List Boot Device Type - Contec IPC Series User Manual

◆List Boot Device Type

Configure the list boot devices.
Figure 4.23. Boot Configuration
Table 4.23. Boot Configuration
Field Name
Default Value /Blank/
Help
Comment
Field Name
Default Value
Help
Comment
In the Boot Option #x device list, the same device may be displayed as follows.
(1) USB Disk
(2) UEFI: USB Disk
In such cases, if (1) is selected, a legacy boot is performed under the assumption the disk is
MBR-formatted. If (2) is selected, a UEFI boot is performed under the assumption the disk is
GPT-formatted. Make sure to specify (1) as the boot setting. Booting with (2) will result in
non-support. Only devices set as the highest in individual settings like CD/DVD ROM Drive BBS
Priorities are listed as selectable under Boot Option #x.
66
Boot Option #1
Boot Device Name 1 of this type
Sets the system boot order
Boot Option #2
/Blank/
Boot Device Name 2 of this type
Sets the system boot order
PT-S2000HX/HXC/LX/LXC Series User's Manual
