Microcom 428LT Operator's Manual page 57

Printer Commands
8 XON/XOFF Flow Control: Sets software flow control handshaking.
CTS/RTS hardware handshaking is always enabled.
5.2.1.2 Software Switch #2
^AB ^D COMMAND
XX 22 Change SW2: Software Switch #2.
^AB12345678 (each bit is represented by a numeric position number)
Position:
1 Clear Text Function: If enabled, all variable text strings will be erased
when the ^D<CR> is processed.
2 >RESTARTED< Response: If the printer has been reset and this
switch has been enabled, the printer will respond with the
>RESTARTED< message for the first enquiry ONLY, to denote the
reset condition and then >READY< with following enquiries.
3 Button Use: If set to a "1", the printer will disable the Print Button.
4 Print Repetition: Defines the function of the Print Button. If set to a
"0", the button can be used for feeding labels but the print function is
disabled and blank forms will be issued.
5 Power-ON Format Type: Determines whether to use a saved format
file or a standard ROM format. User downloaded Label FORMAT files
are saved in non-volatile FLASH memory. Any of these FORMATs may
be used for the Power-ON label. When SW2:5=1, the format is
selected by SW2 switch positions 6, 7, and 8.
6,7,8 Power-up Format: These switches work in conjunction with switch
location 5 above. They determine which stored format is loaded at
power-up. The printer can be instructed not to load a format at power-
up by setting all three switches to 0.
5-14
1 = Enable
0 = Disable
1= Enable
0 = Disable
1 = Enable (>RESTARTED< on first inquiry then >READY<)
0 = Disable (Always responds with >READY<)
1 = Disable
0 = Enable
1 = Label PRINT
0 = Label FEED only
1 = Power-ON label is selected by SW2: 6, 7, and 8
0 = Power-ON label is standard format
000 = No Power-up Format
001 = ROM or Saved Format File 1
010 = ROM or Saved Format File 2
428LT Operator's Manual - 880040-0200
Chapter 5
