Microcom 428LT Operator's Manual page 198

^A ^D COMMAND
xxyy 107 Save Compressed GRAPHICS to RAM:
The special ^Axxyy^D107 code is put at the beginning of the GRAPHIC
download file by the bit map converter program. The ^Axxyy tells the printer
the overall size of the file according to this format:
xx The number of additional 64KB sectors needed to save the graphic file.
yy The memory slot location of the graphic being saved; CGN # (1-255)
X 108 Serial Port Source (Non-volatile)
0 AutoSelect
1 Ethernet
X 109 Serial Port Source (volatile)
0 RS-232
1 USB
2 Ethernet
X 110 General Purpose Status Byte
XX 111 Kiosk Cutter Mode: This command enables the non-volatile full and/or partial
cut operation. The ^D112 command is also used with the ^D111 command to
adjust the advance distance to the cutter blades and then retract to the home
position (dot row one).
0 Disable Kiosk Cutter Mode.
1 Enable Kiosk Cutter Mode.
2 Enable partial Kiosk Cutter Mode.
4 Enable Kiosk Full cut with LPD
XX 112 Kiosk Cutter Advance Distance Command: The valid range is from
0 to 1000 with the recommended distance of 150.
XX 113 Verbose Mode:
0 Disable Verbose Mode.
1 Enable Verbose Mode.
114 RSS-14 Data Entry Command: The Reduced Space Symbology (RSS-14)
barcode is fully supported by the 324M and 424M printers. There are 6
different types of RSS-14 that are supported by the printer:
X 115 Set Cutter Type: Selects the type of cutter installed on the printer.
0 No cutter
1 Guillotine
2 Rotary
X 116 Synchronous Print Mode
0 Exit all sync. modes.
1 Enter single sync. mode.
2 Enter continuous sync. mode.
428LT Operator's Manual - 880040-0200 12-15
