Foreword
Congratulations on choosing a SUBARU vehicle. This Owner's Man-
ual has all the information necessary to keep your SUBARU in excel-
lent condition and to properly maintain the emission control system
for minimizing emission pollutants. We urge you to read this manual
carefully so that you may understand your vehicle and its operation.
For information not found in this Owner's Manual, such as details
concerning repairs or adjustments, please contact the dealer from
whom you purchased your SUBARU or the nearest SUBARU dealer.
The information, specifications and illustrations found in this manual
are those in effect at the time of printing. FUJI HEAVY INDUSTRIES
LTD. reserves the right to change specifications and designs at any
time without prior notice and without incurring any obligation to
make the same or similar changes on vehicles previously sold. This
Owner's Manual applies to all models and covers all equipment, in-
cluding factory installed options. Some explanations, therefore may
be for equipment not installed in your vehicle.
Please leave this manual in the vehicle at the time of resale. The next
owner will need the information found herein.
FUJI HEAVY INDUSTRIES LTD., TOKYO, JAPAN
and
are registered trademarks of FUJI HEAVY INDUSTRIES, LTD.
© copyright 2003 FUJI HEAVY INDUSTRIES LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2004 Legacy and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Subaru 2004 Legacy

Summary of Contents for Subaru 2004 Legacy

  • Page 1 Foreword Congratulations on choosing a SUBARU vehicle. This Owner’s Man- ual has all the information necessary to keep your SUBARU in excel- lent condition and to properly maintain the emission control system for minimizing emission pollutants. We urge you to read this manual carefully so that you may understand your vehicle and its operation.
  • Page 2 This manual describes the following types of the Legacy series. OUTBACK Sedan Legacy Sedan OUTBACK Station Wagon Legacy Station Wagon UBF060AB...

  • Page 4: Warranties For U.s.a

    Warranties Warranties for U.S.A. All SUBARU vehicles distributed by Subaru of Ameri- ca, Inc. and sold at retail by an authorized SUBARU dealer in the United States come with the following warranties: SUBARU Limited Warranty Emission Control Systems Warranty Emissions Performance Warranty All warranty information, including details of coverage and exclusions, is in the “Warranty and Maintenance...

  • Page 5: Seat, Seatbelt And Srs Airbags

    This chapter informs you how to start and operate your SUBARU. Chapter 8: Driving tips This chapter informs you how to drive your SUBARU in various conditions and explains some safety tips on driving. Chapter 9: In case of emergency...

  • Page 6: Index

    Please read these safety warnings as well as all other portions of this manual carefully in order to gain a bet- ter understanding of how to use your SUBARU vehicle safely. A WARNING indicates a situation in which seri- ous injury or death could result if the warning is ignored.

  • Page 7: Safety Precautions When Driving

    ual. This symbol means “Do not”, “Do not do this”, or “Do not let this happen”, depending upon the context. Safety precautions when driving Seatbelt and SRS airbag All persons in the vehicle should fasten their seatbelts BEFORE the vehicle starts to move. Otherwise, the possibility of serious injury be- comes greater in the event of a sudden stop or accident.

  • Page 8: Child Safety

    ment, the driver should always sit upright and well back in the seat as far from the steering wheel as practical while still maintaining full ve- hicle control and the front passenger should move the seat as far back as possible and sit upright and well back in the seat.

  • Page 9: Engine Exhaust Gas (Carbon Monoxide)

    the lock switch when children are riding in the vehicle. Failure to follow this procedure could result in injury to a child operating the power window. Refer to the “Power windows” section in chapter 2. Never leave unattended children in the vehi- cle.

  • Page 10: Drinking And Driving

    checked and corrected as soon as possible. If you must drive under these conditions, drive only with all windows fully open. Keep the trunk lid or rear gate closed while driving to prevent exhaust gas from entering the vehicle. Drinking and driving Drinking and then driving is very dangerous.

  • Page 11: Modification Of Your Vehicle

    drugs, please consult with your doctor. Never drive if you are under the influence of any illicit mind-altering drugs. For your own health and well-be- ing, we urge you not to take illegal drugs in the first place and to seek treatment if you are addicted to those drugs.

  • Page 12: California Proposition 65 Warning

    Driving with pets Unrestrained pets can interfere with your driving and distract your attention from driving. In a collision or sudden stop, unrestrained pets or cages can be thrown around inside the vehicle and hurt you or your passengers. Besides, the pets can be hurt under these situations.

  • Page 14: Table Of Contents

    Table of contents Seat, seatbelt and SRS airbags Keys and doors Instruments and controls Climate control Audio Interior equipment Starting and operating Driving tips In case of emergency Appearance care Maintenance and service Specifications Consumer information and Reporting safety defects Index...
  • Page 15 Illustrated index Exterior UBF003BB Hood lock release (page 11-5) Headlight switch (page 3-19) Bulb replacement (page 11-65) Wiper switch (page 3-26) Moonroof (page 2-32) Roof rail (page 8-20) Door locks (page 2-3) Tire pressure (page 11-44) Flat tires (page 9-5) 10) Tire chains (page 8-15) 11) Fog light switch (page 3-24) 12) Tie-down hooks (page 9-21)

  • Page 16: Tie-Down Hooks (Page

    UBF061BB Rear wiper switch (page 3-27) Rear window defogger switch (page 3-28) Fuel filler lid (page 7-4) Child safety locks (page 2-22) Towing hook (page 9-21) Trunk/Rear gate (page 2-26/2- Tie-down hooks (page 9-21) Bulb replacement (page 11-71) – CONTINUED –...
  • Page 17 Interior Passenger compartment area UBF038BB Lower anchorage for child re- straint system (page 2-22) Seatbelt (page 1-18) Parking brake lever (page 7-40) Front seat (page 1-2) Rear seat (page 1-10)

  • Page 18: Moonroof (Page

    Moonroof (page 2-32) Interior lights (page 6-2) Rear center passenger’s seat seatbelt (page 1-18) Sun visors (page 6-4) Map light (page 6-3) Inside mirror (page 3-31) UBF026BB – CONTINUED –...
  • Page 19 UBF036CB Cup holder (page 6-8) Center console (page 6-6) Glove box (page 6-6) Cigarette lighter (page 6-10) Ashtray (page 6-12)
  • Page 20 Trunk/cargo area UBF062BB Jack (page 9-32) Jack handle (page 9-32) Spare tire (page 9-32) – CONTINUED –...

  • Page 21: Door Locks (Page

    Instrument panel UBF021BB Door locks (page 2-3) Outside mirror (page 3-33) Light control lever (page 3-19) Combination meter (page 3-7) Wiper control lever (page 3-24) Hazard warning flasher switch (page 3-6) Climate control (page 4-1) Gear shift lever (MT) (page 7- 12)/Selector lever (AT) (page 7- Audio (page 5-1) 10) Cruise control (page 7-42)
  • Page 22 Light control and wiper control levers/switches Parking light switch (page 3-23) Windshield wiper (page 3-24) Mist (page 3-26) Windshield washer (page 3-26) Rear window wiper and washer switch (page 3-27) Wiper control lever (page 3-26) Illumination brightness control (page 3-22) Light control lever (page 3-19) Headlight ON/OFF (page 3-19) 10) Headlight flasher High/Low...

  • Page 23: Combination Meter

    Combination meter Overview UBF057BB Fuel gauge (page 3-8) Speedometer (page 3-7) Gear position indicator (page 3- Tachometer (page 3-8) Temperature gauge (page 3-9) Clock setting knob (page 3-18) Clock and outside temperature indicator (page 3-18, 3-8) Selector lever position indicator (page 3-17) Trip meter A/B selection and trip meter reset knob (page 3-7)

  • Page 24: Warning And Indicator Light

    Warning and indicator light Mark Name Seatbelt warning light SRS airbag system warning light CHECK ENGINE warning light/Malfunction indicator lamp Charge warning light Oil pressure warning light AT OIL temperature warn- ing light (if equipped) ABS warning light warning light equipped) Brake system warning light Mark...
  • Page 26 Front seats ... Fore and aft adjustment ... Seat cushion angle and height adjustment (Power seat only) ... Reclining the seatback ... Head restraint adjustment ... Lumbar support (if equipped) ... Seat heater (if equipped) ... Rear seats ... Armrest (if equipped) ... Headrest adjustment –...

  • Page 27: Seat, Seatbelt And Srs Airbags

    Seat, seatbelt and SRS airbags Front seats Seat, seatbelt and SRS airbags Never adjust the seat while driving to avoid the possibility of loss of vehicle control and of personal injury. Before adjusting the seat, make sure the hands and feet of rear seat passengers are clear of the adjusting mechanism.

  • Page 28: Fore And Aft Adjustment

    restrained or improperly restrained. Because children are lighter and weaker than adults, their risk of being injured from deployment is greater. For that reason, we strongly recom- mend that ALL children (including those in child seats and those that have outgrown child restraint devices) sit in the REAR seat properly restrained at all times in a child restraint device or in a seatbelt, whichever is appropriate for the...

  • Page 29: Seat Cushion Angle And Height Adjustment (Power Seat Only)

    Seat, seatbelt and SRS airbags Power seat (if equipped) To adjust the seat forward or backward, move the con- trol switch forward or backward. Seat cushion angle and height adjust- ment (Power seat only) UB1060BA UB1078BA...

  • Page 30: Reclining The Seatback

    To adjust the angle and height of the seat cushion, move the control switch in the corresponding direction. Seat, seatbelt and SRS airbags Reclining the seatback UB1062BA To prevent the passenger from sliding under the seatbelt in the event of a collision, always put the seatback in the upright position while the vehicle is in motion.
  • Page 31 Seat, seatbelt and SRS airbags Manual type Pull the reclining lever up and adjust the seatback to the desired position. Then release the lever and make sure the seat is securely locked into place. The seatback placed in a reclined position can spring back upward with force when released.

  • Page 32: Head Restraint Adjustment

    Head restraint adjustment To raise the head restraint, pull it up. To lower it, push the head restraint down while pressing the release button on the top of the seatback. The head restraint should be adjusted so that the cen- ter of the head restraint is closest to the top of the oc- cupant’s ears.

  • Page 33: Lumbar Support (If Equipped)

    Seat, seatbelt and SRS airbags 1. Slide the front seat forward as far as possible. 2. Pull off the head restraint while pressing the re- lease button. 3. Recline the seatback rearward up to the lowest po- sition. Remember to reinstall the head restraint when- ever the seatback is raised back.

  • Page 34: Seat Heater (If Equipped)

    Seat heater (if equipped) 1) Heating element The seat heater operates when the ignition switch is either in the “ACC” or “ON” position. Seat, seatbelt and SRS airbags 1) Indicator light UB1073BB To turn on the seat heater, push the “LO” or “HI” posi- tion on the switch, as desired, depending on the tem- perature.

  • Page 35: Rear Seats

    Seat, seatbelt and SRS airbags There is a possibility that people with delicate skin may suffer slight burns even at low tem- peratures if he/she uses the seat heater for a long period of time. When using the heater, al- ways be sure to warn the persons concerned.

  • Page 36: Armrest (If Equipped)

    Seat, seatbelt and SRS airbags Armrest (if equipped) HS8005BA UB1068BA Sedan Never stack luggage or other cargo higher than the top of the seatback because it could tumble forward and injure passengers in the event of a sudden stop or accident. –...
  • Page 37 Seat, seatbelt and SRS airbags Station wagon To lower the armrest, pull on the top edge of the arm- rest. To avoid the possibility of serious injury, pas- sengers must never be allowed to sit on the center armrest while the vehicle is in motion. 1-12 Loading long objects (Sedan) UB1100BA...

  • Page 38: Headrest Adjustment - Rear Center Seating Position On Station Wagon

    and heavier than 55 lbs (25 kg). Such objects can interfere with the driver’s proper operation of the car, possibly causing an accident and se- rious injury. Seat, seatbelt and SRS airbags Headrest adjustment – Rear center seating position on Station wagon To raise the headrest, pull it up.

  • Page 39: Folding Down The Rear Seat - Station Wagon

    Seat, seatbelt and SRS airbags Folding down the rear seat – Station wagon After returning the rear seat to its original po- sition, be certain to place all of the seatbelts and the tab attached to the seat cushion above the seat cushion.
  • Page 40 1. Lower the headrests. 2. Unlock the seatback by pulling the release knob and then fold the seatback down. Folding down the seat cushion and seatback 1. Move the front seat forward. 2. Close the rear passengers’ cup holder and ashtray. 3.
  • Page 41 Seat, seatbelt and SRS airbags 1) Seatbelt pocket 2) Buckles of rear center seatbelt 4. Store the seatbelts in the seatbelt pockets to pre- vent them from falling below the cushion. 1-16 UB1074BB 5. Raise the seat cushion by pulling up the tab. Make certain that the rear passenger’s cup holder is fully retracted before raising the seat cushion.
  • Page 42 6. Unlock the seatback by pulling the release knob and fold the seatback down. Confirm that the pin locat- ed at the bottom of the seat cushion is inserted into the slot at the top of the seatback. Seat, seatbelt and SRS airbags UB1027BA 7.

  • Page 43: Seatbelts

    Seat, seatbelt and SRS airbags Seatbelts Seatbelt safety tips All persons in the vehicle should fasten their seatbelts BEFORE the vehicle starts to move. Otherwise, the possibility of serious injury be- comes greater in the event of a sudden stop or accident.

  • Page 44: Emergency Locking Retractor (Elr)

    Infants or small children Use a child restraint system that is suitable for your ve- hicle. See information on “Child restraint systems” in this chapter. Children If a child is too big for a child restraint system, the child should sit in the rear seat and be restrained using the seatbelts.

  • Page 45: Automatic/Emergency Locking Retractor (A/Elr)

    Seat, seatbelt and SRS airbags Automatic/Emergency Locking Retrac- tor (A/ELR) Each passenger’s seatbelt has an Automatic/Emer- gency Locking Retractor (A/ELR). The Automatic/ Emergency Locking Retractor normally functions as an Emergency Locking Retractor (ELR). The A/ELR has an additional locking mode “Automatic Locking Retractor (ALR) mode”...
  • Page 46 backs are not used in the upright position in a collision, the risk of sliding under the lap belt and of the lap belt sliding up over the abdomen will increase, and both can result in serious in- ternal injury or death. Do not put cushions or any other materials between occupants and seatbacks or seat cushions.
  • Page 47 Seat, seatbelt and SRS airbags more slowly. If the belt still cannot be unlocked, let the belt retract slightly after giving it a strong pull, then pull it out slowly again. 4. Insert the tongue plate into the buckle until you hear a click.
  • Page 48 Adjusting the front seat shoulder belt anchor height The shoulder belt anchor height should be adjusted to the position best suited for you. To lower the anchor height, push the release button and slide the anchor down. To raise the anchor height, slide the anchor up. Pull down on the anchor to make sure that it is locked in place.
  • Page 49 Seat, seatbelt and SRS airbags retracted properly to avoid catching the belt webbing in the door. Rear seatbelts (except rear center seatbelt on wagon) 1. Sit well back in the seat. 2. Pick up the tongue plate and pull the belt out slowly. Do not let it get twisted.
  • Page 50 Unfastening the seatbelt Push the button on the buckle. Before closing the door, make sure that the belts are retracted properly to avoid catching the belt webbing in the door. Seat, seatbelt and SRS airbags Rear center seatbelt on wagon model HS1053BA 1) Center seatbelt tongue plate 2) Connector (tongue)
  • Page 51 Seat, seatbelt and SRS airbags Fastening the seatbelt with the webbing twisted can increase the risk or severity of injury in an accident. When fastening the belt after it is pulled out from the retractor, especially when inserting the connector’s tongue plate into the mating buckle (on right-hand side), always check that the webbing is not twisted.
  • Page 52 Rear-center seatbelt is stowed in the recess of the ceiling. 1. Remove the connector (tongue) plate from the holder located at the front of the recess by pulling the connector (tongue) plate rearward. Seat, seatbelt and SRS airbags HS1065CA 2. Pull out the seatbelt slowly from the overhead re- tractor.
  • Page 53 Seat, seatbelt and SRS airbags 3. After confirming that the webbing is not twisted, in- sert the connector (tongue) attached at the webbing end into the buckle on the right-hand side until a click is heard. If the belt stops before reaching the buckle, return the belt slightly and pull it out more slowly.
  • Page 54 5. To make the lap part tight, pull up on the shoulder belt. And place the lap belt as low as possible on your hips, not on your waist. Seat, seatbelt and SRS airbags Unfastening the seatbelt HS1061BA Push the release button of the center seatbelt buckle (on the left-hand side) to unfasten the seatbelt.
  • Page 55 Seat, seatbelt and SRS airbags 1. Insert a key or other hard pointed object into the 1-30 slot in the connector (buckle) on the right-hand side and push it in, and the connector (tongue) plate will disconnect from the buckle. UB1036BA 2.

