2.3 Connecting the InformaCast Enabled Paging
Adapter
Before you connect the InformaCast Enabled Paging Adapter, be sure that you have received all of
the parts described in
See
Adapter.
Pin/Description
1-Fault Sense Input (Common)
2-Fault Sense Input (Sense)
3-Positive 600-Ohm Audio Output
4-Negative 600-Ohm Audio Output
5-Audio Ground Reference
6-Relay Contact - Common
7-Relay Contact - Normally Open

2.3.1 Ground Connection

This connection allows you to connect the device to an electrical ground.

2.3.2 Line In

This RCA 10K Ohm Hi-Z input connection allows you to connect the device to The RCA line-out
(10K Ohm Hi-Z) of an external audio amplifier. The level of this input can be controlled by the
potentiometer located on the front of the device (see
Parameters").

2.3.3 Line Out

This RCA 10K Ohm Hi-Z output connection allows you to connect the device to The RCA line-in
(10K Ohm Hi-Z) of an external audio amplifier.
Operations Guide
Section 2.1, "Parts
Figure 2-2 for the connection options that are available for the InformaCast Enabled Paging
Figure 2-2. Connection Options
RCA Line In
Installing the InformaCast Enabled Paging Adapter

Connecting the InformaCast Enabled Paging Adapter

List".
RCA Line Out
Pin 1 Pin2 Pin 3 Pin 4 Pin 5
Section 2.5.9, "Configure the Fault Detection
931767B
Alternate power if
PoE is not available
Pin 6 Pin 7
CyberData Corporation
7
