CyberData Singlewire Paging Adapter 011280 Installation Quick Reference

Mounting
You have the option to use the following mounting template to mark, and then drill two 3/16-inch (0.1875-inch) holes for
the mounting anchors.
To install and mount the Singlewire Paging Adapter:
1. Install the mounting anchors in the holes, and position the Singlewire Paging Adapter mounting holes over the
anchors.
Drill Hole Size for Anchor Installation: 3/16-inch (0.1875-inch)
Dimensions
4.1 [104.0]
© 2013, CyberData Corporation, ALL RIGHTS RESERVED
6.0 [152.4]
Dimensions are in Inches [Millimeters]
Dimensions are in Inches [Millimeter]
930730B Quick Reference
The IP Endpoint Company
Parameter
IP Addressing
a
IP Address
Web Access Username
Web Access Password
a
Subnet Mask
a
Default Gateway
a. Default if there is not a DHCP server present.
Getting Started
• Be sure that you have received all the parts described in the
• Download the Operations Guide at the following website:
http://www.cyberdata.net/products/voip/digitalanalog/singlewirepagingadapter/docs.html
Parts List
(1) Singlewire Paging Adapter
Contacting CyberData
Corporate Headquarters
CyberData Corporation
1.2 [29.6]
3 Justin Court
Monterey, CA 93940, USA
Phone: 831-373-2601
Fax: 831-373-4193
www.CyberData.net
Quick Reference
Installation Quick Reference
Singlewire Paging Adapter
011280
Factory Default Setting
DHCP
10.10.10.10
admin
admin
255.0.0.0
10.0.0.1
Parts List section.
(1) Mounting Template
(see the last page)
Sales: (831) 373-2601 ext. 334
Support: 831-373-2601 ext. 333
Web: http://www.cyberdata.net/support/contactsupportvoip.php
RMA Dept: (831) 373-2601 ext. 136
Email: RMA@CyberData.net
RMA Status: http://www.cyberdata.net/support/rmastatus.html
Warranty and RMA information is available at the following website:
http://www.cyberdata.net/support/warranty/index.html
930730B © 2013, CyberData Corporation, ALL RIGHTS RESERVED
(1) Mounting Kit
(2) #6 x1.25-inch, PanHead,
Phillips Sheet Metal Screw
(2) Plastic Anchors
