Monitoring Frame Relay WAN Ports

Once you have configured your frame relay WAN interface(s), you can use the CLI to
monitor status and statistics for your WAN ports. The following table describes the
monitoring commands for WAN interfaces, designed to be used in Enable mode:
Display a particular frame relay
service profile
Display all available frame relay
service profiles
Display the last reported frame
relay error
Display active frame relay LMI
parameters
Display MIBII statistics for frame
relay WAN ports
Display a summary of all LMI
statistics

Frame Relay Port Configuration

To configure frame relay WAN ports, you must first define the type and location of the
WAN interface, optionally "set up" a library of configuration settings, then apply those
settings to the desired interface(s). The following examples are designed to give you a
small model of the steps necessary for a typical frame relay WAN interface specification.
To define the location and identity of a serial frame relay WAN port located at slot 5,
port 1 with a speed rating of 45 million bits per second:
ssr(config)# port set se.5.1 wan-encapsulation frame-relay speed
45000000
To define the location and identity of a High-Speed Serial Interface (HSSI) VC located at
slot 4, port 1 with a DLC of 100:
ssr(config)# frame-relay create vc hs.4.1.100
Suppose you wish to set up a service profile called "profile1" that includes the following
characteristics:
• Committed burst value of 2 million and excessive burst value of 1 million
• BECN active shaping at 65 frames
SmartSwitch Router User Reference Manual
Chapter 25: WAN Configuration Guide
frame-relay show service
frame-relay show service all
frame-relay show stats port
last-error
frame-relay show stats port
lmi
frame-relay show stats port
mibII
frame-relay show stats port
summary
<service name>
<port name>
<port name>
<port name>
<port name>
