Foreword
Congratulations on choosing a SUBARU vehicle. This Owner's Man-
ual has all the information necessary to keep your SUBARU in excel-
lent condition and to properly maintain the emission control system
for minimizing emission pollutants. We urge you to read this manual
carefully so that you may understand your vehicle and its operation.
For information not found in this Owner's Manual, such as details
concerning repairs or adjustments, please contact the dealer from
whom you purchased your SUBARU or the nearest SUBARU dealer.
The information, specifications and illustrations found in this manual
are those in effect at the time of printing. FUJI HEAVY INDUSTRIES
LTD. reserves the right to change specifications and designs at any
time without prior notice and without incurring any obligation to
make the same or similar changes on vehicles previously sold. This
Owner's Manual applies to all models and covers all equipment, in-
cluding factory installed options. Some explanations, therefore may
be for equipment not installed in your vehicle.
Please leave this manual in the vehicle at the time of resale. The next
owner will need the information found herein.
FUJI HEAVY INDUSTRIES LTD., TOKYO, JAPAN
is a registered trademark of FUJI HEAVY INDUSTRIES LTD.
© copyright 2005 FUJI HEAVY INDUSTRIES LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2006 Baja and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Subaru 2006 Baja

Summary of Contents for Subaru 2006 Baja

  • Page 1 Foreword Congratulations on choosing a SUBARU vehicle. This Owner’s Man- ual has all the information necessary to keep your SUBARU in excel- lent condition and to properly maintain the emission control system for minimizing emission pollutants. We urge you to read this manual carefully so that you may understand your vehicle and its operation.
  • Page 2 UBF046AA...

  • Page 4: Warranties For U.s.a

    Warranties Warranties for U.S.A. All SUBARU vehicles distributed by Subaru of Ameri- ca, Inc. and sold at retail by an authorized SUBARU dealer in the United States come with the following warranties: SUBARU Limited Warranty Emission Control Systems Warranty Emissions Performance Warranty All warranty information, including details of coverage and exclusions, is in the “Warranty and Maintenance...

  • Page 5: Seat, Seatbelt And Srs Airbags

    This chapter informs you how to start and operate your SUBARU. Chapter 8: Driving tips This chapter informs you how to drive your SUBARU in various conditions and explains some safety tips on driving. Chapter 9: In case of emergency...

  • Page 6: Index

    Please read these safety warnings as well as all other portions of this manual carefully in order to gain a bet- ter understanding of how to use your SUBARU vehicle safely. A WARNING indicates a situation in which seri- ous injury or death could result if the warning is ignored.

  • Page 7: Safety Precautions When Driving

    ual. This symbol means “Do not”, “Do not do this”, or “Do not let this happen”, depending upon the context. Safety precautions when driving Seatbelt and SRS airbag All persons in the vehicle should fasten their seatbelts BEFORE the vehicle starts to move. Otherwise, the possibility of serious injury be- comes greater in the event of a sudden stop or accident.

  • Page 8: Child Safety

    ment, the driver should always sit upright and well back in the seat as far from the steering wheel as practical while still maintaining full ve- hicle control and the front passenger should move the seat as far back as possible and sit upright and well back in the seat.

  • Page 9: Engine Exhaust Gas (Carbon Monoxide)

    the lock switch when children are riding in the vehicle. Failure to follow this procedure could result in injury to a child operating the power window. Refer to the “Power windows” section in chapter 2. Never leave unattended children in the vehi- cle.

  • Page 10: Drinking And Driving

    Drinking and driving Drinking and then driving is very dangerous. Alcohol in the bloodstream delays your reac- tion and impairs your perception, judgment and attentiveness. If you drive after drinking – even if you drink just a little – it will increase the risk of being involved in a serious or fatal accident, injuring or killing yourself, your passengers and others.

  • Page 11: Driving With Pets

    Driving when tired or sleepy When you are tired or sleepy, your reaction will be delayed and your perception, judgment and attentiveness will be impaired. If you drive when tired or sleepy, your, your passengers’ and other persons’ chances of being involved in a serious accident may increase.

  • Page 12: California Proposition 65 Warning

    rier which can be secured to the rear seat by routing a seatbelt through the carrier’s handle. Never restrain pets or pet carriers in the front passenger’s seat. For further information, consult your veterinarian, local an- imal protection society or pet shop. Tire pressures Driving at high speeds with excessively low tire pressures can cause the tires to deform severe-...

  • Page 14: Table Of Contents

    Table of contents Seat, seatbelt and SRS airbags Keys and doors Instruments and controls Climate control Audio Interior equipment Starting and operating Driving tips In case of emergency Appearance care Maintenance and service Specifications Consumer information and Reporting safety defects Index...

  • Page 15: Wiper Switch (Page

    Illustrated index Exterior 10 9 8 UBF047BB Hood lock release knob (page 11-5) Headlight switch (page 3-20) Bulb replacement (page 11-66) Wiper switch (page 3-26) Moonroof (page 2-36) Roof rail (page 6-36) Door locks (page 2-3) Tire pressure (page 11-47) Flat tires (page 9-12) 10) Tire chains (page 8-16) 11) Fog light button (page 3-24)
  • Page 16 Rear window defogger button (page 3-28) Fuel filler lid (page 7-4) Child safety locks (page 2-24) Towing hook (page 9-23) Tailgate (page 2-28) Tie-down hooks (page 9-2) Bulb replacement (page 11-63) Licence plate bracket (page 2- UBF048BB – CONTINUED –...

  • Page 17: Page

    Interior Passenger compartment area UBF065BB Lower anchorage for child re- straint system (page 2-24) Seatbelt (page 1-14) Parking brake lever (page 7-35) Front seat (page 1-2) Rear seat (page 1-9)

  • Page 18: Moonroof (Page

    Moonroof (page 2-36) Interior lights (page 6-2) Sun visors (page 6-3) Map light (page 6-3) Inside mirror (page 3-30) UBF050BB – CONTINUED –...
  • Page 19 UBF066BB Cup holder (page 6-7) Center console (page 6-5) Glove box (page 6-5) Cigarette lighter (page 6-9) Ashtray (page 6-12) Accessory power outlet (page 6- Rear center console (page 6-6)

  • Page 20: Tie-Down Hooks (Page

    Cargo bed/spare tire/jack UBF067BB Cargo lamp (page 6-20) Cargo tie-down hooks (page 6- Temporary spare tire (page 9- Switchback door (page 2-32) Jack/Maintenance tools (page 9-3) Cargo bed extender (page 6-17) – CONTINUED –...

  • Page 21: Door Locks (Page

    Instrument panel UBF021BB Door locks (page 2-3) Outside mirror (page 3-32) Light control lever (page 3-19) Combination meter (page 3-6) Wiper control lever (page 3-25) Hazard warning flasher switch (page 3-6) Climate control (page 4-1) Gear shift lever (MT) (page 7- 12)/Selector lever (AT) (page 7- Audio (page 5-1) 10) Cruise control (page 7-37)
  • Page 22 Light control and wiper control levers/switches UBF023DB Parking light switch (page 3-23) Windshield wiper (page 3-25) Mist (page 3-26) Windshield washer (page 3-26) Wiper control lever (page 3-26) Illumination brightness control (page 3-23) Light control lever (page 3-19) Headlight ON/OFF (page 3-19) Headlight flasher High/Low beam change (page 3-19) 10) Turn signal (for lane change)

  • Page 23: Combination Meter

    Combination meter Non-turbo models UBF063BB Fuel gauge (page 3-8) Speedometer (page 3-6) Tachometer (page 3-8) Temperature gauge (page 3-9) Clock setting knob (page 3-19) Clock and outside temperature indicator (page 3-19, 3-8) Selector lever position indicator (page 3-17) Trip meter A/B selection and trip meter reset knob (page 3-6) Trip meter and odometer (page 3-6)

  • Page 24: Turbo Models

    Turbo models UBF064BB Fuel gauge (page 3-8) Speedometer (page 3-6) Gear position indicator (page 3- Tachometer (page 3-8) Temperature gauge (page 3-9) Clock setting knob (page 3-19) Clock and outside temperature indicator (page 3-19, 3-8) Selector lever position indicator (page 3-17) Trip meter A/B selection and trip meter reset knob (page 3-6) 10) Trip meter and odometer (page...

  • Page 25: Warning And Indicator Light

    Warning and indicator light Mark Name Seatbelt warning light SRS airbag system warning light CHECK ENGINE warning light/Malfunction indicator lamp Charge warning light Oil pressure warning light AT OIL temperature warning light (if equipped) ABS warning light Brake system warning light Door ajar warning light Mark Page...
  • Page 26 Front seats ... Fore and aft adjustment ... Seat cushion angle and height adjustment (Power seat only) ... Reclining the seatback ... Head restraint adjustment ... Lumbar support (if equipped) ... Seat heater (if equipped) ... Rear seats ... Rear headrest ... Folding down the rear seat ...

  • Page 27: Seat, Seatbelt And Srs Airbags

    Seat, seatbelt and SRS airbags Front seats Seat, seatbelt and SRS airbags Never adjust the seat while driving to avoid the possibility of loss of vehicle control and of personal injury. Before adjusting the seat, make sure the hands and feet of rear seat passengers are clear of the adjusting mechanism.

  • Page 28: Fore And Aft Adjustment

    restrained or improperly restrained. Because children are lighter and weaker than adults, their risk of being injured from deployment is greater. Consequently, we strongly recom- mend that ALL children (including those in child seats and those that have outgrown child restraint devices) sit in the REAR seat properly restrained at all times in a child restraint device or in a seatbelt, whichever is appropriate for the...

  • Page 29: Seat Cushion Angle And Height Adjustment (Power Seat Only)

    Seat, seatbelt and SRS airbags Manual type Pull the lever upward and slide the seat to the desired position. Then release the lever and move the seat- back and forth to make sure that it is securely locked into place. Seat cushion angle and height adjust- ment (Power seat only) UB1058BA...

  • Page 30: Reclining The Seatback

    To adjust the angle and height of the seat cushion, move the control switch in the corresponding direction. Seat, seatbelt and SRS airbags Reclining the seatback UB1062BA Pull the reclining lever up and adjust the seatback to the desired position. Then release the lever and make sure the seat is securely locked into place.

  • Page 31: Head Restraint Adjustment

    Seat, seatbelt and SRS airbags To prevent the passenger from sliding under the seatbelt in the event of a collision, always put the seatback in the upright position while the vehicle is in motion. Also, do not place ob- jects such as cushions between the passenger and the seatback.

  • Page 32: Lumbar Support (If Equipped)

    the vehicle is struck from the rear. Lumbar support (if equipped) Pull the lever forward or backward. Pulling the lever forward will increase the amount of support for your lower back. Seat, seatbelt and SRS airbags Seat heater (if equipped) 1) Heating element UB1059BA The seat heater operates when the ignition switch is...
  • Page 33 Seat, seatbelt and SRS airbags 1) Indicator light To turn on the seat heater, push the “LO” or “HI” posi- tion on the switch, as desired, depending on the tem- perature. Selecting the “HI” position will make the seat to heat up quickly. LO: Normal heating HI: Rapid heating The indicator located on the switch comes on when...

  • Page 34: Rear Seats

    Rear seats Seatbelts provide maximum restraint when the occupant sits well back and upright in the seat. Do not put cushions or any other materi- als between occupants and seatbacks or seat cushions. If you do so, the risk of sliding under the lap belt and of the lap belt sliding up over the abdomen will increase, and both can result in serious internal injury or death.

  • Page 35: Folding Down The Rear Seat

    Seat, seatbelt and SRS airbags Folding down the rear seat After returning the rear seat to its original po- sition, be certain to place all of the seatbelts and the tab attached to the seat cushion above the seat cushion. And make certain that the shoulder belts are fully visible.
  • Page 36 Folding down the seatback Before folding down the seatback, check that there is nothing in the seatback pocket. If there is something in the pocket, it could be damaged or cause damage to the seatback and rear cen- ter console when the seatback is folded. A) LOCK B) UNLOCK 1) Red...
  • Page 37 Seat, seatbelt and SRS airbags Folding down the seat cushion and seatback Before folding down the seatback, check that there is nothing in the seatback pocket. If there is something in the pocket, it could be damaged or cause damage to the seatback and rear cen- ter console when the seatback is folded.
  • Page 38 A) LOCK B) UNLOCK 1) Red Seat, seatbelt and SRS airbags UB1112CB 4. Unlock the seatback by pulling the release knob up and fold the seatback down. Confirm that the pin locat- ed at the bottom of the seat cushion is inserted into the slot at the top of the seatback.

  • Page 39: Seatbelts

    Seat, seatbelt and SRS airbags place and make sure that they are securely locked. Make sure that the rear seatbelt buckles are not under the seat cushion or seatback, when returning the seat cushion and the seatback to their original position. Confirm that the rear seatbelts are stored in the seatbelt pocket prior to returning the seat cush- ion to its original position.
  • Page 40 cially if they are 12 years of age and under and are not restrained or improperly restrained. Be- cause children are lighter and weaker than adults, their risk of being injured from deploy- ment is greater. Consequently, we strongly rec- ommend that ALL children (including those in child seats and those that have outgrown child restraint devices) sit in the REAR seat properly...

  • Page 41: Emergency Locking Retractor (Elr)

    Seat, seatbelt and SRS airbags Expectant mothers Expectant mothers also need to use the seatbelts. They should consult their doctor for specific recom- mendations. The lap belt should be worn securely and as low as possible over the hips, not over the waist. Emergency Locking Retractor (ELR) The driver’s seatbelt has an Emergency Locking Re- tractor (ELR).

  • Page 42: Seatbelt Warning Light And Chime

    Seatbelt warning light and chime Your vehicle is equipped with a seatbelt warning de- vice at the driver’s seat, as required by current safety standards. There is a seatbelt warning light in the combination meter. This device causes the seatbelt warning light on the instrument panel to light up for approximately six sec- onds when the ignition switch is turned to the “ON”...

  • Page 43: Front Seatbelts

    Seat, seatbelt and SRS airbags Never place the shoulder belt under the arm or behind the back. If an accident occurs, this can increase the risk or severity of injury. Metallic parts of the seatbelt can become very hot in a vehicle that has been closed up in sun- ny weather;...
  • Page 44 5. To make the lap part tight, pull up on the shoulder belt. 6. Place the lap belt as low as possible on your hips, not on your waist. Seat, seatbelt and SRS airbags Adjusting the front seat shoulder belt anchor height HS1051BA The shoulder belt anchor height should be adjusted to...

  • Page 45: Unfastening The Seatbelt

    Seat, seatbelt and SRS airbags When wearing the seatbelts, make sure the shoulder portion of the webbing does not pass over your neck. If it does, adjust the seatbelt an- chor to a lower position. Placing the shoulder belt over the neck may result in neck injury dur- ing sudden braking or in a collision.

  • Page 46: Seatbelt Maintenance

    4. To make the lap part tight, pull up on the shoulder belt. 5. Place the lap belt as low as possible on your hips, not on your waist. Seat, seatbelt and SRS airbags Unfastening the seatbelt HS1051BA Push the button on the buckle. Before closing the door, make sure that the belts are retracted properly to avoid catching the belt webbing in the door.

  • Page 47: Seatbelt Extender

    SUBARU dealer. When ordering an extender, only or- der one particularly designed for your vehicle. Several different types of extenders are available to match var- ious varieties of front seatbelt designs.
  • Page 48 extender. Do not use the extender if the buckle of the extender rests over the abdomen. Do not let someone else use the extender. Use of an extender when it is not needed could reduce the effectiveness of the seatbelt and re- sult in more serious injury in the event of a col- lision.

  • Page 49: Front Seatbelt Pretensioners

    In the event that a preten- sioner is activated, both the driver’s and front pas- senger’s seatbelt retractor assemblies must be re- placed and only by an authorized SUBARU dealer. When replacing seatbelt retractor assemblies, use only genuine SUBARU parts.

  • Page 50: System Monitors

    If the front seatbelt retractor assembly or sur- rounding area has been damaged, contact your SUBARU dealer as soon as possible. When you sell your vehicle, we urge you to ex- plain to the buyer that it has seatbelt pretension- ers by alerting the buyer to the contents of this section.

  • Page 51: System Servicing

    SRS airbag sys- tem. Immediately take your vehicle to your nearest SUBARU dealer to have the system checked. Unless checked and properly re- paired, the seatbelt pretensioners and/or SRS...

  • Page 52: Precautions Against Vehicle Modification

    SUBARU dealer as soon as possible. Precautions against vehicle modifica- tion Always consult your SUBARU dealer if you want to in- stall any accessory parts to your vehicle. Do not perform any of the following modifica- tions. Such modifications can interfere with proper operation of the seatbelt pertensioners.

  • Page 53: Child Restraint Systems

    Seat, seatbelt and SRS airbags Child restraint systems Infants and small children should always be placed in an infant or child restraint system in the rear seat while riding in the vehicle. You should use an infant or child restraint system that meets Federal Motor Vehicle Safety Standards or Canada Motor Vehicle Safety Standards, is compatible with your vehicle and is ap- propriate for the child’s age and size.