  • Page 56: Seatbelt Maintenance

    Do not allow the retractor to roll up the seat- belt too quickly. Otherwise, the metal tongue plates may hit against the trim, resulting in damaged trim. Have the seatbelt fully rolled up so that the tongue plates are neatly stored. A hanging tongue plate can swing and hit against the trim during driving, causing damage to the trim.

  • Page 57: Seatbelt Extender

    SUBARU dealer. When ordering an extender, only or- der one particularly designed for your vehicle. Several different types of extenders are available to match var- ious varieties of front seatbelt designs.
  • Page 58 extender. Do not use the extender if the buckle of the extender rests over the abdomen. Do not let someone else use the extender. Use of an extender when it is not needed could reduce the effectiveness of the seatbelt and re- sult in more serious injury in the event of a col- lision.

  • Page 59: Front Seatbelt Pretensioners

    In the event that a preten- sioner is activated, both the driver’s and front pas- senger’s seatbelt retractor assemblies must be re- placed and only by an authorized SUBARU dealer. When replacing seatbelt retractor assemblies, use only genuine SUBARU parts.

  • Page 60: System Monitors

    If the front seatbelt retractor assembly or sur- rounding area has been damaged, contact your SUBARU dealer as soon as possible. When you sell your vehicle, we urge you to ex- plain to the buyer that it has seatbelt pretension- ers by alerting him to the contents of this section.

  • Page 61: System Servicing

    In the event of a malfunction indicated by any of follow- ing, the vehicle should be taken promptly to your near- est SUBARU dealer to have the system checked. Un- less checked and repaired, the seatbelt pretensioners and airbags will not function reliably: Flashing or flickering of the indicator light.

  • Page 62: Precautions Against Vehicle Modification

    SUBARU dealer as soon as possible. Precautions against vehicle modifica- tion Always consult your SUBARU dealer if you want to in- stall any accessory parts to your vehicle. Do not perform any of the following modifica- tions. Such modifications can interfere with proper operation of the seatbelt pertensioners.
  • Page 63 Seat, seatbelt and SRS airbags Children could be endangered in an accident if their child restraints are not properly secured in the vehicle. When installing the child restraint system, carefully fol- low the manufacturer’s instructions. According to accident statistics, children are safer when properly restrained in the rear seating positions than in the front seating positions.

  • Page 64: Where To Place A Child Restraint System

    Where to place a child restraint system The following are SUBARU’s recommendations on where to place a child restraint system in your vehicle. Seat, seatbelt and SRS airbags A: Front passenger’s seat...
  • Page 65 Seat, seatbelt and SRS airbags tion. Some types of child restraints might not be able to be secured firmly due to projection of the seat cushion. In this seating position, you should use only a child re- straint system that has a bottom base that fits snugly against the contours of the seat cushion and can be securely retained using the seatbelt.

  • Page 66: Choosing A Child Restraint System

    Choosing a child restraint system Choose a child restraint system that is appropriate for the child’s age and size (weight and height) in order to provide the child with proper protection. The child re- straint system should meet all applicable requirements of Federal Motor Vehicle Safety Standards for United States or Canada Motor Vehicle Safety Standards for Canada.
  • Page 67 Seat, seatbelt and SRS airbags the event of an accident may be increased. Installing a rearward facing child restraint 1. Place the child restraint system in the rear seating position. 2. Run the lap and shoulder belt through or around the child restraint system following the instructions provided by its manufacturer.
  • Page 68 6. Push and pull the child restraint system forward and from side to side to check if it is firmly secured. Sometimes a child restraint can be more firmly se- cured by pushing it down into the seat cushion and then tightening the seatbelt.
  • Page 69 Seat, seatbelt and SRS airbags NOTE When the child restraint system is no longer in use, remove it and restore the ELR function of the retractor. That function is restored by retracting the seatbelt fully. Installing forward facing child restraint 1.
  • Page 70 Seat, seatbelt and SRS airbags UB1126BA UG1087BA 6. Before having a child sit in the child restraint sys- tem, move it back and forth and right and left to check if it is firmly secured. Sometimes a child restraint can be more firmly secured by pushing it down into the seat cushion and then tightening the seatbelt.

  • Page 71: Installing A Booster Seat

    Seat, seatbelt and SRS airbags latch the hook onto the top tether anchor and tighten the top tether. See the “Top tether anchorages” for ad- ditional instructions. 9. To remove the child restraint system, press the re- lease button on the seatbelt buckle and allow the belt to retract completely.
  • Page 72 the event of an accident may be increased. 1. Place the booster seat in the rear seating position and sit the child on it. The child should sit well back on the booster seat. 2. Run the lap and shoulder belt through or around the booster seat and the child following the instruc- tions provided by its manufacturer.

  • Page 73: Installation Of Child Restraint Systems By Use Of Lower And Tether Anchorages (Latch)

    Seat, seatbelt and SRS airbags effective in preventing or reducing injury. Place the lap belt as low as possible on the child’s hips. A high-positioned lap belt will in- crease the risk of sliding under the lap belt and of the lap belt sliding up over the abdomen, and both can result in serious internal injury or death.
  • Page 74 Your vehicle is equipped with four lower anchorages (bars) and three upper anchorages (tether anchorag- es) for accommodating such child restraint systems. Seat, seatbelt and SRS airbags UB1086CA The lower anchorages (bars) are used for installing a child restraint system only on the rear seat window- side seating positions.
  • Page 75 Seat, seatbelt and SRS airbags The tether anchorages (upper anchorages) are pro- vided for all the seating positions (middle and both window-side ones) of the rear seat. 1-50 UB1087BA You will find marks “ seat seatbacks. These marks indicate the positions of the lower anchorages (bars).
  • Page 76 Each lower anchorage is located where the seat cush- ion meets the seatback. When you install a child restraint system, fol- low the manufacturer’s instructions supplied with it. After installing the child restraint sys- tem, check to ensure that it is held securely in position.

  • Page 77: Top Tether Anchorages

    6. To remove the child restraint system, follow the re- verse procedures of installation. If you have any question concerning this type of child restraint system, ask your SUBARU dealer. Top tether anchorages Your vehicle is equipped with three top tether anchor- ages so that a child restraint system having a top teth- er can be installed in the rear seat.
  • Page 78 lows, while observing the instructions by the child re- straint system manufacturer. Since a top tether can provide additional stability by of- fering another connection between a child restraint system and the vehicle, we recommend that you use a top tether whenever one is required or available. Seat, seatbelt and SRS airbags Anchorage location TOP TETHER...
  • Page 79 Seat, seatbelt and SRS airbags TOP TETHER Station wagon A) Center anchorage B) Left (right) anchorage Three anchorages, i.e., ones for the right, center and left positions, are already installed on the rear shelf 1-54 (on Sedan) or on the rear edge of the roof (on Station wagon).
  • Page 80 2. Fasten the top tether hook of the child restraint sys- tem to the appropriate upper anchorage. Seat, seatbelt and SRS airbags UG1087BA 3. Tighten the top tether securely. Do not route the top tether over the headrest. It may happen that the top tether cannot be fas- tened tightly.

  • Page 81: Station Wagon

    Seat, seatbelt and SRS airbags Station wagon Window-side seating position 1-56 UB1096BA Center seating position 1. Remove the headrest (if so equipped) at the seat- ing position where the child restraint system has been installed with the seatbelt or lower anchorages; lift up the headrest while pressing the release button.

  • Page 82: Srs Airbag (Supplemental Restraint System Airbag)

    2. Fasten the top tether hook of the child restraint sys- tem to the appropriate upper anchorage. 3. Tighten the top tether securely. Always remove the headrest when mounting a child restraint system with a top tether. Other- wise, it may happen that the top tether cannot be fastened tightly.
  • Page 83 Seat, seatbelt and SRS airbags To obtain maximum protection in the event of an accident, the driver and all passengers in the vehicle should always wear seatbelts when the vehicle is moving. The SRS airbag is designed only as a supplement to the primary protection provided by the seatbelt.
  • Page 84 Put children aged 12 and under in the rear seat properly restrained at all times. The SRS airbag deploys with considerable speed and force and can injure or even kill children, espe- cially if they are 12 years of age and under and are not restrained or improperly restrained.
  • Page 85 Seat, seatbelt and SRS airbags When the SRS airbag deploys, some smoke will be released. This smoke could cause breathing problems for people with a history of asthma or other breathing trouble. If you or your passengers have breathing problems after SRS airbag deploys, get fresh air promptly.
  • Page 86 Components Airbag control module (including impact sensors) Airbag module (driver’s side) Airbag module (passenger’s side) Front sub sensor (left hand side) Front sub sensor (right hand side) Seatbelt pretensioner (driver’s side) Seatbelt pretensioner (passen- ger’s side) Side airbag module (driver’s side –...

  • Page 87: Srs Frontal Airbag

    Seat, seatbelt and SRS airbags SRS frontal airbag The driver’s SRS frontal airbag is stowed in the center portion of the steering wheel. The passenger’s SRS frontal airbag is stowed near the top of the dashboard under an “SRS AIRBAG” mark. In a moderate to severe frontal collision, the driver’s and front passenger’s SRS frontal airbags deploy and supplement the seatbelts by reducing the impact on...
  • Page 88 Never hold a child on your lap or in your arms. The SRS airbag deploys with considerable force and can injure or even kill the child. Seat, seatbelt and SRS airbags HS1069BA The SRS airbag deploys with considerable speed and force. Occupants who are out of proper position when the SRS airbag deploys could suffer very serious injuries.
  • Page 89 Seat, seatbelt and SRS airbags avoid injuries that can result when the SRS air- bag contacts an occupant not in proper posi- tion such as one thrown toward the front of the car during pre-accident braking. Do not put any objects over the steering wheel pad and dashboard.
  • Page 90 Operation A) Driver’s side B) Passenger’s side 1) SRS airbags deploy as soon as a collision occurs. 2) After deployment, SRS airbags start to deflate immediately so that the driver’s vision is not obstructed. Seat, seatbelt and SRS airbags HS1087BB –...
  • Page 91 Seat, seatbelt and SRS airbags The SRS airbag can function only when the ignition switch is in the “ON” position. If the front sub sensors inside the both front fenders and the impact sensors in the airbag control module detect a certain predetermined amount of force during a frontal collision, the control module sends signals to the frontal airbag modules instructing them to inflate the SRS frontal airbags.
  • Page 92 experienced in the passenger compartment during a collision. That level differs from one type of collision to another, and it may have no bearing on the visible damage done to the vehicle itself. Examples of accident in which the SRS frontal airbag will most likely deploy.
  • Page 93 Seat, seatbelt and SRS airbags from the road surface (such as when the vehicle plunges into a deep ditch, is severely bumped or knocked hard against an obstacle on the road such as a curb). 1-68 Examples of the types of accidents in which the SRS frontal airbag is unlikely to deploy.
  • Page 94 or sign pole, or if it slides under a truck’s load bed, or if it sustains an oblique offset frontal impact, the SRS frontal airbag may not deploy depending on the level of accident forces involved. Seat, seatbelt and SRS airbags Examples of the types of accidents in which the SRS frontal airbag will basically not deploy.

  • Page 95: Srs Side Airbag (If Equipped)

    Seat, seatbelt and SRS airbags speed frontal collision. 1) First impact! 2) Second impact!! In an accident where the vehicle is impacted more than once, the SRS frontal airbag deploys only once. Example: In the case of a double collision, first with an- other vehicle, then against a concrete wall in immedi- ate succession, once the SRS frontal airbag is activat- ed on the first impact, it will not be activated on the...
  • Page 96 Do not sit or lean unnecessarily close to either front door. The SRS side airbag is stored in both front seat seatbacks next to the door, and it provides protection by deploying rapidly (faster than the blink of an eye) in the event of a side impact collision.
  • Page 97 Seat, seatbelt and SRS airbags 1-72 Never allow a child to kneel on the front pas- senger’s seat facing the side window or to wrap his/her arms around the front seat seatback. In the event of an accident, the force of SRS side airbag deployment could seriously injure or even kill the child because his/her head or arms or other body parts are close to the side airbag.
  • Page 98 Do not attach accessories to the door trim or near either SRS side airbags and do not place objects near the SRS side airbags. In the event of the SRS side airbag deployment, they could be propelled dangerously toward the vehicle’s occupants and cause injuries.

  • Page 99: Operation

    Seat, seatbelt and SRS airbags Operation A) SRS side airbag deploys as soon as a collision oc- curs. B) After deployment, SRS side airbag starts to deflate im- mediately. 1-74 The SRS side airbag can function only when the igni- tion switch is in the “ON”...
  • Page 100 the vehicle. Do not touch the SRS side airbag system com- ponents around the front seatback with bare hands right after deployment. Doing so can cause burns because the components can be very hot as a result of deployment. The SRS side airbag is designed to deploy in the event of an accident involving a moderate to severe side im- pact collision.
  • Page 101 Seat, seatbelt and SRS airbags Examples of the types of accidents in which the SRS side airbag is unlikely to deploy. 1-76 UB1167BB 1) The vehicle is involved in an ob- lique side impact. 2) The vehicle is involved in a side impact in an area outside the vicin- ity of the passenger compartment.
  • Page 102 There are many types of collisions which might not necessarily require SRS side airbag deployment. In the event of accidents like those illustrated below, the SRS side airbag may not deploy depending on the lev- el of accident forces involved. Seat, seatbelt and SRS airbags Examples of the types of accidents in which the SRS side airbag will basically not deploy.

  • Page 103: Srs Airbag System Monitors

    Seat, seatbelt and SRS airbags The SRS side airbag is basically not designed to de- ploy if the vehicle is involved in a frontal collision or is struck from behind. Examples of such accidents are il- lustrated below. 1) First impact! 2) Second impact!! In an accident where the vehicle is struck from the side more than once, the SRS side airbag deploys only...

  • Page 104: Srs Airbag System Servicing

    In the event of a malfunction indicated by any of follow- ing, the vehicle should be taken promptly to your near- est SUBARU dealer to have the system checked. Un- less checked and repaired, the SRS airbags will not function reliably: Flashing or flickering of the indicator light.

  • Page 105: Precautions Against Vehicle Modification

    SUBARU parts. To ensure their long-term reliability, the SRS airbags must be inspected by a SUBARU dealer ten years af- ter the date of manufacture, which is shown on the cer- tification label attached to the driver’s door.
  • Page 106 SUBARU genuine accessory parts to the side body (only for vehicles with side airbags). Always consult your SUBARU dealer if you want to in- stall any accessory parts to your vehicle. – CONTINUED –...
  • Page 108 Keys ... Key number ... Door locks ... Locking and unlocking from the outside ... Locking and unlocking from the inside ... Power door locking switches ... Remote keyless entry system (if equipped) ... Locking the doors ... Unlocking the doors ... Illuminated entry ...

  • Page 109: Keys And Doors

    Keys and doors Keys Keys and doors 1) Master key 2) Submaster key 3) Valet key 4) Key number plate Three types of keys are provided for your vehicle. Master key, submaster key and valet key. The master key and submaster key fit all locks on your vehicle.

  • Page 110: Door Locks

    Door locks Locking and unlocking from the out- side To lock the door from the outside with the key, turn the key toward the rear. To unlock the door, turn the key toward the front. Lift the outside door handle to open an unlocked door. Locking without the key 1) Rotate the lock lever rearward.

  • Page 111: Locking And Unlocking From The Inside

    Keys and doors Locking without the key 1) Push the power door locking switch forward. 2) Close the door. To lock the door from the outside using the power door locking switch, push the switch forward (“LOCK” side) and then close the door. In this case, all closed doors and the rear gate (for station wagon) are locked at the same time.

  • Page 112: Power Door Locking Switches

    1) Lock 2) Unlock To lock the door from the inside, rotate the lock lever rearward. To unlock the door from the inside, rotate the lock lever forward. The red mark on the lock lever appears when the door is unlocked. Pull the inside door handle to open an unlocked door.
  • Page 113 Keys and doors Front passenger’s switch 1) Lock 2) Unlock All doors and the rear gate (station wagon) can be locked and unlocked by the power door locking switch- es located at the driver’s side and the front passen- ger’s side doors. To lock the doors, push the switch forward.

