◆PCH-IO Configuration

Configure the South Bridge settings.
Figure 4.16. PCH-IO Configuration
Table 4.16. PCH-IO Configuration
Field Name
Help
Comment
Field Name DeepSx Power Policies
Default Value [Disabled]
Enabled in S4-S5
Possible Value
Disabled
configure the DeepSx Mode configuration.
Help
Field Name Wake On LAN
Default Value [Enabled]
Enabled
Possible Value
Disabled
Help SEnabled/Disabled integrated LAN to wake the system.
Field Name State After G3
Default Value [S5 State]
Possible Value
Specify what state to go to when power is re-applied after a power
Help
failure (G3 state).
PT-S2000HX/HXC/LX/LXC Series User's Manual
HD Audio Configuration
HD Audio Subsystem Configuration Settings
Press Enter when selected to go into the associated Sub-Menu.
Enabled
Disabled
