- Page 1 MMAC-Plus ™ Module Local Management 9F106-02 Module Specific Appendix 9031681...
- Page 2 Appendix 9F106-02 Module Specific Information Introduction This appendix contains local management information that is specific to the 9F106-02 FDDI Repeater Module.
-
Page 3: Module Specific Configuration Screen
9F106-02 Module Specific Information Module Specific Configuration Screen The 9F106-02 FDDI Repeater Module physically attaches to the FNB-1 and the FNB-2 on the MMAC-Plus backplane. By default, the module inserts into four rings (the primary and secondary rings of the FNB-1 and the FNB-2). The 9F106-02 Configuration Screen allows you to customize this configuration to your particular needs. - Page 4 Appendix The 9F106-02 Module Specific Configuration Screen displays the current configuration of the module’s front panel connections in relation to the FNB rings on the MMAC-Plus backplane, and allows you to change the configuration. MMAC-Plus LOCAL MANAGEMENT 9F106-02 Configuration Module Name: 9F106-02 Firmware Revision: 00.00.00 Slot Number: 12 BOOTPROM Revision: 00.00.01...
- Page 5 9F106-02 Module Specific Information 9F106-02 Module Specific Configuration Screen Fields The following information appears on the 9F106-02 Configuration Screen. (FNB-1) FNB Status is an INSERTED/BYPASS toggle selection which allows you to control whether or not the module’s FDDI-1 front panel ports will connect (insert) to the backplane’s FNB-1 rings.
- Page 6 Appendix (FNB-2) FNB Status is an INSERTED/BYPASS toggle selection which allows you to control whether or not the module’s FDDI-2 front panel ports will connect (insert) to the backplane’s FNB-2 rings. When set to INSERTED, the module’s FDDI-2 (B and A) ports insert directly into the backplane’s FNB-2 primary and secondary rings, respectively.
- Page 7 9F106-02 Module Specific Information To edit a toggle selection: Use the arrow keys to highlight the particular value in the field that you want to change. Use the Space Bar to toggle the value (for example, INSERTED will toggle to BYPASS).
