adapter into the appropriate connector on the system board. 6.

  • Page 31: Installing Internal Drives

    Installing internal drives This section provides information and instructions for installing and removing internal drives. Internal drives are devices that your computer uses to read and store data. You can add drives to your computer to increase storage capacity and to enable your computer to read other types of media.
  • Page 32 5 Bay 5 - Maximum height: 25.8 mm (1.0 in.) 3.5-inch SATA hard disk drive (preinstalled) * You can obtain a Universal Adapter Bracket, 5.25 to 3.5-inch from a local computer retailer or by contacting the IBM Support Center. User Guide...

  • Page 33: Installing A Drive In Bay 1 Or Bay 2

    Note: If you are installing a 3.5-inch hard disk drive you must use a Universal Adapter Bracket, 5.25 to 3.5-inch. You can obtain this bracket from a local computer retailer or by contacting the IBM Support Center. 5. PATA drives must be jumpered as either a master or a slave device. SATA hard disk drives do not require either a master or a slave device jumper.

  • Page 34: Installing A Hard Disk Drive In Bay 3

    v If you are installing an additional optical drive, set it as a slave device. v If there is a combination of optical and parallel ATA hard disk drives in bays 1 and 2, set the hard disk drive as a master device and the optical drive as a slave device.
  • Page 35 2. Remove the front bezel by pushing the blue release button as shown. 3. Remove the metal shield from drive bay 3 by using a flat-blade screwdriver to gently pry it loose. 4. PATA drives must be jumpered as either a master or a slave device. SATA hard disk drives do not require either a master or a slave device jumper.

  • Page 36: Connecting Drives

    7. Install the drive into the bay until it snaps into position. 8. Continue at “Connecting drives.” Connecting drives The steps to connect a drive are different depending on the type of drive you are installing. Use one of the following procedures for your drive connection. Connecting the first optical drive 1.

  • Page 37: Connecting A Serial Ata Hard Disk Drive

    2. Connect the extra connector in the signal cable to the new drive. 3. Locate the extra four-wire power connector and connect it to the drive. Connecting a serial ATA hard disk drive A serial hard disk drive can be connected to any available SATA IDE connector. 1.

  • Page 38: Identifying Security Locks

    Identifying security locks The following illustration shows the locations of the security locks on the rear of the computer. Padlock loop Integrated cable lock User Guide...

  • Page 39: Integrated Cable Lock

    This is the same type of lock used with many laptop computers. You can order a cable lock directly from http://www.ibm.com/pc/support/ and search on Kensington. Chapter 1. Installing options...

  • Page 40: Padlock

    Padlock Your computer is equipped with a padlock loop such that the cover cannot be removed when a padlock is installed. Password protection To deter unauthorized use of your computer, you can use the Setup Utility program to set passwords. See “Using passwords” on page 27. What to do next v To work with another option, go to the appropriate section.

  • Page 41: Erasing A Lost Or Forgotten Password (Clearing Cmos)

    Erasing a lost or forgotten password (clearing CMOS) This section applies to lost or forgotten passwords. For more information about lost or forgotten passwords, see Access IBM on your desktop. To erase a forgotten password: 1. Turn off the computer and all attached devices.

  • Page 42: Replacing The Cover And Connecting The Cables

    6. Replace the computer cover and connect the power cord. See “Replacing the cover and connecting the cables.” 7. Restart the computer, leave it on for approximately 10 seconds. Turn off the computer by holding the power switch for approximately 5 seconds. The computer will turn off.

  • Page 43: Chapter 2. Using The Setup Utility Program

    Administrator Password Setting an Administrator Password deters unauthorized persons from changing configuration settings. If you are responsible for maintaining the settings of several computers, you might want to set an Administrator Password. © Copyright IBM Corp. 2005...

  • Page 44: Setting, Changing, And Deleting A Password

    After you set an Administrator Password, a password prompt is displayed each time you try to access the Setup Utility program. If you type the wrong password, you will see an error message. If you type the wrong password three times, you must turn the computer off and start again.

  • Page 45: Changing The Startup Sequence

    1. Turn off your computer. 2. Press and hold the F12 key then turn on the computer. When the Startup Device Menu appears, release the F12 key. Note: If you are using a USB keyboard and the Startup Device Menu does not display using this method, press and release the F12 key repeatedly rather than leaving it pressed when turning on the computer.
  • Page 46 User Guide...

  • Page 47: Appendix A. Updating System Programs

    8. Follow the instructions on the screen to complete the update. Updating (flashing) BIOS from your operating system Note: Due to constant improvements being made to the IBM Web site, Web page content (including the links referenced in the following procedure) is subject to change.

