Chapter 17: Web Hosting Configuration Guide
To set the status of a load balancing server, enter the following command in Enable mode:
Set status of load balancing
server.
Load Balancing and FTP
File Transfer Protocol (FTP) packets require special handling with load balancing, because
the FTP PORT command packets contain IP address information within the data portion
of the packet. If the FTP control port used is not port 21, it is important for the SSR to know
the port number that is used for FTP.
To define an FTP control port (other than port 21) to the load balancing function, enter the
following command in Configure mode:
Specify the FTP control port.
Allowing Access to Load Balancing Servers
Load balancing causes both source and destination addresses to be translated on the SSR.
It may be undesirable in some cases for a source address to be translated; for example,
when data is to be updated on an individual server. Specified hosts can be allowed to
directly access servers in the load balancing group without address translation. Note,
however, that such hosts cannot use the virtual IP address and port number to access the
load balancing group of servers.
To allow specified hosts to access the load balancing servers without address translation,
enter the following command in Configure mode:
Specify the hosts that can access
servers without address
translation.
Setting Timeouts for Load Balancing Mappings
A mapping between a host (source) and a load-balancing server (destination) times out
after a certain period. After the mapping times out, any server in the load balancing group
can be selected. The default timeouts depend upon the session persistence level
configured when the load balance group is created. You can specify the timeout for
source-destination load balancing mappings.
238
load-balance set server-status server-ip
<ipaddr/range>
server-port
<group name>
group-name
load-balance set ftp-control-port
number>
load-balance allow access-to-servers
<ipaddr/range>
client-ip
<group name>
SmartSwitch Router User Reference Manual
<port number>
status up|down
<port
group-name