  • Page 54: Where To Place A Child Restraint System

    Where to place a child restraint system The following are SUBARU’s recommendations on where to place a child restraint system in your vehicle. HS1070BA – CONTINUED –...
  • Page 55 Seat, seatbelt and SRS airbags A: Front passenger’s seat You should not install a child restraint system (includ- ing a booster seat) due to the hazard to children posed by the passenger’s airbag. B: Rear seat Recommended positions for all types of child restraint systems.

  • Page 56: Choosing A Child Restraint System

    SINCE YOUR VEHICLE IS EQUIPPED WITH A PASSENGER’S SRS AIRBAG, DO NOT IN- STALL A REARWARD FACING CHILD SAFETY SEAT IN THE FRONT PASSENGER’S SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD’S HEAD TOO CLOSE TO THE SRS AIRBAG. Seat, seatbelt and SRS airbags Choosing a child restraint system HS1072BA...

  • Page 57: Installing Child Restraint Systems With A/Elr Seatbelt

    Seat, seatbelt and SRS airbags Installing child restraint systems with A/ELR seatbelt Child restraint systems and seatbelts can be- come hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check the child restraint system before you place a child in it.
  • Page 58 4. Take up the slack in the lap belt. 5. Pull out the seatbelt fully from the retractor to change the retractor over from the Emergency Lock- ing Retractor (ELR) to the Automatic Locking Retrac- tor (ALR) function. Then, allow the belt to rewind into the retractor.
  • Page 59 Seat, seatbelt and SRS airbags 8. To remove the child restraint system, press the re- lease button on the seatbelt buckle and allow the belt to retract completely. The belt will return to the ELR mode. NEVER INSTALL A REARWARD FACING CHILD SEAT IN THE FRONT PASSENGER’S SEAT.
  • Page 60 position. If it is not held tight and secure, the danger of your child suffering personal injury in the event of an accident may be increased. 1. Place the child restraint system in the seating posi- tion on the rear seat cushion. Seat, seatbelt and SRS airbags 2.
  • Page 61 Seat, seatbelt and SRS airbags 3. Connect the tether belt hook onto the tether an- chorage on the backside of the seatback. Take up any slack in the tether belt after connecting it to the tether anchorage. 1-36 UB1144BA 4. Put the other end of the tether belt through under the headrest.
  • Page 62 Seat, seatbelt and SRS airbags 8. Take up the slack in the lap belt. 9. Pull out the seatbelt fully from the retractor to change the retractor over from the Emergency Lock- ing Retractor (ELR) to the Automatic Locking Retrac- tor (ALR) function.
  • Page 63 ELR mode. 1-38 If you have any question concerning proper child re- straint system installation, ask your SUBARU dealer. NOTE When the child restraint system is no longer in use, remove it and restore the ELR function of the retractor.
  • Page 64 3. Insert the tongue plate into the buckle. Seat, seatbelt and SRS airbags 4. Take up the slack in the lap belt. 5. Pull out the seatbelt fully from the retractor to change the retractor over from the Emergency Lock- ing Retractor (ELR) to the Automatic Locking Retrac- tor (ALR) function.

  • Page 65: Installation Of Child Restraint Systems By Use Of Lower And Tether Anchorages (Latch)

    The belt will return to ELR mode. If you have any question concerning proper child re- straint system installation, ask your SUBARU dealer. NOTE When the child restraint system is no longer in use, remove it and restore the ELR function of the retractor.
  • Page 66 Some types of child restraint systems can be installed on the rear seat of your vehicle without use of the seat- belts. Such child restraint systems are secured to the dedicated anchorages provided on the vehicle body. The lower and tether anchorages are sometimes re- ferred to as the LATCH system (Lower Anchors and Tethers for CHildren).
  • Page 67 Seat, seatbelt and SRS airbags Each lower anchorage is located where the seat cush- ion meets the seatback. 1. Place the child restraint system on the rear seat cushion. 1-42 UB1133BA 2. Unlock the rear seatback locking knob and fold the seatback forward to see the tether anchorages on the backside of the seatback.
  • Page 68 3. Connect the hook of the upper tether belt onto the tether anchorage on the backside of the seatback. Do not allow slack in the tether belt. Seat, seatbelt and SRS airbags UB1144BA 4. Put the other end of the tether belt through under the headrest.
  • Page 69 Seat, seatbelt and SRS airbags 6. While following the instructions supplied by the child restraint system manufacturer, connect the lower hooks onto the lower anchorages located at “ marks on the bottom of the rear seatback. When the hooks are connected, make sure the adjacent seat- belts are not caught.

  • Page 70: Installing A Booster Seat

    11.To remove the child restraint system, follow the re- verse procedures of installation. If you have any question concerning proper child re- straint system installation, ask your SUBARU dealer. Seat, seatbelt and SRS airbags Installing a booster seat Child restraint systems and seatbelts can be- come hot in a vehicle that has been closed up in sunny weather;...
  • Page 71 Seat, seatbelt and SRS airbags the event of an accident may be increased. 1. Place the booster seat in the rear seating position and sit the child on it. The child should sit well back on the booster seat. 2. Run the lap and shoulder belt through or around the booster seat and the child following the instruc- tions provided by its manufacturer.

  • Page 72: Srs Airbag (Supplemental Restraint System Airbag)

    effective in preventing or reducing injury. Place the lap belt as low as possible on the child’s hips. A high-positioned lap belt will in- crease the risk of sliding under the lap belt and of the lap belt sliding up over the abdomen, and both can result in serious internal injury or death.
  • Page 73 Seat, seatbelt and SRS airbags To obtain maximum protection in the event of an accident, the driver and all passengers in the vehicle should always wear seatbelts when the vehicle is moving. The SRS airbag is designed only as a supplement to the primary protection provided by the seatbelt.
  • Page 74 Put children aged 12 and under in the rear seat properly restrained at all times. The SRS airbag deploys with considerable speed and force and can injure or even kill children, especially if they are 12 years of age and under and are not restrained or improperly restrained.
  • Page 75 Seat, seatbelt and SRS airbags When the SRS airbag deploys, some smoke will be released. This smoke could cause breathing problems for people with a history of asthma or other breathing trouble. If you or your passengers have breathing problems after SRS airbag deploys, get fresh air promptly.
  • Page 76 Components Airbag control module (including impact sensors) Airbag module (driver’s side) Airbag module (passenger’s side) Front sub sensor (left-hand side) Front sub sensor (right-hand side) Seatbelt pretensioner (driver’s side) Seatbelt pretensioner (passen- ger’s side) UB1135BB Seat, seatbelt and SRS airbags –...

  • Page 77: Srs Frontal Airbag

    Seat, seatbelt and SRS airbags SRS frontal airbag The driver’s SRS frontal airbag is stowed in the center portion of the steering wheel. The passenger’s SRS frontal airbag is stowed near the top of the dashboard under an “SRS AIRBAG” mark. In a moderate to severe frontal collision, the driver’s and front passenger’s SRS frontal airbags deploy and supplement the seatbelts by reducing the impact on...
  • Page 78 Never hold a child on your lap or in your arms. The SRS airbag deploys with considerable force and can injure or even kill the child. Seat, seatbelt and SRS airbags HS1069BA The SRS airbag deploys with considerable speed and force. Occupants who are out of proper position when the SRS airbag deploys could suffer very serious injuries.
  • Page 79 Seat, seatbelt and SRS airbags avoid injuries that can result when the SRS air- bag contacts an occupant not in proper posi- tion such as one thrown toward the front of the vehicle during pre-accident braking. Do not put any objects over the steering wheel pad and dashboard.
  • Page 80 Operation A) Driver’s side B) Passenger’s side 1) SRS airbags deploy as soon as a collision occurs. 2) After deployment, SRS airbags start to deflate immediately so that the driver’s vision is not obstructed. Seat, seatbelt and SRS airbags HS1087BB –...
  • Page 81 Seat, seatbelt and SRS airbags The SRS airbag can function only when the ignition switch is in the “ON” position. If the front sub sensors inside the both front fenders and the impact sensors in the airbag control module detect a certain predetermined amount of force during a frontal collision, the control module sends signals to the frontal airbag modules instructing them to inflate the SRS frontal airbags.
  • Page 82 experienced in the passenger compartment during a collision. That level differs from one type of collision to another, and it may have no bearing on the visible damage done to the vehicle itself. Examples of accident in which the SRS frontal airbag will most likely deploy.
  • Page 83 Seat, seatbelt and SRS airbags The SRS frontal airbag may be activated when the ve- hicle sustains a hard impact in the undercarriage area from the road surface (such as when the vehicle plunges into a deep ditch, is severely impacted or knocked hard against an obstacle on the road such as a curb).
  • Page 84 or sign pole, or if it slides under a truck’s load bed, or if it sustains an oblique offset frontal impact, the SRS frontal airbag may not deploy depending on the level of accident forces involved. Seat, seatbelt and SRS airbags Examples of the types of accidents in which the SRS frontal airbag will basically not deploy.

  • Page 85: Srs Airbag System Monitors

    Seat, seatbelt and SRS airbags in a low-speed frontal collision. 1) First impact! 2) Second impact!! In an accident where the vehicle is impacted more than once, the SRS frontal airbag deploys only once. Example: In the case of a double collision, first with an- other vehicle, then against a concrete wall in immedi- ate succession, once the SRS frontal airbag is activat- ed on the first impact, it will not be activated on the...

  • Page 86: Srs Airbag System Servicing

    SRS airbag sys- tem. Immediately take your vehicle to your nearest SUBARU dealer to have the system checked. Unless checked and properly re- paired, the seatbelt pretensioners and/or SRS...

  • Page 87: Precautions Against Vehicle Modification

    SUBARU parts. To ensure their long-term reliability, the SRS airbags must be inspected by a SUBARU dealer ten years af- ter the date of manufacture, which is shown on the cer- tification label attached to the driver’s door.
  • Page 88 Owner’s Manual. Always consult your SUBARU dealer if you want to in- stall any accessory parts on your vehicle. Seat, seatbelt and SRS airbags – CONTINUED –...
  • Page 90 Keys ... Key number ... Door locks ... Locking and unlocking from the outside ... Locking and unlocking from the inside ... Power door locking switches ... Remote keyless entry system ... Locking the doors ... Unlocking the doors ... Illuminated entry ...

  • Page 91: Keys And Doors

    Keys and doors Keys Keys and doors Keys 1) Master key 2) Submaster key 3) Valet key 4) Key number plate Three types of keys are provided for your vehicle. Master key, submaster key and valet key. The master key and submaster key fit all locks on your vehicle.

  • Page 92: Door Locks

    Door locks Door locks Locking and unlocking from the out- side To lock the driver’s door from the outside with the key, insert the key into the keyhole and turn the key toward the rear. To unlock the door, turn the key toward the front.

  • Page 93: Locking And Unlocking From The Inside

    Keys and doors Locking without the key 1) Push the power door locking switch forward. 2) Close the door. To lock the door from the outside without the key, ro- tate the lock lever rearward and then close the door. To lock the door from the outside using the power door locking switch, push the switch forward (“LOCK”...

  • Page 94: Power Door Locking Switches

    1) Lock 2) Unlock To lock the door from the inside, rotate the lock lever rearward. To unlock the door from the inside, rotate the lock lever forward. The red mark on the lock lever appears when the door is unlocked. Pull the inside door handle to open an unlocked door.
  • Page 95 Keys and doors Front passenger’s switch 1) Lock 2) Unlock All doors can be locked and unlocked by the power door locking switches located at the driver’s side and the front passenger’s side doors. To lock the doors, push the switch forward. To unlock the doors, push the switch rearward.

  • Page 96: Remote Keyless Entry System

    Remote keyless entry system Remote keyless entry system Two transmitters are provided for your vehicle. The remote keyless entry system has the following functions. Locking and unlocking the doors without a key Sounding a panic alarm Arming and disarming the alarm system. See the next section “Alarm system”...

  • Page 97: Locking The Doors

    Keys and doors : LOCK/ARM button Press to Lock all doors. Press and Hold to activate panic alarm. Press three times in a five-second period to use vehicle finder function. : UNLOCK/DISARM button 1) Press once to Unlock driver’s door. 2) Press a second time to Unlock all other doors.

  • Page 98: Illuminated Entry

    Illuminated entry The interior dome light and ignition switch light will illu- Illuminated entry minate when the “ ” button is pressed. These lights stay illuminated for approximately 30 seconds if any of the doors is not opened. If the “ ”...

  • Page 99: Replacing The Battery

    If this happens, repeat the whole procedure from Step 1. You may have the above settings done by your SUBARU dealer. Replacing the battery When the transmitter battery begins to get weak, Replacement (Remote keyless entry system)
  • Page 100 2. Separate the case. 3. Remove the old battery from the holder. UB2209BA 1) Negative (–) side facing up 4. Replace with a new battery (Type CR2025 or equivalent) making sure to install the new battery with the negative (–) side facing up. 5.

  • Page 101: Replacing Lost Transmitters

    Keys and doors Do not let dust, oil or water get on or in the transmitter when replacing the battery. Be careful not to damage the printed circuit board in the transmitter when replacing the bat- tery. Replacing lost transmitters If you lose a transmitter or want to purchase additional Replacing Lost transmitters (keyless entry system)
  • Page 102 Keys and doors 3. Perform the following steps within 45 seconds. UB2209BA 200813 Transmitter circuit board 1) Open and close the driver’s door once. To register a new transmitter with the keyless entry system, it is necessary to program the transmitter’s code (identification number) into the system.
  • Page 103 Keys and doors 1) ON 2) LOCK 2) Insert the key into the ignition switch, then turn it from the “LOCK” position to the “ON” position 10 times within 15 seconds. NOTE When you complete step 2), an electronic tone will sound once.
  • Page 104 times if the leftmost digit of the code is 8. NOTE The electronic tone will stop sounding when you start entering the number. If you do not start entering the number using the locking switch before the electronic tone stops sounding, an error will occur.
  • Page 105 Keys and doors with the second digit (counting from the left) and finish- ing with the eighth digit. NOTE When you finish entering the eighth digit, an electronic tone will sound for 30 seconds. If the interval between one push of the switch and the next exceeds five seconds, an error will occur.

  • Page 106: Alarm System

    Your vehicle’s alarm system has been set for activa- tion at the time of shipment from the factory. You can set the system for deactivation yourself or have it done by your SUBARU dealer. System operation The alarm system will give the following alarm when triggered: The vehicle’s horn will sound and the turn signal...

  • Page 107: Activating And Deactivating The Alarm System

    The horn sounds once, indicating that the system is 2-18 now activated. NOTE You may have the above setting change done by your SUBARU dealer. If you have accidentally triggered the alarm system To stop the alarm Do any of the following operations: Press any button on the remote transmitter.
  • Page 108 UG2042BA : Press to Arm the system. : Press to Disarm the system. Keys and doors 1) Security indicator light 6. Briefly press the “ ” button (for less than two sec- onds). All doors will lock, an electronic chirp will sound once, the turn signal lights will flash once, and the in- dicator lights will start flashing rapidly.
  • Page 109 Always make sure that they are fully closed before arming the system. The 30-second standby time can be eliminated if you prefer. Have it performed by your SUBARU dealer. The system is in the standby mode for a 30-sec- ond period after locking the doors with the remote transmitter.

  • Page 110: Disarming The System

    Note that in this mode, DOORS MUST BE MANUALLY LOCKED. To enter the passive mode If you wish to program the passive arming mode, have it done by your SUBARU dealer. – CONTINUED – 2-21...
  • Page 111 Keys and doors Arming the system 1. Turn the ignition switch to the “ON” position. 1) ON 2) LOCK 2. Turn the ignition switch from “ON” to “LOCK” posi- tion and remove the key from the ignition switch. 2-22 3. Open the doors and get out of the vehicle. HS2024BC 4.

  • Page 112: Tripped Sensor Identification

    30 seconds. If you desire, your SUBARU dealer can connect them and set them for activation or deactivation. NOTE...

  • Page 113: Child Safety Locks

    Example: Vibration from construction site Vibration in multistory car park Vibration from trains You can have the sensitivity of the shock sen- sors adjusted to your preference by your SUBARU dealer. 2-24 Child safety locks Child safety Locks Always use the child safety lock whenever a child rides in the rear seat.

  • Page 114: Windows

    the doors from being opened even if the inside door handle is pulled. When the child safety lock lever is in the lock position, the door cannot be opened from inside regardless of the position of the inner door handle lock lever. The door can only be opened from the outside.
  • Page 115 Keys and doors Driver’s side switches 1) Lock switch 2) For driver’s window 3) For rear left passenger’s window 4) For front passenger’s window 5) For rear right passenger’s window All door windows can be controlled by the power win- dow switch cluster at the driver side door.
  • Page 116 way, pull the switch up lightly. To close: Pull the switch up lightly and hold it. The window will close as long as the switch is held. Operating the passengers’ windows To open the passengers’ windows, push the appropri- ate switch down and hold it until the window reaches the desired position.

  • Page 117: Tailgate

    Tailgate Keep the tailgate closed when the vehicle is moving. If you must drive with the tailgate open, use the optional SUBARU Bed Extender and place the License Plate Bracket at its fully lowered/open position. Cargo must not stick out beyond the Extender. Otherwise a danger- ous road hazard or personal injury could result.
  • Page 118 Keys and doors upper surface of the rear bumper to avoid damaging Vehicle with hard bed cover: the tailgate. Vehicle without hard bed cover: To open the tailgate, lift up on its handle while pulling the tailgate toward you. The support cables hold the tailgate open.

