Ports

There are two different hubs available, each with their own port configurations. They are the:
Single Ethernet
This configuration has a connection which allows you
to connect an Ethernet cable from your Internet
connection to the hub.
Dual Phone Line
This configuration has two ports which allows you to
connect to a phone line and to connect to your phone.

The WiFi Access Point / Repeater

The access point is the second component of the TD
Generation WiFi package The access point acts like a
router by receiving any transactions sent wirelessly
from your terminal(s) and then forwards them to the
payment system.Repeaters are additional routers
extend the terminal's range over larger areas.

Lights

There are five lights on the access point, but only the
WAN, PWR and WPS are used. You will use these to
troubleshoot any communication problems between
the terminal and the access point/repeater.
• Be sure not to move it or place barriers around
your existing access point / repeaters after the
installation as any changes may interfere with the
signal strength.
• The access point is the first one installed at a
site. Additional access points are referred to as
repeaters.
• Don't worry, no one can access the WiFi signal via
their laptop or smartphone.
LAN
WLAN
- 6 -
WPS
USB WAN
PWR
