Cabletron Systems SMALL OFFICE CyberSwitch 150 Manual

Remote access switch example networks release 7.2
Hide thumbs Also See for SMALL OFFICE CyberSwitch 150:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Cabletron Systems
(603) 332-9400 phone
(603) 337-3075 fax
support@ctron.com
R
EMOTE
E
XAMPLE
S
O
MALL
FFICE
A
S
CCESS
WITCH
N
ETWORKS
Release 7.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMALL OFFICE CyberSwitch 150 and is the answer not in the manual?

Questions and answers

Related Manuals for Cabletron Systems SMALL OFFICE CyberSwitch 150

Summary of Contents for Cabletron Systems SMALL OFFICE CyberSwitch 150

  • Page 1 Cabletron Systems (603) 332-9400 phone (603) 337-3075 fax support@ctron.com EMOTE XAMPLE MALL FFICE CCESS WITCH ETWORKS Release 7.2...
  • Page 2 You may post this document on a network server for public use as long as no modifications are made to the document. Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made.

  • Page 3: Fcc Notice

    All other product names mentioned in this manual are trademarks or registered trademarks of their respective companies. COPYRIGHTS All of the code for this product is copyrighted by Cabletron Systems, Inc. © Copyright 1991-1997 Cabletron Systems, Inc. All rights reserved. Printed in the United States of America.

  • Page 4: Doc Notice

    CABLETRON SYSTEMS, INC. PROGRAM LICENSE AGREEMENT IMPORTANT: Before utilizing this product, carefully read this License Agreement. This document is an agreement between you, the end user, and Cabletron Systems, Inc. ("Cabletron") that sets forth your rights and obligations with respect to the Cabletron software program (the "Program") contained in this package.

  • Page 5: Table Of Contents

    Overview Initial Installation Steps System Details Resources Lines Device Information Device Information Bridging and Routing Information Bridging IP Routing Configure the CyberSWITCH Configuring the CyberSWITCH Options Configuring the Security Save Configuration Files Verify the Installation Small Office Remote Access Switch...
  • Page 6 EXAMPLE NETWORKS IP Routing Network with Remote Bridge Devices Overview Business Assumptions Initial Installation Steps Resources Lines Device Information Bridging and Routing Information Bridging IP Routing Configure the CyberSWITCH Configuring the CyberSWITCH Options Configuring the Security Verify the Installation IP Routing Network with PPP Devices Overview Initial Installation Steps System Details...
  • Page 7 Verify the Installation AppleTalk Routing Network Overview Initial Installation Steps Resources Lines AppleTalk Routing Configure the CyberSWITCH Configuring the Options Configuring Device Information Configuring an AppleTalk Static Route Save Configuration Files Verify the Installation Index Small Office Remote Access Switch...

  • Page 8: Example Networks

    XAMPLE ETWORKS We provide several example networks, beginning with a simple network and progressing to more complex networks. You may find the configuration instructions provided for each example helpful when configuring your own network. We include the following chapters: • Simple Remote Bridging Network An example of a simple network using remote bridge devices to access a CyberSWITCH’s four basic rate lines.

  • Page 9: Simple Remote Bridging Network

    IMPLE EMOTE VERVIEW This chapter provides an example of a simple network using remote bridge devices to access four basic rate lines in the CyberSWITCH. Bridges are formed between each of the LANs to which the remote bridge devices are connected, and the LAN to which the CyberSWITCH is connected. The following section provides the initial installation steps that would be used with any type of network installation.

  • Page 10: System Details

    Slot Port Line1 PRI Lines Name Slot V.35 and RS232 Lines Name CyberSWITCH YSTEM ETAILS PAP Password:_______________ CHAP Secret:___________________ Slot Switch type 5ESS Line type Call screen Auto Port Framing type Line coding Slot Port Device/Network Synchronization type SPID Directory number Sig.

  • Page 11: Bridging And Routing Information

    Name IP address Mask Name IP address Mask Name IP address 192.42.1.6 192.42.1.7 Mask IP address Mask Mask default? default? default? default? Small Office Remote Access Switch IMPLE EMOTE RIDGING ETWORK Bridging and Routing Information Next hop...

  • Page 12: Configure The Cyberswitch

    4) ISDN Subaddress Select function from above or <RET> for previous menu: You may only configure the switch type. The rest of the resource information may only be displayed. We will next add the line information. Press 2 at the Physical Resources Menu and press 1 to add a line.
  • Page 13 Select Option [default = POINT_TO_POINT] or press <RET> for previous menu: 1 The next item that you need to configure is the Data Link for the line. Depending on the switch type, there may be more than one Data Link per line. In our example, we use one Data Link with...
  • Page 14 EXAMPLE NETWORKS "SITE1" 192.42.1.0 Telnet Client The network illustrated above is a bridged network. Each system, SITE1 and SITE2 have been configured with all the necessary bridging information. SITE1 and SITE2 have also been configured in the IP host operating mode, and each have an IP host interface. This will allow each system to be managed remotely by the PC using Telnet client software (once the initial configuration has been completed).