  • Page 119: License Plate Bracket

    Keys and doors 1) Straps 2) Cargo tie-down hooks If you are going to drive with the optional SUBARU Bed Extender installed, the rear section of the hard bed cover must be secured before starting to drive. Release the two straps at the back of the rear section of the cover.
  • Page 120 To use the license plate bracket at its lowered/open position, push the two release buttons and pull the li- cense plate bracket up until it clicks. And then open the tailgate. If your vehicle is equipped with a trailer hitch, remove the ball mount from the hitch receiver tube before opening the tailgate.

  • Page 121: Switchback Door

    Keys and doors Switchback door Switchback door With the switchback door open, you can increase the usable cargo space and can carry long objects. Secure long objects properly to prevent them from sliding forward and causing serious injury during a sudden stop or sharp cornering. Tie long objects down with a rope or something equivalent.
  • Page 122 1) Red A) LOCK B) UNLOCK UB1112CB 2. Unlock the rear seatback by pulling up on the knob and fold down the rear seatback. Confirm that the pins located at the bottom of the seat cushion is inserted into the slots at the top of the seatback. Keys and doors UB1113BA –...
  • Page 123 Keys and doors 3. Fold down the switchback door by releasing the 2-34 lock knob. Then you can have a flat and larger cargo space. 4. Place the long object on the cargo bed through the switchback door opening. Be sure all items are secured in place. NOTE When opening the switchback door in snow, ac- cumulated snow in the cargo bed may enter the...

  • Page 124: Switchback Door Indicator Light

    the vehicle body that prevent the door from ful- ly closing or that crimp the weather strip around the door. To close the switchback door, firmly push it upward until it latches. Return the seatback and seat cushion to their original positions and make sure they are securely locked.

  • Page 125: Moonroof (If Equipped)

    Keys and doors Moonroof (if equipped) Moonroof Never let anyone’s hands, arms, head or any objects protrude from the moonroof. A person could be seriously injured if the vehicle stops suddenly or turns sharply or if the vehicle is in- volved in an accident.

  • Page 126: Sun Shade

    roof is fully closed. Push the rear side of the “Tilt” switch to raise the moonroof. Push the front side of the “Tilt” switch to lower the moonroof. Release the switch after the moonroof has been raised or has been lowered completely. Pushing the switch continuously may cause damage to the moon- roof.
  • Page 128 Ignition switch ... LOCK ... ACC ... ON ... START ... Key reminder chime ... Ignition switch light (if equipped) ... Key interlock release (AT vehicles) ... Hazard warning flasher ... Meters and gauges ... Speedometer ... Odometer/Trip meter ... Tachometer ...

  • Page 129: Ignition Switch

    Instruments and controls Ignition switch Instruments and controls Ignition switch Never turn the ignition switch to “LOCK” while the vehicle is being driven or towed be- cause that will lock the steering wheel, prevent- ing steering control. And when the engine is turned off, it takes a much greater effort than usual to steer.

  • Page 130: Instruments And Controls

    holder is attached to the key, your knees or hands may accidentally touch it in a way that turns the ig- nition switch. LOCK The key can only be inserted or removed in this posi- tion. The ignition switch will lock the steering wheel when you remove the key.

  • Page 131: Manual Transmission Vehicles

    Instruments and controls Manual transmission vehicles The key can be turned from “ACC” to “LOCK” only when the key is pushed in while turning it. In this position the electrical accessories (radio, ciga- rette lighter socket, etc.) can be used. This is the normal operating position after the engine is started.

  • Page 132: Key Interlock Release (At Vehicles)

    2. Remove the cover under the steering column using a Phillips screwdriver. 3. Turn the ignition key while pressing the key inter- lock release lever. Take your vehicle to the nearest SUBARU dealer im- HS3016BA mediately to have the key interlock system repaired. Instruments and controls UG3025BA –...

  • Page 133: Hazard Warning Flasher

    Instruments and controls Hazard warning flasher Hazard warning flasher The hazard warning flasher is used to warn other driv- ers when you have to park your vehicle under emer- gency conditions. The hazard warning flasher works with the ignition switch in any position. To turn on the hazard warning flasher, push the haz- ard warning button on the instrument panel.
  • Page 134 1) Trip meter 2) Odometer Odometer The odometer shows the total distance that the vehicle has been driven. Double trip meter UB3026BB 1) A trip meter 2) B trip meter The trip meter shows the distance that the vehicle has been driven since you last set it to zero.

  • Page 135: Tachometer

    Instruments and controls more than 1 second. NOTE If the connection between the combination meter and battery is broken for any reason such as vehi- cle maintenance or fuse replacement, the data re- corded on the trip meter will be lost. Tachometer Tachometer Do not operate the engine with the pointer of...

  • Page 136: Temperature Gauge

    The fuel gauge shows the approximate amount of fuel remaining in the tank. The gauge does not return to “E” even though the ig- nition switch is in the “ACC” or “LOCK” position. The gauge may move slightly during braking, turning or acceleration due to fuel level movement in the tank.
  • Page 137 Instruments and controls See “In case of emergency” in chapter 9. 1) Normal operating range The temperature gauge shows engine coolant temper- ature when the ignition switch is in the “ON” position. The coolant temperature will vary in accordance with the outside temperature and driving conditions.

  • Page 138: Warning And Indicator Lights

    If any lights fail to come on, it indicates a burned-out bulb or a malfunction of the corresponding system. Consult your authorized SUBARU dealer for repair. Seatbelt warning light and chime When the ignition switch is turned to the “ON” position,...

  • Page 139: Check Engine Warning Light/Malfunction Indicator Lamp

    Warning lights If the CHECK ENGINE light comes on while you are driving, have your vehicle checked/repaired by your SUBARU dealer as soon as possible. Continued vehicle operation without having the emission control system checked and repaired as necessary could cause serious damage, which may not be covered by your vehicle’s...

  • Page 140: Charge Warning Light

    If the belt is loose, broken or if the belt is in good condition but the light remains on, contact your nearest SUBARU deal- er immediately. Instruments and controls...

  • Page 141: Abs Warning Light

    Automatic transmission control system warn- If the light flashes after the engine starts, it may indi- cate that the automatic transmission control system is not working properly. Contact your nearest SUBARU dealer for service immediately. ABS warning light The ABS warning light comes on when the ignition...

  • Page 142: Brake System Warning Light

    “MIN” mark in the reservoir, do not drive the vehicle. Have the vehicle towed to the near- est SUBARU dealer for repair. Door ajar warning lights The specific door ajar warning light comes on if any...

  • Page 143: Low Fuel Warning Light

    Instruments and controls Low fuel warning light The low fuel warning light comes on when the tank is nearly empty approximately 2.6 US gal (10.0 liters, or 2.2 Imp gal). It only operates when the ignition switch is in the “ON” position. NOTE This light does not go out unless the tank is re- plenished up to an internal fuel quantity of approx-...

  • Page 144: Security System Status Indicator Light (If Equipped)

    Security system status indicator light (if equipped) This light is found at the bottom center of the combina- tion meter panel. On vehicles equipped with a security system, it blinks to show the driver the operational status of the security system.

  • Page 145: High Beam Indicator Light

    “ACC” or “LOCK” position, and then turn it again to the “ON” position. If this indicator light and the “ light flash simultaneously during driving, have the vehicle checked by your nearest SUBARU dealer. ” indicator...

  • Page 146: Clock

    Clock Clock To set the time, turn the setting knob clockwise to ad- vance and counterclockwise to retard the time. To ensure safety, do not attempt to set the time while driving, as an accident from inadequate attention to the road could result. Light control switch Light control switch To prevent battery discharge resulting from ac-...

  • Page 147: Headlights

    Instruments and controls Headlights Headlights To turn on the headlights, turn the knob on the end of the turn signal lever. first position Parking lights, instrument panel illumination, tail lights and license plate light are on. second position Headlights, parking lights, instrument panel illumina- tion, tail lights, and license plate light are on.

  • Page 148: Headlight Flasher

    Headlight flasher Headlight flasher Do not hold the lever in the flashing position for more than just a few seconds. To flash the headlights, pull the lever toward you and then release it. The high beam will stay on for as long as you hold the lever.

  • Page 149: Turn Signal Lever

    Instruments and controls Turn signal lever Turn signal lever 1) Right turn 2) Left turn To activate the right turn signal, push the turn signal le- ver up. To activate the left turn signal, push the turn signal lever down. When the turn is finished, the lever will return automatically.

  • Page 150: Illumination Brightness Control

    Illumination brightness control Illumination brightness control 1) Brighten 2) Darken When the lighting switch is in the “ position, you can adjust brightness of the instrument panel illumination for better visibility. To brighten, turn the control dial counterclockwise. To darken, turn the control dial clockwise. Parking light switch Parking Light switch...

  • Page 151: Front Fog Light Button

    Instruments and controls that will run down the battery. 3-24 Front fog light button Front fog light button The front fog lights operate only when the headlights are on low beam. Push the front fog light button to turn the front fog lights on. Press the button again to turn them off.

  • Page 152: Wiper And Washer

    Use clean water if windshield washer fluid is unavailable. In areas where water freezes in winter, use SUBARU Windshield Washer Fluid or the equivalent. (See “Windshield washer flu- id” section in chapter 11.)

  • Page 153: Windshield Wiper And Washer Switches

    Instruments and controls blades. NOTE The wiper operates only when the ignition switch is in the “ON” or “ACC” position. Clean your wiper blades and window glass peri- odically with a washer solution to prevent streak- ing, and to remove accumulations of road salt or road film.
  • Page 154 To turn the wipers off, return the lever to the “OFF” po- sition. Mist (for a single wipe) For a single wipe of the wipers, pull the lever toward you. The wipers operate until you release the lever. Wiper intermittent time control (if equipped) When the wiper switch is in the “...

  • Page 155: Rear Window Defogger Button

    Instruments and controls Rear window defogger button Defogger button Rear window Do not use sharp instruments or window cleaner containing abrasives to clean the inner surface of the rear window. They may damage the conductors printed on the window. To prevent the battery from being dis- charged, do not operate the defogger continu- ously for any longer than necessary.

  • Page 156: Windshield Wiper Deicer (If Equipped)

    Windshield wiper deicer (if equipped) Windshield Wiper deicer To prevent the battery from being discharged, do not operate the windshield wiper deicer con- tinuously for any longer than necessary. The windshield wiper deicer operates only when the ignition switch is in the “ON” position. Before turning on the windshield wiper deicer, remove any snow from the windshield.

  • Page 157: Mirrors

    Instruments and controls Mirrors Mirrors Always check that the inside and outside mirrors are properly adjusted before you start driving. Inside mirror Inside mirror 1) Tab The inside mirror has a day and night position. Pull the tab at the bottom of the mirror toward you for the night position.
  • Page 158 will illuminate. By pressing and releasing the right button, the com- pass display is toggled on or off. When the compass is on, an illuminated compass reading will appear in the lower part of the mirror. Even with the mirror in anti-glare mode, the mirror sur- face turns bright if the transmission is shifted into re- verse.

  • Page 159: Outside Mirrors

    Instruments and controls Compass zone adjustment 1. The zone setting is factory preset to Zone 8. Refer to the “Compass calibration zone” map at the end of this manual to verify that the compass zone setting is correct for your geographical location. 2.
  • Page 160 1) Selection switch 2) Direction control switch 1. Press either end of the selection switch, “L” for the left, “R” for the right. 2. Move the direction control switch in the direction you want to move the mirror. 3. Return the selection switch to the neutral position to prevent unintentional operation.

  • Page 161: Tilt Steering Wheel

    Instruments and controls The indicator light located on the button will come on when the outside mirror defogger heater in operation. To turn it off, push the button again. 3-34 Tilt steering wheel Tilt steering wheel Do not adjust the steering wheel tilt position while driving.

  • Page 162: Horn

    place. 5. Make sure that the steering wheel is securely locked by moving it up and down. Instruments and controls Horn Horn To sound the horn, push the horn pad. HS3044BA – CONTINUED – 3-35...
  • Page 164 Climate control Ventilator ... Driver’s side ventilators ... Center ventilators ... Front passenger’s side ventilators ... Air flow selection ... Manual heating and air conditioning system ... Control panel ... Heater operation ... Air conditioner operation ... Operating tips for heater and air conditioner ...

  • Page 165: Ventilator

    Climate control Ventilator Climate control Driver’s side ventilators 1) Open 2) Close Move the thumb-wheel up and down or right and left to adjust the flow direction. Center ventilators Move the thumb-wheel up and down or right and left to UB4038BB adjust the flow direction.

  • Page 166: Climate Control

    Front passenger’s side ventilators 1) Open 2) Close Move the thumb-wheel up and down or right and left to adjust the flow direction. UB4040BB Climate control – CONTINUED –...

  • Page 167: Air Flow Selection

    Climate control Air flow selection UB4036BA...

  • Page 168: Manual Heating And Air Conditioning System

    Manual heating and air conditioning system Control panel 1) Temperature control dial 2) Fan speed control dial 3) Air flow control dial 4) Air conditioner button 5) Air inlet selection button 6) Rear window defogger button (Refer to “Rear window defogger button”...

  • Page 169: Air Inlet Selection Button

    Climate control NOTE When the dial is placed in the “ sition, the air conditioner compressor operates automatically regardless of the position of the air conditioner button to defog the windshield quick- ly. At the same time, the air inlet selection is auto- matically set to “Outside air”...

  • Page 170: Heater Operation

    ON position (Recirculation): Interior air is recirculat- ed inside the vehicle. Push the air inlet selection but- ton to the ON position. The indicator light will come on. Push the air inlet selection button to the ON position for fast cooling with the air conditioner or when driving on a dusty road.

  • Page 171: Heating And Defrosting

    Climate control “ ” position. Heating and defrosting To direct warm air toward the floor and the windshield: 1. Set the air flow control dial to “ 2. Set the temperature control dial to the desired tem- perature level. 3. Set the fan speed control dial to the desired speed. NOTE Warm air also comes out from the right and left air outlets.
  • Page 172 Bi-level heating This setting allows you to direct air of different temper- atures from the instrument panel and foot outlets. The air from the foot outlets is slightly warmer than from the instrument panel outlets. 1. Set the air inlet selection button to the “OFF” posi- tion.

  • Page 173: Air Conditioner Operation

    Climate control Continued operation with the air inlet selection button in the ON position may fog up the win- dows. Switch to the OFF position as soon as the outside dusty condition clears. Air conditioner operation Cooling or dehumidifying 1) ON position For cooling and dehumidification of the passenger 4-10 compartment, performing the following steps will allow...

  • Page 174: Operating Tips For Heater And Air Conditioner

    2. Set the temperature control dial to the red area. 3. Set the fan speed control dial at the highest speed. Climate control Operating tips for heater and air con- ditioner Cleaning ventilator grille Always keep the front ventilator inlet grille free of snow, leaves, or other obstructions to ensure efficient heating and defrosting.
  • Page 175 Check the air conditioner unit for refrigerant leaks, hose conditions, and proper operation each spring. This check is best performed by your SUBARU dealer. Cooling and dehumidifying in high humidity and low temperature weather condition Under certain weather conditions (high relative humid- ity, low temperatures, etc.) a small amount of water...

  • Page 176: Air Filtration System (If Equipped)

    Under ex- tremely dusty conditions, the filter should be replaced more frequently. Have your filter checked or replaced by your SUBARU dealer. Replacement schedule: Every 12 months or 9,300 miles (15,000 km) whichev- er comes first...
  • Page 178 Antenna system ... Pillar mounted antenna (Non-turbo models) .. Roof mounted antenna (Turbo models) ... FM reception ... Installation of accessories ... Audio set ... Type A audio set ... Type B audio set ... In-dash 6 CD auto changer (Optional audio unit –...

  • Page 179: Antenna System

    Audio Antenna system Audio Pillar mounted antenna (Non-turbo models) Pull the antenna out to extend it to its full length. Roof mounted antenna (Turbo models) UB5070BA UB5073BA UB5074BA...

  • Page 180: Audio

    Stand the roof antenna up for use. You can detach the roof antenna by turning it counterclockwise. When fit- ting the roof antenna, turn it clockwise and tighten it securely. When working on the cargo bed, be careful not to get poked in the eye by the roof antenna. NOTE Detach the roof antenna before putting the vehi- cle in a garage and before washing it in an auto-...

  • Page 181: Installation Of Accessories

    Audio set Your SUBARU may be equipped with one of the fol- lowing audio sets. See the pages indicated in this sec- tion for operating details.

  • Page 182: Type B Audio Set

    Type B audio set Radio operation: refer to page 5-17 Built-in CD changer operation: refer to page 5-23 In-dash 6 CD auto changer (Optional audio unit – if equipped) UB5075AA Inserting and removing a disc or all discs: refer to page 5-27 Audio HS5011AA...

