To check the status for ports configured for mirroring:
1. Type
status <PORT>
The display could look like the following:
ELS100-16 > status 1
Type/Speed:
Port Mirroring:
Duplex Mode:
Bridging:
Enabled/Disabled:
Spanning Tree:
Trunking State:
Pkts Transmitted:
Pkts Received:
Carrier Losses:
Total Collisions:
Excess Collisions:
RX Missed pkts:
RX Runt pkts:
RX FCS/Align Errs:
Internal TX Errs:
Type <CR> to display port 2 status...>
The following conditions can be displayed:
• Rx only — mirroring is enabled, but mirroring only packets
received by the port.
• Tx only — mirroring is enabled, but mirroring only packets
transmitted by the port.
• Rx and Tx — mirroring is enabled, mirroring both transmit and

receive packets.

• No — mirroring is not enabled.
Port 1 Status
Configuring Your ELS100-16TX
100B-TX/100Mbits
No
Half Duplex
Transparent Bridging
Enabled, Rip listening
Forwarding
Off
1693
0
1693
0
0
0
0
0
0
