As illustrated in the previous diagram, virtual workgroups allow
you to associate multiple ports and define a workgroup. In reality,
you are assigning workgroup IDs to SmartSTACK 100
ELS100-16TX ports.

1.6 LOCAL CONSOLE MANAGER

The Local Console Manager (LCM) is a command-line interface
built into the SmartSTACK 100 ELS100-16TX. The LCM enables
you to monitor, manage, and configure the SmartSTACK 100
ELS100-16TX through the out-of-band RS232C connection attached
to any non-intelligent terminal or workstation running terminal
emulation.
You can also use a Cabletron Systems Network Management
System, or a standard SNMP-based Network Management System,
to manage the SmartSTACK 100 ELS100-16TX. For a list of
available SmartSTACK 100 ELS100-16TX network management
tools, see Section 4.1, ELS100-16TX Management Tools.
The following sections describe LCM command syntax and the
basic LCM commands for logging in, logging out, and getting
help.
• LCM commands used for configuring the SmartSTACK 100
ELS100-16TX are described in Chapter 3, Configuring Your
ELS100-16TX.
• LCM commands used for monitoring and managing the
SmartSTACK 100 ELS100-16TX are described in Chapter 4,
Monitoring and Managing Your ELS100-16TX.
Note: The Getting Started with the SmartSTACK 100 ELS100-16TX
guide lists the available LCM commands, including each
command's options.
