Configuration Example - Cabletron Systems SMARTSWITCH ROUTER 9032578-05 User's Reference Manual

Show RIP information on the specified
interface.
Show RIP interface policy information.
Show detailed information of all RIP
packets.
Show detailed information of all packets
received by the router.
Show detailed information of all packets
sent by the router.
Show detailed information of all request
received by the router.
Show detailed information of all response
received by the router.
Show detailed information of response
packets sent by the router.
Show detailed information of request
packets sent by the router.
Show RIP timer information.

Configuration Example

! Example configuration
!
! Create interface SSR1-if1 with ip address 1.1.1.1/16 on port et.1.1 on SSR-1
interface create ip SSR1-if1 address-netmask 1.1.1.1/16 port et.1.1
!
! Configure rip on SSR-1
rip add interface SSR1-if1
rip set interface SSR1-if1 version 2
rip start
!
!
! Set authentication method to md5
rip set interface SSR1-if1 authentication-method md5
!
! Change default metric-in
rip set interface SSR1-if1 metric-in 2
SmartSwitch Router User Reference Manual
SSR 1
Interface 1.1.1.1
Chapter 10: RIP Configuration Guide
rip show interface
rip show interface-policy
rip trace packets detail
rip trace packets receive
rip trace packets send
rip trace request receive
rip trace response receive
rip trace response send
rip trace send request
rip show timers
SSR 2
Interface 3.2.1.1
<Name or IP-addr>
109
