Specify the number of seconds
required to transmit a link state
update on an OSPF interface.
Specify the time a neighbor router
will listen for OSPF hello packets
before declaring the router down.
Disable IP multicast for sending OSPF
packets to neighbors on an OSPF
interface.
Specify the poll interval on an OSPF
interface.
Specify the identifier of the key chain
containing the authentication keys.
Specify the authentication method to
be used on this interface.

Configuring an OSPF Area

OSPF areas are a collection of subnets that are grouped in a logical fashion. These areas
communicate with other areas via the backbone area. Once OSPF areas are created, you
can add interfaces, stub hosts, and summary ranges to the area.
In order to reduce the amount of routing information propagated between areas, you can
configure summary-ranges on Area Border Routers (ABRs). On the SSR, summary-ranges
are created using the ospf add summary-range command – the networks specified using
this command describe the scope of an area. Intra-area Link State Advertisements (LSAs)
that fall within the specified ranges are not advertised into other areas as inter-area routes.
Instead, the specified ranges are advertised as summary network LSAs.
To create areas and assign interfaces, enter the following commands in the Configure
mode.
Create an OSPF area.
Add an interface to an OSPF area.
SmartSwitch Router User Reference Manual
Chapter 11: OSPF Configuration Guide
ospf set interface
<num>
transit-delay
ospf set interface
router-dead-interval
ospf set interface
no-multicast
ospf set interface
<num>
poll-interval
ospf set interface
<num-or-string>
key-chain
ospf set interface
authentication-method
none|simple|md5
<area-num>
ospf create area
ospf add interface
<area-addr>
to-area
[type broadcast|non-broadcast|
point-to-multipoint]
<name-or-IPaddr>
|all
<name-or-IPaddr>
|all
<num>
<name-or-IPaddr>
|all
<name-or-IPaddr>
|all
<name-or-IPaddr>
|all
<name-or-IPaddr>
|all
|backbone
<name-or-IPaddr>
|backbone