  • Page 183: Am/Fm Radio With Cd Player

    Audio AM/FM radio with CD player The audio set will operate only when the ignition switch is in the “ACC” or “ON” position. Radio operation UB5067BB (1) Power switch/Volume, Tone, Balance, Fader control dial (2) BAND button (3) Tuning buttons (4) Preset buttons (5) AUDIO button (6) SCAN button...
  • Page 184 Power switch and volume/bass/treble/fader/ balance control Power switch and volume control (PWR/VOL) The dial (1) is used for both power (ON/OFF) and vol- ume control. The radio is turned ON and OFF by push- ing the dial and the volume is controlled by turning the dial.
  • Page 185 Audio Display Control mode Bass control Treble control Balance control Fader control Volume control Turn counterclockwise For less bass sound For less treble sound To increase left speaker volume and decrease right speaker volume To increase rear speaker volume and decrease front speaker volume For less volume HS5014BA...
  • Page 186 Waveband selection FM/AM selection Push the “BAND” button (2) to select FM1, FM2 or AM reception. The display indicates which one is currently selected. Stereo indicator The stereo indicator “ST” will come on when an FM stereo broadcast is received. Tuning (TUNE) Manual tuning (TUNE) Press the “...
  • Page 187 Audio seconds to store the frequency. At this time, there will momentarily be no sound from the radio. If the button is pressed for less than 2 seconds, the preceding se- lection will remain in memory. NOTE If the connection between the radio and battery is broken for any reason such as vehicle mainte- nance or radio removal, all stations stored in the preset buttons are cleared.

  • Page 188: Compact Disc Player Operation

    Compact disc player operation (14) (15) (13) (7) Disc slot (8) CD button (9) Eject button (10) Fast-forwarding and track up button (11) Fast-reversing and track down button (12) Random button (13) Repeat button (14) Scan button (15) PWR (power) switch (10) (12) (11)

  • Page 189: Fast-Forwarding

    Audio To playback a compact disc When CD is not in the player Hold a disc with a finger in the center hole while grip- ping the edge of the disc, then insert it in to the slot (with the label side up) and the player will automatical- ly pull the disc into position.

  • Page 190: Cd Changer Control (If Optional In Dash Cd Changer Is Connected)

    CD changer is connected) An optional CD changer can be connected to this au- dio unit. See your SUBARU dealer for more informa- tion. For procedures for loading and unloading CDs, refer to “In-dash 6 CD auto changer (Optional audio unit –...
  • Page 191 Audio (20) 5-14 (16) (19) (18) (17) UB5067DB (16) CD button (17) Track selection buttons (18) RAND (Random) button (19) RPT (Repeat) button (20) SCAN button...
  • Page 192 To start playback Press the “CD” button (16). The “CD” indicator will come on and the disc number will appear on the dis- play and the CD changer will start playback. NOTE If the “CD” button is pressed during a radio broadcast, the CD changer will interrupt the broadcast.
  • Page 193 Audio – The display shows “SCAN” and the track number being scanned. – You hear the first 10 seconds of each track. – The operation is automatically cleared after play- ing all programs. Then, normal playback starts. 2. Press the “SCAN” button again when you hear a track you like.

  • Page 194: Type B Audio Set (If Equipped)

    Type B audio set (if equipped) The radio will operate only when the ignition switch is in the “ACC” or “ON” position. Radio operation (1) Power switch, Volume control, Bass/Midrange/Treble control and Fader/Balance control dial (2) AUDIO (audio mode) button (3) Fader/Balance selection button (4) FM button (5) AM button...
  • Page 195 Audio Power switch and volume/bass/treble/fader/ balance control (PWR/VOL) The dial (1) is used for both power (ON/OFF) and vol- ume control. The radio is turned ON and OFF by push- ing the dial and the volume is controlled by turning the dial.
  • Page 196 Display Control mode BASS Bass control MIDDLE Midrange control TREBLE Treble control FADER Fader control To increase rear speaker volume and de- BALANCE Balance control To increase left speaker volume and de- VOLUME Volume control Turn counterclockwise For less bass sound For less midrange sound For less treble sound To increase front speaker volume and de-...
  • Page 197 Audio Tone control The volume control dial (1) normally function as vol- ume control. The dial become a control for Bass, Midrange or Treble when you select the appropriate tone control mode. Choose desired volume level for each mode by turning the volume control dial.
  • Page 198 AM button Press the “AM” button (5) for AM reception. Stereo indicator The stereo indicator “ST” will come on when an FM stereo broadcast is received. Manual tuning (TUNE) Manual tuning for AM and FM Push the “ ” side of the tuning button (7) to in- crease the tuning frequency and press the “...
  • Page 199 Audio button is pressed for less than 1.5 seconds, the pre- ceding selection will remain in memory. NOTE If the connection between the radio and battery is broken for any reason such as vehicle mainte- nance or radio removal, all stations stored in the preset buttons are cleared.

  • Page 200: Built-In Cd Changer Operation

    Audio Built-in CD changer operation (9) Eject button (10) Disc slot (11) CD (CD player selection) button (12) Repeat button (10) (11) (12) (13) (14) (13) Random button (14) LOAD button (15) Disc select buttons (16) Track selection buttons (17) SCAN button (17) (16) (15)
  • Page 201 Audio NOTE Make sure to always insert a disc with the label side up. If a disc is inserted with the label side down, it might be ejected or the player might shut off. How to insert a CD(s) Inserting a CD 1.
  • Page 202 enter standby mode. Press the “CD” button to start playback. Loading all the magazine (Full disc loading mode) 1. If you continue to press the “LOAD” button for more than 1.5 seconds, the player will produce beep sound and will enter the full disc loading mode. 2.

  • Page 203: Random Playback

    Audio Release the button to stop fast-reversing. Repeat playback Press the “RPT” button (12) while a song is playing to play the song repeatedly. The “RPT” indicator will come on and the song will be played continuously. To cancel the repeat mode, press the button again. Then the “RPT”...

  • Page 204: In-Dash 6 Cd Auto Changer (If Equipped)

    Audio In-dash 6 CD auto changer (if equipped) (1) Disc slot (2) Disc indicators (disc No.1 to 6) (3) Disc select buttons (disc No.1 to (4) Eject button HS5016BB – CONTINUED – 5-27...
  • Page 205 Audio Do not attempt to insert two or more discs into the slot at a time. Doing so can cause me- chanical damage to the CD changer. only music mark. Do not use CDs listed in the following which could cause damage to the CD player. 3 inch (8 cm) compact disc.
  • Page 206 2. Press the “Eject” button (4). The selected disc will be ejected and the indicator light will begin blinking. 3. To remove another disc, repeat Steps 1 and 2 choosing a different “Disc select” button. (To remove discs when the ignition switch is in the “Lock”...

  • Page 207: Precautions To Observe When Handling A Compact Disc

    Audio Precautions to observe when han- dling a compact disc Use only compact discs (CDs) that have the mark shown in the following illustration. CD-RWs cannot be used. Also, some CD-Rs cannot be played. 5-30 DualDisc You cannot use a DualDisc in the CD player. If you insert a DualDisc into the player, the disc may not come out again, possibly causing the player to mal- function.
  • Page 208 poor tone quality. Do not touch the disc surface. Use a clean disc whenever possible. If there are de- posits, wipe the disc surface from the center outward with a dry, soft cloth. Be sure not to use a hard cloth, thinner, benzene, alcohol, etc.
  • Page 210 Interior light ... Dome light ... Map light ... Sun visors ... Vanity mirror (if equipped) ... Storage compartment ... Glove box ... Center console ... Rear center console ... Coin compartment ... Cup holder ... Front cup holder ... Rear passenger’s cup holder ...

  • Page 211: Interior Light

    Interior and exterior equipments Interior light Interior and exterior equipments Dome light DOOR The dome light switch has three positions: ON: The light stays on continuously. DOOR (middle position): The light comes on when any of the doors is open. The light remains on for sev- eral seconds and gradually goes out after all doors are closed.

  • Page 212: Map Light

    Map light 1) Switches 2) Map lights To turn on the map light, push the switch. To turn it off, push the switch again. When leaving the vehicle, make sure the light is turned off to avoid battery discharge. Interior and exterior equipments Sun visors UG6021CB To block out glare, swing down the visors.

  • Page 213: Vanity Mirror (If Equipped)

    Interior and exterior equipments Vanity mirror (if equipped) To use the vanity mirror, swing down the sun visor and open the vanity mirror cover. The light beside the vanity mirror comes on when the ignition switch is either in the “ACC” or “ON” position and the mirror cover is opened.

  • Page 214: Glove Box

    Glove box 1) Lock 2) Unlock To open the glove box, pull the handle. To close it, push the lid firmly upward. To lock the glove box, insert the key and turn it clock- wise. Interior and exterior equipments Center console HS6030BB To open the lid, pull up the lock release.

  • Page 215: Rear Center Console

    Interior and exterior equipments Rear center console To open the lid, push the button. Coin compartment UB6028BA To open the coin compartment, pull the upper edge of the lid. HS6055BA...

  • Page 216: Cup Holder

    Cup holder Do not pick up a cup from the cup holder or put a cup in the holder while you are driving, as this may distract you and lead to an accident. Take care to avoid spills. Beverages, if hot, might burn you or your passengers.

  • Page 217: Rear Passenger's Cup Holder

    Interior and exterior equipments Rear passenger’s cup holder A dual cup holder is built in the rear center console. Accessory power outlet UB6029BA The accessory power outlet is located at the rear of the center console. Electrical power (12V DC) from the battery is available at the outlet when the ignition switch is either in the “ACC”...

  • Page 218: Cigarette Lighter Socket

    Cigarette lighter socket The electrical power socket located on the lower part of the instrument panel is originally designed to use a genuine SUBARU cigarette lighter plug. Do not use non-genuine cigarette lighter plugs in the socket. Doing so may cause a short-circuit and overheating, resulting in a fire.

  • Page 219: Use With A Cigarette Lighter

    A cigarette lighter plug is an optional acces- sory. It is available from your SUBARU dealer. The cigarette lighter socket may also be used as a power source for an in-car use electrical appliance.

  • Page 220: Using As An Accessory Power Outlet

    If you want to use the socket for a ciga- rette lighter again, or to protect your purchaser before you sell your vehicle, have your SUBARU dealer re- place the socket with a new one. – CONTINUED –...

  • Page 221: Ashtray

    Interior and exterior equipments Ashtray Do not use ashtrays as waste receptacles or leave a lighted cigarette in an ashtray. This could cause a fire. Fully close the ashtray after using it to help reduce re- sidual smoke. To open the ashtray, pull the lid out. To remove the ashtray for cleaning, open it and pull it 6-12 out while pushing the inner plate down.

  • Page 222: Convenience Hook

    Convenience hook Coat hook Never hang anything on the coat hook that might obstruct the driver’s view or that could cause injury in sudden stops or in a collision. And do not hang items on the coat hook that weigh 2.2 lbs (1 kg) or more. The coat hook is attached to each rear passenger’s Interior and exterior equipments hand grip.
  • Page 223 Interior and exterior equipments There are four hooks on the back panel behind the rear seatback. These hooks can be used for installing a cargo net so that small and light items can be held next to the back panel when the rear seatback is in the down position. Fold the rear seatback forward by pulling the release knob up for access to the hooks.

  • Page 224: Floor Mat (If Equipped)

    Floor mat (if equipped) Make sure the driver’s floor mat is placed back in its proper location and correctly secured on its retaining pin. If the floor mat slips forward and interferes with the movement of the pedals during driving, it could cause an accident. Interior and exterior equipments A retaining pin is located on the driver’s side of the ve- hicle.

  • Page 225: Cargo Bed

    Never drive the vehicle with the tailgate open unless the optional SUBARU Bed Extender is used. Cargo should be placed in the cargo bed. Make sure all items are secured in place.

  • Page 226: Cargo Tie-Down Hooks

    front end of the cargo bed. Keep those holes clear and free from obstructions. Cargo tie-down hooks The cargo bed is equipped with four tie-down hooks so that cargo can be secured with a luggage net or ropes. Interior and exterior equipments Bed extender (if equipped) The bed extender is designed to increase the usable cargo area of the bed.

  • Page 227: Operation

    Interior and exterior equipments Remove the bed extender for vehicle “Off Road” use. To avoid creating a dangerous road hazard or causing personal injury, cargo must not stick out beyond the bed extender. To avoid damage, the tailgate and bed ex- tender must remain in the closed/inward posi- tion when towing with a trailer hitch.

  • Page 228: Bed Extender Removal

    NOTE Use care when rotating bed extender. Do not per- mit the buckles to come in contact with vehicle sheet metal and bed trim. Closed/Inward Position – With the tailgate closed and the bed extender in the inward position, small loads can be placed inside the vehicle bed between the tailgate and the extender (groceries, ice chests, etc.).

  • Page 229: Cargo Lamp

    Interior and exterior equipments Cargo lamp 6-20 The cargo lamp comes on and goes off whenever the UB3018AA cargo lamp switch is pushed regardless of the position of the ignition switch. The cargo lamp indicator light lo- cated in the meter panel will illuminate when the cargo lamp is on.

  • Page 230: Soft Bed Cover (If Equipped)

    Soft bed cover (if equipped) Before installing the soft bed cover, carefully read the warning labels on the inside wall of the cargo bed. Do not place cargo on top of the bed cover. Do not use the hard bed cover section as a step.

  • Page 231: Cover Removal

    Interior and exterior equipments To secure the soft portion of the bed cover to the bed, simply start from either side of the vehicle and place the plastic strip under the rail. Slide your hand down the side of the vehicle pushing the plastic strip under the rail as you go.

  • Page 232: Cover Reinstallation

    The soft portion of the bed cover can be removed from the bed cover’s hard section for cleaning or storage. Unfasten the Velcro on the tube closeout wraps and firmly pull the cover out to one side. Cover reinstallation The soft portion of the bed cover can be reinstalled onto the bed cover’s hard section.

  • Page 233: Hard Bed Cover (If Equipped)

    Interior and exterior equipments Hard bed cover (if equipped) 1) Warning labels Carefully read the warning labels on the in- side walls of the cargo bed. Do not sit, stand or place cargo on this cover. Help prevent young children from locking themselves in the cargo bed.

  • Page 234: Locking And Unlocking The Bed Cover

    1) Front section 2) Rear section The hard bed cover can be used to cover the entire cargo area. Its front section and rear section can be opened separately. Also, the bed cover can be re- moved and reinstalled as desired. The bed cover is water-resistant, but not waterproof.

  • Page 235: Front Section

    Interior and exterior equipments The front and rear sections of the bed cover can each be locked and unlocked. Each section is automatically locked when it is closed. (Refer to “Opening and clos- ing the hard bed cover” in this section.) Front section 1) Lock 2) Unlock...

  • Page 236: Internal Hard Bed Cover Release Handle

    NOTE If you find the key hard to turn when unlocking the rear section, press the middle of the rear section with your other hand while turning the key. Internal hard bed cover release handle Never allow any child to get in the cargo bed and play with the release handle.

  • Page 237: Opening And Closing The Hard Bed Cover

    UB6081BA If the movement of the release handle feels restricted or not entirely smooth during operation, or the handle and/or handle base is cracked, contact your SUBARU dealer. Opening and closing the hard bed cov- Keep the front and rear covers closed while driving.
  • Page 238 bars with the attached strap. Failure to do so may result in damage to cargo. When opening or closing the cover, hold the cover by hand and open or close the cover slowly. Be careful not to trap your fingers be- tween the cover and cargo bed.
  • Page 239 Interior and exterior equipments 2. Raise the cover slightly while holding the key in the unlock position. After making sure that the cover is completely unlocked, remove the key from the key cyl- inder and open the cover slowly to the fully opened po- sition.
  • Page 240 1) Straps Interior and exterior equipments UB6067BA 1) Rear section of cover 2) Rear sport bar 3) Strap 4) Connector 3. Take the strap from the back of the cover and wind it around the rear sport bar. Join the strap connector’s buckle and tongue together until they click, then pull on the tab of the strap to take up the slack.

  • Page 241: Removal And Installation Of The Hard Bed Cover

    Interior and exterior equipments ly locked. If this does not lock the cover, release it from a slightly higher position. Do not push the cover forcibly to lock Removal and installation of the hard bed cover 1) Brackets When removing the bed cover, never remove the brackets shown in the above drawing.
  • Page 242 Interior and exterior equipments UB6069BA UB6070BA 1) Bolts 3. Remove the two bolts shown in the above drawing using the wheel nut wrench. – CONTINUED – 6-33...

  • Page 243: Installation

    Interior and exterior equipments 4. Fold up the front and rear sections of the cover. Re- move the cover by holding it (by two or more adults) and place it in a safe location. 5. Put the wheel nut wrench back in the tool bag. (Re- fer to “Jack and tools”...
  • Page 244 3. Tighten the two bolts shown in the above drawing by hand and confirm that the hard bed cover is mount- ed correctly. 4. Take out the wheel nut wrench from the tool bag. (Refer to “Jack and tools” section in chapter 9.) Interior and exterior equipments UB6073BA 5.

  • Page 245: Roof Rail And Crossbar

    Interior and exterior equipments Roof rail and crossbar For cargo carrying purposes, the roof rail must be used together with a roof crossbar kit and the appropriate carrying attachment. The roof rail must never be used alone to carry car- go.