  • Page 15: Save Configuration Files

    We have now configured all of the required information. Press 4 from the Main menu to save the changes and then press <RET> to exit. Reboot the system to activate your changes. IMPLE EMOTE RIDGING Bridging and Routing Information Small Office Remote Access Switch ETWORK...

  • Page 16: Verify The Installation

    EXAMPLE NETWORKS ERIFY THE NSTALLATION Steps on how to verify the installation are detailed in the System Verification chapter of the User’s Guide. This section gives an outline of which steps should be executed. On the CyberSWITCH: Verify resources are operational Issue dr command Look for BRI line messages Look for LAN initialized messages...

  • Page 17: Remote Bridging Network With Security

    EMOTE RIDGING VERVIEW This example network is a bridged network with Calling Line Id security and Bridge MAC Address security enabled. The network is configured with two devices. One device will be configured to require a Bridge MAC Address security password, and one device will not. This network uses BRI lines.

  • Page 18: Network Topology

    EXAMPLE NETWORKS 13135551212 13135552121 Bridge Ethernet Address: 000123456789 Password: JXF30 User Name: Mike Mann CyberSWITCH ETWORK OPOLOGY File Server CSX150 Hunt Group Number: 13135551111 13135551112 ISDN User Name: Pat Smith 13135551111 13135556789 13135559876 Bridge Ethernet Address: 003456789000 Password: None...

  • Page 19: Resources

    * Hunt Group Number: 13135551111 EMOTE YSTEM ETAILS PAP Password:_______________ CHAP Secret:___________________ Slot Switch type NI-1 Line type Call screen Auto Small Office Remote Access Switch RIDGING ETWORK WITH ECURITY Initial Installation Steps Synchronization type SPID Directory number 3135551111 13135551111* 3135551112...

  • Page 20: Device Information

    EXAMPLE NETWORKS Device Name: Mike Mann Calling (ISDN, FR, etc.) Information Line Protocol HDLC bridge Base Data Rate Initial Data Rate Max Data Rate Dial-Out Number(s) Authentication Information : PAP Password CHAP Secret IP Host ID Bridge Ethernet Address* 000123456789 Bridge Password* CLID(s) 13135551212...
  • Page 21 Make calls for IP data? AppleTalk disabled AppleTalk enabled? disabled AppleTalk Address disabled Make calls for AT data? AT Routing Protocol Small Office Remote Access Switch ETWORK WITH ECURITY Device Information enabled disabled 0.0.0.0 if unnumbered link enabled disabled enabled...

  • Page 22: Bridging And Routing Information

    EXAMPLE NETWORKS RIDGING AND RIDGING Bridging Mode of Operation Bridge Filters Bridge Dial Out/ Known Connect List IP R OUTING IP Routing Mode of Operation Network Interface Information Unnumbered WAN Remote LAN Traditional WAN Direct Host WAN IP Host Mode Static Routes Destination network address CyberSWITCH...

  • Page 23: Configure The Cyberswitch

    Repeat “Select to add a line” for each additional line Data links are handled differently on a NI-1 switch. Some BRI lines have only one phone number (for the Data Link), but can handle two calls (one for each bearer channel). For NI-1 switches, the BRI line has two phone numbers (one for each bearer channel), and each phone number has its own SPID.

  • Page 24: Configuring The Security

    EXAMPLE NETWORKS ONFIGURING THE ECURITY This network has remote devices, and the device information for each of those devices must be configured. Device security is used, and the remote devices are configured in the on-node authentication database. Device security using a on-node authentication database are the default values.
  • Page 25 "0" to disable ISDN access for this device [default = 1]? 2 EMOTE RIDGING "PPP (Point to Point Protocol)" "64000 bps" "64000 bps" "128000 bps" "" "" "Default_Profile" ENABLED Small Office Remote Access Switch ETWORK WITH ECURITY Configure the CyberSWITCH...
  • Page 26 EXAMPLE NETWORKS The only other item on the Device ISDN Line Protocol Menu that this type of device needs is the maximum data rate. We will accept the default value of 128,000 bps. No changes are required. Return to the Device Table Menu. At the Device Table Menu, press 4 to enter the authentication information needed for this device.

