Getting Started
6. Lift up the cutter to release and rotate the cutter assembly to the open position.
7. Insert media between the guides and through the cutter assembly.
3-6
Media
Guide
Figure 3-7 Cutter in the Open Position
Figure 3-8 Media Loading
428LT Operator's Manual - 880040-0200
Chapter 3
