36" & 48" Shutter Box Fan
Figure 1. Decal Placement
Technical Information
Important
MV1666D
The diagram below shows the proper location of the safety decal (DANGER--
ROTATING FAN BLADE) as shipped from the factory. Replace damaged or
missing decals. Make sure the decals may be easily seen at all times.
If the fan is purchased unassembled, the Chore-Time Fan Assembly Part Number
Decal will be packed with this instruction manual. Make sure the decal location
shown below is clean and dry. Remove the backing of the decal and affix it to the Fan
Shroud.
Motor choices and specifications are provided in the Parts List section of this manual.
See page 20 for Fan Motor specifications.
Chore-Time Equipment strongly recommends that a good alarm system
should be installed in confinement buildings to warn of power failure
and high temperature.
Chore-Time Equipment also recommends that an alternate power source be available
for confinement buildings in case of power failure.
Tools Required
•
Hammer
•
1/2" Open End Wrench or Socket Wrench with 1/2" Socket
•
Wire Cutters & Strippers
•
Adequate Size & Quantity of Electrical Wire
•
5/16" Hex Key Wrench
•
5/16" Open End Wrench or a 12 Point 3/8" Socket and Ratchet