  • Page 27: Save Configuration Files

    On each HDLC Bridge LAN: Attempt accessing a resource on the CyberSWITCH LAN. This may require that you reboot your system and proceed through the logon sequence. EMOTE RIDGING ETWORK WITH Verify the Installation Small Office Remote Access Switch ECURITY...

  • Page 28: Ip Routing Network

    IP R OUTING ETWORK VERVIEW This sample network has an IP network with devices accessing the network from their homes. NITIAL NSTALLATION The initial steps in the CyberSWITCH installation process are basically the same no matter how complicated the network. These steps are: •...
  • Page 29 San Fran Host Host 192.1.1.2 Rick Bear 192.1.1.3 Victoria Moose IP R Initial Installation Steps LAN 131.1.0.0 Router 1 131.1.1.16 128.1.1.16 128.1.1.1 WAN Interface 192.1.1.1 ISDN Host Host 128.1.1.3 Todd Jones 128.1.1.2 Jill Smith Small Office Remote Access Switch OUTING ETWORK...

  • Page 30: System Details

    EXAMPLE NETWORKS System Name: IP Network ESOURCES Type Ethernet_1 INES BRI Lines Name Slot Port line1 CyberSWITCH YSTEM ETAILS PAP Password:_______________ CHAP Secret:___________________ Slot Switch type Line type Call screen Auto Synchronization type SPID Directory number...

  • Page 31: Device Information

    Make calls for IP data? AppleTalk disabled AppleTalk enabled? disabled AppleTalk Address disabled Make calls for AT data? AT Routing Protocol Small Office Remote Access Switch IP R OUTING ETWORK Device Information X enabled disabled 192.1.1.2 0.0.0.0 if unnumbered link...
  • Page 32 EXAMPLE NETWORKS Device Name: Jill Smith Calling (ISDN, FR, etc.) Information Line Protocol Base Data Rate Initial Data Rate Max Data Rate Dial-Out Number(s) Authentication Information : PAP Password CHAP Secret IP Host ID Bridge Ethernet Address* Bridge Password* CLID(s) * HDLC Bridge only Protocol for this particular device? Bridge...

  • Page 33: Device Information

    Make calls for IP data? AppleTalk disabled AppleTalk enabled? disabled AppleTalk Address disabled Make calls for AT data? AT Routing Protocol Small Office Remote Access Switch IP R OUTING ETWORK Device Information X enabled disabled 192.1.1.23 0.0.0.0 if unnumbered link...
  • Page 34 EXAMPLE NETWORKS Device Name: Todd Jones Calling (ISDN, FR, etc.) Information Line Protocol Base Data Rate Initial Data Rate Max Data Rate Dial-Out Number(s) Authentication Information : PAP Password CHAP Secret IP Host ID Bridge Ethernet Address* Bridge Password* CLID(s) * HDLC Bridge only Protocol for this particular device? Bridge...

  • Page 35: Bridging And Routing Information

    X enabled disabled X router IP host SanFran 128.1.1.1 need don’t need SanJose 192.1.1.1 Monterey (unnumbered) Mask default? default? default? default? Small Office Remote Access Switch IP R OUTING ETWORK Bridging and Routing Information Next hop...

  • Page 36: Configure The Cyberswitch

    Start the CFGEDIT program Select physical resources Select to add a resource Select Switch type to be 4ESS Select to add a line Enter “Line1” as the line name Select slot 1, port 1 Add Data Links...
  • Page 37 RIP determines the shortest path between two points in a network in terms of the number of “hops” between these points. For the rest of the required RIP LAN interface information, accept the default values. Small Office Remote Access Switch...
  • Page 38 EXAMPLE NETWORKS The interactive LAN interface session should be similar to the following: 1) LAN 2) WAN 3) WAN (Direct Host) 4) WAN (RLAN) 5) WAN (UnNumbered) Select function from above or <RET> for previous menu: 1 INTERFACE NAME or <RET> to cancel? SanFran Enter the IP Address in dotted decimal notation or <RET>...
  • Page 39 IP device is connected to the system. Do you wish to ENABLE Host Route Propagation (Y or N) [default = N]? <RET> Network Topology Worksheet). You will then be asked for the IP Small Office Remote Access Switch IP R OUTING ETWORK...

  • Page 40: Configuring The Security

    EXAMPLE NETWORKS The WAN interface summary screen will then be displayed. If all of the configured information is accurate, press <return> to save the information. Finally, we will enter the interface information for the WAN (Direct Host) interface. Press 1 to add another interface.
  • Page 41 ISDN line protocol. The device Rick Bear uses RFC 1294 protocol, so we will press 3: ATABASE "PPP (Point to Point Protocol)" "64000 bps" "64000 bps" "128000 bps" "" "Default_Profile" DISABLED Small Office Remote Access Switch IP R OUTING ETWORK Configure the CyberSWITCH...
  • Page 42 EXAMPLE NETWORKS Device ISDN Line Protocol Menu: (Device = "Rick Bear") 1) PPP (Point to Point Protocol) 2) HDLC Bridge 3) IP Host (RFC1294) Select option to associate with device "Rick Bear", or "0" to disable ISDN access for this device [default = 1]? 3 The only other item on the Device ISDN Line Protocol Menu that this type of device needs is the maximum data rate.