  • Page 114: Remote Keyless Entry System (If Equipped)

    Remote keyless entry system (if equipped) Do not expose the transmitter to severe shocks, such as those experienced as a result of dropping or throwing. Do not take the transmitter apart except when replacing the battery. Do not get the transmitter wet. If it gets wet, wipe it dry with a cloth immediately.

  • Page 115: Locking The Doors

    Keys and doors A: “LOCK/ARM” button (Orange) Press to lock all doors. Press and Hold to activate panic alarm. Press three times in a five second period to use vehi- cle finder function. B: “UNLOCK/DISARM” button (Blue) 1) Press once to Unlock driver’s door. 2) Press a second time to Unlock all other doors and rear gate.

  • Page 116: Illuminated Entry

    es of the “UNLOCK/DISARM” button (for unlock- ing of all of the doors and the rear gate) is extreme- ly short, the system may not respond. Illuminated entry The interior (dome) light will illuminate when the “UN- LOCK/DISARM” button is pressed. These lights stay illuminated for approximately 30 seconds if any of the doors (or the rear gate on the station wagon) is not opened.

  • Page 117: Replacing The Battery

    Keys and doors Replacing the battery Do not let dust, oil or water get on or in the transmitter when replacing the battery. When the transmitter battery begins to get weak, transmitter range will begin to decrease and the LED will not illuminate.

  • Page 118: Replacing Lost Transmitters

    LOCK/DISARM” button six times to synchronize the unit. Replacing lost transmitters If you lose a transmitter or want to purchase additional transmitters (up to four can be programmed), you should re-program all of your transmitters for security reasons. It is recommended that you have your dealer program all of your transmitters into your system.
  • Page 119 Keys and doors 2. Open the driver’s door and sit in the driver’s seat. 3. Close the driver’s door. 2-12 HS2019BB 1) ON 2) LOCK 4. Place the ignition key into the ignition switch and cycle the switch from LOCK to ON ten times within 15 seconds.
  • Page 120 To program the transmitters: 1. Open the driver’s door. 2. Close the driver’s door. HS2019BC 1) Press any button. 3. Press and release any button on the transmitter that you wish to program into the system. The horn will sound two times to indicate that the transmitter has been programmed.
  • Page 121 Keys and doors system has exited the programming mode. to your vehicle. 2. Make sure that the keyless entry system properly operates by operating each transmitter. Deleting old transmitter codes The control unit of the keyless entry system has four memory locations to store transmitter codes, giving it the ability to operate with up to four transmitters.

  • Page 122: Security System (If Equipped)

    Security system (if equipped) The security system helps to protect your vehicle and valuables from theft. The horn sounds and the turn signal lights flash if someone attempts to break into your vehicle. The starter motor is also interrupted to prevent starting the vehicle without a key.
  • Page 123 Keys and doors 5. Close all doors (and the rear gate on the station wagon). 1) Press to Arm the system. 2) Press to Disarm the system. 2-16 1) Security system indicator light HS2016EB 6. Briefly press the “LOCK/ARM” button (for less than two seconds).

  • Page 124: Disarming The System

    To arm the system using power door locking switches 1. Close all windows and moonroofs (if so equipped). 2. Remove the key from the ignition switch. 3. Open the doors and get out of the vehicle. 4. Make sure that the engine hood (and the trunk lid) is locked.

  • Page 125: Sounding A Panic Alarm

    Keys and doors 1. Unlock the door with the key and then open the door. 2. The alarm will sound. 3. Insert the key into the ignition switch and cycle it from the “LOCK” to the “ON” position three (3) times within 5 seconds.
  • Page 126 1. Remove the side sill cover on the driver’s side. 1) Open the driver’s door. 2) Remove the two clips fastening the front portion of the cover with a screwdriver. 3) Remove the side sill cover by pulling it up. UB2036BA 1) Connector for SRS airbag system (yellow) 2) White (1P)
  • Page 127 Keys and doors Arming the system In passive mode, the system will automatically activate the alarm but WILL NOT automatically lock the doors. In order to lock the doors you must either lock them as indicated in step 4 be- low or with the key once they have been closed.
  • Page 128 3. Open the doors and get out of the vehicle. 4. Before closing the doors, lock all doors with the in- side door lock levers. 5. Close the doors. The system will automatically arm after one minute. In the passive mode, the system can also be armed with the remote transmitter or with the power door locking switches.

  • Page 129: Child Safety Locks

    Keys and doors To exit this mode, close the door and turn the ignition switch to the “ON” position. 2-22 Child safety locks Always use the child safety lock whenever a child rides in the rear seat. Serious injury could result if a child accidentally opened the door and fell out.

  • Page 130: Windows

    the doors from being opened even if the inside door handle is pulled. When the child safety lock lever is in the lock position, the door cannot be opened from inside regardless of the position of the inner door handle lock lever. The door can only be opened from the outside.
  • Page 131 Keys and doors Driver’s side switches 1) Lock switch 2) For driver’s window 3) For rear left passenger’s window 4) For front passenger’s window 5) For rear right passenger’s window All door windows can be controlled by the power win- dow switch cluster at the driver side door.
  • Page 132 way, pull the switch up lightly. To close: Pull the switch up lightly and hold it. The window will close as long as the switch is held. Operating the passengers’ windows To open the passengers’ windows, push the appropri- ate switch down and hold it until the window reaches the desired position.

  • Page 133: Trunk Lid (Sedan)

    Keys and doors 1) Open 2) Close To open the window, push the switch down and hold it until the window reaches the desired position. To close the window, pull the switch up and hold it until the window reaches the desired position. When the lock switch on the power window switch cluster, located on the driver’s side door, is in the “LOCK”...

  • Page 134: To Open And Close The Trunk Lid From Outside

    To open and close the trunk lid from outside 1) Open To open the trunk lid from outside, insert the key and turn it clockwise. To close the trunk lid, lightly press the trunk lid down until the latch engages. To open the trunk lid from inside UBF013CB 1) Open...

  • Page 135: To Cancel The Trunk Lid Release

    Keys and doors To cancel the trunk lid release The inside trunk lid release can be cancelled to help prevent unauthorized entry into the trunk. To cancel the trunk lid release, set the lid release cancel lever (located on the inside of the trunk lid, mounted to the trunk lid latch) to the “CANCEL”...
  • Page 136 play with the release handle. If the driver starts the vehicle without knowing that a child is in- side the trunk and the child opens the lid using the release handle, the child could fall out and be killed or seriously injured. Do not close the lid while gripping the release handle.
  • Page 137 3. Move the release handle, from outside the vehicle, in the direction of the arrow to check if the latch is re- leased. If the latch is not released, contact your SUBARU dealer. In that case, use the key to release the latch, then close the trunk lid.

  • Page 138: Rear Gate (Station Wagon)

    Rear gate (Station wagon) 1) Lock 2) Unlock To unlock the rear gate, insert the key in the keyhole and turn it clockwise. To lock the rear gate, insert the key in the keyhole and turn it counterclockwise. If your vehicle is equipped with power door locking switches, the rear gate can also be locked and unlocked through use of the power door locking switches.

  • Page 139: Moonroof (If Equipped)

    Keys and doors the rear gate by pulling on the recessed grip from inside the cargo space. There is a danger of your hand being caught and injured. Do not jam a plastic bag in or place cellophane tape on the rear gate stays or scratch the stays while loading or unloading cargo.

  • Page 140: Tilting/Sliding Moonroof (Sedan)

    or extremely cold conditions have caused it to freeze shut. Tilting/sliding moonroof (Sedan) The moonroof has both tilting and sliding functions. The moonroof operates only when the ignition switch is in the “ON” position. 1) Open/Close switch 2) Tilt switch To raise or lower the moonroof The tilting function will only operate when the moon- roof is fully closed.

  • Page 141: Dual Moonroofs (Station Wagon)

    Keys and doors For the procedure, refer to “Moonroof – if the moonroof cannot be closed” in Chapter 9 “In case of emergency”. Sun shade The sun shade can be slid forward or backward by hand while the moonroof is closed. If the moonroof is opened, the sun shade also moves back.
  • Page 142 The front moonroof has a tilting function and the rear moonroof has a sliding function. Both moonroofs operate only when the ignition switch is in the “ON” position. 1) Open 2) Close To open the moonroof(s) 1. Open the front sunshade. 2.
  • Page 143 Keys and doors initial stop position of 7.9 in (20 cm), and the wind noise should diminish. If the moonroof cannot be closed through switch operation because of system failure, it can be closed manually using a hex-headed wrench. For the procedure, refer to “Moonroof – if the moonroof cannot be closed”...
  • Page 144 Ignition switch ... LOCK ... ACC ... ON ... START ... Key reminder chime ... Ignition switch light ... Key interlock release (AT vehicles only) ... Hazard warning flasher ... Meters and gauges ... Speedometer ... Odometer/Trip meter ... Tachometer ... Outside temperature indicator (if equipped) ..
  • Page 145 Instruments and controls For vehicles with manual heating and air conditioning systems ... For vehicles with automatic climate control .. Windshield wiper deicer (if equipped) ... Mirrors ... Inside mirror ... Auto-dimming mirror/compass (if equipped) Outside mirrors ... Tilt steering wheel ... Horn ...

  • Page 146: Instruments And Controls

    Ignition switch Instruments and controls Never turn the ignition switch to “LOCK” while the vehicle is being driven or towed because that will lock the steering wheel, preventing steering control. And when the engine is turned off, it takes a much greater effort than usual to steer.

  • Page 147: Acc

    Instruments and controls Automatic transmission vehicles The key can be turned from “ACC” to “LOCK” only when the selector lever is in the “P” position. Manual transmission vehicles HS3015BA The key can be turned from “ACC” to “LOCK” only when the key is pushed in while turning it. In this position the electrical accessories (radio, ac- cessory power outlet, etc.) can be used.

  • Page 148: Start

    This is the normal operating position after the engine is started. START Do not turn the ignition switch to the “START” position while the engine is running. The engine is started in this position. The starter cranks the engine to start it. When the key is released (after the engine has started), the key automatically returns to the “ON”...

  • Page 149: Hazard Warning Flasher

    Instruments and controls 3. Turn the ignition key while pressing the key inter- lock release lever. Take your vehicle to the nearest SUBARU dealer im- mediately to have the key interlock system repaired. Hazard warning flasher UG3025BA The hazard warning flasher is used to warn other driv- ers when you have to park your vehicle under emer- gency conditions.

  • Page 150: Meters And Gauges

    Meters and gauges Speedometer The speedometer shows the vehicle speed. Odometer/Trip meter 1) Trip meter 2) Odometer To ensure safety, do not attempt to change the function of the indicator during driving, as an accident could result. Odometer The odometer shows the total distance that the vehicle has been driven.

  • Page 151: Tachometer

    Instruments and controls nately. A trip meter B trip meter To set the trip meter to zero, select either the A trip or B trip meter and push the knob and keep it pushed for more than 1 second. NOTE If the connection between the combination meter and battery is broken for any reason such as vehi- cle maintenance or fuse replacement, the data re-...

  • Page 152: Temperature Gauge

    nition switch is in the “ACC” or “LOCK” position. The gauge may move slightly during braking, turning or acceleration due to fuel level movement in the tank. Temperature gauge If the pointer exceeds the normal operating range, safely stop the vehicle as soon as possi- ble.

  • Page 153: Warning And Indicator Lights

    Brake system warning light If any lights fail to come on, it indicates a burned-out bulb or a malfunction of the corresponding system. Consult your authorized SUBARU dealer for repair. 3-10 Seatbelt warning light and chime When the ignition switch is turned to the “ON” position,...

  • Page 154: Check Engine Warning Light/Malfunction Indicator Lamp

    Malfunction indicator lamp If the CHECK ENGINE light comes on while you are driving, have your vehicle checked/repaired by your SUBARU dealer as soon as possible. Continued vehicle operation without having the emission control system checked and repaired as necessary could cause serious damage, which may not be covered by your vehicle’s...

  • Page 155: Charge Warning Light

    If the belt is loose, broken or if the belt is in good condition but the light remains on, contact your nearest SUBARU deal- er immediately. Oil pressure warning light Do not operate the engine with the oil pressure warning light on.

  • Page 156: Abs Warning Light

    8 mph (12 km/h). The warning light comes on during driving. If these occur, have the ABS system repaired at the first available opportunity by your SUBARU dealer. (U.S.) NOTE...

  • Page 157: Brake System Warning Light

    You will be safe while driving with this condition, but you should have your vehicle checked at a SUBARU dealer as soon as possible. 3-14...

  • Page 158: Door Open Warning Lights

    “MIN” mark in the reservoir, do not drive the vehicle. Have the vehicle towed to the near- est SUBARU dealer for repair. Door open warning lights The specific door open warning light comes on if any door or the rear gate is not fully closed.

  • Page 159: Security System Status Indicator Light (If Equipped)

    The VDC system is probably faulty under any of the following conditions. Have your vehicle checked at a SUBARU dealer as soon as possible. The VDC OFF indicator light does not come on when the ignition switch is turned to the “ON” position.

  • Page 160: Selector Lever Position Indicator (At Vehicles)

    Selector lever position indicator (AT vehicles) This indicator shows the position of the selector lever. Gear position indicator (AT vehicle with SPORTSHIFT) UB3025AA When the selector lever is in the manual gate, this in- dicator shows the currently selected gear. Turn signal indicator lights These lights show the operation of the turn signal or lane change signal.

  • Page 161: High Beam Indicator Light

    Instruments and controls High beam indicator light This light shows that the headlights are in the high beam mode. This indicator light also comes on when the headlight flasher is operated. Cruise control set indicator light This light comes on when vehicle speed has been set. 3-18 Clock To set the time, turn the setting knob clockwise to ad-...

  • Page 162: Light Control Switch

    Light control switch To prevent battery discharge resulting from ac- cidentally leaving your lights on when your ve- hicle is parked, the light switch operates only when the ignition switch is in the “ON” posi- tion. In any other position, the vehicle’s lights will be out.

  • Page 163: High/Low Beam Change (Dimmer)

    Instruments and controls High/low beam change (dimmer) To change from low beam to high beam, push the turn signal lever forward. When the headlights are on high beam, the high beam indicator light “ strument panel is also on. To switch back to low beam, pull the lever back to the detent position.

  • Page 164: Daytime Running Light System

    indicator light “ ” on the instrument panel also comes on. Daytime running light system The tail lights, parking lights, and side marker lights are not turned on by the daytime running light system. The light switch must always be turned to the “...

  • Page 165: Illumination Brightness Control

    Instruments and controls of the turn or lane change. The lever will return auto- matically to the neutral position when you release it. 3-22 Illumination brightness control 1) Brighten 2) Darken When the lighting switch is in the “ position, you can adjust brightness of the instrument panel illumination for better visibility.

  • Page 166: Parking Light Switch

    Instruments and controls Parking light switch that will run down the battery. HS3029BA The parking light switch operates regardless of the ig- nition switch position. By pushing the front end of this switch, following lights will come on. – Parking lights –...

  • Page 167: Fog Light Switch (If Equipped)

    Instruments and controls Fog light switch (if equipped) The fog lights operate only when the headlights are on low beam. Push the fog light switch to turn the fog lights on. Press the switch again to turn them off. The indicator light located on the switch will illuminate when the fog lights are on.
  • Page 168 Use clean water if windshield washer fluid is unavailable. In areas where water freezes in winter, use SUBARU Windshield Washer Fluid or the equivalent. (See “Windshield washer flu- id” section in chapter 11.)

  • Page 169: Windshield Wiper And Washer Switches

    Instruments and controls blades” section (chapter 11) for replacement in- structions. Windshield wiper and washer switches Windshield wipers 1) MIST To turn the wipers on, push the wiper control lever down. : Intermittent LO: Low speed HI: High speed To turn the wipers off, return the lever to the “OFF” po- 3-26 sition.

  • Page 170: Rear Window Wiper And Washer Switch (If Equipped)

    Washer To wash the windshield, push the washer button at the end of the wiper control lever. The washer fluid sprays until you release the washer button. The wipers oper- ate while you push the button. Rear window wiper and washer switch (if equipped) UB2020BA 1) ON...

  • Page 171: Rear Window Defogger Switch

    Instruments and controls ating, turn the knob on the end of the wiper control le- ver upward to the “ ” position. The washer fluid sprays until you release the knob. To wash the rear window when the rear wiper is not in use, turn the knob on the end of the wiper control lever downward to the “...