  • Page 246: Installing Carrying Attachments On The Crossbars

    formation on loading cargo into or onto your vehicle. The maximum load limit of the cargo, crossbars and carrying attachment must not exceed 100 lbs (45 kg). Place the heaviest load at the bottom, nearest the roof, and evenly distribute the cargo. Always properly secure all cargo.
  • Page 247 Interior and exterior equipments To remove the crossbar 6-38 1. Loosen and remove the T-30 torx® head screw from the side of each crossbar end support. 2. Move the end support and inner clamp to unhook each side of the crossbar from the roof rail. 3.
  • Page 248 1) Front 2) Rear 3) Crossbar (section) Interior and exterior equipments Front crossbar: Front crossbar has 100 LBS. Load Label on left hand side. UB6055BB 1) Load label UB6051BB – CONTINUED – 6-39...
  • Page 249 Interior and exterior equipments 7 in (180 mm) 1. Before placing the crossbar on the roof rails, make sure that the T-30 torx® head screw is fully loosened from each end support. 2. Spread the inner clamp and the end support as far apart as possible.
  • Page 250 vided). Rear crossbar: 0 in (0 mm) Interior and exterior equipments Install the rear crossbar in the same manner as the front crossbar. UB6049BB NOTE The rear crossbar should be positioned just in front of the rear radius in the roof rail. Before each use of the roof crossbar, make sure the four T-30 crossbar clamp screws have been checked, and retightened if necessary to 35 lbf·in...

  • Page 251: Sport Activity Lights (If Equipped)

    Interior and exterior equipments Sport activity lights (if equipped) 1) Indicator light The sport activity lights will operate only when the parking brake is engaged. Push the “SPORT LIGHTS” switch to turn the sport activity lights on. Press the switch again to turn them off. The indicator light located on the switch will illuminate when the sport activity lights are on.
  • Page 252 Interior and exterior equipments (downward) position when washing your vehicle. If you choose to remove sport activity lights, the follow- ing sequence should be utilized: 1. Disconnect the roof harness from the cross bar har- ness connector. 2. Attach the water proof connector cap to the roof harness connector.
  • Page 254 Fuel ... Fuel requirements ... Fuel filler door and cap ... State emission testing (U.S. only) ... Preparing to drive ... Starting the engine ... Manual transmission vehicle ... Automatic transmission vehicle ... Stopping the engine ... Manual transmission ... Shifting speeds ...

  • Page 255: Fuel

    Starting and operating Fuel Starting and operating Use of a fuel which is low in quality or use of an inappropriate fuel additive may cause engine damage. Fuel requirements Non-turbo models The 2.5-liter engine is designed to operate using un- leaded gasoline with an octane rating of 87 AKI or higher.

  • Page 256: Starting And Operating

    ENGINE warning light/Malfunction indicator lamp may turn on. If this happens, return to your authorized SUBARU Dealer for service. If it is determined that the condition is caused by the type of fuel used, repairs may not be covered by your warranty.

  • Page 257: Fuel Filler Door And Cap

    Do not let fuel spill on the exterior surfaces of the vehicle. Fuels may cause paint damage, which is not covered under the SUBARU Limit- ed Warranty. Always use a genuine SUBARU fuel filler cap. If you use the wrong cap, it may not fit or have proper venting, and your fuel tank and emis- sion control system might be damaged.
  • Page 258 1. To open the fuel filler door, pull it outward. UB7034BA 1) Open 2) Close 2. Remove the fuel filler cap by turning it slowly coun- terclockwise. 3. Stop filling the tank after the fuel filler pump auto- matically clicks off. Do not add any more fuel. 4.

  • Page 259: State Emission Testing (U.s. Only)

    HS3023AA Resultant vehicle damage due to improper test- ing is not covered under the SUBARU Limited ” sign in the Warranty and is the responsibility of the state inspection program or its contractors or licens- ees.
  • Page 260 There are some states that use four-wheel dynamom- eters in their testing programs. When properly used, that equipment will not damage an AWD SUBARU ve- hicle. Under no circumstances should the rear wheels be Starting and operating jacked off the ground, nor should the driveshaft be dis- connected for state emission testing.

  • Page 261: Preparing To Drive

    Owners of rejected or failing vehicles should contact their SUBARU Dealer for service. Preparing to drive You should perform the following checks and adjust- ments every day before you start driving.

  • Page 262: Starting The Engine

    “START” position without depressing the accelera- tor pedal. 4) If the engine still refuses to start, contact your nearest SUBARU dealer for assistance. 6. Confirm that all warning and indicator lights have gone off after the engine has started. The fuel injection system automatically lowers the idle speed as the en- gine warms up.

  • Page 263: Automatic Transmission Vehicle

    “START” position without depressing the accelera- tor pedal. 4) If the engine still refuses to start, contact your nearest SUBARU dealer for assistance. 6. Confirm that all warning and indicator lights have gone out after the engine has started. The fuel injec- tion system automatically lowers the idle speed as the engine warms up.

  • Page 264: Stopping The Engine

    While the engine is warming up, make sure that the selector lever is at the “P” or “N” position and that the parking brake is applied. NOTE (Turbo models) The engine may be difficult to start when the bat- tery has been disconnected and reconnected (for maintenance or other purposes).

  • Page 265: Manual Transmission

    Starting and operating Manual transmission Do not drive the vehicle with the clutch disen- gaged (i.e., when the clutch pedal is depressed) or with the shift lever in the neutral position. Engine braking has no effect in either of these conditions and the risk of an accident is conse- quently increased.

  • Page 266: Shifting Speeds

    Shifting speeds Recommended shifting speeds The best compromise between fuel economy and ve- hicle performance during normal driving is ensured by shifting up at the speeds listed in the following table. Shift up mph (km/h) 1st to 2nd 15 (24) 2nd to 3rd 25 (40) 3rd to 4th...

  • Page 267: Driving Tips

    Starting and operating Driving tips Do not drive with your foot resting on the clutch pedal and do not use the clutch to hold your vehicle at a standstill on an upgrade. Either of those actions may cause clutch damage. Do not drive with your hand resting on the shift lever.

  • Page 268: Selector Lever

    When parking the vehicle, first securely apply the parking brake and then place the selector lever in the “P” position. Avoid parking for a long time with the selector lever in any other position as doing so could result in a dead bat- tery.
  • Page 269 Starting and operating : With the brake pedal depressed, move the lever along the gate. : Move the lever along the gate. The selector lever has seven positions. P (Park) This position is for parking the vehicle and starting the engine.
  • Page 270 In this position the wheels and transmission are not locked. In this position, the transmission is neutral; the vehicle will roll freely, even on the slightest incline un- less the parking brake or foot brake is on. Avoid coasting with the transmission neutral. During coasting, the engine braking does not act.

  • Page 271: Maximum Speeds

    Starting and operating 3 (Third) This position is for using engine braking when going down a hill or for climbing a grade. The transmission automatically shifts into a suitable gear from 1st to 3rd according to the vehicle speed and the acceleration you require. When more acceleration is required in this position, press the accelerator pedal fully to the floor and hold that position.

  • Page 272: Driving Tips

    Position Non-turbo models 23 (38) 55 (89) 91 (147) Never exceed posted speed limits. NOTE In order to prevent over-revving during acceler- ation of the vehicle, the transmission will automat- ically shift to the next highest gear if the Maximum Allowable Speed for the current gear is exceeded.
  • Page 273 “P” to the “N” position. 6. Remove the screwdriver from the hole. Depress the brake pedal and start the engine. Take your vehicle to the nearest SUBARU dealer im- mediately to have the system repaired. HS7009BA...

  • Page 274: Automatic Transmission (Turbo Models)

    Automatic transmission (Turbo mod- els) Do not shift from the “P” or “N” position into the “D”, “3”, “2”, “1” or “R” position while de- pressing the accelerator pedal. This may cause the vehicle to jump forward or backward. Shift into the “P” or “R” position only after the vehicle is completely stopped.

  • Page 275: Selector Lever

    Starting and operating as the vehicle continues to be driven for a while. Selector lever 1) Release button 7-22 : With the brake pedal depressed, shift while pressing the button in. : Shift while pressing the button in. UB7026BB : Shift without pressing the button. The selector lever has seven positions, “P”, “R”, “N”, “D”, “3”, “2”...
  • Page 276 locked to prevent the vehicle from rolling freely. When you park the vehicle, first set the parking brake fully, then shift into the “P” position. Do not hold the ve- hicle with only the transmission. A shift interlock function is employed in the automatic transmission system to ensure safe starting of the ve- hicle.
  • Page 277 Starting and operating The transmission automatically shifts into a suitable gear from 1st to 4th according to the vehicle speed and the acceleration you require. When more acceleration is required in this position, press the accelerator pedal fully to the floor and hold that position.

  • Page 278: Selector Lever Reverse Inhibiting Function

    that position. The transmission will automatically downshift to 2nd or 1st gear. When you release the pedal, the transmission will return to the original gear position. 2 (Second) To shift from the “3” to “2” position, push the release button. This position is for using engine braking when going down a hill or for climbing a steep grade.

  • Page 279: Selection Of Sportshift Mode (Manual Mode)

    “P” posi- tion while pressing the release button. If the selector lever reverse inhibiting function fails, have the vehicle inspected by the nearest SUBARU dealer. 7-26 Selection of SPORTSHIFT mode (man-...
  • Page 280 1) Lamp showing whether upshift is possible 2) Lamp showing whether downshift is possible 3) Indication of currently selected gear 2. Once the SPORTSHIFT mode is selected, the cur- rently selected gear is shown by the shift position indi- cator in the meter cluster. Next to this indication, ar- row-shaped lamps show whether an upshift is possi- ble and whether a downshift is possible.
  • Page 281 Starting and operating matic transmission from damage. The transmission does not automatically shift up in the SPORTSHIFT mode. Perform gearshifts in accordance with road conditions so that the ta- chometer needle does not enter the red zone. If the engine speed reaches a predetermined level, a fuel-cut function will operate.

  • Page 282: Driving Tips

    Never exceed posted speed limits. NOTE In order to prevent over-revving during acceler- ation of the vehicle, the transmission will automat- ically shift to the next higher gear if the Maximum Allowable Speed for the current gear is reached. Similarly, in order to prevent over-revving dur- ing deceleration of the vehicle, the transmission will remain in the current gear if the speed of the vehicle is in excess of the Maximum Allowable...

  • Page 283: Limited Slip Differential (Lsd)

    “P” to the “N” position. 6. Remove the screwdriver from the hole. Depress the brake pedal and start the engine. Take your vehicle to the nearest SUBARU dealer im- mediately to have the system repaired. 7-30 Limited slip differential (LSD) Never start the engine while a tire on one side is jacked up, as the vehicle may move.

  • Page 284: Power Steering

    Power steering Do not hold the steering wheel at the fully locked position left or right for more than five seconds. This may damage the power steering pump. The power steering system operates only when the engine is running. If you lose power steering assist because the engine stops or the system fails to function, you can steer but it will take much more effort.

  • Page 285: Brake System

    The disc brake pad wear warning indicators on the disc brakes give a warning noise when the brake pads are worn. If a squeaking or scraping noise is heard from the disc brakes while braking, immediately have your vehicle inspected by the nearest SUBARU dealer. HS7012BA...

  • Page 286: Abs (Anti-Lock Brake System)

    ABS (Anti-lock Brake System) Always use the utmost care in driving – over- confidence because you are driving with an ABS equipped vehicle could easily lead to a se- rious accident. The ABS system does not always decrease stopping distance. You should always maintain a safe following distance from other vehicles.

  • Page 287: Abs Warning Light

    8 mph (12 km/h). The warning light comes on during driving. If these occur, have the ABS system repaired at the first available opportunity by your SUBARU dealer. NOTE If the warning light behavior is as described in the...

  • Page 288: Parking Your Vehicle

    age and does not indicate a malfunction. When the battery becomes fully charged, the light will go out. Starting and operating Parking your vehicle Never leave unattended children or pets in the vehicle. They could accidentally injure themselves or others through inadvertent oper- ation of the vehicle.
  • Page 289 Starting and operating make sure that the parking brake has been fully released. To set the parking brake, press the brake pedal firmly and hold it down while fully pulling up the parking brake lever. To release the parking brake, pull the lever up slightly, press the release button, then lower the lever while keeping the button pressed.

  • Page 290: Cruise Control

    When facing downhill, the front wheels should be turned into the curb. Cruise control Do not use the cruise control under any of the following conditions. This may cause loss of vehicle control: driving up or down a steep grade driving on slippery or winding roads driving in heavy traffic UB7032AA...

  • Page 291: To Set Cruise Control

    Starting and operating To set cruise control 7-38 1. Push the “CRUISE” main switch. The indicator light on the switch will come on. 2. Depress the accelerator pedal until the vehicle reaches the desired speed. 3. Push the control lever downward in the “SET, COAST”...

  • Page 292: To Temporarily Cancel The Cruise Control

    When the accelerator pedal is released, the vehicle will return to and maintain the previous cruising speed. To temporarily cancel the cruise con- trol There are five ways to cancel the cruise control tem- porarily: Depress the brake pedal. Pull the control lever in the “CANCEL” direction. Depress the clutch pedal (manual transmission ve- hicles only).

  • Page 293: Cruise Control Set Indicator Light

    “ACC” or “LOCK” position, and then turn it again to the “ON” position. If this indicator light and the “ light flash simultaneously during driving, have the vehicle checked by your nearest SUBARU dealer. ” indicator...
  • Page 294 Driving tips New vehicle break-in driving – the first 1,000 miles (1,600 km) ... Fuel economy hints ... Engine exhaust gas (Carbon monoxide) ... Catalytic converter ... Periodic inspections ... Driving in foreign countries ... Driving tips for AWD vehicles ... Off road driving ...

  • Page 295: New Vehicle Break-In Driving - The First 1,000 Miles (1,600 Km)

    Driving tips New vehicle break-in driving – the Driving tips first 1,000 miles (1,600 km) The performance and long life of your vehicle are de- pendent on how you handle and care for your vehicle while it is new. Follow these instructions during the first 1,000 miles (1,600 km): Do not race the engine.

  • Page 296: Driving Tips

    Engine exhaust gas (Carbon monox- ide) Never inhale engine exhaust gas. Engine ex- haust gas contains carbon monoxide, a color- less and odorless gas which is dangerous, or even lethal, if inhaled. Always properly maintain the engine exhaust system to prevent engine exhaust gas from en- tering the vehicle.

  • Page 297: Catalytic Converter

    Driving tips Catalytic converter Avoid fire hazards. Do not drive or park the vehicle anywhere near flammable materials (e.g. grass, paper, rags or leaves), because the catalytic converter operates at very high tem- peratures. Keep everyone and flammable materials away from the exhaust pipe while the engine is running.
  • Page 298 Keep your engine tuned-up. If you feel the engine running rough (misfiring, backfiring or incomplete combustion), have your vehicle checked and repaired by an authorized SUBARU dealer. Do not apply undercoating or rust prevention treat- ment to the heat shield of catalytic converter and the exhaust system.

  • Page 299: Periodic Inspections

    Driving tips Periodic inspections To keep your vehicle in the best condition at all times, always have the recommended maintenance services listed in the maintenance schedule in the “Warranty and Maintenance Booklet” performed at the specified time or mileage intervals. Driving in foreign countries When planning to use your vehicle in another country: Confirm the availability of the correct fuel.

  • Page 300: Driving Tips For Awd Vehicles

    By shifting power between the front and rear wheels, SUBARU AWD can also provide added traction during acceler- ation, and added engine braking force during deceler- ation.
  • Page 301 Driving tips An AWD vehicle is better able to climb steeper roads under snowy or slippery conditions than a two wheel drive vehicle. There is little difference in han- dling, however, during extremely sharp turns or sud- den braking. Therefore, when driving down a slope or turning corners, be sure to reduce your speed and maintain an ample distance from other vehicles.

  • Page 302: Off Road Driving

    But please keep in mind that an AWD SUBARU is neither a conventional off-road vehicle nor an all-terrain vehicle. If you do take your SUBARU off- road, certain common sense precautions such as the following should be taken: Make certain that you and all of your passengers are wearing seatbelts.
  • Page 303 Driving tips less of its depth, it can wash away the ground from un- der your tires, resulting in possible loss of traction and even vehicle rollover. Always check your brakes for effectiveness immedi- ately after driving in sand, mud or water. Do this by driving slowly and stepping on the brake pedal.

  • Page 304: Winter Driving

    “Warranty and Maintenance Booklet”. Remember that damage done to your SUBARU while operating it off-road and not using common sense pre- cautions such as those listed above is not eligible for warranty coverage.
  • Page 305 Do not use engine antifreeze or other substitutes because they may damage the paint of the vehicle. SUBARU Windshield Washer Fluid contains 58.5% methyl alcohol and 41.5% surfactant, by volume. Its freezing temperature varies according to how much it is diluted, as indicated in the following table.

  • Page 306: Driving On Snowy And Icy Roads

    If your SUBARU is not going to be used for an extend- ed period, it is best to have the fuel tank filled to capac- ity.
  • Page 307 Driving tips Avoid prolonged continuous driving in snow- storms. Snow will enter the engine’s intake sys- tem and may hinder the air flow, which could re- sult in engine shutdown or even breakdown. To prevent skidding and slipping, avoid sudden brak- ing, abrupt acceleration, high-speed driving, and sharp turning when driving on snowy or icy roads.

