• VC Mode
• Service Definition
The following is an example of the information that is displayed with the command listed
above (for a SONET PHY interface):
ssr(atm-show)# port-settings at.8.1
Port information for Slot 8, Port 1:
Port Type:
Xmt Clock Source:
VC Mode:
Service Definition: ubr-default
• Port Type
• Xmt Clock Source
• VC Mode
• Service Definition
SmartSwitch Router User Reference Manual
SONET STS-3c MMF
Local
1 bit of VPI, 11 bits of VCI
Service Class:
Peak Bit Rate:
Encapsulation Type: Routed LLC
F5-OAM:
Displaying ATM Port Information
esf indicates extended super frame and is used
for T1 framing.
g832 is used for E3 framing.
g751 is used for E3 framing.
Shows the bit allocation for vpi and vci.
Shows the name of the defined service on the port
and its traffic parameters.
UBR
Best Effort
Requests & Responses
Shows the type of PHY interface for the port.
Shows the timing source for the port.
Local indicates the onboard clock oscillator as the
timing source.
Loop indicates the receiver input as the timing
source.
Shows the bit allocation for vpi and vci.
Shows the name of the defined service on the port
and its traffic parameters.