  • Page 172: For Vehicles With Manual Heating And Air Conditioning Systems

    For vehicles with manual heating and air conditioning systems To turn on the defogger, push the switch. To turn it off, push the switch again. The indicator light located on the switch lights up while the rear window defogger is operating. For vehicles with automatic climate control UG3508BA...

  • Page 173: Windshield Wiper Deicer (If Equipped)

    Instruments and controls Windshield wiper deicer (if equipped) To prevent the battery from being discharged, do not operate the windshield wiper deicer con- tinuously for any longer than necessary. The windshield wiper deicer operates only when the ignition switch is in the “ON” position. Before turning on the windshield wiper deicer, remove any snow from the windshield.

  • Page 174: Mirrors

    Mirrors Always check that the inside and outside mirrors are properly adjusted before you start driving. Inside mirror 1) Tab The inside mirror has a day and night position. Pull the tab at the bottom of the mirror toward you for the night position.

  • Page 175: Compass Calibration

    Instruments and controls dicator light (green) located to the right of the button will illuminate. By pressing and releasing the right button, the com- pass display is toggled on or off. When the compass is on, an illuminated compass reading will appear in the lower part of the mirror.

  • Page 176: Outside Mirrors

    Compass zone adjustment 1. The zone setting is factory preset to Zone 8. Refer to the “Compass calibration zone” map attached to the end of this manual to verify that the compass zone set- ting is correct for your geographical location. 2.
  • Page 177 Instruments and controls Remote control mirror switch (if equipped) 1) Selection switch 2) Direction control switch The remote control mirrors operate only when the ig- nition switch is in the “ON” or “ACC” position. 1. Press either end of the selection switch, “L” for the left, “R”...

  • Page 178: Tilt Steering Wheel

    The indicator light located on the switch will come on when the outside mirror defogger heater in operation. To turn it off, push the switch again. Instruments and controls Tilt steering wheel Do not adjust the steering wheel tilt position while driving.

  • Page 179: Horn

    Instruments and controls place. 5. Make sure that the steering wheel is securely locked by moving it up and down. 3-36 Horn To sound the horn, push the horn pad. HS3044BA...
  • Page 180 Climate control Ventilator ... Driver’s side ventilators ... Center ventilators ... Front passenger’s side ventilators ... Air flow selection ... Manual heating and air conditioning system ... Control panel ... Heater operation ... Air conditioner operation ... Automatic climate control system (if equipped) ...

  • Page 181: Ventilator

    Climate control Ventilator Climate control Driver’s side ventilators 1) Open 2) Close Move the thumb-wheel up and down or right and left to adjust the flow direction. Center ventilators Move the thumb-wheel up and down or right and left to UB4038BB adjust the flow direction.

  • Page 182: Climate Control

    Front passenger’s side ventilators 1) Open 2) Close Move the thumb-wheel up and down or right and left to adjust the flow direction. UB4040BB Climate control – CONTINUED –...

  • Page 183: Air Flow Selection

    Climate control Air flow selection UB4036BA...

  • Page 184: Manual Heating And Air Conditioning System

    Manual heating and air conditioning system Control panel 1) Temperature control dial 2) Fan speed control dial 3) Air flow control dial 4) Air conditioner button 5) Air inlet selection button 6) Rear window defogger button (Refer to “Rear window defogger switch”...

  • Page 185: Air Inlet Selection Button

    Climate control NOTE When the dial is placed in the “ sition, the air conditioner compressor operates automatically regardless of the position of the air conditioner button to defog the windshield quick- ly. At the same time, the air inlet selection is auto- matically set to “Outside air”...

  • Page 186: Heater Operation

    ON position (Recirculation): Interior air is recirculat- ed inside the vehicle. Push the air inlet selection but- ton to the ON position. The indicator light will come on. Push the air inlet selection button to the ON position for fast cooling with the air conditioner or when driving on a dusty road.

  • Page 187: Heating And Defrosting

    Climate control “ ” position. Heating and defrosting To direct warm air toward the floor and the windshield: 1. Set the air flow control dial to the “ 2. Set the temperature control dial to the most com- fortable level. 3.
  • Page 188 Bi-level heating This setting allows you to direct air of different temper- atures from the instrument panel and foot outlets. The air from the foot outlets is slightly warmer than from the instrument panel outlets. 1. Set the air inlet selection button to the “OFF” posi- tion.

  • Page 189: Air Conditioner Operation

    Climate control 1. Set the air inlet selection button to the “OFF” posi- tion. 2. Set the air flow control dial to the “ 3. Set the temperature control dial all the way left. 4. Set the fan speed control dial to the desired speed. When driving on a dusty road, set the air inlet control lever to the “ON”...

  • Page 190: Automatic Climate Control System (If Equipped)

    2. Set the temperature control dial to the red area. 3. Set the fan speed control dial at the highest speed. Climate control Automatic climate control system (if equipped) NOTE Operate the automatic climate control system when the engine is running. When the engine coolant is cold, for instance in cold weather, the air flows through the windshield defroster outlets and the blower runs at the lowest...

  • Page 191: Control Panel

    Climate control pressed, and is used in conjunction with the Temper- ature control dial to maintain a constant, comfortable climate within the passenger compartment. The temperature can be set within a range of 65 to 85°F (18 to 32°C). NOTE The temperature is shown in units of Fahrenheit for US model and in Centigrade for Canadian mod- 4-12...
  • Page 192 AUTO switch AUTO mode operation: The Automatic Climate Control system automatically controls the air temperature of the passenger com- partment in the AUTO mode. When the “AUTO” switch is pressed, the indicator light “AUTO” on the control panel comes on. In this state, outlet air temperature, fan speed, air flow distribution, air-inlet control, and air conditioner compressor operation are automatically controlled.
  • Page 193 Climate control OUT.TEMP switch To check the outside air temperature, push the “OUT.TEMP” switch. The outside air temperature will be displayed for five seconds, and then the display au- tomatically changes back to the inside air tempera- ture. The display changes over from the inside air tempera- ture to the outside air temperature as its normal indi- cation if you keep the switch pressed for more than 2 seconds.
  • Page 194 – Fan speed control switch AUTO 1) Fan speed control switch The fan speed control switch has the 5 positions: AUTO position and 4 different fan speed positions. With the fan speed control switch in the AUTO posi- tion, the fan speed changes automatically correspond- ing to various conditions: air temperature inside and outside of the passenger compartment, intensity of the sunlight, etc.
  • Page 195 Climate control (Heat-def): Air flows through the windshield de- froster outlets and foot outlet. NOTE When the “ ” mode is selected, the air condi- tioner compressor operates automatically regard- less of the position of the air conditioner button to defog the windshield quickly.
  • Page 196 this switch is pushed. : Outside air is drawn into the passenger com- partment. When the air conditioning system is operat- ed in the “AUTO” mode, this position is selected auto- matically. The indicator light “ ” on the control panel comes on when this switch is pushed.

  • Page 197: Temperature Sensors

    Climate control Temperature sensors 1) Sun-load sensor 4-18 UB5024BB 1) In vehicle air temperature sensor This Automatic Climate Control system employs the several sensors. These are very delicate parts. There- fore, if these sensors are damaged, it is possible that the Automatic Climate Control system will not properly control the air temperature in the passenger compart- ment.

  • Page 198: Operating Tips For Heater And Air Conditioner

    grille) – In-vehicle temperature sensor (beside the tempera- ture control dial.) – Ambient sensor (at the under side of the bumper) Climate control Operating tips for heater and air con- ditioner Cleaning ventilator grille 1) Ventilator inlet grill Always keep the front ventilator inlet grille free of snow, leaves, or other obstructions to ensure efficient heating and defrosting.

  • Page 199: Efficient Cooling After Parking In Direct Sunlight

    Checking air conditioning system be- fore summer season Check the air conditioner unit for refrigerant leaks, hose conditions, and proper operation each spring. This check is best performed by your SUBARU dealer. 4-20 Cooling and dehumidifying in high hu- midity and low temperature weather...

  • Page 200: Air Filtration System (If Equipped)

    Since the filter element is a viscous type, it is unnecessary to clean or wash the element. Have your filter checked or replaced by your SUBARU deal- Replacement schedule: Every 12 months or 9,300 miles (15,000 km) whichev-...
  • Page 202 Antenna system ... Printed antenna ... Pillar mounted antenna ... Installation of accessories ... Audio set ... Type A and type B audio set ... Type C audio set ... McIntosh audio set ... In-dash 6 CD auto changer (Optional audio unit –...

  • Page 203: Antenna System

    Audio Antenna system Audio Printed antenna Do not use sharp instruments or window clean- er containing abrasives to clean the inner sur- face of the window on which the antenna is printed. Doing so may damage the antenna printed on the window. Sedan The antenna is printed on the inside of the rear window glass.

  • Page 204: Audio

    If reception continues to be unsatisfactory, switch to a stronger station. Installation of accessories Always consult your SUBARU dealer before installing a citizen band radio or other transmitting device in your vehicle. Such devices may cause the electronic control system to malfunction if they are incorrectly in- stalled or if they are not suited for the vehicle.

  • Page 205: Type A And Type B Audio Set

    Audio Audio set Your SUBARU may be equipped with one of the fol- lowing audio sets. See the pages indicated in this sec- tion for operating details. Type A and type B audio set Radio operation: refer to page 5-6...

  • Page 206: Mcintosh Audio Set

    McIntosh audio set Radio operation: refer to page 5-28 Built-in CD changer operation: refer to page 5-34 In-dash 6 CD auto changer (Optional audio unit – if equipped) UB5063AA Inserting and removing a disc or all discs: refer to page 5-39 Audio HS5011AA –...

  • Page 207: Type A And B Audio Set (If Equipped)

    Audio Type A and B audio set (if equipped) Type A: Without weather band Type B: With weather band The audio set will operate only when the ignition switch is in the “ACC” or “ON” position. Radio operation UB5052BB (1) Power switch/Volume, Tone, Balance, Fader control dial (2) BAND button (3) Tuning buttons...
  • Page 208 Power switch and volume/bass/treble/fader/ balance control Power switch and volume control (PWR/VOL) The dial (1) is used for both power (ON/OFF) and vol- ume control. The radio is turned ON and OFF by push- ing the dial and the volume is controlled by turning the dial.
  • Page 209 Audio Display Control mode Bass control Treble control Fader control Balance control Volume control Turn counterclockwise For less bass For less treble To increase rear speaker volume and decrease front speaker volume To increase left speaker volume and decrease right speaker volume For less volume HS5014BA Turn clockwise...
  • Page 210 Waveband selection FM/AM selection Push the “BAND” button (2) to select FM1, FM2 or AM reception. The display indicates which one is currently selected. FM/AM/Weather band selection Push the “BAND” button (2) to select FM1, FM2, AM or Weather band (WB) reception. The display indi- cates which is currently selected.
  • Page 211 Audio tion reception is weakened by distance from the sta- tion or proximity to tall buildings and hills. Selecting preset stations Presetting a station with a “preset button” (4) allows you to select that station in a single operation. Up to six WB (if equipped), AM, FM1 and FM2 stations each may be preset.

  • Page 212: Compact Disc Player Operation

    Audio Compact disc player operation (7) Disc slot (8) CD button (9) Eject button (10) Fast forward and track up button (11) Fast reverse and track down (8) (9) button (12) Random button (13) Repeat button (14) Scan button (15) PWR (power) switch (14) (15) (13) (12)
  • Page 213 Audio To playback a compact disc When CD is not in the player Hold a disc with a finger in the center hole while grip- ping the edge of the disc, then insert it in to the slot (with the label side up) and the player will automatical- ly pull the disc into position.
  • Page 214 Release the button to stop fast reverse. Repeat playback Use this to play a certain track repeatedly. During playback, press the “RPT” button (13) and release it in less than 2 seconds. The “RPT” indicator will come on and the song will be played continuously. To cancel the repeat mode, press the button again.

  • Page 215: Cd Changer Control (If Optional In Dash Cd Changer Is Connected)

    An optional CD changer can be connected to this audio unit. See your SUBARU dealer for more information. For procedures for loading and un- loading CDs, refer to “In-dash 6 CD auto changer (Optional audio unit – if equipped)” in this chapter.
  • Page 216 To start playback Press the “CD” button (16). The “CD” indicator will come on and the disc number will appear on the dis- play and the CD changer will start playback. NOTE If the “CD” button is pressed during a radio broadcast, the CD changer will interrupt the broadcast.
  • Page 217 Audio – The display shows “SCAN” and the track number being scanned. – You hear the first 10 seconds of each track. – The operation is automatically cleared after play- ing all programs. Then, normal playback starts. 2. Press the “SCAN” button again when you hear a track you like.

  • Page 218: Type C Audio Set (If Equipped)

    Type C audio set (if equipped) The radio will operate only when the ignition switch is in the “ACC” or “ON” position. Radio operation (1) Power switch, Volume control, Bass/Middle/Treble control and Fader/Balance control dial (2) AUDIO (audio mode) button (3) Fader/Balance selection button (4) FM/AM selection button (5) WB (weather band) button...
  • Page 219 Audio Power switch and volume/bass/treble/fader/ balance control (PWR/VOL) The dial (1) is used for both power (ON/OFF) and vol- ume control. The radio is turned ON and OFF by push- ing the dial and the volume is controlled by turning the dial.
  • Page 220 Display Control mode BASS Bass control MIDDLE Middle note control TREBLE Treble control FADER Fader control To increase rear speaker volume and BALANCE Balance control To increase left speaker volume and VOLUME Volume control Turn counterclockwise For less bass For less middle note For less treble To increase front speaker volume and decrease front speaker volume...

  • Page 221: Tone Control

    Audio Tone control The volume control dial (1) normally function as vol- ume control. The dial become a control for Bass, Mid- dle note or Treble when you select the appropriate tone control mode. Choose desired level for each mode by turning the vol- ume control dial.
  • Page 222 lect FM1, FM2 or AM reception. Each time this button is pressed, the band will change in the following order: The display indicates which one is currently selected. Stereo indicator The stereo indicator “ST” will come on when an FM stereo broadcast is received.

  • Page 223: Selecting Preset Stations

    Audio ing, stations are scanned in the direction of low fre- quencies to high frequencies only. Automatic tuning may not function properly if the sta- tion reception is weakened by distance from the sta- tion or proximity to tall buildings and hills. Selecting preset stations Presetting a station with a preset button (6) allows you to select that station in a single operation.

  • Page 224: Built-In Cd Changer Operation

    Audio Built-in CD changer operation (9) Eject button (10) Disc slot (11) CD (CD player selection) button (12) Repeat button (10) (11) (12) (13) (14) (13) Random button (14) LOAD button (15) Disc select buttons (16) Track selection buttons (17) SCAN button (17) (16) (15)
  • Page 225 Audio NOTE Make sure to always insert a disc with the label side up. If a disc is inserted with the label side down, it might be ejected or the player might shut off. How to insert a CD(s) Inserting a CD 1.
  • Page 226 standby mode. Press the “CD” button to start play- back. Loading all the magazine (Full disc loading mode) 1. If you continue to press the “LOAD” button for more than 1.5 seconds, the player will produce beep sound and will enter the full disc loading mode. 2.

  • Page 227: Random Playback

    Audio Repeat playback Press the “RPT” button (12) while a song is playing to play the song repeatedly. The “RPT” indicator will come on and the song will be played continuously. To cancel the repeat mode, press the button again. Then the “RPT”...

  • Page 228: Onstar® System Operation

    OnStar® system operation (models with OnStar® system) When the OnStar system operates and a call is initiat- ed, the message “CALL” will be shown on the display, and the speakers will automatically switch over to the incoming voice signal. NOTE A call will not be suspended even if the ignition key is turned to the Off position.

  • Page 229: Radio Operation

    Audio Radio operation (1) (2) 5-28 UB5063BB (1) FM/AM selection button (2) Weather band button (3) Tuning/FF·FB dial (4) SCAN button (5) Preset buttons (6) Fader/Balance control button (7) Power switch, Volume control, Bass/Treble control and Fader/ Balance control dial (8) Bass/Treble sound control but-...
  • Page 230 Power switch and volume/bass/treble/fader/ balance control (ON/VOL) The dial (1) is used for both power (ON/OFF) and vol- ume control. The radio is turned ON and OFF by push- ing the dial and the volume is controlled by turning the dial.
  • Page 231 Audio Display Control mode BASS Bass control TREB Treble control Fader control Balance control Volume control 5-30 Turn counterclockwise For less bass For less treble To increase rear speaker volume and decrease front speaker volume To increase left speaker volume and decrease right speaker volume For less volume HS5014BA...
  • Page 232 Tone control The volume control dial (7) normally function as vol- ume control. The dial become a control for Bass or Treble when you select the appropriate tone control mode. Choose desired level for each mode by turning the vol- ume control dial.