  • Page 308: Corrosion Protection

    give superior wiping performance in snowy conditions. Be sure to use blades that are suitable for your vehi- cle. During high-speed driving, non-freezing type wiper blades may not perform as well as stan- dard wiper blades. If this happens, reduce the vehicle speed.

  • Page 309: Tire Chains

    Driving tips stall four winter tires that are of the same size, con- struction, brand and load range and you should never mix radial, belted bias or bias tires since this may re- sult in dangerous handling characteristics. When you choose a tire, make sure that there is enough clear- ance between the tire and vehicle body.

  • Page 310: Loading Your Vehicle

    When the road surface is extremely slippery, you can obtain better traction by starting the vehicle with the transmission in 2nd than 1st (both for MT and AT). Refer to the “Automatic transmission” section in chap- ter 7 for information on holding the transmission in 2nd position.
  • Page 311 Driving tips event of a sudden stop or accident. Keep lug- gage or cargo low, as close to the floor as pos- sible. When you carry something inside the vehicle, secure it whenever you can to prevent it from being thrown around inside the vehicle during sudden stops, sharp turns or in an accident.

  • Page 312: Vehicle Capacity Weight

    Vehicle capacity weight The load capacity of your vehicle is determined by weight, not by available cargo space. The maximum load you can carry in your vehicle is shown on the ve- hicle placard attached to the driver’s side door pillar. It includes the total weight of the driver and all passen- gers and their belongings, any optional equipment such as a trailer hitch, roof rack or bike carrier, etc.,...

  • Page 313: Trailer Hitch (If Equipped)

    Driving tips door shows GVWR (Gross Vehicle Weight Rating) and GAWR (Gross Axle Weight Rating). The GVW (Gross Vehicle Weight) must never exceed the GVWR. GVW is the combined total of weight of the vehicle, fuel, driver, all passengers, luggage, any op- tional equipment and trailer tongue load.

  • Page 314: Connecting A Trailer

    tributing hitch. The trailer hitch is designed to tow a Class 1 rated load. A maximum of 2,400 lbs (1,087 kg) gross trailer weight and a maximum of 200 lbs (90 kg) gross tongue weight are permissible for the trailer hitch. When you tow a trailer, follow the instructions in the next section “Trailer towing”.
  • Page 315 Driving tips 3. Insert the hitch pin into the hole on the hitch receiv- er tube so that the pin passes through the ball mount. 8-22 UB8018BA 4. Insert the safety pin into the hitch pin securely. 5. Pull the ball mount to make sure it does not come off the hitch receiver.
  • Page 316 1) Hitch ball installation point 2) Hooks for safety chains 6. Use only a hitch ball that is appropriate for the ball mount and your trailer. The hitch ball must be securely installed on the ball mount. 7. Connect your trailer to the hitch ball. 8.

  • Page 317: When You Do Not Tow A Trailer

    Driving tips Hitch harness connector 9. Connect the hitch wire harness’s black four-pin wire connector to the towing trailer’s wire harness. 10.Confirm proper function of the hitch wire harness by individually activating the brake, right turn signal, left turn signal, stop, and parking lights on the trailer. NOTE Always disconnect the trailer wire harness before launching or retrieving a watercraft.

  • Page 318: Trailer Towing

    Seek the ad- vice of your SUBARU dealer to assist you in purchas- ing a hitch and other necessary towing equipment ap- propriate for your vehicle. In addition, be sure to follow...
  • Page 319 Driving tips and trailer are acceptable. Total trailer weight Total trailer weight The total trailer weight (trailer weight plus its cargo load) must never exceed the maximum weight shown in the following table. 8-26 Model MT models When towing a trailer with- out brakes.
  • Page 320 Gross Vehicle Weight (GVW) and Gross Vehicle Weight Rating (GVWR) Gross Vehicle Weight The Gross Vehicle Weight (GVW) must never exceed the Gross Vehicle Weight Rating (GVWR). Gross Vehicle Weight (GVW) is the combined total of the weight of the vehicle, driver, passengers, luggage, trailer hitch, trailer tongue load and any other optional equipment installed on your vehicle.
  • Page 321 Driving tips Gross Axle Weight (GAW) and Gross Axle Weight Rating (GAWR) Gross Axle Weight The total weight applied to each axle (GAW) must nev- er exceed the Gross Axle Weight Rating (GAWR). The front and rear GAWs can be adjusted by relocating passengers and luggage inside the vehicle.
  • Page 322 Tongue load Tongue load If the trailer is loaded with more weight in the back of trailer’s axle than in the front, the load is taken off the rear axle of the towing vehicle. This may cause the rear wheels to skid, espe- cially during braking or when vehicle speed is reduced during cornering, resulting in over- steer, spin out and/or jackknifing.

  • Page 323: Trailer Hitches

    Do not use axle-mounted hitches as they can cause damage to the axle housing, wheel bear- ings, wheels or tires. The use of a genuine SUBARU trailer hitch is recom-...

  • Page 324: Connecting A Trailer

    A genuine SUBARU hitch is available from your SUBARU dealer. If use of a non-genuine hitch is unavoidable, be sure the hitch is suited to your vehicle and trailer. Consult with a professional hitch supplier to assist you in choosing an appropriate hitch for your vehicle.
  • Page 325 To ensure the trailer lights are connected properly, please consult your SUBARU dealer. Check for proper operation of the turn signals, the brake lights and parking lights each time you hitch up.

  • Page 326: Trailer Towing Tips

    tire is used. The temporary spare tire is not de- signed to sustain the towing load. Use of the temporary spare tire when towing can result in failure of the spare tire and/or less stability of the vehicle. Make sure that all the tires on your vehicle are properly inflated.
  • Page 327 Driving tips – the trailer tongue is connected properly to the hitch ball. – the trailer lights connector is connected properly and trailer’s brake lights illuminate when the vehi- cle’s brake pedal is pressed, and that the trailer’s turn signal lights flash when the vehicle’s turn signal lever is operated.
  • Page 328 If the ABS warning light illuminates while the vehicle is in motion, stop towing the trailer and have repairs performed immediately by the nearest SUBARU deal- Driving on grades Before going down a steep hill, slow down and shift...
  • Page 329 Driving tips vehicle and trailer wheels. 3. When the wheel blocks are in place, release the regular brakes slowly until the blocks absorb the load. 4. Apply the regular brakes and then apply the park- ing brake; slowly release the regular brakes. 5.
  • Page 330 In case of emergency If you park your vehicle in an emergency .. Jack and tools ... Location of jack and tools ... Removing jack and tool bag ... Restoring jack and tools ... Spare tire ... Removing the spare tire ... Re-storage of spare tire ...

  • Page 331: In Case Of Emergency

    In case of emergency If you park your vehicle in an emer- In case of emergency gency The hazard warning flasher should be used in day or night to warn other drivers when you have to park your vehicle under emergency conditions. Avoid stopping on the road.

  • Page 332: Jack And Tools

    Jack and tools The jack supplied with the vehicle is designed only for changing a tire. Before using the jack, see the “Flat tires” section in this chapter for instructions and precautions. Location of jack and tools The jack and tool bag are located in the left side rear quarter pocket at the back side of the rear seatback.
  • Page 333 In case of emergency 1) Red A) LOCK B) UNLOCK 1. Pull the rear seatback locks up and fold down the rear seatback to gain access to the rear quarter pock- ets at both sides. UB1109BB 2. Open the left-hand pocket lid by turning the knob. 3.

  • Page 334: Restoring Jack And Tools

    4. Loosen the jack holding screw by turning counter- clockwise and remove the jack from the pocket. NOTE Be careful not to lose the jack holding screw af- ter removing it. Make sure the jack is well lubricated before us- ing it.
  • Page 335 In case of emergency 3. Place the jack onto the bracket in the pocket. 4. Securely fix the jack with the jack holding screw by turning it clockwise. 5. Install the left-hand pocket lid and lock it by turning the knob. NOTE Confirm no looseness exists after securing the jack.

  • Page 336: Spare Tire

    Spare tire The spare tire is stored in the spare tire holder located under the rear of the cargo bed. The spare tire holder has a hoist mechanism that can lower and raise the spare tire easily. The spare tire holder is designed to carry only the temporary spare tire that comes with your vehicle.
  • Page 337 In case of emergency 4. Turn the hoist shaft end counterclockwise with the wheel nut wrench until the temporary spare tire is on the ground with enough cable slack to allow you to pull it out from under the vehicle. Do not put your fingers into the center hole of the temporary spare tire while you pulling it out, because they might be pinched in between the...

  • Page 338: Re-Storage Of Spare Tire

    underside of the vehicle. Driving with the cable not retracted fully could result in damage to the adjacent under floor parts and lead to a serious accident. The spare tire holder is designed to carry only the smaller temporary spare tire. Never store a full size tire (flat or otherwise) in the spare tire holder.

  • Page 339: Temporary Spare Tire

    In case of emergency Temporary spare tire Using the temporary spare tire Never tow a trailer when the temporary spare tire is used. The temporary spare tire is not de- signed to sustain the towing load. Use of the temporary spare tire when towing can result in failure of the spare tire and/or less stability of the vehicle and may lead to an accident.
  • Page 340 1) Tread wear indicator bar 2) Indicator location mark When the wear indicator appears on the tread, re- place the tire. The temporary spare tire must be used only on a rear wheel. If a front wheel tire gets punctured, replace the wheel with a rear wheel and install the temporary spare tire in place of the removed rear wheel.

  • Page 341: Flat Tires

    In case of emergency Flat tires If you get a flat tire while driving, never brake sudden- ly; keep driving straight ahead while gradually reduc- ing speed. Then slowly pull off the road to a safe place. Changing a flat tire Do not jack up the vehicle on an incline or a loose road surface.
  • Page 342 agonally opposite the flat tire. 5. Take out the spare tire, jack, and wheel nut wrench. Refer to the sections “Spare tire” and “Jack and tools” in this chapter for their location, instructions and pre- cautions. After the spare tire is removed from the spare tire hold- er, the cable must be wound up completely by turning the hoist nut shaft clockwise until you hear a clicking sound.
  • Page 343 In case of emergency indicated by arrow marks on the side of the side sill skirt. 3. Turn the jackscrew by hand until the groove of the jack head engages firmly into the jack-up point. 9-14 4. Insert the jack drive tube into the jackscrew and at- UB9089BA tach the wheel nut wrench into the jack drive tube, and turn the handle until the tire clears the ground.
  • Page 344 6. Before putting the spare tire on, clean the mounting surface of the wheel and hub with a cloth. 7. Put on the spare tire. Replace the wheel nuts. Tighten them by hand. Do not use oil or grease on the wheel studs or nuts when the spare tire is installed.
  • Page 345 In case of emergency 9. Use the wheel nut wrench to securely tighten the wheel nuts to the specified torque, following the tight- ening order in the illustration. The torque for tightening the nuts is 74 to 89 lbf·ft (100 to 120 N·m, 10 to 12 kgf·m).
  • Page 346 1) Holding rod 2) Retainer 3. Place the flat tire in the cargo bed with the outer side of the wheel facing up. For an aluminum wheel, remove the center cap before placing it in the cargo bed. 4. Place the retainer on the center hole of the wheel as illustrated and put the tire holding rod into the re- tainer.

  • Page 347: Jump Starting

    In case of emergency tions and precautions described in the “Temporary spare tire” section in this chapter. Replace the temporary spare tire with a conventional tire as soon as you can. 9-18 Jump starting Battery fluid is SULFURIC ACID. Do not let it come in contact with the eyes, skin, clothing or the vehicle.

  • Page 348: How To Jump Start

    Do not jump start unless cables in suitable con- dition are available. A running engine can be dangerous. Keep your fingers, hands, clothing, hair and tools away from the cooling fan, belts and any other moving engine parts. Removing rings, watches and ties is advisable.
  • Page 349 In case of emergency 1) Booster battery 2) Engine lifting bracket 9-20 900275 1) Connect one jumper cable to the positive (+) terminal on the dis- charged battery. 2) Connect the other end of the jumper cable to the positive (+) ter- minal of the booster battery.

  • Page 350: Engine Overheating

    5. Start the engine of the vehicle with the booster bat- tery and run it at moderate speed. Then start the en- gine of the vehicle that has the discharged battery. 6. When finished, carefully disconnect the cables in exactly the reverse order. In case of emergency Engine overheating Never attempt to remove the radiator cap until...

  • Page 351: Towing

    This will cause the vehicle to spin away due to the operation or de- terioration of the center differential. If towing is necessary, it is best done by your SUBARU UB9064BA...

  • Page 352: Towing And Tie-Down Hooks

    dealer or a commercial towing service. Observe the following procedures for safety. Towing and tie-down hooks The towing hooks should be used only in an emergen- cy (e.g., to free a stuck vehicle from mud, sand or snow). Use only specified towing hooks and tie- down hooks.
  • Page 353 In case of emergency 1) Tie-down hook 9-24 UB9070BB 1) Tie-down hook 2) Towing and tie-down hook UB9066CB...
  • Page 354 Vehicle with trailer hitch (if equipped) 1) Tie-down hook Towing hook cover removal procedure The towing hook cover is secured by tabs that fit into corresponding slots in the vehicle body. To remove the cover: UB9010BB 1. Free the tabs on the towing hook cover by firmly pressing the point indicated by an arrow with the palm of your hand.
  • Page 355 In case of emergency 2. Pull off the towing hook cover. 9-26 Towing hook cover installation procedure UB9084BA To reinstall the towing hook cover, push it in on both sides while pushing it back to its original position. Make certain that the tabs at the end of the cover are securely inserted into the corresponding slots in the vehicle’s body.

  • Page 356: Using A Flat-Bed Truck

    Using a flat-bed truck This is the best way to transport your vehicle. Use the following procedures to ensure safe transportation. 1. Shift the selector lever into the “P” position for au- tomatic transmission vehicles or “1st” for manual transmission vehicles. 2.
  • Page 357 In case of emergency If transmission failure occurs, transport your vehicle on a flat-bed truck. Do not run the engine while the vehicle is be- ing towed using this method. Transmission damage could result if the vehicle is towed with the engine running.

  • Page 358: Appearance Care

    Appearance care Exterior care ... Washing ... Waxing and polishing ... Cleaning aluminum wheels ... Cleaning front fog light lens ... Corrosion protection ... Most common causes of corrosion ... To help prevent corrosion ... Cleaning the interior ... Seat fabric ... Leather seat materials ...

  • Page 359: Exterior Care

    Appearance care Exterior care Appearance care Washing When washing the vehicle, the brakes may get wet. As a result, the brake stopping dis- tance will be longer. To dry the brakes, drive the vehicle at a safe speed while lightly pressing the brake pedal to heat up the brakes.

  • Page 360: Waxing And Polishing

    Frequent polishing with a compound or an in- correct polishing technique will result in removing the paint layer and exposing the undercoat. When in doubt, it is always best to contact your SUBARU deal- er or an auto paint specialist. NOTE...

  • Page 361: Cleaning Aluminum Wheels

    Appearance care Cleaning aluminum wheels Promptly wipe the aluminum wheels clean of any kind of grime or agent. If dirt is left on too long, it may be difficult to clean off. Do not use soap containing grit to clean the wheels. Be sure to use a neutral cleaning agent, and later rinse thoroughly with water.

  • Page 362: Corrosion Protection

    Corrosion protection Your SUBARU has been designed and built to resist corrosion. Special materials and protective finishes have been used on most parts of the vehicle to help maintain fine appearance, strength, and reliable oper- ation. Most common causes of corrosion The most common causes of corrosion are: 1.

  • Page 363: Cleaning The Interior

    Appearance care cumulation under the floor mats because that could cause corrosion. Occasionally check under the mats to make sure the area is dry. Keep your garage dry. Do not park your vehicle in a damp, poorly ventilated garage. In such a garage, cor- rosion can be caused by dampness.

  • Page 364: Leather Seat Materials

    If your SUBARU is to be parked for a long time in bright sun- light, it is recommended that the seats and headrests be covered, or the windows shaded, to prevent fading or shrinkage.

  • Page 366: Maintenance And Service

    Maintenance schedule ... Maintenance precautions ... Before checking or servicing in the engine compartment ... When you do checking or servicing in the engine compartment while the engine is running ... Engine hood ... Engine compartment overview ... Non-turbo models ... Turbo models ...
  • Page 367 Maintenance and service Types of tires ... 11-46 Tire inspection ... 11-47 Tire pressures and wear ... 11-47 Wheel balance ... 11-50 Wear indicators ... 11-50 Tire rotation ... 11-51 Tire replacement ... 11-51 Wheel replacement ... 11-52 Aluminum wheels ... 11-53 Windshield washer fluid ...

  • Page 368: Maintenance Schedule

    If you perform maintenance and service by yourself, you should familiarize yourself with the information provided in this section on general maintenance and service for your SUBARU. Incorrect or incomplete service could cause improper or unsafe vehicle operation. Any problems caused by improper maintenance and service performed by you are not eligible for warranty coverage.

  • Page 369: Before Checking Or Servicing In The Engine Compartment

    This will cause a fire. Because the fuel system is under pressure, replacement of the fuel filter should be per- formed only by your SUBARU dealer. Wear adequate eye protection to guard against getting oil or fluids in your eyes. If something does get in your eyes, thoroughly wash them out with clean water.

