Parts List - Analog Devices LINEAR DC2469A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CVIN
2 2 C26, C27
3 2 CVIN1, CVIN2
4 1 CVIN3
5 4 CVIN4, CVIN5, CVIN6, CVIN7
6 1 C1
7 3 C2, C3, C32
8 2 C6, C9
9 1 C7
10 1 C8
11 2 C10, C17
12 2 C11, C15
13 2 C12, C22
14 3 C13, C19, C23
15 1 C18
16 2 C20, C21
17 1 C25
18 1 C29
19 1 C30
20 1 C31
21 2 C34, C38
22 1 D1
23 2 D2, D3
24 1 FB1
25 1 L1
26 1 L2
27 1 L3
28 1 L4
29 1 L5
30 1 Q1
31 1 R1
32 4 R2, R3, R4, R5
33 1 R6
34 1 R7
35 1 R8
36 5 R9, R11, R13, R14, R19
37 1 R12
38 1 R15
39 1 R16
40 1 R17
41 1 R18
DEMO MANUAL DC2469A
PART DESCRIPTION
Cap, X5R 1µF 50V 10% 0603
Cap, X7R 4.7µF 50V 10% 1206
Cap, X7R 4.7µF 16V 10% 0805
Cap, X5R 10µF 6.3V 20% 0603
Cap, X5R 10µF 50V 10% 1206
Cap, Alum 22µF 50V 10%
Cap, X7R 0.1µF 50V 10% 0402
Cap, X5R 47µF 16V 10% 1210
Cap, Alum 47µF 16V 20%
Cap, X7R 0.1µF 50V 10% 0603
Cap, X7R 0.1µF 16V 10% 0402
Cap, X7R 47nF 25V 20% 0603
Cap, X5R 47µF 10V 10% 1206
Cap, X7R 2.2µF 10V 10% 0402
Cap, X5R 100µF 6.3V 20% 1206
Cap, X7R 4.7µF 10V 10% 0603
Cap, C0G 1500pF 25V 5% 0603
Cap, C0G 2.2pF 50V ±0.25pF 0603
Cap, C0G 4.7pF 50V ±0.25pF 0603
Cap, C0G 22pF 50V 5% 0603
Cap, X7R 10µF 50V 10% 1210
Schottky Rectifier, 60V, 5A, SOT1289
Schottky Rectifier, 0.2A, SOD523
BEAD, 4A 1206
Res, Jumper, Chip, 0Ω 0805
Inductor, 3.3µH XEL4030
Inductor, 1.5µH XEL4030
Inductor, 1µH NPIM42P
Inductor, 1.5µH
MOSFET-N Channel, PG-TSDSON-8
RES, CHIP , 0.008, 1W, 1%, 0815
Res, Chip 24.9k 0.1W 1% 0603
Res, Chip 3.32M 0.1W 1% 0603
Res, Chip 365k 0.1W 1% 0603
Res, Chip 806k 0.1W 1% 0603
Res, Chip 200k 0.1W 1% 0603
Res, Chip 464k 0.1W 1% 0603
Res, Chip 1M 0.1W 1% 0603
Res, Chip 30.1k 0.1W 1% 0603
Res, Chip 187k 0.1W 1% 0603
Res, Chip 150k 0.1W 1% 0603
MANUFACTURER/PART NUMBER
Murata, GRM188R61H105KAALD
Murata, GRM31CR71H475KA12L
Murata, GRM21BR71C475KA73L
Murata, GRM188R60J106ME47D
Murata, GRM31CR61H106KA12L
Sun Elect Ind, 50CE22BSS
Murata, GRM155R71H104KE14J
Murata, GRM32ER61C476KE15K
Sun Elect Ind, 16CE47BS
Murata, GRM188R71H104KA93D
Murata, GRM155R71C104KA88D
Murata, GRM188R71C473KA01D
Murata, GRM31CR61A476KE15L
Murata, GRM155R61A225KE95D
Murata, GRM31CR60J107ME39K
Murata, GRM188R61A475KE15D
Murata, GRM1885C1E152JA01D
Murata, GRM1885C1H2R2CA01D
Murata, GRM1885C1H4R7CA01D
Murata, GRM1885C1H220JA01D
Murata, GRM32ER71H106KA12L
Nexperia, PMEG060V050EPD
NXP , PMEG6002EB
Wurth Elektronik, 742792150
Vishay, CRCW08050000Z0EA
Coilcraft, XEL4030-332ME
Coilcraft, XEL4030-152ME
NIC Comp Corp, NPIM42P1R0MTRF
Wurth Elektronik, 7448700015
Infineon, BSZ067N06LS3 G
Susumu, RL3720WT-R008-F
Vishay, CRCW060324K9FKEA
Vishay, CRCW06033M32FKEA
Vishay, CRCW0603365KFKEA
Vishay, CRCW0603806KFKEA
Vishay, CRCW0603200KFKEA
Vishay, CRCW0603464KFKEA
Vishay, CRCW06031M00FKEA
Vishay, CRCW060330K1FKEA
Vishay, CRCW0603187KFKEA
Vishay, CRCW0603150KFKEA
dc2469af
7