  • Page 233: Manual Tuning

    Audio wish to listen. Weather band button (WB) Press the “WB” button (2) to choose weather band. The display will show WB. Use the tuning dial to select the station to which you wish to listen. Manual tuning Turn the tuning dial (3) outer tuner to increase or de- crease the reception frequency in individual steps.
  • Page 234 Audio and will be required to be re-input. If a mobile telephone is placed near the radio, it may cause the radio to emit noise when it receives calls. This noise does not indicate a radio fault. – CONTINUED – 5-33...

  • Page 235: Built-In Cd Changer Operation

    Audio Built-in CD changer operation (10) 5-34 (11) (12) (14) (16) (15) (13) UB5063CB (9) DISC IN indicator light (10) Disc slot (11) Eject button (12) LOAD button (13) Repeat button (14) FF·FB dial (15) Disc button (16) Disc select button...
  • Page 236 NOTE Single CDs (i.e., 8-cm/3-inch CDs) are not sup- ported, and if inserted, they will be immediately ejected. Make sure to always insert a disc with the label side up. If a disc is inserted with the label side down, it might be ejected or the player might shut off.
  • Page 237 Audio cally drawn in, and the player will start playback of the disc, beginning with the first number. To insert more discs in succession, repeat Steps 1 and 2. While the player is in the loading mode, if you press FM/AM selection button, the player will enter standby mode.
  • Page 238 Selecting a desired track (TRACK) : Skipping forward : Skipping backward : Fast forwarding : Fast reversing Skipping forward Turn the FF·FB dial (14) clockwise and release it im- mediately to skip to the beginning of the next track. Each time the knob is turned and released, the indicat- ed track number will increase.

  • Page 239: Onstar® System Operation

    Audio 1. Press the “Disc select” button (16) of the disc whose “DISC” indicator is ON. 2. Press the “EJECT” button (11). Then the “DISC” in- dicator associated with the disc you have selected will blink, and the disc will be ejected. To remove more discs in succession, repeat Steps 1 and 2.

  • Page 240: In-Dash 6 Cd Auto Changer (If Equipped)

    Audio In-dash 6 CD auto changer (if equipped) (1) Disc slot (2) Disc indicators (disc No.1 to 6) (3) Disc select buttons (disc No.1 to (4) Eject button HS5016BB – CONTINUED – 5-39...
  • Page 241 Audio Do not attempt to insert two or more discs into the slot at a time. Doing so can cause me- chanical damage to the CD changer. only music mark. Do not use CDs listed below which could cause damage to the CD player. 3-inch (8 cm) compact disc.
  • Page 242 2. Press the “Eject button” (4). The selected disc will be ejected and the indicator light will begin blinking. 3. To remove another disc, repeat step 1 and 2 choosing a different “Disc select” button. (To remove discs when the ignition switch is in the “Lock”...

  • Page 243: Precautions To Observe When Handling A Compact Disc (Cd)

    Audio Precautions to observe when han- dling a compact disc (CD) Use only compact discs (CDs) that have the mark shown below. CD-RWs cannot be used. Also, some CD-Rs cannot be played. In cold and/or rainy weather, dew can form inside the CD player, preventing normal operation.
  • Page 244 Audio HS5018BA – CONTINUED – 5-43...
  • Page 246 Interior light ... Dome light ... Cargo area light (if equipped) ... Map light (if equipped) ... Sun visors ... Vanity mirror (if equipped) ... Storage compartment ... Glove box ... Center console ... Coin compartment ... Overhead console (if equipped) ... Cup holder ...

  • Page 247: Interior Light

    Interior equipment Interior light Interior equipment Dome light DOOR The dome light switch has three positions: ON: The light stays on continuously. DOOR (middle position): The light comes on when any of the doors (or the rear gate on the wagon) is opened.

  • Page 248: Interior Equipment

    Map light (if equipped) Vehicle with moonroof (Sedan) 1) Switches 2) Map lights Vehicle with dual moonroofs (Wagon) UG6021CB 1) Switches 2) Map lights Interior equipment UB2006CC – CONTINUED –...

  • Page 249: Sun Visors

    Interior equipment Vehicle without moonroof 1) Switches 2) Map lights To turn on the map light, push the switch. To turn it off, push the switch again. When leaving the vehicle, make sure the light is turned off to avoid battery discharge. Sun visors UB6006BC To block out glare, swing down the visors.

  • Page 250: Vanity Mirror (If Equipped)

    Vanity mirror (if equipped) To use the vanity mirror, swing down the sunvisor and open the vanity mirror cover. Vanity mirror with light (if equipped) The light beside the vanity mirror comes on when the ignition switch is either in the “ACC” or “ON” position and the mirror cover is opened.

  • Page 251: Glove Box

    Interior equipment Glove box 1) Lock 2) Unlock To open the glove box, pull the handle. To close it, push the lid firmly upward. To lock the glove box, insert the key and turn it clock- wise. Center console HS6030BB To open the lid, pull up the lock release.

  • Page 252: Coin Compartment

    Coin compartment To open the coin compartment, pull the upper edge of the lid. Overhead console (if equipped) HS6055BA To open the console, push on the lid lightly and it will automatically open. When your vehicle is parked in the sun or a warm day, the inside of the overhead console heats up.

  • Page 253: Cup Holder

    Interior equipment Cup holder Do not pick up a cup from the cup holder or put a cup in the holder while you are driving, as this may distract you and lead to an accident. Take care to avoid spills. Beverages, if hot, might burn you or your passengers.

  • Page 254: Rear Passenger's Cup Holder (If Equipped)

    Rear passenger’s cup holder (if equipped) The rear passenger’s cup holder is located on the low- er side of the back of the center console. To use the UB7009CA cup holder, open the lid by pulling its upper edge. Interior equipment UB6024BA –...

  • Page 255: Cigarette Lighter Socket (If Equipped)

    A cigarette lighter plug is an optional acces- sory. It is available from your SUBARU dealer. The cigarette lighter socket may also be used as a power source for an in-car use electrical appliance.

  • Page 256: Using As An Accessory Power Outlet

    the heating element. Do not hold the lighter pushed in, because it will overheat. The cigarette lighter operates only when the ignition switch is in the “ON” and “ACC” positions. To use the cigarette lighter, push in the knob and wait a few moments.

  • Page 257: Ashtray

    If you want to use the socket for a ciga- rette lighter again, or to protect your purchaser before you sell your car, have your SUBARU dealer replace the socket with a new one. 6-12...

  • Page 258: Rear Ashtray (If Equipped)

    To open the ashtray, pull the lid out. Rear ashtray (if equipped) The rear ashtray is located on the upper side of the back of the center console. To open the ashtray, pull the upper edge of the lid. To remove the ashtray for cleaning, open it and pull it out while pushing the inner plate down.

  • Page 259: Onstar Services Button

    OnStar advisor. If the connection is made, the advisor will assist you in making sure your OnStar system is operating properly. If you cannot contact the OnStar Center, please take your vehicle to the nearest SUBARU dealership for diagnosis and service.

  • Page 260: Volume Control

    Volume control You can control the volume of the OnStar System us- ing the volume control knob on the radio. OnStar subscription plans The OnStar safe & sound plan Choose this plan for excellent protection, 24/7, 365 days a year. It includes valuable services such as Au- tomatic Notification of Air Bag Deployment, Remote Door Unlock and Online Concierge services, to...

  • Page 261: Route Support

    Interior equipment (flat tire, out of gas, or engine trouble), just call OnStar. We will contact your vehicle manufacturer’s roadside service provider for the help you need to get you quick- ly back on the road. *3: There will be no charge for Roadside Assistance as long as the basic limited warranty on your vehicle has not expired.

  • Page 262: Onstar Personal Calling

    listings including hotels, restaurants, gas stations, dealerships, hospitals, ATMs and airports – more than 250 service categories in all. Our Advisors can even assist you with hotel and restaurant reservations. OnStar concierge Safe & Sound, Directions & Connections and Luxury and Leisure plan subscribers can access self-serve Online Concierge services for event tickets, dining reservations, gift recommendations and more at...

  • Page 263: Onstar System Limitations

    Interior equipment OnStar system limitations Complete limitations can be found on the Subscriber Services Agreement at www.onstar.com. An OnStar Service Subscription Agreement is re- quired in order to receive OnStar services, including OnStar Personal Calling and OnStar Virtual Advisor. OnStar services require vehicle electrical system and wireless service to be available and operating for fea- tures to function properly.

  • Page 264: Accessory Power Outlet

    Accessory power outlet In the luggage compartment (if equipped) Electrical power (12V DC) from the battery is on tap at the outlet when the ignition switch is either in the “ACC” or “ON” position. You can use an in-car use electrical appliance by con- necting it to the outlet.

  • Page 265: Convenience Hook

    Interior equipment Convenience hook Coat hook Never hang anything on the coat hook that might obstruct the driver’s view or that could cause injury in sudden stops or in a collision. And do not hang items on the coat hook that weigh 2.2 lbs (1 kg) or more.

  • Page 266: Floor Mat (If Equipped)

    For station wagon models A shopping bag hook is attached to each side of the cargo area. To use the hook, push the upper portion and the shop- ping bag hook will appear. Floor mat (if equipped) UB7014BA A retaining pin is located on the driver’s side of the ve- hicle next to the fuel filler door release.

  • Page 267: Luggage Cover (If Equipped)

    Interior equipment Make sure the driver’s floor mat is placed back in its proper location and correctly secured on its retaining pin. If the floor mat slips forward and interferes with the movement of the pedals during driving, it could cause an accident. 6-22 Luggage cover (if equipped) Do not place anything on the extended cover.

  • Page 268: Using The Cover

    Using the cover To extend the cover, pull the end of the cover out of the housing, then insert its hooks into the catches as shown. To rewind it, unhook it from the catches and it will rewind automatically. You should hold on to the cover and guide it back into the cover housing while it is rewinding.

  • Page 269: Convenient Tie-Down Hooks (If Equipped)

    Interior equipment 1. Rewind the cover. 2. To take it off the cover rails, lift it out while pressing the release knobs located both sides of the cover housing. 3. Store the cover in the cargo area. To install the cover: Hang the both ends of the cover housing on the cover rails.

  • Page 270: Subfloor Storage (If Equipped)

    so that cargo can be secured with a luggage net or ropes. When using the tie-down hooks, turn them down out of the storing recesses. When not in use, put the hooks up into the storing recesses. Interior equipment Subfloor storage (if equipped) The subfloor storage is located under the floor of the trunk or cargo area and can be used to store small items.

  • Page 271: Station Wagon

    Interior equipment Sedan 6-26 Station wagon UB6007BA UB7019AA UB6008BA...
  • Page 272 Interior equipment Hang the hook provided on the underside of the lid on the rear edge of the roof to keep the lid open. – CONTINUED – 6-27...
  • Page 274 Fuel ... Fuel requirements ... Fuel filler lid and cap ... State emission testing (U.S. only) ... Preparing to drive ... Starting the engine ... Starting the engine for a manual transmission vehicle ... Starting the engine for an automatic transmission vehicle ...

  • Page 275: Fuel

    Starting and operating Fuel Starting and operating Use of a fuel which is low in quality or use of an inappropriate fuel additive may cause engine damage. Fuel requirements 2.5 Liter models The 2.5 Liter engine is designed to operate using un- leaded gasoline with an octane rating of 87 AKI or higher.

  • Page 276: Starting And Operating

    ENGINE warning light/Malfunction indicator lamp may turn on. If this happens, return to your authorized SUBARU Dealer for service. If it is determined that the condition is caused by the type of fuel used, repairs may not be covered by your warranty.

  • Page 277: Fuel Filler Lid And Cap

    SUBARU dealer. Fuel system damage or driveability problems which result from the use of improper fuel are not covered under the SUBARU Limited Warranty. Fuel filler lid and cap Refueling Sedan...
  • Page 278 Starting and operating UB3007BA UG7502BA Station wagon 1. To open the fuel filler lid, pull the lid release lever – CONTINUED –...
  • Page 279 Starting and operating 1) Open 2) Close 2. Remove the fuel filler cap by turning it slowly coun- terclockwise. Gasoline vapor is highly flammable. Before refueling, always first stop the engine and make sure that there are no lighted cigarettes, open flames or electrical sparks in the adjacent area.

  • Page 280: State Emission Testing (U.s. Only)

    Do not let fuel spill on the exterior surfaces of the vehicle. Fuels may cause paint damage, which is not covered under the SUBARU Limit- ed Warranty. Always use a genuine SUBARU fuel filler cap. If you use the wrong cap, it may not fit or have proper venting, and your fuel tank and emis- sion control system might be damaged.
  • Page 281 There are some states that use four-wheel dynamom- eters in their testing programs. When properly used, that equipment will not damage an AWD SUBARU ve- hicle. Under no circumstances should the rear wheels be jacked off the ground, nor should the driveshaft be dis- connected for state emission testing.

  • Page 282: Preparing To Drive

    Owners of rejected or failing vehicles should contact their SUBARU Dealer for service. Starting and operating Preparing to drive You should perform the following checks and adjust- ments every day before you start driving.

  • Page 283: Starting The Engine

    Starting and operating Starting the engine Do not operate the starter motor continuously for more than ten seconds. If the engine fails to start after operating the starter for five to ten seconds, wait for ten seconds or more before trying again.

  • Page 284: Starting The Engine During Cold Weather Below -4°F (-20°C)

    check the operation of the warning and indicator lights. Refer to the “Warning and indicator lights” section (chapter 3). 5. Turn the ignition switch to the “START” position without depressing the accelerator pedal. Release the key immediately after the engine has started. If the engine does not start within ten seconds, wait a while and then turn the ignition switch to the “START”...

  • Page 285: Stopping The Engine

    Starting and operating Stopping the engine Do not stop the engine when the vehicle is mov- ing. This will cause loss of power to the power steering and the brake booster, making steer- ing and braking more difficult. It could also re- sult in accidental activation of the “LOCK”...

  • Page 286: Shifting Speeds

    The shift pattern is shown on the shift lever knob. When shifting from 5th gear to reverse gear, first re- turn the shift lever to the neutral position then shift into reverse gear. To change gears, fully depress the clutch pedal, move the shift lever, and gradually let up on the clutch pedal.

  • Page 287: Driving Tips

    Starting and operating pery surface can lead to wheel locking; as a consequence, control of the vehicle may be lost and the risk of an accident increased. The following table shows the maximum speeds that are possible with each different gear. Never exceed the speed limit below for each gear po- sition except for brief acceleration in an emergency.

  • Page 288: Automatic Transmission (L, L-S, Outback)

    Automatic transmission (L, L-S, OUT- BACK) Do not shift from the “P” or “N” position into the “D”, “3”, “2”, “1” or “R” position while de- pressing the accelerator pedal. This may cause the vehicle to jump forward or backward. Shift into the “P”...

  • Page 289: Selector Lever

    Starting and operating Selector lever 7-16 HS7009AA : With the brake pedal depressed, move the lever along the gate. : Move the lever along the gate. The selector lever has seven positions. P (Park) This position is for parking the vehicle and starting the engine.
  • Page 290 A shift interlock function is employed in the automatic transmission system to ensure safe starting of the ve- hicle. To shift the selector lever from the “P” to the any other position, you have to depress the brake pedal fully when the ignition switch is in the “ON”...
  • Page 291 Starting and operating NOTE The transmission may downshift to 2nd or 1st gear, depending on the way the accelerator pedal is pressed to accelerate the vehicle again. While going down a hill When descending a steep hill, depressing the brake pedal will cause the transmission to downshift to 3rd gear, thus applying engine braking.
  • Page 292 Maximum speeds When shifting down a gear, ensure that the ve- hicle is not travelling at a speed exceeding the Maximum Allowable Speed for the gear which is about to be selected. Failure to observe this precaution can lead to engine over-revving and this in turn can result in engine damage.

  • Page 293: Shift Lock Release

    “P” to the “N” position. 6. Remove the screwdriver from the hole. Depress the brake pedal and start the engine. Take your vehicle to the nearest SUBARU dealer im- mediately to have the system repaired. HS7009BA...