  • Page 370: When You Do Checking Or Servicing In The Engine Compartment While The Engine Is Running

    even when the engine is stopped. When you do checking or servicing in the engine compartment while the en- gine is running A running engine can be dangerous. Keep your fingers, hands, clothing, hair and tools away from the cooling fan, belts and any other mov- ing engine parts.
  • Page 371 Maintenance and service 3. Release the secondary hood release located under the front grille by moving the lever toward the left. 11-6 UBB094BA 4. Lift up the hood, release the hood prop from its re- tainer and put the end of the hood prop into the slot in the hood.
  • Page 372 Maintenance and service it. It could deform the metal. Always check that the hood is properly locked before you start driving. If it is not, it might fly open while the vehicle is moving and block your view, which may cause an accident and serious bodily injury.

  • Page 373: Engine Compartment Overview

    Maintenance and service Engine compartment overview Engine Compartment overview Non-turbo models 11-8 UBB106BB Manual transmission oil level gauge (MT) (page 11-27) or Dif- ferential gear oil level gauge (AT) (page 11-32) Air cleaner element (page 11- Clutch fluid reservoir (page 11- Automatic transmission fluid lev- el gauge (page 11-29) Brake fluid reservoir (page 11-...

  • Page 374: Turbo Models

    Turbo models Air cleaner element (page 11- Manual transmission oil level gauge (MT) (page 11-27) or Dif- ferential gear oil level gauge (AT) (page 11-32) Clutch fluid reservoir (page 11- Automatic transmission fluid lev- el gauge (page 11-29) Brake fluid reservoir (page 11- Windshield washer tank (page 11-53) Fuse box (page 11-59)

  • Page 375: Engine Oil

    Maintenance and service Engine oil Engine Oil level Engine Checking the oil level Check the engine oil level at each fuel stop. Checking Engine oil level 1. Park the vehicle on a level surface and stop the en- gine. Non-turbo models 11-10 Turbo models 2.
  • Page 376 Non-turbo models 1) Notch 2) Upper level 3) Lower level UGB081BB Turbo models 1) Notch 2) Upper level 3) Lower level 4. Pull out the dipstick again and check the oil level on it. If it is below the lower level, add oil to bring the level up to the upper level.

  • Page 377: Changing The Oil And Oil Filter

    Maintenance and service a bad smell, smoke, and/or a fire. If engine oil gets on the exhaust pipe, be sure to wipe it off. If you check the oil level just after stopping the engine, wait a few minutes for the oil to drain back into the oil pan before checking the level.
  • Page 378 oil. 1) Sealing washer 2) Drain plug 5. Wipe the seating surface of the drain plug with a clean cloth and tighten it securely with a new sealing washer after the oil has completely drained out. 6. Remove three clips at the front of the cover under the oil filter.
  • Page 379 Maintenance and service 7. Slide the cover toward the vehicle front to remove 8. Remove the oil filter with an oil filter wrench. 9. Before installing a new oil filter, apply a thin coat of engine oil to the seal. 10.Clean the rubber seal seating area of the bottom of engine and install the oil filter by hand turning.

  • Page 380: Recommended Grade And Viscosity

    Oil capacity (Guideline): 4.2 US qt (4.0 liters, 3.5 Imp qt) The oil quantity indicated above is only a guideline. The necessary quantity of oil depends on the quantity of oil that has been drained. The quantity of drained oil differs slightly depending on the temperature of the oil and the time the oil is left flowing out.

  • Page 381: Recommended Grade And Viscosity Under Severe Driving Conditions

    The following table lists the recommended viscosities and applicable temperatures. When adding oil, different brands may be used togeth- er as long as they are the same API classification and SAE viscosity as those recommended by SUBARU. 11-16 -30 -20 -10 B00446 SAE viscosity No.

  • Page 382: Cooling System

    –33°F (–36°C). For adding, use genuine SUBARU coolant or an equivalent: a mixture of 50% soft water and 50% ethylene-glycol basis coolant. Use of improper coolants may result in corrosion in the cooling system.

  • Page 383: Hose And Connections

    Check the fuse and replace it if necessary. If the fuse is not blown, have the cooling system checked by your SUBARU dealer. If frequent addition of coolant is necessary, there may be a leak in the engine cooling system. It is recom- mended that the cooling system and connections be checked for leaks, damage, or looseness.
  • Page 384 Changing the coolant Always add genuine SUBARU cooling system condi- tioner whenever the coolant is replaced. Change the engine coolant and add genuine SUBARU cooling system conditioner using the following proce- dures according to the maintenance schedule in the “Warranty and Maintenance Booklet”.
  • Page 385 Maintenance and service Turbo models 2. Place a proper container under the drain plug and loosen the drain plug. Never attempt to remove the radiator cap until the engine has been shut off and has cooled down completely. Since the coolant is under pressure, you may suffer serious burns from a spray of boiling hot coolant when the cap is re- moved.
  • Page 386 4. Slowly pour the coolant and fill up to just below the filler neck, allowing enough room to add genuine SUBARU cooling system conditioner in the radiator. Add genuine SUBARU cooling system conditioner un- til the coolant level reaches the filler neck. Do not pour the coolant too quickly, as this may lead to insufficient air bleeding and trapped air in the system.
  • Page 387 Maintenance and service FULL 1) “FULL” level mark 2) “LOW” level mark 5. Pour the coolant and fill to the reservoir tank’s “FULL” level mark. 11-22 UBB004FB 1) Rubber gaskets 6. Put the radiator cap back on and tighten firmly. At this time, make sure that the rubber gasket in the radi- ator cap is correctly in place.

  • Page 388: Air Cleaner Element

    “Warranty and Mainte- nance Booklet”. Under extremely dusty conditions, re- place it more frequently. It is recommended that you always use genuine SUBARU parts. Maintenance and service 1) Bolt 1. Remove the bolt securing the rear air cleaner ele- ment case.
  • Page 389 Maintenance and service 1) Air cleaner element 3. Separate the rear air cleaner element case from the front air cleaner element case and remove the air cleaner element. 4. Clean the inside of the front and rear air cleaner el- ement cases with a damp cloth and install a new air cleaner element.

  • Page 390: Spark Plugs

    Make sure the cables are replaced in the cor- rect order. USB522BB It may be difficult to replace the spark plugs. It is rec- ommended that you have the spark plugs replaced by your SUBARU dealer. Maintenance and service HSB032BA – CONTINUED – 11-25...

  • Page 391: Recommended Spark Plugs

    Maintenance and service The spark plugs should be replaced according to the maintenance schedule in the “Warranty and Mainte- nance Booklet”. Recommended spark plugs Spark plugs Recommended Non-turbo models: RC10YC4 (Champion) BKR6E-11 (NGK) BKR5E-11 (NGK) Turbo models: ILFR6B (NGK) 11-26 Drive belts Drive belts The alternator, power steering pump, and air condi-...

  • Page 392: Manual Transmission Oil

    Deflection New belt Used belt 0.28 – 0.35 (7.0 – 9.0) 0.35 – 0.43 (9.0 – 11.0) 0.30 – 0.33 (7.5 – 8.5) 0.35 – 0.40 (9.0 – 10.0) To check belt tension, place a straightedge (ruler) across two adjacent pulleys and apply a force of 22 lbs (98 N, 10 kg) midway between the pulleys by using a spring scale.
  • Page 393 Maintenance and service Turbo models 1. Park the vehicle on a level surface and stop the en- gine. 2. Pull out the dipstick, wipe it clean, and insert it again. 11-28 UGB001JA 1) Upper level 2) Lower level 3. Pull out the dipstick again and check the oil level on it.

  • Page 394: Recommended Grade And Viscosity

    Recommended grade and viscosity Each oil manufacturer has its own base oils and addi- Oil grade and viscosity Recommended tives. Never use different brands together. Oil grade: API classification GL-5 -30 -20 -10 75W/90 SAE viscosity No. and applicable temperature Automatic transmission fluid Fluid Automatic transmission...
  • Page 395 Maintenance and service HSB018MB UBB004KB 1) Yellow handle 1) Yellow handle 11-30...

  • Page 396: Recommended Fluid

    A) HOT range B) COLD range 1) Upper level 2) Lower level 4. Pull out the dipstick and check the fluid level on the gauge. If it is below the lower level on the “HOT” range, add the recommended automatic transmission fluid up to the upper level.

  • Page 397: Front Differential Gear Oil (At Vehicles)

    Maintenance and service Front differential gear oil (AT vehi- cles) Differential gear oil Front Front Differential gear oil Oil level Front differential (AT vehicles) Checking the oil level Gear oil level Checking 1) Yellow 1. Park the vehicle on a level surface and stop the en- gine.

  • Page 398: Recommended Grade And Viscosity

    If the vehicle requires frequent refilling, there may be an oil leak. If you suspect a problem, have the vehicle checked at your SUBARU deal- Your vehicle may be equipped with a rear differential protector. The differential protector provides protec-...
  • Page 399 Maintenance and service Non-turbo AT 1) Filler plug 2) Drain plug 11-34 OM-U0213 1) Filler hole 2) Drain hole 3) Oil level OM-U0214...

  • Page 400: Recommended Grade And Viscosity

    Others 1) Filler plug 2) Drain plug HSB042BB 1) Filler hole 2) Drain hole 3) Oil level Remove the plug from the filler hole and check the oil level. The oil level should be kept even with the bottom of the filler hole. If the oil level is below the bottom edge of the hole, add oil through the filler hole to raise the level.

  • Page 401: Power Steering Fluid

    Maintenance and service Oil grade: API classification GL-5 -30 -20 -10 75W/90 SAE viscosity No. and applicable temperature 11-36 Power steering fluid Fluid level Power steering Power Steering fluid Checking the fluid level Checking Fluid level HSB036BA 1) Reservoir tank Be careful not to burn yourself because the flu- id may be hot.
  • Page 402 “MIN” and “MAX” line. If the fluid level is extreme low, it may indicate possible leakage. Consult your SUBARU dealer for an inspec- HSB045BB – CONTINUED –...

  • Page 403: Recommended Fluid

    If the vehicle requires frequent refilling, there may be a leak. If you suspect a problem, have the vehicle checked at your SUBARU dealer. Never use different brands of brake fluid to- gether. Also, avoid mixing DOT 3 and DOT 4 brake fluids even if they are of the same brand.

  • Page 404: Recommended Brake Fluid

    Never splash the brake fluid over painted sur- faces or rubber parts. Alcohol contained in the brake fluid may damage them. Be careful not to spill brake fluid when add- ing it. If brake fluid touches the exhaust pipe, it may cause a bad smell, smoke, and/or a fire.

  • Page 405: Clutch Fluid (Mt Vehicles)

    If the vehicle requires frequent refilling, there may be a leak. If you suspect a problem, have the vehicle checked at your SUBARU dealer. Never use different brands of clutch fluid to- gether. When clutch fluid is added, be careful not to allow any dirt into the tank.

  • Page 406: Recommended Clutch Fluid

    1) “MAX” level mark 2) “MIN” level mark Check the fluid level on the outside of the reservoir. If the level is below “MIN” level mark, add the recom- mended clutch fluid to “MAX” level mark. Use only clutch fluid from a sealed container. Recommended clutch fluid Clutch fluid Recommended...

  • Page 407: Brake Booster

    Booster If the brake booster does not operate as described in the following, have it checked by your SUBARU deal- 1. With the engine off, depress the brake pedal sever- al times, applying the same pedal force each time. The distance the pedal travels should not vary.

  • Page 408: Checking The Brake Pedal Reserve Distance

    (294 N, 30 kg) and measure the distance between the upper surface of the pedal pad and the floor. When the measurement is smaller than the specifica- tion, or when the pedal does not operate smoothly, contact with your SUBARU dealer. Clutch pedal (Manual transmission vehicles) Clutch pedal Check the clutch pedal free play and reserve distance according to the maintenance schedule in the “War-...

  • Page 409: Checking The Clutch Pedal Free Play

    Lightly press the clutch pedal down with your finger until you feel resistance, and check the free play. If the free play is not within proper specification, con- tact your SUBARU dealer. 11-44 Replacement of brake pad and lining Brake pad and lining...

  • Page 410: Breaking-In Of New Brake Pads And Linings

    When replacing the brake pad or lining, use only gen- Breaking Breaking-in of new brake pads and linings uine SUBARU parts. After replacement, the new parts must be broken in as follows: Brake pad and lining While maintaining a speed of 30 to 40 mph (50 to 65 km/h), step on the brake pedal lightly.

  • Page 411: Parking Brake Stroke

    (approximately 44 lbs [196 N, 20 kg]). If the parking brake lever stroke is not within the specified range, have the brake sys- tem checked and adjusted at your SUBARU dealer. 11-46 Tires and wheels...

  • Page 412: Tire Inspection

    Tire Inspection rious damage, nails, and stones. At the same time, check the tires for abnormal wear. Contact your SUBARU dealer immediately if you find any problem. NOTE When the wheels and tires strike curbs or are subjected to harsh treatment as when the vehicle is driven on a rough surface, they can suffer dam- age that cannot be seen with the naked eye.
  • Page 413 Maintenance and service values shown on the tire placard. The tire placard is lo- cated on the door pillar on the driver’s side. Driving even a short distance warms up the tires and increases the tire pressures. Also, the tire pressures are affected by the outside temperature.
  • Page 414 Abnormally low tire pressure (tread worn at shoulders) Rolling resistance is high, so fuel consumption is also higher. Abnormally high tire pressure (tread worn in cen- ter) HSB053AA Ride comfort is poor. Also, the tire magnifies the ef- fects of road-surface bumps and dips, possibly result- ing in vehicle damage.

  • Page 415: Wheel Balance

    If you suspect that the wheels are not correctly bal- anced, have them checked and adjusted by your SUBARU dealer. Also have them adjusted after tire re- pairs and after tire rotation. NOTE Loss of correct wheel alignment* causes the tires to wear on one side and reduces the vehicle’s run-...

  • Page 416: Tire Rotation

    ible, the tire is worn beyond the acceptable limit and must be replaced immediately. With a tire in this condition, driving at high speeds in wet weather can cause the vehicle to hydroplane. The resulting loss of vehicle control can lead to an accident.

  • Page 417: Wheel Replacement

    For safe vehicle operation, SUBARU recommends re- placing all four tires at the same time. All four tires must be the same in terms of...

  • Page 418: Aluminum Wheels

    When wheel nuts, balance weights, or the center cap is replaced, be sure to replace them with genuine SUBARU parts designed for aluminum wheels. Maintenance and service Windshield washer fluid Windshield...
  • Page 419 Maintenance and service freeze type windshield washer fluid. SUBARU Wind- shield Washer Fluid contains 58.5% methyl alcohol and 41.5% surfactant, by volume. Its freezing temper- ature varies according to how much it is diluted, as in- dicated in the following table.

  • Page 420: Replacement Of Windshield Wiper Blades

    Replacement of windshield wiper blades Windshield wiper blades Replacement Grease, wax, insects, or other materials on the wind- shield or the wiper blade results in jerky wiper opera- tion and streaking on the glass. If you cannot remove the streaks after operating the windshield washer or if the wiper operation is jerky, clean the outer surface of the windshield (or rear window) and the wiper blades using a sponge or soft cloth with a neutral detergent or...
  • Page 421 Maintenance and service 1) Metal support 3. Grasp the locked end of the blade rubber assembly and pull it firmly until the stoppers on the rubber are free of the metal support. 11-56 HSB059BB 1) Metal spines 4. If the new blade rubber is not provided with two metal spines, remove the metal spines from the old blade rubber and install them in the new blade rubber.
  • Page 422 5. Align the claws of the metal support with the grooves in the rubber and slide the blade rubber as- sembly into the metal support until it locks. HSB061BA 1) Stopper 6. Be sure to position the claws at the end of the metal support between the stoppers on the rubber as shown.

  • Page 423: Battery

    Maintenance and service Battery Battery Before beginning work on or near any bat- tery, be sure to extinguish all cigarettes, match- es, and lighters. Never expose a battery to an open flame or electric sparks. Batteries give off a gas which is highly flammable and explosive. For safety, in case an explosion does occur, wear eye protection or shield your eyes when working near any battery.

  • Page 424: Fuses

    Fuses Fuses Never replace a fuse with one having a higher rating or with material other than a fuse be- cause serious damage or a fire could result. The fuses are designed to melt during an overload to prevent damage to the wiring harness and electrical equipment.
  • Page 425 Maintenance and service 1) Fuse puller 2) Spare fuses The fuse puller and spare fuses are stored in the main fuse box cover in the engine compartment. 11-60 HSB066BB 1) Good 2) Blown If any lights, accessories or other electrical controls do not operate, inspect the corresponding fuse.

  • Page 426: Main Fuse

    5. Inspect the fuse. If it has blown, replace it with a spare fuse of the same rating. 6. If the same fuse blows again, this indicates that its system has a problem. Contact your SUBARU dealer for repairs. Main fuse...

  • Page 427: Installation Of Accessories

    Maintenance and service Installation of accessories Accessories Always consult your SUBARU dealer before installing fog lights or any other electrical equipment in your ve- hicle. Such accessories may cause the electronic sys- tem to malfunction if they are incorrectly installed or if they are not suited for the vehicle.