  • Page 43: Save Configuration Files

    .BAK (e.g., the old NODE.NEI file will be called NODE.BAK). After you save the configuration files, press <RET> to exit the CFGEDIT program. Reboot the system to activate your changes. NFORMATION NFORMATION Small Office Remote Access Switch IP R OUTING ETWORK Configure the CyberSWITCH...

  • Page 44: Verify The Installation

    EXAMPLE NETWORKS ERIFY THE NSTALLATION Steps on how to verify the installation are detailed in the System Verification chapter of the User’s Guide. This section gives an outline of which steps should be executed for Example 3. On the CyberSWITCH: Verify hardware resources are operational Issue dr command Look for BRI line messages...

  • Page 45: Ip Routing Network With Remote Bridge Devices

    Uses PAP to authenticate remotes; CHAP on central site. • Carmel and Monterey dial into Corporate Office. • Corporate Office supports two BRI lines (4-port BRI card), with NTT custom switch configuration. • Assumes we want to route IP traffic onto the corporate LAN.
  • Page 46 EXAMPLE NETWORKS Corporate Office Host CSX150 128.1.1.1 "Corp" RLAN Interface 198.12.10.1 ISDN CyberSWITCH ETWORK OPOLOGY File Server Remote Satellite Offices HDLC Bridge "Carmel" HDLC Bridge "Monterey" IP (Sub-) Network Number 198.12.10.0 Host 198.12.10.2 Host 198.12.10.3...

  • Page 47: Resources

    INES BRI Lines Name Slot Port line1 line2 IP R OUTING ETWORK WITH YSTEM ETAILS CHAP Secret:_______________ Slot Switch type Line type Call screen Auto Auto Small Office Remote Access Switch EMOTE RIDGE EVICES Resources Synchronization type SPID Directory number...

  • Page 48: Device Information

    EXAMPLE NETWORKS Device Name: Monterey Calling (ISDN, FR, etc.) Information Line Protocol HDLC Bridge Base Data Rate Initial Data Rate Max Data Rate Dial-Out Number(s) Authentication Information : PAP Password CHAP Secret IP Host ID Bridge Ethernet Address* 123123123123 Bridge Password* CLID(s) * HDLC Bridge only Protocol for this particular device?
  • Page 49 Make calls for IP data? AppleTalk disabled AppleTalk enabled? disabled AppleTalk Address disabled Make calls for AT data? AT Routing Protocol Small Office Remote Access Switch ETWORK WITH EMOTE RIDGE EVICES Device Information enabled X disabled 0.0.0.0 if unnumbered link...

  • Page 50: Bridging And Routing Information

    EXAMPLE NETWORKS RIDGING AND RIDGING Bridging Mode of Operation Bridge Filters Bridge Dial Out/ Known Connect List IP R OUTING IP Routing Mode of Operation Network Interface Information Name IP address Mask Unnumbered WAN Remote LAN Name IP address Mask Traditional WAN Name IP address...

  • Page 51: Configure The Cyberswitch

    Start the CFGEDIT program Select physical resources Select to add a resource Select Switch type to be NI-1 Select to add a line Select slot 1, port 1 Enter “Line1” as the line name Add Data Links...
  • Page 52 EXAMPLE NETWORKS IP I ONFIGURING THE NTERFACE NFORMATION In our example, we need to configure two types of interfaces. The LAN interface represents the system connection to the LAN IP Network 128.1.0.0. The WAN RLAN interface represents the system connection to the remote IP network 198.12.10.0. Press 2 at the IP main menu to begin the configuration of the IP interface information.
  • Page 53 RLAN interface. Press 1 to add the next interface. Configure the information for the WAN (RLAN) interface as follows: IP R OUTING ETWORK WITH EMOTE Configure the CyberSWITCH Small Office Remote Access Switch RIDGE EVICES...

  • Page 54: Configuring The Security

    EXAMPLE NETWORKS The interface name is a symbolic name given to the interface. For the WAN (RLAN) interface, you should use a name that describes this interface. Type Satellites for this example. You will then be asked for the IP address for the interface. In our example, the value you should enter is 198.12.10.1.