  • Page 48: Recovering From A Post/Bios Update Failure

    2. Locate the Downloadable files for your machine type. 3. Under Select your product, choose your machine type and click Go. 4. In Downloadable file by category, click BIOS. 5. Under Download files - BIOS by date, click your machine type. 6.

  • Page 49: Appendix B. Cleaning The Mouse

    To clean a mouse with a ball: 1. Turn off your computer. 2. Turn the mouse over, with the top side down, and look carefully at the bottom. Twist the retainer ring 1 to the unlocked position to remove the ball. © Copyright IBM Corp. 2005...
  • Page 50 3. Place your hand over the retainer ring and ball 2 , and then turn the mouse over, top side up, so that the retainer ring and ball fall out into your hand. 4. Wash the ball in warm, soapy water then dry it with a clean cloth. Blow air carefully into the ball cage 4 to dislodge dust and lint.

  • Page 51: Appendix C. Manual Modem Commands

    Dial one of the four telephone numbers (n=0-3) stored in the modem non-volatile memory. Commands are not echoed Commands are echoed Escape Characters - Switch from Data Mode to Command Mode (T.I.E.S. Command) Force modem on-hook (hang up) © Copyright IBM Corp. 2005...
  • Page 52 Command Function Force modem off-hook (make busy) Note: H1 command is not supported for Italy Display product-identification code Factory ROM checksum test Internal memory test Firmware ID Reserved ID Low speaker volume Low speaker volume Medium speaker volume High speaker volume Internal speaker off Internal speaker on until carrier detected Internal speaker always on...

  • Page 53: Extended At Commands

    Extended AT commands Command Function &C_ &C0 Force Carrier Detect Signal High (ON) &C1 Turn on CD when remote carrier is present &D0 &D_ Modem ignores the DTR signal &D1 Modem returns to Command Mode after DTR toggle &D2 Modem hangs up, returns to the Command Mode after DTR toggle &D3 Resets modem after DTR toggle...

  • Page 54: Mnp/V.42/V.42Bis/V.44 Commands

    Command Function &V1 Display Last Connection Statistics &W_ &W0 Stores the active profile as Profile 0 &W1 Stores the active profile as Profile 1 Disable auto-retrain Enable auto-retrain +MS? Displays the current Select Modulation settings +MS=? Displays a list of supported Select Modulation options +MS=a,b,c,e,f Select modulation where: a=0, 1, 2, 3, 9, 10, 11,...

  • Page 55: Fax Class 1 Commands

    Fax Class 1 commands +FAE=n Data/Fax Auto Answer +FCLASS=n Service Class +FRH=n Receive data with HDLC framing Receive data +FRM=n +FRS=n Receive silence +FTH=n Transmit data with HDLC framing +FTM=n Transmit data +FTS=n Stop transmission and wait Fax Class 2 commands +FCLASS=n Services class.

  • Page 56: Voice Commands

    +FPHCTO Phase C time out. +FPOLL Indicates polling request. +FPTS: Page transfer status. +FPTS= Page transfer status. +FREV? Identify revision. +FSPT Enable polling. +FTSI: Report the transmit station ID. Voice commands Select Baud Rate #BDR #CID Enable Caller ID detection and reporting format Select Data, Fax or Voice/Audio #CLS #MDL?
  • Page 57 Attention Switzerland User: If your Swisscom phone line does not have Taxsignal switched OFF, modem function may be impaired. The impairment may be resolved by a filter with the following specifications: Telekom PTT SCR-BE Taximpulssperrfilter-12kHz PTT Art. 444.112.7 Bakom 93.0291.Z.N Appendix C.
  • Page 58 User Guide...

  • Page 59: Appendix D. Notices

    Web sites. The materials at those Web sites are not part of the materials for this IBM product, and use of those Web sites is at your own risk.

  • Page 60: Television Output Notice

    vary significantly. Some measurements may have been made on development-level systems and there is no guarantee that these measurements will be the same on generally available systems. Furthermore, some measurements may have been estimated through extrapolation. Actual results may vary. Users of this document should verify the applicable data for their specific environment.

  • Page 61: Index

    12 information resources xiii input/output (I/O) features 2 installing options recovering from a POST/BIOS update failure 32 adapters 13 removing the cover 10 external 6 replacing the cover 26 memory modules 12 security features 21 © Copyright IBM Corp. 2005...
  • Page 62 safety information v SATA connectors 12 security features 3, 21 integrated cable lock 23, 24 security profile by device 28 serial connector 9 Setup Utility 27 system board connectors 12 identifying parts 11 location 12 memory 4, 12 system programs 31 USB connectors 9 using passwords 27...
  • Page 64 Part Number: 39J7678 Printed in USA (1P) P/N: 39J7678...
