3. Enter the new community name.

LCM prompts you to verify the new community name by

retyping it.

4. Retype the new community name.

4.5.5 Setting the Baud Rate

You can set the baud rate for your LCM console connection. The

options for baud rate include:

• 1200

• 2400

• 4800

• 9600

• 19200

The default rate is 9600.

Note: Make sure that the baud rate you set matches the baud rate setting

for the terminal you are using.

To display the current baud rate setting, at the LCM prompt:

1. Type

baud

LCM responds:

Usage: baud [1200|2400|4800|9600|19200]

Monitoring and Managing Your ELS100-16TX

Baud rate is 4800.

4-13