  • Page 55: Security Level

    ISDN line protocol. The device Monterey uses HDLC protocol, so we will press 2: IP R OUTING NFORMATION ATABASES “PPP (Point to Point Protocol)” “64000 bps” “64000 bps” “128000 bps” “” “” “Default_Profile” DISABLED Small Office Remote Access Switch ETWORK WITH EMOTE RIDGE EVICES Configure the CyberSWITCH...
  • Page 56 EXAMPLE NETWORKS Device ISDN Line Protocol Menu: (Device = "Monterey") 1) PPP (Point to Point Protocol) 2) HDLC Bridge 3) IP Host (RFC1294) Select option to associate with device "Monterey", or “0” to disable ISDN access for this device [default = 1]? 2 No other changes are required.

  • Page 57: Verify The Installation

    • Have the remote hosts ping the CyberSWITCH. • Have the CyberSWITCH ping the remote hosts (if a connection is up). IP R OUTING NFORMATION NFORMATION Small Office Remote Access Switch ETWORK WITH EMOTE RIDGE EVICES Verify the Installation...

  • Page 58: Ip Routing Network With Ppp Devices

    IP R OUTING ETWORK WITH VERVIEW This sample network uses IP routing to connect two of our products, both using PPP. Each system is on a separate LAN. The configuration for this network is designed to allow three different types of accesses: •...
  • Page 59 Router 128.1.1.3 128.1.1.7 128.1.1.8 LAN 1 LAN Interface 128.1.1.1 CSX150 Phone Number: "SITE1" 918105551234 ISDN IP UnNumbered Interface for SITE1 and SITE2 CSX150 Host #2 Phone Number: "SITE2" 913135553232 LAN Interface 128.3.3.1 128.3.3.4 LAN 2 Small Office Remote Access Switch...

  • Page 60: System Details

    EXAMPLE NETWORKS System Name: Site1 ___Site2____ ESOURCES Type Ethernet_1 INES BRI Lines Name Slot Port Line1 CyberSWITCH YSTEM ETAILS PAP Password:_______________ CHAP Secret:_____ df8sfds33 _________ Slot Switch type 5ESS Line type Call screen Auto _____ikcd98s_____ Synchronization type SPID Directory number...

  • Page 61: Bridging And Routing Information

    Name IP address Mask Name IP address Mask Name IP address Mask IP address Mask Mask default? default? default? Small Office Remote Access Switch IP R PPP D OUTING ETWORK WITH EVICES Bridging and Routing Information Next hop (SITE2)

  • Page 62: Bridging And Routing Information

    EXAMPLE NETWORKS RIDGING AND RIDGING Bridging Mode of Operation Bridge Filters Bridge Dial Out/ Known Connect List IP R OUTING IP Routing Mode of Operation Network Interface Information Unnumbered WAN Remote LAN Traditional WAN Direct Host WAN IP Host Mode Static Routes Destination network address 128.1.0.0...

  • Page 63: Device Information

    Make calls for IP data? AppleTalk disabled AppleTalk enabled? disabled AppleTalk Address disabled Make calls for AT data? AT Routing Protocol Small Office Remote Access Switch IP R PPP D OUTING ETWORK WITH EVICES Device Information X enabled disabled unnumbered X 0.0.0.0 if...
  • Page 64 EXAMPLE NETWORKS Device Name: Site1 Calling (ISDN, FR, etc.) Information Line Protocol Base Data Rate Initial Data Rate Max Data Rate Dial-Out Number(s) 918105551234 Authentication Information : PAP Password CHAP Secret IP Host ID Bridge Ethernet Address* Bridge Password* CLID(s) * HDLC Bridge only Protocol for this particular device? Bridge...

  • Page 65: Configure Site1

    Using the detailed instructions for these steps found in the complete the following configuration steps. Start the CFGEDIT program Select physical resources Select Switch type to be 5ESS Select to add a line Enter the line name Select slot and port numbers Select line interface type of “Point-to-Point”...
  • Page 66 EXAMPLE NETWORKS IP I ONFIGURING THE NTERFACE NFORMATION In our example, we need to configure two types of interfaces. The LAN interface represents SITE1’s connection to the LAN IP Network 128.1.1.1. A WAN UnNumbered interface represents SITE1’s logical connection to SITE2. A WAN UnNumbered interface allows you to configure an IP WAN interface without assigning an IP address to it.

