36" & 48" Shutter Box Fan
Itemized Parts and Listing: 36" DD Shutter Fan
2
3
MV1666D
2
8
3
Mv1666-014 01/01
15
16
Item
Qty.
1*
1
Motor
2
16
Bolt, Carriage 5/16-18 x .625
3
16
5/16-18 Hex Ser. Flange Nut
4
4
36" Shutter Fan Panel
5
1
Shroud 36'' Fan
6
2
36" Fan Post
7
4
10-32 Serrated Flange Nut
8
12
36" Shutter Rod
9
1
36" Fan Blade
10
1
36" DD Fan Motor Support
11
2
Danger Decal
12
1
EZ DD Shutter Fan Decal
13
16
Screen Clip
14
1
40" x 40" Wire Inlet Screen
15
2
36" Fan Shutter Rail
16
24
36" Shutter Louver
*See Shutter Fan Specifications Page 20.
Itemized Parts and Listing: 36" DD Shutter Fan
4
13
14
10
2 2
3
9
6
12
11
Part
Description
Number
Varies
8282
8490
40705
5538
46127
48113
38702-10
40358
36564
2527-50
39002-208
38891
36629
40706
38038-11
1
7
5
21
