OPERATION, PARTS
AND
SAFETY
MANUAL
BXT 10
BATTERY-HAND TOOL FOR PLASTIC STRAPPING
READ ALL INSTRUCTIONS BEFORE OPERATING THIS SIGNODE PRODUCT
SIGNODE
3610
W. LAKE AVENUE • GLENVIEW,
ILLINOIS
60025 U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BXT 10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Signode BXT 10

  • Page 1 BUY AT ALLSTRAP (866) 779-2673 OPERATION, PARTS SAFETY MANUAL BXT 10 BATTERY-HAND TOOL FOR PLASTIC STRAPPING READ ALL INSTRUCTIONS BEFORE OPERATING THIS SIGNODE PRODUCT SIGNODE • 3610 W. LAKE AVENUE • GLENVIEW, ILLINOIS 60025 U.S.A.
  • Page 2: Table Of Contents

    BUY AT ALLSTRAP (866) 779-2673 TABLE OF CONTENTS Page Technical data General information Information on environmental protection Safety instructions Safety instructions for battery charger and battery Description Major components Operating panel Function Battery charger indicators Initial operation Battery charger 5 .2 First battery charge Charging the battery Operating instructions...
  • Page 3: Technical Data

    BUY AT ALLSTRAP (866) 779-2673 TECHNICAL DATA Weight 3.5 kg (7.7 lbs) (incl. battery) Dimensions Length 375 mm (14.7“) Width 130 mm (5.1“) Height 140 mm (5.5“) Strap tension 0–700 N (0–155 lbs) Tension speed 330 mm/s (12.9“/s) Sealing Friction welded BATTERY CHARGER / BATTERY Voltage Battery charger, 100/240 V...
  • Page 4: General Information

    BUY AT ALLSTRAP (866) 779-2673 WARNING GENERAL INFORMATION These operating instructions are intended to sim- CAUTION! plify familiarisation with the strapping tool and its proper use for the intended purpose. The operating Used where there is dan- instructions contain important information concern- ger to life and health.
  • Page 5: Safety Instructions

    BUY AT ALLSTRAP (866) 779-2673 WARNING SAFETY INSTRUCTIONS Inform yourself! Original spare parts must be Read the operating instructions used exclusively! carefully. Not using original spare parts Preventive and corrective main- will dissolve the warranty and tenance on the tool may only be the liability.
  • Page 6: Description

    BUY AT ALLSTRAP (866) 779-2673 DESCRIPTION 4.1 MAJOR COMPONENTS 1 Operating panel 2 Strap tensioning push button 3 Handle 4 Battery 5 Rocker lever 6 Welding/cutting button 7 Welding/Cutting 8 Tensioning 9 Battery charger Fig. 1 4.2 OPERATING PANEL 1 Welding time push button 2 Strap tension push button 3 Battery push button 4 LED-indicators 1–7...
  • Page 7: Battery Charger Indicators

    BUY AT ALLSTRAP (866) 779-2673 4.4 BATTERY CHARGER INDICATORS Continuous Ready for charging green light Battery not inserted, mains supply is connected. Flashing Rapid charging green light Rapid charging operates until the battery is fully recharged. The battery charger then switches automatically to trickle charging.
  • Page 8: Initial Operation

    BUY AT ALLSTRAP (866) 779-2673 INITIAL OPERATION 5.1 BATTERY CHARGER Input 230 V 50/60 Hz / 44 W The mains supply must comply with the specifi cati- ons on the rating plate (Fig. 5). Output 7.2-14.4 V 1.9 A The battery charger is suitable only for charging Fig.
  • Page 9: Operating Instructions

    BUY AT ALLSTRAP (866) 779-2673 OPERATING INSTRUCTIONS WARNING Wear safety glasses. Stand to one side of the strap when tensioning. Make sure all bystanders are clear before proceeding. 6.1 OPERATING THE TOOL – Insert charged battery (7/1) into strapping tool. –...
  • Page 10: Strap Seal Inspection

    BUY AT ALLSTRAP (866) 779-2673 – Depress button (10/1) completely to the stop. The straps are welded together and the upper strap is cut off. The LED indicator (10/2) indica- tes the cooling time of the sealing: LED fl ashing After fi...
  • Page 11: Operating Panel

    BUY AT ALLSTRAP (866) 779-2673 6.3 OPERATING PANEL a) Standard indication max. min. a) Standard indication (green) The current strap tension setting is monitored with inserted and charged battery. green 1 = minimum strap tension (approx. 100 N) (22 lbs) 7 = maximum strap tension (approx.
  • Page 12: Setting Strap Width

    BUY AT ALLSTRAP (866) 779-2673 6.4 SETTING STRAP WIDTH NOTE: The tool can be used with two different strap widths 9–11 mm ( “) or 12–13 mm ( “). Strap width 12–13 mm ( “) only for PP straps! a) Change strap width from 9–11 mm to 12–13 mm –...
  • Page 13: Preventive And Corrective Maintenance

    Installation – Install the parts in reverse order. Fig. 19 (2 = Tension wheel type for BXT 10) – Grease gear teeth of tension wheel lightly with Klüber grease GBU Y 131 (Microlube). The tension wheel must not be cleaned –...
  • Page 14: Recommended Spare Parts

    BUY AT ALLSTRAP (866) 779-2673 RECOMMENDED SPARE PARTS When ordering please indicate part number. KEY QTY PART # DESCRIPTION KEY QTY PART # KEY QTY PART # DESCRIPTION DESCRIPTION 427508 Tension wheel 427509 Tooth plate 427510 Cutter knife 8.1 PARTS LIST BXT 427511 Base plate complete, incl.
  • Page 15 BUY AT ALLSTRAP (866) 779-2673 KEY QTY PART # DESCRIPTION KEY QTY PART # DESCRIPTION 425951 Retaining ring, A Ø23 425729 427548 Set screw, M5 x 8 425952 Retaining ring, A Ø12 425692 Micro switch, welding 426772 Connecting rod 427549 Oval head screw, M2 x 10 426773 Shaft...
  • Page 16 BUY AT ALLSTRAP (866) 779-2673 KEY QTY PART # DESCRIPTION 427567 Name plate 427568 Indication plate 427569 Indication plate 425982 Tool-set 425983 Screwdriver (Phillips) 425697 Wire brush 425765 Option: protection plate- 425984 Protection plate 426824 Counter sunk screw, M 5 x 8 425764 Option: suspension bow- 427570...
  • Page 17: Exploded Drawing

    BUY AT ALLSTRAP (866) 779-2673...
  • Page 18 22th June 1998 (98/37/EEC), “Machine Guidelines“ and on 3th May 1989 (89/336/EEC), “EMV Guidelines“. Machine Description: BXT 10 Machine Type: Battery-hand tool for plastic strapping Provisions with which machine complies:...
  • Page 19 Signode reserves the right to replace any tool which proves not to operate per functional specifi cations with a new or like-new tool of the same model if in Signode’s judgement such replacement is appropriate.
