Chore-Time Mv1666-021 Installation & Operator's Instruction Manual page 23

Part Numbers (48" Fans)
Item Qty. Description
1* 1 Motor
2 38 Bolt, Carriage 5/16-18 x .625
3 38 5/16-18 Hex Ser. Flange Nut
4 4 48" Shutter Fan Panel
5 1 Shroud 48'' Fan
6 2 48" Fan Post
7 1 Motor Mount Pivot Plate
8 1 Pivot Plate Mounting Bracket
9 1 Z-Motor Mounting Bracket
10 1 ST BD Module Bushing
11 1 Spring
12 1 48" Fan Blade
13 1 5-16-18 x 3/8 Set Screw
14 2 1/4 x 1 x 1/8 Square Key
15 1 Shaft
16 1 Rear Bearing Mount Plate
Part
Item Qty.
Number
Varies 17 1
8282 18 2
8490 19 1
45719 20 1
37583 21 2
43688 22 1
43713 23 16
46444 24 1
46445 25 1
38896 26 2
43715 27 3
28140 28 4
1174 29 3
2419-2 30* 1
43691 31 1
43690 32 32
33 16
*See Shutter Fan Specifications Page 20.
Description
Number
Front Bearing Mount Plate 43689
1" Bore Cast Flange Bearing 43654
8-1/4" O.D 1" Bore Sheave 42072
AX56 V-Belt 58.2 43816
Danger Decal 2527-50
EZ Fan Decal 39002-131
Screen Clip 38891
48" Wire Screen 45865
5/16-18 x 5.5" Bolt 4412-21
Spring Coil Cap 44002
.375 x .875 x .078 Flat Washer 546
5/16-18 x 1.25 Carriage Bolt 34885-2
5/16-18 Hex Lock Nut 2148
Cast Iron Sheave Varies
48" Fan Shutter Rail 40510
48" Shutter Louver 38038-12
48" Shutter Rod 38702-11
