2. System Reference

Specification

Table 2.1. Functional specification< 1 / 2 >
MODEL
PT-S2000HX/HXC-DC2xxx
PROCESSOR
CHIPSET Intel® SoC integrated
MEMORY DDR4 2133/2400, 260-pin SO-DIMM x 2, Max. 32 GB (Non-ECC)
GRAPHICS Intel® HD Graphics
ETHERNET Intel® I219LM Giga LAN + I211AT Giga LAN
AUDIO Realtek ALC283
I/O CHIPSET Nuvoton NCT6104D
TPM Nuvoton NPCT650ABCYX TPM2.0
Storage: PCI Express Full-Length Mini Card slot (USB / PCIe /SATA)
EXPANSION SLOT
Wireless: M.2 2230 E key (PCIe / USB)
BIOS AMI BIOS
H/W MONITOR Temperature Monitor, Voltage Monitor, Fan Monitor
WATCHDOG TIMER 1~255 Steps by Software Program
GRAPHICS
HDMI Up to 4096 x 2160 @24 Hz
DISPLAYPORT Up to 4096 x 2304 @60 Hz
LVDS (Internal) Up to 1920 x 1200 @60 Hz
REAR I/O
USB USB 3.0 x 4
DISPLAY I/O HDMI x 1, DP x 1
AUDIO I/O Audio jack (Line-out) x 1
GPIO PORT 8-bit General-purpose I/O
SERIAL PORT COM A RS232 & COM B RS232/422/485
LAN I/O Giga LAN X 2
POWER REQUIREMENT
Power header 4PIN
POWER INPUT
12~24VDC ±10%
OS
Windows ® 7 32/64bit, Windows ® 10 64bit,
OS SUPPORT
Linux (support by request)
PT-S2000HX/HXC/LX/LXC Series User's Manual
PT-S2000HX/HXC-DCxxxxxxx
PT-S2000HX/HXC-DC3xxx
xxx
Intel® Celeron 3955U Intel® Core i5-6300U
PT-S2000LX/LXC-DCxxxxxxx
PT-S2000LX/LXC-DC2xxx
xxx xxx
Intel® Celeron 3955U
PT-S2000LX/LXC-DC3xxx
xxx
Intel® Core i5-6300U
13