  • Page 294: Automatic Transmission (With Sportshift Mode - 2.5Gt, 2.5Gtlo)

    Automatic transmission (with SPORTSHIFT mode – 2.5GT, 2.5GTLO) Do not shift from the “P” or “N” position into the “D”, “3”, “2”, “1” or “R” position while de- pressing the accelerator pedal. This may cause the vehicle to jump forward or backward. Shift into the “P”...

  • Page 295: Selector Lever

    Starting and operating Selector lever 1) Release button 7-22 UB7026BB : When the brake pedal depressed, shift while pressing the button in. : Shift while pressing the button in. : Shift without pressing the button. The selector lever has seven positions, “P”, “R”, “N”, “D”, “3”, “2”...
  • Page 296 locked to prevent the vehicle from rolling freely. When you park the vehicle, first set the parking brake fully, then shift into the “P” position. Do not hold the ve- hicle with only the transmission. A shift interlock function is employed in the automatic transmission system to ensure safe starting of the ve- hicle.
  • Page 297 Starting and operating the pedal, the transmission will return to the original gear position. To use the SPORTSHIFT mode, move the lever from this position into the manual gate. While climbing a grade When driving up a hill, undesired upshift to 4th gear is prevented from taking place when the accelerator is released.

  • Page 298: Selection Of Sportshift Mode (Manual Mode)

    button. This position is for using engine braking when going down a hill or for climbing a steep grade. In this position, the transmission holds in the 2nd gear. Use this position when starting off from a standstill on slippery road surfaces such as mud or snow. It will en- sure greater traction.
  • Page 299 Starting and operating 1) Lamp showing whether upshift is possible 2) Lamp showing whether downshift is possible 3) Indication of currently selected gear 2. Once the SPORTSHIFT mode is selected, the cur- rently selected gear is shown by the shift position indi- cator in the meter cluster.
  • Page 300 matic transmission from damage. Automatic gearshifts do not take place in the SPORTSHIFT mode. Perform gearshifts in accor- dance with road conditions so that the tachometer needle does not enter the red zone. If the engine speed reaches a predetermined level, a fuel-cut function will operate.

  • Page 301: Shift Lock Release

    Starting and operating Position 2.5GT, 2.5GTLO 23 (38), 30 (48)* 51 (83), 55 (88)* 85 (136), 93 (150)* *: SPORTSHIFT mode Never exceed posted speed limits. Driving tips Always apply the foot or parking brake when the ve- hicle is stopped in the “D”, “3”, “2”, “1”, or “R” position. Always set the parking brake when parking your ve- hicle.

  • Page 302: Rear Viscous Limited Slip Differential (Lsd) (If Equipped)

    “P” to the “N” position. 6. Remove the screwdriver from the hole. Depress the brake pedal and start the engine. Take your vehicle to the nearest SUBARU dealer im- mediately to have the system repaired. Rear viscous limited slip differential (LSD) (if equipped) Never start the engine while a tire on one side is jacked up, as the vehicle may move.

  • Page 303: Power Steering

    Starting and operating Power steering Do not hold the steering wheel at the fully locked position left or right for more than five seconds. This may damage the power steering pump. The power steering system operates only when the engine is running. If you lose power steering assist because the engine stops or the system fails to function, you can steer but it will take much more effort.

  • Page 304: Brake System

    If a squeaking or scraping noise is heard from the disc brakes while braking, immediately have your vehicle checked by your SUBARU dealer. HS7012BA – CONTINUED – 7-31...

  • Page 305: Abs (Anti-Lock Brake System)

    Starting and operating ABS (Anti-lock Brake System) Always use the utmost care in driving – over- confidence because you are driving with an ABS equipped vehicle could easily lead to a se- rious accident. The ABS system does not always decrease stopping distance.

  • Page 306: Abs Warning Light

    8 mph (12 km/h). The warning light comes on during driving. If these occur, have the ABS system repaired at the first available opportunity by your SUBARU dealer. NOTE UB4010LA If the warning light behavior is as described be- low, the ABS system may be considered normal.

  • Page 307: Vdc (Vehicle Dynamics Control) System (If Equipped)

    Starting and operating age and does not indicate a malfunction. When the battery becomes fully charged, the light will go out. 7-34 VDC (Vehicle Dynamics Control) sys- tem (if equipped) Always use the utmost care in driving – over- confidence because you are driving with a VDC system equipped vehicle could easily lead to a serious accident.
  • Page 308 Whenever suspension components, steering components, or an axle are removed from a ve- hicle equipped with VDC, have an authorized SUBARU dealer perform an inspection of that system. The following precautions should be ob- served in order to ensure that the VDC system is operating properly: –...

  • Page 309: Vdc System Monitor

    Starting and operating driving off where the brake pedal seems to exhibit a jolting motion. This too is a consequence of the VDC operational check and is normal. In the circumstances listed below, the vehicle may be more unstable than it feels to the driver. The Vehicle Dynamics Control System may there- fore operate.
  • Page 310 The following situations could indicate a malfunction of the VDC system; if any should occur, have an autho- rized SUBARU dealer carry out an inspection of the system at the first available opportunity. The VDC warning light does not turn on when the ig- nition key is turned to the ON position.

  • Page 311: Vdc Off Switch

    ABS do not adversely affect operation of the vehicle in any way when they are inoperable; however should such a situation occur, drive with care and have an authorized SUBARU dealer carry out an inspection of those systems at the first available op- portunity.
  • Page 312 With OnStar® System Note: Even when the lighting switch is turned to the “ ” or “ ” position, the “OFF” portion of the symbol stamped on the switch will not illuminate in the dark. Only “VDC” portion will illuminate. Pressing the VDC OFF switch to deactivate the VDC system can facilitate the following operations: a standing start on a steeply sloping road with a...

  • Page 313: Parking Your Vehicle

    Starting and operating off, the VDC system is activated, and the system ignores any further pressing of the VDC OFF switch. To make the VDC OFF switch usable again, turn the ignition key to the OFF position and re- start the engine. 7-40 Parking your vehicle Never leave unattended children or pets in...
  • Page 314 make sure that the parking brake has been fully released. To set the parking brake, press the brake pedal firmly and hold it down while fully pulling up the parking brake lever. To release the parking brake, pull the lever up slightly, press the release button, then lower the lever while keeping the button pressed.

  • Page 315: Cruise Control (If Equipped)

    Starting and operating When facing downhill, the front wheels should be turned into the curb. 7-42 Cruise control (if equipped) Do not use the cruise control under any of the following conditions. This may cause loss of vehicle control: driving up or down a steep grade driving on slippery or winding roads driving in heavy traffic UB4015AA...

  • Page 316: To Set Cruise Control

    Starting and operating To set cruise control HS7018BA UB7038BA Cruise control lever Main switch 1. Push the “CRUISE” main switch. The indicator light on the switch will come on. 2. Depress the accelerator pedal until the vehicle reaches the desired speed. 3.

  • Page 317: To Temporarily Cancel The Cruise Control

    Starting and operating At this time, the “ ” indicator light is illuminated in the combination meter. The vehicle will maintain the desired speed. Vehicle speed can be temporarily increased while driving with the cruise control activated. Simply de- press the accelerator pedal to accelerate the vehicle. When the accelerator pedal is released, the vehicle will return to and maintain the previous cruising speed.

  • Page 318: To Change The Cruising Speed

    To change the cruising speed To increase the speed (by control lever) Push the control lever upward in the “ACCEL, RE- SUME” direction and hold it until the vehicle reaches the desired speed. Then, release the control lever. The vehicle speed at that moment will be memorized and treated as the new set speed.
  • Page 320 New vehicle break-in driving – the first 1,000 miles (1,600 km) ... Fuel economy hints ... Engine exhaust gas (Carbon monoxide) ... Catalytic converter ... Periodic inspections ... Driving in foreign countries ... Driving tips for AWD vehicles ... Off road driving ... Winter driving ...

  • Page 321: New Vehicle Break-In Driving - The First

    Driving tips New vehicle break-in driving – the Driving tips first 1,000 miles (1,600 km) The performance and long life of your vehicle are de- pendent on how you handle and care for your vehicle while it is new. Follow these instructions during the first 1,000 miles (1,600 km): Do not race the engine.

  • Page 322: Driving Tips

    Engine exhaust gas (Carbon monox- ide) Never inhale engine exhaust gas. Engine ex- haust gas contains carbon monoxide, a color- less and odorless gas which is dangerous, or even lethal, if inhaled. Always properly maintain the engine exhaust system to prevent engine exhaust gas from en- tering the vehicle.

  • Page 323: Catalytic Converter

    Driving tips Catalytic converter Avoid fire hazards. Do not drive or park the vehicle anywhere near flammable materials (e.g. grass, paper, rags or leaves), because the catalytic converter operates at very high tem- peratures. Keep everyone and flammable materials away from the exhaust pipe while the engine is running.

  • Page 324: Periodic Inspections

    SUBARU dealer. Do not apply undercoating or rust prevention treat- ment to the heat shield of catalytic converter and the exhaust system. Periodic inspections To keep your vehicle in the best condition at all times, always have the recommended maintenance services listed in the maintenance schedule in the “Warranty...

  • Page 325: Driving In Foreign Countries

    Driving tips Driving in foreign countries When planning to use your vehicle in another country: Confirm the availability of the correct fuel. (Refer to the “Fuel requirements” section in chapter 7.) Comply with all regulations and requirements of each country. Driving tips for AWD vehicles Always maintain a safe driving speed accord- ing to the road and weather conditions in order...
  • Page 326 By shifting power between the front and rear wheels, SUBARU AWD can also provide added traction during acceler- ation, and added engine braking force during deceler- ation.

  • Page 327: Off Road Driving

    Operating it under other than those conditions could subject the vehicle to excessive stress which might result in damage not eligible for repair under warranty. If you do take your SUBARU off road, you should review the common sense precautions in the...
  • Page 328 SUBARU can be driven on ordinary roads or off-road. But please keep in mind that an AWD SUBARU is a passenger car and is neither a conven- tional off-road vehicle nor an all-terrain vehicle. If you do take your SUBARU off-road, certain common...
  • Page 329 “Warranty and Maintenance Booklet”. Remember that damage done to your SUBARU while operating it off-road and not using common sense pre- cautions such as those listed above is not eligible for...

  • Page 330: Winter Driving

    Winter driving Operation during cold weather Carry some emergency equipment, such as tire chains, a window scraper, a bag of sand, flares, a small shovel, and jumper cables. Check the battery and cables. Cold temperatures re- duce battery capacity. The battery must be in good condition to provide enough power for cold winter starts.

  • Page 331: Driving On Snowy And Icy Roads

    If your SUBARU is not going to be used for an extend- ed period, it is best to have the fuel tank filled to capac- ity.

  • Page 332: Corrosion Protection

    ing, abrupt acceleration, high-speed driving, and sharp turning when driving on snowy or icy roads. Always maintain ample distance between your vehicle and the vehicle ahead of you to avoid the need for sud- den braking. To supplement the foot brake, use the engine brake effectively to control the vehicle speed.

  • Page 333: Snow Tires

    Driving tips Snow tires All models except OUTBACK When replacing original tires with winter (snow) tires, make sure you use only the same size, construction and load range as the origi- nal tires listed on the tire placard. Using other sizes and construction may affect speedome- ter/odometer calibration and clearance be- tween the body and tires.

  • Page 334: Tire Chains

    ous and lead to loss of vehicle control. You must install four winter tires that are of the same size, circumferences, construction, brand, and load range. Mixing other sizes, cir- cumferences or constructions may result in se- vere mechanical damage to the drive train of your vehicle and may affect ride, handling, braking and speedometer/odometer calibra- tion.

  • Page 335: Rocking The Vehicle

    Driving tips models Driving on snowy grades or icy roads may require the use of tire chains, in which case put the chains on the front wheels only. Use only SAE class S type chains that are of the correct size for your tires so as not to damage the vehicle body or suspension.

  • Page 336: Loading Your Vehicle

    Loading your vehicle Never allow passengers to ride on the folded rear seatback, in the trunk or in the cargo area. Doing so may result in serious injury. Never stack luggage or other cargo higher than the top of the seatback because it could tumble forward and injure passengers in the event of a sudden stop or accident.

  • Page 337: Vehicle Capacity Weight

    Driving tips Do not carry spray cans, containers with flam- mable or corrosive liquids or any other danger- ous items inside the vehicle. NOTE For better fuel economy, do not carry unneeded cargo. Vehicle capacity weight 8-18 The load capacity of your vehicle is determined by weight, not by available cargo space.

  • Page 338: Gvwr And Gawr (Gross Vehicle Weight Rating And Gross Axle Weight Rating)

    GVWR and GAWR (Gross Vehicle Weight Rating and Gross Axle Weight Rating) Certification label The certification label attached to the driver’s side door shows GVWR (Gross Vehicle Weight Rating) and GAWR (Gross Axle Weight Rating). The GVW (Gross Vehicle Weight) must never exceed the GVWR.

  • Page 339: Roof Rail And Crossbar (If Equipped)

    Driving tips Roof rail and crossbar (if equipped) 1) Crossbar kit For cargo carrying purposes, the roof rail must be used together with a roof crossbar kit and the appropriate carrying attachment. The roof rail must never be used alone to carry car- go.
  • Page 340 heaviest load at the bottom, nearest the roof, and evenly distribute the cargo. Always properly secure all cargo. Installing carrying attachments on the cross- bars When installing any carrying attachment such as a bike carrier, ski carrier, kayak carrier, cargo basket, etc.
  • Page 341 Driving tips 3. Carefully raise the crossbar from roof rails. 8-22 To install the crossbar Front crossbar: Front crossbar has 100 LBS Load Label on left-hand side. UB8051BA 1) T-30 torx® head screw 2) Lower clamp 1. Before placing the crossbar on the roof rails, make sure that the T-30 torx®...
  • Page 342 6 in (150mm) 1) 100 LBS load label 2) Front arrow label 3. With the front direction arrow label on the top right side of the crossbar pointing toward the front of the ve- hicle, carefully place the crossbar across the top of the vehicle so that the crossbar end supports rest on the top of the roof rails approximately 6 inches (150 mm) rearward from the seam (joint) between the front roof...
  • Page 343 Driving tips Rear crossbar: 6 in (150 mm) 1) T-30 torx® head screw 2) Front arrow label Install the rear crossbar in the same manner as the front crossbar. NOTE The rear crossbar should be positioned 6 inches (150 mm) forward of the rear seam (joint) between the rear roof rail support and the roof rail.

  • Page 344: Trailer Hitch (If Equipped)

    Trailer hitch (if equipped) Never exceed the maximum weight specified for the trailer hitch. Exceeding the maximum weight could cause an accident resulting in se- rious personal injuries. Permissible trailer weight changes depending on the situation. Re- fer to the next section “Trailer towing” for pos- sible recommendations and limitations.
  • Page 345 Driving tips 2. Insert the hitch pin into the hole on the hitch receiv- er tube so that the pin passes through the ball mount. 3. Insert the safety pin into the hitch pin securely. 4. Pull the ball mount to make sure it does not come off the hitch receiver.

  • Page 346: When You Do Not Tow A Trailer

    ground. Do not connect safety chains to part of the ve- hicle other than the safety chain hooks. UG8034BA Hitch harness connector 8. Connect the hitch wire harness’s black four-pin wire connector to the towing trailer’s wire harness. 9. Confirm proper function of the hitch wire harness by individually activating the brake, right turn signal, left turn signal, stop, and parking lights on the trailer.

  • Page 347: Trailer Towing

    Seek the ad- vice of your SUBARU dealer to assist you in purchas- ing a hitch and other necessary towing equipment ap- propriate for your vehicle. In addition, be sure to follow...

  • Page 348: Maximum Load Limits

    tenance schedule under severe driving conditions” in the “Warranty and Maintenance Booklet”.) Under no circumstances should a trailer be towed with a new vehicle or a vehicle with any new powertrain component (engine, transmission, differential, wheel bearings, etc.) for the first 1,000 miles (1,600 km) of driving.
  • Page 349 Driving tips OUTBACK Wagon Model Conditions MT models When towing a trailer with- out brakes. When towing a trailer with brakes. AT models When towing a trailer with- out brakes. When towing a trailer with brakes. When towing a trailer on a long uphill grade continu- ously for over 5 miles (8 km) with an outside temperature...
  • Page 350 Gross Vehicle Weight (GVW) and Gross Vehicle Weight Rating (GVWR) Gross Vehicle Weight The Gross Vehicle Weight (GVW) must never exceed the Gross Vehicle Weight Rating (GVWR). Gross Vehicle Weight (GVW) is the combined total of the weight of the vehicle, driver, passengers, luggage, trailer hitch, trailer tongue load and any other optional equipment installed on your vehicle.
  • Page 351 Driving tips Gross Axle Weight (GAW) and Gross Axle Weight Rating (GAWR) Gross Axle Weight The total weight applied to each axle (GAW) must nev- er exceed the Gross Axle Weight Rating (GAWR). The front and rear GAWs can be adjusted by relocating passengers and luggage inside the vehicle.
  • Page 352 Tongue load Tongue load If the trailer is loaded with more weight in the back of trailer’s axle than in the front, the load is taken off the rear axle of the towing vehicle. This may cause the rear wheels to skid, espe- cially during braking or when vehicle speed is reduced during cornering, resulting in over- steer, spin out and/or jackknifing.

