◆Serial Port 2 (COM B)

Figure 4.8. Serial Port 2 Configuration
Table 4.9. Serial Port 2 Configuration
Field Name
Default Value
Possible Value
Help
Field Name
Default Value
Comment
Field Name
Default Value
Possible Value
Help
44
Serial Port
[Enabled]
Enabled
Disabled
Enable or Disable Serial Port (COM B)
Device Settings
Device Super IO COM2 Address and IRQ.
This field is not selectable. There is no help text associated with it.
Change Settings
[Auto]
Auto
IO=2E8h; IRQ=7;
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12;
IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12;
Select an optional settings for Super IO Device
