These are the 7 RSS-14 parameters that MUST follow the ^D114 command:
Valid values for parameters
Type of RSS-14 barcode:
1) 0 = RSS-14 (this is the Standard RSS-14 barcode)
2) 1 = RSS-14 Truncated
3) 2 = RSS-14 Stacked
4) 3 = RSS-14 Stacked Omni-directional
5) 4 = RSS-14 Limited
6) 5 = RSS-14 Expanded
Multiplier:
1 to 100. This specifies how big to make the symbol. Multiplies both X & Y.
Segments per ROW:
2 to 22. EVEN number ONLY!
X Undercut:
0 to (MULTIPLIER-1)
Y Undercut:
0 to (MULTIPLIER-1)
Separator Height:
MULTIPLIER < = Separator Height < = 2 * MULTIPLIER.
Specifies the vertical separation between the linear data and the 2D data.
Data:
Always 13 digits for the linear data unless using RSS Expanded which can be up to
74 numeric or 41 alphabetic characters.
The "pipe" character ( | ) is used to separate the linear data from the 2D data.
Sample RSS-14 FORMAT: This sample uses the standard RSS-14 symbology
^D114<CR> ß Here comes RSS-14 data
0<CR>
5<CR>
22<CR>
0<CR>
0<CR>
5<CR>
428LT Operator's Manual - 880040-0200
1) Type of RSS-14 barcode
2) Multiplier
3) Segments per row
4) X undercut
5) Y undercut
6) Separator Height
7) Data to be encoded
ß Use standard RSS-14 symbol
ß Multiply size by 5
ß Use 22 segments/row
ß X undercut = 0
ß Y undercut = 0
ß Set vertical separator = 5