  • Page 353: Trailer Hitches

    Driving tips F: Front The tongue load can be adjusted by proper distribution of the load in the trailer. Never load the trailer with more weight in the back than in the front; approximate- ly 60 percent of the trailer load should be in the front and approximately 40 percent in the rear.

  • Page 354: Connecting A Trailer

    OUTBACK wagon The use of a genuine SUBARU trailer hitch is recom- mended. A genuine SUBARU hitch is available from your SUBARU dealer. If use of a non-genuine hitch is unavoidable, be sure the hitch is suited to your vehicle and trailer. Consult with a professional hitch supplier to assist you in choosing an appropriate hitch for your vehicle.

  • Page 355: Side Mirrors

    Driving tips Trailer safety chains Always use safety chains between your vehicle and the trailer. Towing trailer without safety chains could create a traffic safety hazard if the trailer separates from the hitch due to coupling damage or hitch ball damage. In case the trailer hitch connector or hitch ball should break or become disconnected, the trailer could get loose and create a traffic safety hazard.

  • Page 356: Trailer Towing Tips

    To ensure the trailer lights are connected properly, please consult your SUBARU dealer. Check for proper operation of the turn signals, the brake lights and parking lights each time you hitch up.
  • Page 357 Driving tips speed. You should also keep the following tips in mind: Before starting out on a trip Check that the vehicle and vehicle-to-hitch mount- ing are in good condition. If any problems are appar- ent, do not tow the trailer. Check that the vehicle sits horizontally with the trail- er attached.
  • Page 358 If the ABS warning light illuminates while the vehicle is in motion, stop towing the trailer and have repairs performed immediately by the nearest SUBARU deal- Driving on grades Before going down a steep hill, slow down and shift...
  • Page 359 Driving tips overheating. A lower gear should be used. Parking on a grade Always block the wheels under both vehicle and trailer when parking. Apply the parking brake firmly. You should not park on a hill or slope. But if parking on a hill or slope cannot be avoided, you should take the following steps: 1.
  • Page 360 In case of emergency If you park your vehicle in an emergency .. Temporary spare tire ... Flat tires ... Jump starting ... How to jump start ... Engine overheating ... If steam is coming from the engine compartment ... If no steam is coming from the engine compartment ...

  • Page 361: In Case Of Emergency

    In case of emergency If you park your vehicle in an emer- In case of emergency gency The hazard warning flasher should be used in day or night to warn other drivers when you have to park your vehicle under emergency conditions. Avoid stopping on the road.

  • Page 362: Temporary Spare Tire

    Temporary spare tire Never tow a trailer when the temporary spare tire is used. The temporary spare tire is not de- signed to sustain the towing load. Use of the temporary spare tire when towing can result in failure of the spare tire and/or less stability of the vehicle and may lead to an accident.
  • Page 363 In case of emergency When the wear indicator appears on the tread, re- place the tire. 1) Spare fuse 2) FWD connector NOTE [Automatic transmission vehicle not equipped with VDC (Vehicle Dynamics Control) and not equipped with SPORTSHIFT] Before driving your vehicle with the temporary spare tire, put a spare fuse inside the FWD connector located in the en- gine compartment and confirm that the Front-...

  • Page 364: Flat Tires

    Flat tires Do not jack up the vehicle on an incline or a loose road surface. The jack can come out of the jacking point or sink into the ground and this can result in a severe accident. Use only the jack provided with your vehicle. The jack supplied with the vehicle is designed only for changing a tire.
  • Page 365 In case of emergency Sedan 1) Jack 2) Jack handle 3) Spare tire UBF015CB Station wagon 1) Jack 2) Jack handle 3) Spare tire 5. Take out the spare tire, jack, and wheel nut wrench. UB8004BD...
  • Page 366 To remove the spare tire, proceed as follows: Sedan: Remove the floor cover from the trunk. Re- move the storage tray. UB9003BA Turn the attaching bolt counterclockwise, then take the spare tire out. In case of emergency US0252 – CONTINUED –...
  • Page 367 In case of emergency Station wagon: Open the lid and hang the hook pro- vided on the underside of the lid on the rear edge of the roof to keep the lid open. Remove the storage tray. UB6008BA Turn the attaching bolt counterclockwise, then take spare tire out.
  • Page 368 In case of emergency UB9001BA UB7008CA Sedan Station wagon The jack is stored on the left side of the trunk or cargo area. To take out the jack: Remove the cover, turn the jackscrew counterclock- wise to loosen it, then remove the jack. –...
  • Page 369 In case of emergency If the jackscrew is too tight to be loosened by hand, loosen it using a screwdriver or the jack handle. The jack handle is stored under the spare tire cover. NOTE Make sure the jack is well lubricated before using 9-10 UB1169CA 6.
  • Page 370 In case of emergency OM-U0376 7. Loosen the wheel nuts using the wheel nut wrench but do not remove the nuts. UB9086BA – CONTINUED – 9-11...
  • Page 371 In case of emergency For vehicles with side sill skirt 1) Jack up point mark 8. Place the jack under the side sill at the front or rear jack-up point closest to the flat tire. 9-12 Turn the jackscrew by hand until the jack head engag- es firmly into the jack-up point.
  • Page 372 In case of emergency surface of the wheel and hub with a cloth. 12.Put on the spare tire. Replace the wheel nuts. Tighten them by hand. 13.Turn the jack handle counterclockwise to lower the vehicle. OM-U0172 OM-U0377 14.Use the wheel nut wrench to securely tighten the wheel nuts to the specified torque, following the tight- ening order in the illustration.
  • Page 373 In case of emergency the wheel nut torque checked at the nearest automo- tive service facility. 15.Store the flat tire in the spare tire compartment. When storing a conventional tire, put the spacer up- side down and tighten the attaching bolt firmly. Also store the jack and wheel nut wrench in their stor- age locations.

  • Page 374: Jump Starting

    place. In case of emergency Jump starting Battery fluid is SULFURIC ACID. Do not let it come in contact with the eyes, skin, clothing or the vehicle. If battery fluid gets on you, thoroughly flush the exposed area with water immediately. Get med- ical help if the fluid has entered your eyes.

  • Page 375: How To Jump Start

    In case of emergency Do not jump start unless cables in suitable con- dition are available. A running engine can be dangerous. Keep your fingers, hands, clothing, hair and tools away from the cooling fan, belts and any other moving engine parts. Removing rings, watches and ties is advisable.
  • Page 376 In case of emergency UB8007BC 2.5 liter models A) Booster battery B) Engine lifting bracket – CONTINUED – 9-17...
  • Page 377 In case of emergency 3.0 liter models 9-18 1) Connect one jumper cable to the positive (+) terminal on the dis- charged battery. 2) Connect the other end of the jumper cable to the positive (+) ter- minal of the booster battery. 3) Connect one end of the other cable to the negative (–) terminal of the booster battery.

  • Page 378: Engine Overheating

    5. Start the engine of the vehicle with the booster bat- tery and run it at moderate speed. Then start the en- gine of the vehicle that has the discharged battery. 6. When finished, carefully disconnect the cables in exactly the reverse order. In case of emergency Engine overheating Never attempt to remove the radiator cap until...

  • Page 379: Towing

    This will cause the vehicle to spin away due to the operation or de- terioration of the center differential. If towing is necessary, it is best done by your SUBARU UG9013BA...

  • Page 380: Towing And Tie-Down Hooks

    dealer or a commercial towing service. Observe the following procedures for safety. Towing and tie-down hooks The towing hooks should be used only in an emergen- cy (e.g., to free a stuck vehicle from mud, sand or snow). Use only the specified towing hooks and tie- down hooks.
  • Page 381 In case of emergency 1) Towing hook cover 2) Towing hook The front towing hook is located on the inside of the towing hook cover below the right-hand headlight. 9-22 UB9051BB 1) Tie-down hook 2) Towing and tie-down hook UB8013CB...
  • Page 382 Tie-down hook: Vehicle with trailer hitch (if equipped) 1) Tie-down hook Towing hook cover removal procedure For except OUTBACK models: UB9010BB To use the towing hook, insert the top end of the flat tip screwdriver in a slot on the upper part of the cover, and remove the cover while prying it off.
  • Page 383 In case of emergency For OUTBACK models: 9-24 1. Squeeze the sides of portion A and pull the towing hook cover toward you. UB9045BB UB9042BA UB9021CB...
  • Page 384 2. Press portion B and simultaneously pull the towing hook cover toward you. UB9043BA 3. Turn the towing hook cover clockwise, pivoting it about the side that is next to the fog lamp. Pull out the towing hook cover to remove it. In case of emergency UB9044AA –...
  • Page 385 In case of emergency Towing hook cover installation procedure For except OUTBACK models: Align the towing hook cover with its original installation position and press all parts of it into place. 9-26 For OUTBACK models: UB9052BA 1. Insert the projection C into the hole D. UB9044CB...

  • Page 386: Using A Flat-Bed Truck

    In case of emergency Using a flat-bed truck UB9030CB 2. Push at the portion E. UB8008AA This is the best way to transport your vehicle. Use the following procedures to ensure safe transportation. 1. Shift the selector lever into the “P” position for au- tomatic transmission vehicles or “1st”...

  • Page 387: Towing With All Wheels On The Ground

    In case of emergency Towing with all wheels on the ground Never turn the ignition switch to the “LOCK” position while the vehicle is being towed be- cause the steering wheel and the direction of the wheels will be locked. Remember that the brake booster and power steering do not function when the engine is not running.

  • Page 388: Moonroof - If The Moonroof Cannot Be Closed

    Moonroof – if the moonroof cannot be closed If the moonroof cannot be closed with the moonroof switch, you can close the moonroof manually. Sedan 1. Take out the hex-headed wrench from the glove box and screwdriver from the tool bag. 1) Screws 2.

  • Page 389: Station Wagon

    To lower the moonroof, turn the wrench clock- wise. To close the moonroof, turn the wrench counter- clockwise. Have your vehicle checked by an authorized SUBARU dealer. Station wagon 1. Take out the hex-headed wrench from the glove box and screwdriver from the tool bag.

  • Page 390: Maintenance Tools

    3. Insert the wrench in the end of the motor shaft. To close the moonroof, turn the wrench clockwise. Have your vehicle checked or repaired by an autho- rized SUBARU dealer. Maintenance tools UB9034BA Your vehicle is equipped with the following mainte-...

  • Page 391: Jack And Jack Handle

    In case of emergency Jack and jack handle Sedan 1) Jack 2) Jack handle 3) Spare tire 9-32 UBF015CB UB9001BA...
  • Page 392 Station wagon 1) Jack 2) Jack handle 3) Spare tire UB8004BD The jack is stored on the left side of the trunk or cargo area. To take out the jack, turn the jackscrew counterclock- wise to loosen it, then remove the jack. The jack handle is stored under the spare tire cover.

  • Page 394: Appearance Care

    Appearance care Exterior care ... Washing ... Waxing and polishing ... Cleaning aluminum wheels ... Cleaning fog light lens (for OUTBACK) ... Corrosion protection ... Most common causes of corrosion ... To help prevent corrosion ... Cleaning the interior ... Seat fabric ...

  • Page 395: Exterior Care

    Appearance care Exterior care Appearance care Washing When washing the vehicle, the brakes may get wet. As a result, the brake stopping dis- tance will be longer. To dry the brakes, drive the vehicle at a safe speed while lightly pressing the brake pedal to heat up the brakes.

  • Page 396: Waxing And Polishing

    Frequent polishing with a compound or an in- correct polishing technique will result in removing the paint layer and exposing the undercoat. When in doubt, it is always best to contact your SUBARU deal- er or an auto paint specialist. NOTE Be careful not to block the windshield washer noz- zles with wax when waxing the vehicle.

  • Page 397: Cleaning Aluminum Wheels

    Appearance care Cleaning aluminum wheels Promptly wipe the aluminum wheels clean of any kind of grime or agent. If dirt is left on too long, it may be difficult to clean off. Do not use soap containing grit to clean the wheels. Be sure to use a neutral cleaning agent, and later rinse thoroughly with water.

  • Page 398: Corrosion Protection

    Appearance care Corrosion protection Your SUBARU has been designed and built to resist corrosion. Special materials and protective finishes have been used on most parts of the vehicle to help maintain fine appearance, strength, and reliable oper- ation.

  • Page 399: To Help Prevent Corrosion

    Contact your SUBARU dealer to perform this kind of maintenance and treatment if you need assistance. Repair chips and scratches in the paint as soon as you find them.

  • Page 400: Cleaning The Interior

    If your SUBARU is to be parked for a long time in bright sun- light, it is recommended that the seats and headrests be covered, or the windows shaded, to prevent fading or shrinkage.

  • Page 401: Climate Control Panel, Audio Panel, Instrument Panel, Console Panel, Switches, Combination Meter, And Other Plastic Surface

    Appearance care NOTE Strong cleaning agents such as solvents, paint thinners, window cleaner or gasoline must never be used on leather or synthetic interior materials. Climate control panel, audio panel, in- strument panel, console panel, switch- es, combination meter, and other plas- tic surface Gently wipe away contamination using a clean, soft cloth moistened with cold or lukewarm water.

  • Page 402: Maintenance And Service

    Maintenance schedule ... Maintenance precautions ... Before checking or servicing in the engine compartment ... When you do checking or servicing in the engine compartment while the engine is running ... Engine hood ... Engine compartment overview ... 2.5 liter models ... 2.5 liter CALIFORNIA spec models ...
  • Page 403 Maintenance and service Parking brake stroke ... 11-43 Tires and wheels ... 11-43 Types of tires ... 11-43 Tire inspection ... 11-44 Tire pressures and wear ... 11-44 Wheel balance ... 11-47 Wear indicators ... 11-47 Tire rotation ... 11-48 Tire replacement ...

  • Page 404: Maintenance Schedule

    If you perform maintenance and service by yourself, you should familiarize yourself with the information provided in this section on general maintenance and service for your SUBARU. Incorrect or incomplete service could cause improper or unsafe vehicle operation. Any problems caused by improper maintenance and service performed by you are not eligible for warranty coverage.

  • Page 405: Before Checking Or Servicing In The Engine Compartment

    This will cause a fire. Because the fuel system is under pressure, replacement of the fuel filter should be per- formed only by your SUBARU dealer. Wear adequate eye protection to guard against getting oil or fluids in your eyes. If something does get in your eyes, thoroughly wash them out with clean water.

  • Page 406: When You Do Checking Or Servicing In The Engine Compartment While The Engine Is Running

    even when the engine is stopped. When you do checking or servicing in the engine compartment while the en- gine is running A running engine can be dangerous. Keep your fingers, hands, clothing, hair and tools away from the cooling fan, belts and any other mov- ing engine parts.
  • Page 407 2Maintenance and service 3. Release the secondary hood release located under the front grille by moving the lever toward the left. 11-6 UBB002BA 4. Lift up the hood, release the hood prop from its re- tainer and put the end of the hood prop into the slot in the hood.
  • Page 408 2Maintenance and service it. It could deform the metal. Always check that the hood is properly locked before you start driving. If it is not, it might fly open while the vehicle is moving and block your view, which may cause an accident and serious bodily injury.

  • Page 409: Engine Compartment Overview

    2Maintenance and service Engine compartment overview 2.5 liter models 11-8 5 6 7 UBB036BB Manual transmission oil level gauge (MT) (page 11-27) or Dif- ferential gear oil level gauge (AT) (page 11-30) Air cleaner element (page 11- Clutch fluid reservoir (page 11- Automatic transmission fluid lev- el gauge (page 11-28) Brake fluid reservoir (page 11-...