  • Page 67: Configure Site1

    After you have entered all of the information for the interface, a summary screen will be displayed. If all of the configured information is accurate, follow the onscreen prompt to save the information. IP R PPP D OUTING ETWORK WITH Configure SITE1 Small Office Remote Access Switch EVICES...
  • Page 68 EXAMPLE NETWORKS After you save the LAN interface configuration, press 1 to add the next interface. Configure the information for the WAN (UnNumbered) interface as follows: 1) LAN 2) WAN 3) WAN (Direct Host) 4) WAN (RLAN) 5) WAN (UnNumbered) Select function from above or <RET>...
  • Page 69 For this example, enter 384,000 for the maximum data rate. IP R OUTING "PPP (Point to Point Protocol)" "64000 bps" "64000 bps" "128000 bps" "" "Default_Profile" DISABLED Small Office Remote Access Switch PPP D ETWORK WITH EVICES Configure SITE1...
  • Page 70 EXAMPLE NETWORKS Press 5 to enter the first dial out number. A phone number must be defined for each remote device that will be dialed. This number includes any prefix digits, area codes, or extensions as required to dial the destination device. It is possible to specify two phone numbers for the remote device. For this example, we will only be entering one phone number, 913135553232, which is the phone number for SITE2.
  • Page 71 0 for the Next Hop address. This interface will provide the gateway to this network. When prompted, enter SITE2 as the device name of the next hop device. IP R PPP D OUTING ETWORK WITH Configure SITE1 Small Office Remote Access Switch EVICES...
  • Page 72 EXAMPLE NETWORKS Host #1 128.1.1.8 LAN Interface 128.1.1.1 CSX150 "SITE1" SITE1 needs static route to SITE2 Host #2 128.3.3.4 LAN 2 We now need to enter the metric value for this route. The metric value is the administrative distance to the destination of the entry. The administrative distance is typically measured by the number of hop counts (number of routers) between the system and the destination, but it is up to you to assign a proper value to each route entry.

  • Page 73: Security Information

    To complete the security configuration, press 3 at the Main CFGEDIT Menu. The Security Menu will then be displayed. The sections below provide instructions for configuring the remaining security information. IP R Next Hop 255.255.0.0 (SITE2) Small Office Remote Access Switch PPP D OUTING ETWORK WITH EVICES Configure SITE1 Metric...

  • Page 74: Configure Site2

    EXAMPLE NETWORKS ONFIGURING YSTEM PTIONS AND To configure System Options and Information, press 2 at the Security Menu. By default, all system options are enabled by default, which is acceptable for this network. Press “2” at the System Options and Information Menu. This is where we will configure the system information for SITE1.

  • Page 75: Configuring Security

    Check connectivity to SITE2 CALL DEVICE SITE2 Check connectivity to remote devices IP PING 128.3.3.1 (SITE2) IP PING 128.3.3.4 (host) IP R NFORMATION Small Office Remote Access Switch PPP D OUTING ETWORK WITH EVICES Verify the Installation (page 74) with the...
  • Page 76 EXAMPLE NETWORKS On SITE2: Check connectivity to local devices IP PING 128.3.3.4 (host) Check connectivity to SITE1 CALL DEVICE SITE1 Check connectivity to remote devices IP PING 128.1.1.8 (host) IP PING 128.1.1.3 (server) IP PING 128.1.1.7 (router) IP PING 128.1.1.1 (SITE1) CyberSWITCH...

  • Page 77: Ipx Routing Network

    Central site dials out only to Dallas; Tampa and Orlando dial in to central site. • Central site supports two BRI lines (4-port BRI card), with 5ESS custom switch configuration. • Assumes bridging enabled at system level (at central site) so that the device routes enabled network-layer protocols and bridges all other packets.

  • Page 78: Network Topology

    EXAMPLE NETWORKS CSX1200 B-CHANNELS E1 ONLY POWER SERVICE 10BASE - T B13 B15 B17 B19 B21 B23 B25 B27 B29 B31 B10 B12 B14 B16 B18 B20 B22 B24 B26 B28 Remote Bridge PAP Password: tbpswd Tampa Network External # 0128 Orlando Network CSX150 External # 0128...

  • Page 79: System Details

    Name Slot Port line1 line2 YSTEM ETAILS PAP Password:_______________ CHAP Secret: Slot Switch type 5ESS Line type Call screen Auto Auto Small Office Remote Access Switch IPX R OUTING ETWORK System Details df8sds33 Synchronization type SPID Directory number 3137611111 3137612222...

