◆Serial Port 1 (COM A)

Figure 4.7. Serial Port 1 configuration
Table 4.8. Serial Port 1 Configuration
Field Name Serial Port
Default Value [Enabled]
Enabled
Possible Value
Disabled
Help Enable or Disable Serial Port (COM A)
Field Name Device Settings
Default Value Device Super IO COM A Address and IRQ.
Comment This field is not selectable. There is no help text associated with it.
Field Name Change Settings
Default Value [Auto]
Auto
IO=2F8h; IRQ=3;
IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12;
Possible Value
IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12;
Help Select an optional settings for Super IO Device