  • Page 428: Replacing Bulbs

    Maintenance and service Replacing bulbs UBF047CB – CONTINUED – 11-63...
  • Page 429 Maintenance and service Wattage Headlight BAJA-S 12V-65/ BAJA-B Low beam 12V-55W H1 High beam 12V-60W 9005 Front turn signal light 12V-27W 1156NA Map light 12V-8W Dome light 12V-8W Door step light 12V-3.4W – Front turn signal light/ 12V-27/ parking and front side marker light Front fog light 12V-51W 9006...
  • Page 430 Maintenance and service 9 10 11 UBB100BB – CONTINUED – 11-65...

  • Page 431: Headlight

    If there are finger prints or grease on the bulb surface, wipe them away with a soft cloth moistened with alcohol. NOTE If headlight aiming is required, consult your SUBARU dealer for proper adjustment of the head- light aim.
  • Page 432 BAJA-Sport 1) Electrical connector 2) Push 1. Disconnect the electrical connector while pressing the lock release tab. UBB045BB 2. Remove the bulb holder from the headlight assem- bly by turning it counterclockwise. 3. Remove the bulb from the headlight assembly. 4.
  • Page 433 Maintenance and service BAJA-Turbo 11-68 UBB039BA 1) Low beam light bulb 2) High beam light bulb Remove the headlight bulb cover, by turning it coun- terclockwise. UBB040BB...
  • Page 434 Low beam light bulbs 1) Electrical connector 2) Red cable 3) Black cable 1. Disconnect the electrical connector for the black cable. UBB041BB 2. Remove the retainer spring. 3. Replace the bulb, then set the retainer spring se- curely. 4. Reconnect the electrical connector for black cable. 5.

  • Page 435: Front Fog Light

    Maintenance and service High beam light bulbs 11-70 UBB043BA 1) Push 1. Disconnect the electrical connector from the bulb. 2. Remove the bulb from the headlight assembly by turning it counterclockwise. 3. Replace the bulb with new one. 4. Reconnect the electrical connector. At this time, use care not to touch the bulb surface.

  • Page 436: Front Turn Signal Light, Parking Light And Side Marker Light

    After a bulb has been replaced, it is recommended that the head- light aiming adjustment be made at a SUBARU dealer. 1. Remove the headlight assembly mounting screws located at the top of and the front of the headlight as- sembly using a Phillips screwdriver or an open-end wrench.

  • Page 437: Rear Combination Lights

    Maintenance and service 4. Remove the bulb from the socket by pushing it and turning counterclockwise. Install a new bulb in the socket. 5. Set the bulb socket into the headlight assembly and turn it clockwise until it locks. 6. Set the headlight assembly into the vehicle body. Tighten the mounting screws.
  • Page 438 3. Remove the rear combination light mounting bolts. Then, slide the rear combination light assembly to the rear and remove it from the vehicle. UBB084BA 1) Backup light bulb 2) Brake/turn/tail/light bulb 4. Remove the bulb socket from the rear combination light assembly by turning it counterclockwise.

  • Page 439: Tail Light (On The Tailgate)

    Maintenance and service Tail light (on the tailgate) 1. Open the tailgate. Tail light Tail light Replacing bulbs 2. Remove the tailgate trim by loosening the installa- tion screws. 11-74 3. Remove the tail light cover by loosening the instal- UBB086BA lation screws.
  • Page 440 4. Remove the bulb socket from the tail light by turn- ing it counterclockwise. UBB088BA 5. Remove the bulb from the socket by pulling it. 6. Install a new bulb into the socket by pushing it. 7. Install the bulb socket into the tail light by turning it clockwise until it stops.

  • Page 441: License Plate Light

    Maintenance and service License plate light License plate light License plate light Replacing bulbs 1. Push two release buttons and pull the license plate bracket up until it clicks. 11-76 UBB096BA 2. Remove the two cover installation screws. 3. Push the license plate bracket back to the original position.
  • Page 442 4. Remove the screw from the side of the cover. 5. Remove the cover. UBB092BA 6. Remove the bulb socket from the license plate bracket by turning it counterclockwise. 7. Pull the bulb out of the socket. 8. Install a new bulb in the socket by pushing it. 9.

  • Page 443: Map Light, Dome Light And Door Step Light

    Maintenance and service Map light, dome light and door step light Dome light Map light Replacing bulbs Replacing bulbs Dome light Map light 11-78 Dome light UBB068BA HSB088BA...

  • Page 444: High Mount Stop And Cargo Light Assembly

    Door step light 1. Remove the lens by prying the edge of the lens with a flat-head screwdriver. 2. Pull the bulb out of the socket. Install a new bulb. 3. Reinstall the lens. High mount stop and cargo light as- sembly Replacing bulbs High mount stop light assembly...
  • Page 445 Maintenance and service 1) Cargo lights 2) High mount stop lights 2. Remove the bulb socket from the light assembly by turning it counterclockwise. 11-80 UBB090BB 3. Remove the bulb from the socket by pulling it. 4. Install a new bulb in the socket by pushing it. 5.

  • Page 446: Sport Activity Lights (If Equipped)

    6. Install the lens and reflector in the housing and se- cure with the screw. NOTE Other bulbs may be difficult to replace. Have your SUBARU dealer replace these bulbs if necessary. Maintenance and service UBB082BA – CONTINUED – 11-81...
  • Page 448 Specifications Specifications ... Dimensions ... Engine ... Electrical system ... Capacities ... Tires ... Wheel alignment ... Fuses and circuits ... Fuse panel located behind the coin tray ... Fuse panel located in the engine compartment ... Bulb chart ... Vehicle identification ...

  • Page 449: Specifications

    Specifications Specifications Specifications These specifications are subject to change without notice. Dimensions Model Overall length Overall width Overall height Wheelbase Tread Front Rear Ground clearance Engine Item Engine model Engine type Displacement cc (cu-in) Bore × Stroke in (mm) Compression ratio Firing order 12-2 BAJA-Sport...

  • Page 450: Specifications

    Electrical system Battery type and capacity (5HR) Alternator Spark plugs Non-turbo Turbo Capacities Fuel tank Engine oil Transmission oil (MT) Transmission fluid (AT) AT differential gear oil Rear differential gear oil Power steering fluid Engine coolant Non-turbo Turbo 55D23L (12-48AH) 75D23L (12-52AH) 12V-90A RC10YC4 (Champion)

  • Page 451: Tires

    Specifications Tires Type Tire size Wheel size Pressure Front Rear Temporary spare tire Size Pressure Wheel alignment Front Rear Camber Front Rear 12-4 Steel belted radial, Tubeless P225/60R16 97H 16 × 6 33 psi (230 kPa, 2.3 kgf/cm 33 psi (230 kPa, 2.3 kgf/cm T145/80R16 60 psi (420 kPa, 4.2 kgf/cm 0 in (0 mm)

  • Page 452: Fuses And Circuits

    Fuses and circuits Fuse panel located behind the coin tray Fuse panel Fuse rating UBC001BB Specifications Circuit Heater fan Heater fan Power door lock Keyless entry Mirror heater Cigarette lighter Remote controlled rear view mirrors Tail light Parking light SRS airbag Front fog light ABS solenoid Radio...

  • Page 453: Fuse Panel Located In The Engine Compartment

    Specifications Fuse panel Fuse rating Illumination brightness control Fuel pump Rear window wiper and washer Windshield wiper and washer Brake light Air conditioner Backup light Cruise control ABS control Wiper deicer Sports activity light Cargo lamp Accessory power outlet Seat heater 12-6 Fuse panel located in the engine com- Circuit...
  • Page 454 Fuse panel Fuse rating Circuit 20A (Non-tur- Radiator cooling fan (Main) 30A (Turbo) 20A (Non-tur- Radiator cooling fan (Sub) 30A (Turbo) ABS motor Rear window defogger Hazard warning flasher Horn Meter SRS airbag system warning light Automatic transmis- sion control unit ABS UNIT Alternator Headlight (right side)

  • Page 455: Bulb Chart

    Specifications Bulb chart Description Wattage Headlight S models 12V-65/55W Except S models Low beam 12V-55W High beam 12V-60W Front turn signal light 12V-27W Spot light 12V-8W Dome light 12V-8W Door step light 12V-3.4W Parking and front 12V-27/8W side marker light Front fog light 12V-51W Backup light...

  • Page 456: Vehicle Identification

    Vehicle identification Emission control label Vehicle identification number Tire inflation pressure label Certification and bar code label Vehicle identification number plate Model number plate C00113 Specifications – CONTINUED – 12-9...
  • Page 458 Consumer information and Reporting safety defects Tire information ... Tire labeling ... Recommended tire inflation pressure ... Glossary of tire terminology ... Tire care – maintenance and safety practices Vehicle load limit – how to determine ... Determining compatibility of tire and vehicle load capacities ...

  • Page 459: Tire Information

    Consumer information and Reporting safety defects For U.S.A. Consumer information and Reporting safety defects The following information has been compiled accord- ing to Code of Federal Regulations “Title 49, Part 575”. Tire information Tire labeling Many markings (e.g. Tire size, Tire Identification Number or TIN) are placed on the sidewall of a tire by tire manufacturers.

  • Page 460: Consumer Information And Reporting Safety Defects

    Example: 225 / 60 R 16 97 H (6) (7) Size designation (6) Load Index: A numerical code which speci- fies the maximum load a tire can carry at the speed indicated by its speed symbol, at maxi- mum inflation pressure. For example, “97”...
  • Page 461 Consumer information and Reporting safety defects (2) Tire Size (3) Tire Type Code (4) Date of Manufacture The first two figures identify the week, starting with “01” to represent the first full week of the cal- endar year; the second two figures represent the year.

  • Page 462: Recommended Tire Inflation Pressure

    Recommended tire inflation pressure Recommended cold tire inflation pressure Recommended cold tire inflation pressure for your vehicle’s tires is as follows, Tire size P225/60 R16 97H 16 × 6 1/2JJ Wheel size Pressure Front 33 psi (230 kPa, 2.3 kgf/cm Rear 33 psi (230 kPa, 2.3 kgf/cm Temporary...

  • Page 463: Glossary Of Tire Terminology

    Consumer information and Reporting safety defects Example: TIRE AND LOADING INFORMATION SEATING CAPACITY TOTAL 4 The combined weight of occupants and cargo should never exceed 363kg or 800 lbs. ORIGINAL TIRE SIZE COLD TIRE INFLATION PRESSURE FRONT 230 kPa,33 PSI P225/60R16 REAR 230 kPa,33 PSI...

  • Page 464: Occupant Distribution

    The maximum cold inflation pressure to which a tire may be inflated. Recommended inflation pressure The cold inflation pressure recommended by a vehicle manufacturer. Intended outboard sidewall 1)The sidewall that contains a whitewall, bears white lettering or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on the other sidewall of the tire, or...

  • Page 465: Tire Care - Maintenance And Safety Practices

    Consumer information and Reporting safety defects distributing to each axle its share of the curb weight, accessory weight, and normal occupant weight and dividing by two. Tire care – maintenance and safety practices Check on a daily basis that the tires are free from serious damage, nails, and stones.
  • Page 466 the tongue load of a trailer. Therefore cargo ca- pacity can be calculated by the following method. Cargo capacity = Load limit – (total weight of oc- cupants + total weight of optional equipment + tongue load of a trailer (if applicable)) For towing capacity information and weight lim- its, refer to “Trailer towing”...

  • Page 467: Total Weight

    Consumer information and Reporting safety defects Total weight = 154 lbs (70 kg) + 551 lbs (250 kg) (Occupant) (Cargo) = 705 lbs (320 kg) 2. Calculate the available load capacity by sub- tracting the total weight from the vehicle capacity weight of 800 lbs (363 kg).
  • Page 468 Total weight = 154 lbs (70 kg) + 176 lbs (80 kg) (Occupant) + 551 lbs (250 kg) (Cargo) = 881 lbs (400 kg) 2. Calculate the available load capacity. Available Load Capacity = 800 lbs (363 kg) 881 lbs (400 kg) (Vehicle (Total weight) capacity weight)
  • Page 469 Consumer information and Reporting safety defects the trailer tongue (i.e. Tongue load = 176 lbs (80 kg)). 1. Calculate the total weight. Total weight = 165 lbs (75 kg) + 265 lbs (120 kg) (Occupant) (Cargo) + 22 lbs (10 kg) + 176 lbs (80 kg) (Tongue load) (Trailer hitch) = 628 lbs (285 kg)

  • Page 470: Determining Compatibility Of Tire And Vehicle Load Capacities

    Total weight = 165 lbs (75 kg) + 143 lbs (65 kg) + 40 lbs (18 kg) (Occupant) + 11 lbs (5 kg) + 265 lbs (120 kg) (Child restraint) (Cargo) + 22 lbs (10 kg) + 176 lbs (80 kg) (Trailer hitch) (Tongue load) = 822 lbs (373 kg)

  • Page 471: Adverse Safety Consequences Of Overloading On Handling And Stopping And On Tires

    Consumer information and Reporting safety defects Adverse safety consequences of over- loading on handling and stopping and on tires Overloading could affect vehicle handling, stop- ping distance, vehicle and tire as shown in the following. This could lead to an accident and possibly result in severe personal injury.

  • Page 472: Uniform Tire Quality Grading Standards

    Uniform tire quality grading stan- dards This information indicates the relative perfor- mance of passenger car tires in the area of treadwear, traction, and temperature resistance. This is to aid the consumer in making an in- formed choice in the purchase of tires. Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width.

  • Page 473: Temperature A, B, C

    Consumer information and Reporting safety defects tests, and does not include acceleration, cornering, hydroplaning, or peak traction characteristics. Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.

  • Page 474: Reporting Safety Defects (Usa)

    However, NHTSA cannot become involved in individual problems between you, your dealer, or Subaru of America, Inc. To con- tact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 366-0123 in the Washington D.C. area) or write to: NHTSA, U.S.

  • Page 476: Index

    Index 14-1...
  • Page 477 Index ABS (Anti-lock Brake System) ... 7-33 Warning light ... 3-14 Accessories ... 5-4, 11-62 Air cleaner element ... 11-23 Air conditioner operation ... 4-10 Air filtration system ... 4-13 Alarm system ... 2-17 All-Wheel Drive warning light ... 3-16 Aluminum wheels ...
  • Page 478 Cargo Bed ... 6-16 Lamp ... 6-20 Lamp indicator light ... 3-18 Net hooks ... 6-13 Tie-down hooks ... 6-17 Catalytic converter ... 8-4 Center Console ... 6-5 Ventilators ... 4-2 Changing Flat tire ... 9-12 Oil and oil filter ... 11-12 Charge warning light ...
  • Page 479 Index Differential gear oil Front ... 11-32 Rear ... 11-33 Dimensions ... 12-2 Disarming the system ... 2-21, 2-23 Disc brake pad wear warning indicators ... 7-32 Dome light ... 6-2, 11-78 Door ajar warning lights ... 3-15 Door locks ... 2-3 Drive belts ...
  • Page 480 Gauge ... 3-8 Requirements ... 7-2 Fuses ... 11-59 Fuses and circuits ... 12-5 GAWR (Gross Axle Weight Rating) ... 8-19 Glove box ... 6-5 GVWR (Gross Vehicle Weight Rating) ... 8-19 Hard bed cover ... 6-24 Hazard warning flasher ... 3-6 Head restraint adjustment (Front) ...
  • Page 481 Index LSD (Limited slip differential) ... 7-30 Main fuse ... 11-61 Maintenance Precautions ... 11-3 Schedule ... 11-3 Seatbelt ... 1-21 Malfunction indicator lamp (Check Engine light) ... 3-12 Manual transmission ... 7-12 Manual transmission oil ... 11-27 Map light ... 6-3 Maximum load limits ...
  • Page 482 Rear seat Folding down ... 1-10 Rear window Defogger button ... 3-28 Recommended Automatic transmission fluid ... 11-31 Brake fluid ... 11-39 Clutch fluid ... 11-41 Oil grade and viscosity ... 11-15, 11-16, 11-29, Power steering fluid ... 11-38 Spark plugs ... 11-26 Remote keyless entry system ...
  • Page 483 Index Specifications ... 12-2 Speedometer ... 3-6 Sport activity lights ... 6-42, 11-81 SRS airbag (Supplemental Restraint System airbag) ... 4, 1-47 SRS airbag system monitors ... 1-60 SRS airbag system servicing ... 1-61 SRS airbag system warning light ... 3-11 SRS frontal airbag ...
  • Page 484 Valet mode ... 2-21 Vanity mirror ... 6-4 Vehicle Capacity weight ... 8-19 Identification ... 12-9 Ventilator ... 4-2 Warning and indicator lights ... 3-11 Warning lights ABS ... 3-14 All-Wheel Drive ... 3-16 Anti-lock Brake System ... 3-14 AT OIL TEMPerature ... 3-13 Brake system ...
  • Page 486 HSF028AA...

  • Page 487: Fuel Octane Rating

    GAS STATION REFERENCE Fuel: Non-turbo models Use only unleaded gasoline with an octane rat- ing of 87 AKI or higher. Turbo models Use premium unleaded gasoline with an oc- tane rating of 91 AKI or higher. If premium un- leaded gasoline is not available, regular un- leaded gasoline with octane rating of 87 AKI or higher may be temporarily used.