  • Page 80: Device Information

    EXAMPLE NETWORKS Device Name: dallasnet Calling (ISDN, FR, etc.) Information Line Protocol Base Data Rate Initial Data Rate Max Data Rate Dial-Out Number(s) 912143339999 Authentication Information : PAP Password CHAP Secret IP Host ID Bridge Ethernet Address* Bridge Password* CLID(s) * HDLC Bridge only Protocol for this particular device? Bridge...
  • Page 81 Make calls for IP data? 0128 AppleTalk X disabled AppleTalk enabled? X disabled AppleTalk Address disabled Make calls for AT data? AT Routing Protocol Small Office Remote Access Switch IPX R OUTING ETWORK Device Information enabled disabled 0.0.0.0 if unnumbered link enabled disabled...
  • Page 82 EXAMPLE NETWORKS Device Name: orlandobr Calling (ISDN, FR, etc.) Information Line Protocol Base Data Rate Initial Data Rate Max Data Rate Dial-Out Number(s) Authentication Information : PAP Password CHAP Secret IP Host ID Bridge Ethernet Address* Bridge Password* CLID(s) * HDLC Bridge only Protocol for this particular device? Bridge Bridging enabled?

  • Page 83: Bridging And Routing Information

    IP host Name IP address Mask need don’t need Name IP address Mask Name IP address Mask Name IP address Mask IP address Mask Mask Small Office Remote Access Switch IPX R OUTING ETWORK Bridging and Routing Information Next hop...

  • Page 84: Ipx Routing

    EXAMPLE NETWORKS IPX R OUTING IPX Routing Information X enabled IPX routing Internal network number Network Interface Information LAN name detroitlan IPX Static Routes Destination network number NetWare Static Services Server name CyberSWITCH disabled 111abc External network Remote LAN name number 0100 remotelan...

  • Page 85: Configure Ipx Routing: Masternet (Detroit)

    This menu provides various configuration options for the device dallasnet. For purposes of our example, we will provide the following ISDN and Authentication information. Configure IPX Routing: Masternet (Detroit) ASTERNET ETROIT Simple Remote Bridging Small Office Remote Access Switch IPX R OUTING ETWORK chapter, use the CFGEDIT...
  • Page 86 EXAMPLE NETWORKS ISDN Information From the Device Table Menu, select ISDN. Accept the ISDN Line Protocol default value of PPP, as well as the default values for Base Data Rate and Initial Data Rate. However, increase the Maximum Data Rate to 256,000 (to use a maximum of four calls/connections running in parallel).

  • Page 87: Configure System Options

    To begin its configuration, press 2 at the Main Menu. For this example, we will enable bridging, enable IPX routing, and configure the necessary IPX routing information. Configure IPX Routing: Masternet (Detroit) Remote LAN interface. For more details, refer to the Configuring IPX NONE ENABLED DISABLED 0128 Small Office Remote Access Switch IPX R OUTING ETWORK...
  • Page 88 EXAMPLE NETWORKS NABLE RIDGING Select Options from the Main Menu. Select Bridging. Follow screen prompts to insure that bridging is enabled (to support Remote LAN). IPX R NABLE OUTING Select Options from the Main Menu. Select IPX Routing. Enable IPX Routing. Press any key to display the complete IPX routing menu: IPX Menu: IPX Routing (Enable/Disable) IPX Internal Network Number...
  • Page 89 Enter a RIP Receive Control from the above menu [default = 2]? 2 RIP Respond Control: 1) Do Not Respond. 2) Send. Enter a RIP Respond Control from the above menu [default = 2]? 2 Configure IPX Routing: Masternet (Detroit) remotelan Small Office Remote Access Switch IPX R OUTING ETWORK 0128...
  • Page 90 EXAMPLE NETWORKS SAP Send Control: 1) Do Not Send. 2) Send. Enter a SAP Send Control from the above menu [default = 2]? 1 SAP Receive Control: 1) Do Not Receive. 2) Send. Enter a SAP Receive Control from the above menu [default = 2]? 2 SAP Respond Control: 1) Do Not Respond.

  • Page 91: Ipx Spoofing

    WAN peer list information, or change the global RIP/SAP timer configuration. View the WAN peer list to assure that dallasnet is properly listed. Skip past the global timer configuration, since we will accept the default values for this option. IPX R OUTING Configure IPX Routing: Masternet (Detroit) Small Office Remote Access Switch ETWORK...

  • Page 92: Save Configuration Files

    EXAMPLE NETWORKS ONFIGURATION ILES We have now configured all the required information for masternet, the IPX router in Detroit. Return to the Main Menu, save your configuration files, and exit. Restart the IPX router to activate the changes. ONFIGURE THE EMOTE Configure the remote devices in a similar manner as the masternet configuration: •...

  • Page 93: Appletalk Routing Network

    PPLE OUTING VERVIEW This chapter provides an example configuration of an AppleTalk Routing network. Our AppleTalk network is made up of two LANs, separated by the WAN. The MACs on each side of the WAN need to exchange packets with the MACs on the other side of the WAN. Both LANs also have a CyberSWITCH (SITE1 and SITE2).
  • Page 94 EXAMPLE NETWORKS "SITE1" CyberSWITCH ETWORK OPOLOGY SITE1 AppleTalk Configuration CSX150 Network Range: 10-13 Zones: SITE1.Engineering (default) SITE1.Marketing ISDN SITE2 AppleTalk Configuration CSX150 Network Range: 45-50 "SITE2" Zones: SITE2.Engineering (default) SITE2.Marketing...

