Introduction
Figure 1-5 shows two Ethernet segments, A and B, that do not
include a SmartSTACK 100 ELS100-16TX.
Repeater
Traffic
Traffic B
A
Figure 1-5. Multiple Ethernet Segments Sharing 100 Mbps Bandwidth
Each host on segments A and B is limited to sharing a network
bandwidth of 10 Mbps.