  • Page 95: Resources

    * Hunt Group Number: 13135551111 YSTEM ETAILS PAP Password:_______________ CHAP Secret: Slot Switch type NI-1 Line type Call screen Auto Small Office Remote Access Switch PPLE OUTING ETWORK Initial Installation Steps Synchronization type SPID Directory number 3135551111 13135551111* 3135551112 13135551112*...

  • Page 96: Appletalk Routing

    EXAMPLE NETWORKS PPLE OUTING AppleTalk Routing/Port Information AppleTalk routing Unnumbered WAN MAC Dial In WAN AppleTalk Port Static Routes Network type Destination to be network accessed range X extended 45-50 nonextended extended nonextended extended nonextended CyberSWITCH X enabled disabled Name lanport1 Port number Network type...
  • Page 97 Make calls for IP data? AppleTalk disabled AppleTalk enabled? disabled AppleTalk Address disabled Make calls for AT data? AT Routing Protocol Small Office Remote Access Switch PPLE OUTING ETWORK Initial Installation Steps enabled disabled 0.0.0.0 if unnumbered link enabled disabled...

  • Page 98: Configure The Cyberswitch

    Repeat “Select to add a line” for each additional line Data links are handled differently on a NI-1 switch. Some BRI lines have only one phone number (for the Data Link), but can handle two calls (one for each bearer channel). For NI-1 switches, the BRI line has two phone numbers (one for each bearer channel), and each phone number has its own SPID.
  • Page 99 254 nodes and supports multiple zones, whereas the nonextended network allows up to 254 nodes and supports only one zone.This network requires a range of network numbers and multiple zones. Select the extended network type. PPLE Configure the CyberSWITCH lanport1 Small Office Remote Access Switch OUTING ETWORK...
  • Page 100 EXAMPLE NETWORKS • AppleTalk network range: This range specifies the AppleTalk network range of the LAN segment that the port is connected to. As indicated by the topology worksheet, the network range for SITE1’s LAN is 10-13. Note: If we wanted SITE1 to be in discovery mode, we could have entered a range of 0-0. In the discovery mode, the system is a non-seed router, learning about its network from a seed router.

  • Page 101: Configuring Device Information

    We will begin by specifying the type of device. This device is an ISDN device, so we will select ISDN from the Device Table Menu. The ISDN Menu will then be displayed with preconfigured default values as shown below: NFORMATION Small Office Remote Access Switch PPLE OUTING ETWORK...
  • Page 102 EXAMPLE NETWORKS Device ISDN Menu: (Device = "SITE2") 1) ISDN Line Protocol 2) Base Data Rate 3) Initial Data Rate 4) Maximum Data Rate 5) Dial Out Phone Number(s) "" 6) Subaddress 7) Profile Name 8) H0 Call Support Select function from above or <RET> for previous menu: The ISDN Line Protocol default configuration value of “PPP”...
  • Page 103 Select Make calls for AppleTalk Data. Follow the on-screen instructions to enable making calls for AppleTalk data. NFORMATION "" "ikcd98s" ENABLED DISABLED "" "" "" "" NFORMATION (Device = "SITE2") None DISABLED DISABLED None Small Office Remote Access Switch PPLE OUTING ETWORK Configure the CyberSWITCH...

  • Page 104: Configuring An Appletalk Static Route

    EXAMPLE NETWORKS After the device’s AppleTalk information has been entered, the menu will appear as follows: Device AppleTalk Configuration Menu: 1) AppleTalk Address 2) AppleTalk Routing 3) Make calls for AppleTalk data 4) AppleTalk Routing Protocol Select function from above or <RET> for previous menu: We will now continue with the AppleTalk Routing configuration.

  • Page 105: Save Configuration Files

    Look for “Data Link up 1,1” in reports On each AppleTalk LAN: Attempt accessing a resource on the CyberSWITCH LAN. This may require that you reboot your system and proceed through the logon sequence. PPLE OUTING Verify the Installation Small Office Remote Access Switch ETWORK...

  • Page 106: Index

    EXAMPLE NETWORKS NDEX AppleTalk routing example network compliance notices Configuring RLAN Users DOC notice example networks AppleTalk Routing IP routing with PPP devices IP routing with remote bridges IPX routing with PPP devices remote bridging with security simple bridging FCC notice IP operating mode 13, 23 example configuration...