  • Page 410: 2.5 Liter California Spec Models

    2.5 liter CALIFORNIA spec models Air cleaner element (page 11- Manual transmission oil level gauge (MT) (page 11-27) or Dif- ferential gear oil level gauge (AT) (page 11-30) Clutch fluid reservoir (page 11- Automatic transmission fluid lev- el gauge (page 11-28) Brake fluid reservoir (page 11- Windshield washer tank (page 11-51)

  • Page 411: 3.0 Liter Models

    2Maintenance and service 3.0 liter models 11-10 UBB058BB Air cleaner element (page 11- Differential gear oil level gauge (AT) (page 11-30) Automatic transmission fluid lev- el gauge (page 11-28) Brake fluid reservoir (page 11- Fuel filter Windshield washer tank (page 11-51) Fuse box (page 11-59) Battery (page 11-58)

  • Page 412: Engine Oil

    Engine oil Checking the oil level Check the engine oil level at each fuel stop. 1. Park the vehicle on a level surface and stop the en- gine. 2. Pull out the dipstick, wipe it clean, and insert it again. 3.

  • Page 413: Changing The Oil And Oil Filter

    2Maintenance and service wait a few minutes for the oil to drain back into the oil pan before checking the level. To prevent overfilling the engine oil, do not add any additional oil above the upper level when the engine is cold.
  • Page 414 1) Sealing washer 2) Drain plug 5. Wipe the seating surface of the drain plug with a clean cloth and tighten it securely with a new sealing washer after the oil has completely drained out. UBB051BB 6. Remove three clips at the front of the cover under the oil filter.
  • Page 415 2Maintenance and service 7. Slide the cover toward the vehicle front to remove 8. Remove the oil filter with an oil filter wrench. 9. Before installing a new oil filter, apply a thin coat of engine oil to the seal. 10.Clean the rubber seal seating area of the bottom of engine and install the oil filter by hand turning.

  • Page 416: Recommended Grade And Viscosity

    Recommended grade and viscosity Use only engine oil with the recommended grade and viscosity. Oil grade: ILSAC GF-3, which can be identified with the new API certification mark (Starburst mark) or API classification SL with the words “ENERGY CONSERVING” (if you cannot obtain the oil with SL grade, you may use SJ grade “ENERGY CON- SERVING”...

  • Page 417: Recommended Grade And Viscosity Under Severe Driving Conditions

    The following table lists the recommended viscosities and applicable temperatures. When adding oil, different brands may be used togeth- er as long as they are the same API classification and SAE viscosity as those recommended by SUBARU. 11-16 -30 -20 -10 HSB022BB SAE viscosity number and applicable temperature *: 5W-30 is preferred.

  • Page 418: Cooling System

    –33°F (–36°C). For adding, use genuine SUBARU coolant or an equivalent: a mixture of 50% soft water and 50% ethylene-glycol basis coolant. Use of improper coolants may result in corrosion in the cooling system.

  • Page 419: Hose And Connections

    Check the fuse and replace it if necessary. If the fuse is not blown, have the cooling system checked by your SUBARU dealer. If frequent addition of coolant is necessary, there may be a leak in the engine cooling system. It is recom- mended that the cooling system and connections be checked for leaks, damage, or looseness.
  • Page 420 1) Rubber gaskets 3. After refilling the reserve tank and the radiator, re- install the caps and check that the rubber gaskets in- side the radiator cap are in the proper position. Changing the coolant Change the engine coolant using the following proce- dures according to the maintenance schedule in the “Warranty and Maintenance Booklet”.
  • Page 421 2Maintenance and service 1) Drain plug 3. Loosen the radiator cap to drain the coolant from the radiator. Then drain the coolant from the reserve tank. Tighten the drain plug securely. Never attempt to remove the radiator cap until the engine has been shut off and has cooled down completely.
  • Page 422 Coolant capacity (Guideline): 2.5 liter models: MT. 7.2 US qt (6.8 liters, 6.0 Imp qt) AT. 7.1 US qt (6.7 liters, 5.9 Imp qt) 3.0 liter models: 8.4 US qt (7.9 liters, 7.0 Imp qt) Be careful not to spill engine coolant when adding it.

  • Page 423: Air Cleaner Element

    Replacing the air cleaner element Replace the air cleaner element according to the maintenance schedule in the “Warranty and Mainte- nance Booklet”. Under extremely dusty conditions, re- place it more frequently. It is recommended that you always use genuine SUBARU parts.
  • Page 424 2.5 liter models 1) Bolt 1. Remove the bolt securing the rear air cleaner ele- ment case. 2. Unsnap the three clamps holding the rear air clean- er element case. UBB063BB 1) Air cleaner element 3. Separate the rear air cleaner element case from the front air cleaner element case and remove the air cleaner element.
  • Page 425 2Maintenance and service 2.5 liter CALIFORNIA spec models and 3.0 liter models 1. Unsnap the two clamps holding the air cleaner case cover. 11-24 2. Open the air cleaner case cover and remove the air UBB056BA cleaner element. 3. Clean the inside of the air cleaner cover and case with a damp cloth and install a new air cleaner ele- ment.

  • Page 426: Spark Plugs

    It may be difficult to replace the spark plugs. It is rec- ommended that you have the spark plugs replaced by your SUBARU dealer. The spark plugs should be replaced according to the maintenance schedule in the “Warranty and Mainte- nance Booklet”.

  • Page 427: Drive Belts

    However, replacement of the belt should be done according to the maintenance sched- HSB033BB ule in the “Warranty and Maintenance Booklet”. Con- sult your SUBARU dealer for replacement. If a belt is loose, cracked, or worn, contact your SUBARU dealer. in (mm)

  • Page 428: Manual Transmission Oil

    Manual transmission oil Checking the oil level 1) Yellow 1. Park the vehicle on a level surface and stop the en- gine. 2. Pull out the dipstick, wipe it clean, and insert it again. 1) Upper level 2) Lower level UBB004DB 3.

  • Page 429: Automatic Transmission Fluid

    2Maintenance and service -30 -20 -10 75W/90 SAE viscosity No. and Applicable Temperature 11-28 Automatic transmission fluid Checking the fluid level The automatic transmission fluid expands largely as its temperature rises; the fluid level differs according to fluid temperature. Therefore, there are two different scales for checking the level of hot fluid and cold fluid on the dipstick.
  • Page 430 1) Yellow UBB004KB A) HOT range B) COLD range 1) Upper level 2) Lower level 4. Pull out the dipstick and check the fluid level on the gauge. If it is below the lower level on the “HOT” range, add the recommended automatic transmission fluid up to the upper level.

  • Page 431: Recommended Fluid

    2Maintenance and service fluid up to the upper level. Be careful not to overfill. Recommended fluid “Dexron III” Type Automatic Transmission Fluid 11-30 Front differential gear oil (AT vehi- cles) Checking the oil level 1) Yellow 1. Park the vehicle on a level surface and stop the en- gine.

  • Page 432: Recommended Grade And Viscosity

    1) Upper level 2) Lower level 3. Pull out the dipstick again and check the oil level on it. If it is below the lower level, add oil to bring the level up to the upper level. Recommended grade and viscosity Each oil manufacturer has its own base oils and addi- tives.

  • Page 433: Rear Differential Gear Oil

    If the vehicle requires frequent refilling, there may be an oil leak. If you suspect a problem, have the vehicle checked at your SUBARU deal- Your vehicle may be equipped with a rear differential protector. The differential protector provides protec- tion to the rear differential assembly during off-road use.
  • Page 434 1) Filler hole 2) Drain hole 3) Oil level UBB103BB Others 1) Filler plug 2) Drain plug 2Maintenance and service HSB042BB – CONTINUED – 11-33...

  • Page 435: Recommended Grade And Viscosity

    2Maintenance and service 1) Filler hole 2) Drain hole 3) Oil level Remove the plug from the filler hole and check the oil level. The oil level should be kept even with the bottom of the filler hole. If the oil level is below the bottom edge of the hole, add oil through the filler hole to raise the level.

  • Page 436: Power Steering Fluid

    Power steering fluid Checking the fluid level 1) Reservoir tank Be careful not to burn yourself because the flu- id may be hot. When power steering fluid is being added, use only clean fluid, and be careful not to allow any dirt into the tank.

  • Page 437: Recommended Fluid

    “MIN” and “MAX” line. If the fluid level is extreme low, it may indicate possible leakage. Consult your SUBARU dealer for inspection. Recommended fluid “Dexron III” Type Automatic Transmission Fluid...

  • Page 438: Recommended Brake Fluid

    faces or rubber parts. Alcohol contained in the brake fluid may damage them. Check the fluid level monthly. 1) “MAX” level mark 2) “MIN” level mark Check the fluid level on the outside of the reservoir. If the level is below “MIN”, add the recommended brake fluid to “MAX”.

  • Page 439: Clutch Fluid (Mt Vehicles)

    If the vehicle requires frequent refilling, there may be a leak. If you suspect a problem, have the vehicle checked at your SUBARU dealer. Never use different brands of clutch fluid to- gether. When clutch fluid is added, be careful not to allow any dirt into the tank.

  • Page 440: Brake Booster

    Brake booster If the brake booster does not operate as described be- low, have it checked by your SUBARU dealer. 1. With the engine off, depress the brake pedal sever- al times, applying the same pedal force each time. The distance the pedal travels should not vary.

  • Page 441: Checking The Brake Pedal Reserve Distance

    (294 N, 30 kg) and measure the distance between the upper surface of the pedal pad and the floor. When the measurement is smaller than the specifica- tion, or when the pedal does not operate smoothly, contact with your SUBARU dealer. 11-40 Clutch pedal (Manual transmission vehicles) Check the clutch pedal free play and reserve distance according to the maintenance schedule in the “War-...

  • Page 442: Checking The Clutch Pedal Free Play

    Lightly press the clutch pedal down with your finger until you feel resistance, and check the free play. If the free play is not within proper specification, con- tact your SUBARU dealer. Replacement of brake pad and lining If you continue to drive despite the scraping...

  • Page 443: Breaking-In Of New Brake Pads And Linings

    Breaking-in of new brake pads and lin- ings When replacing the brake pad or lining, use only gen- uine SUBARU parts. After replacement, the new parts must be broken in as follows: Brake pad and lining While maintaining a speed of 30 to 40 mph (50 to 65 km/h), step on the brake pedal lightly.

  • Page 444: Parking Brake Stroke

    (about 44 lbs, 196 N, 20 kg). If the parking brake lever stroke is not within the specified range, have the brake system checked and adjusted at your SUBARU dealer. Tires and wheels Types of tires You should be familiar with type of tires present on your vehicle.

  • Page 445: Tire Inspection

    Check on a daily basis that the tires are free from se- rious damage, nails, and stones. At the same time, check the tires for abnormal wear. Contact your SUBARU dealer immediately if you find any problem. NOTE When the wheels and tires strike curbs or are...
  • Page 446 a pressure gauge to adjust the tire pressures to the values shown on the tire placard. The tire placard is lo- cated on the door pillar on the driver’s side. Driving even a short distance warms up the tires and increases the tire pressures.
  • Page 447 2Maintenance and service Abnormally low tire pressure (tread worn at shoulders) Rolling resistance is high, so fuel consumption is also higher. 11-46 Abnormally high tire pressure (tread worn in cen- ter) HSB053AA Ride comfort is poor. Also, the tire magnifies the ef- fects of road-surface bumps and dips, possibly result- ing in vehicle damage.

  • Page 448: Wheel Balance

    If you suspect that the wheels are not correctly bal- anced, have them checked and adjusted by your SUBARU dealer. Also have them adjusted after tire re- pairs and after tire rotation. NOTE Loss of correct wheel alignment* causes the tires to wear on one side and reduces the vehicle’s run-...

  • Page 449: Tire Rotation

    2Maintenance and service ible, the tire is worn beyond the acceptable limit and must be replaced immediately. With a tire in this condition, driving at high speeds in wet weather can cause the vehicle to hydroplane. The resulting loss of vehicle control can lead to an accident.

  • Page 450: Wheel Replacement

    For safe vehicle operation, SUBARU recommends re- placing all four tires at the same time. All four tires must be the same in terms of...

  • Page 451: Wheel Covers

    2Maintenance and service Wheel covers Removing the wheel cover Insert the wheel nut wrench into the notch provided, and pry the wheel cover off. 11-50 Installing the wheel cover Align the valve with the valve hole in the cover, then fit UB9032BA the cover on the wheel by tapping your hand evenly around the circumference of the cover.

  • Page 452: Aluminum Wheels (If Equipped)

    When wheel nuts, balance weights, or the center cap is replaced, be sure to replace them with genuine SUBARU parts designed for aluminum wheels. 2Maintenance and service Windshield washer fluid Never use engine coolant as washer fluid be- cause it could cause paint damage.

  • Page 453: Replacement Of Wiper Blades

    2Maintenance and service freeze type windshield washer fluid. SUBARU Wind- shield Washer Fluid contains 58.5% methyl alcohol and 41.5% surfactant, by volume. Its freezing temper- ature varies according to how much it is diluted, as in- dicated below. Washer Fluid Concentration Freezing Temperature 10.4°F (–12°C)

  • Page 454: Replacement Wiper Blade Assembly

    Replacement wiper blade assembly 1. Raise the wiper arm off the windshield. 1) Stopper 2. Remove the wiper blade assembly by holding its pivot area and pushing it in the direction shown by the arrow while depressing the wiper blade stopper. 3.
  • Page 455 2Maintenance and service 1) Metal spines 2. If the new blade rubber is not provided with two metal spines, remove the metal spines from the old blade rubber and install them in the new blade rubber. 11-54 HSB060BB 3. Align the claws of the metal support with the grooves in the rubber and slide the blade rubber as- sembly into the metal support until it locks.
  • Page 456 1) Stopper 4. Be sure to position the claws at the end of the metal support between the stoppers on the rubber as shown. If the rubber is not retained properly, the wiper blade may scratch the windshield. Rear window wiper blade rubber HSB062BB 1) Plastic support 1.
  • Page 457 2Maintenance and service 2. Pull the blade rubber assembly out of the plastic support. 11-56 USB586BA 1) Metal spines 3. If the new blade rubber is not provided with two metal spines, remove the metal spines from the old blade rubber and install them in the new blade rubber. USB583BB...
  • Page 458 4. Align the claws of the plastic support with the grooves in the blade rubber assembly, then slide the blade rubber assembly into place. USB586CA Securely lock the end of the plastic support as shown in the illustration. If the rubber is not retained properly, the wiper may scratch the rear window glass.

  • Page 459: Battery

    2Maintenance and service Battery Before beginning work on or near any bat- tery, be sure to extinguish all cigarettes, match- es, and lighters. Never expose a battery to an open flame or electric sparks. Batteries give off a gas which is highly flammable and explosive. For safety, in case an explosion does occur, wear eye protection or shield your eyes when working near any battery.

  • Page 460: Fuses

    Fuses Never replace a fuse with one having a higher rating or with material other than a fuse be- cause serious damage or a fire could result. The fuses are designed to melt during an overload to prevent damage to the wiring harness and electrical equipment.
  • Page 461 2Maintenance and service 1) Fuse puller 2) Spare fuses The fuse puller and spare fuses are stored in the main fuse box cover in the engine compartment. 11-60 HSB066BB A) Good B) Blown If any lights, accessories or other electrical controls do not operate, inspect the corresponding fuse.

  • Page 462: Main Fuse

    5. Inspect the fuse. If it has blown, replace it with a spare fuse of the same rating. 6. If the same fuse blows again, this indicates that its system has a problem. Contact your SUBARU dealer for repairs. Main fuse...

  • Page 463: Installation Of Accessories

    2Maintenance and service Installation of accessories Always consult your SUBARU dealer before installing fog lights or any other electrical equipment in your ve- hicle. Such accessories may cause the electronic sys- tem to malfunction if they are incorrectly installed or if they are not suited for the vehicle.

  • Page 464: Replacing Bulbs

    2Maintenance and service Replacing bulbs 14 10 9 10 UBB101BB – CONTINUED – 11-63...

  • Page 465: Headlight

    2Maintenance and service Wattage 1) Headlight OUTBACK models Low beam 12V-55W High beam 12V-60W Except GT and OUT- 12V-65/ BACK models 2) Front turn signal 12V-27W 3) Spot light 12V-8W 4) Dome light 12V-8W 5) Door step light 12V-3.4W – 6) Front turn signal light/park- 12V-27/8W 1157NA ing and front side marker...
  • Page 466 NOTE If headlight aiming is required, consult your SUBARU dealer for proper adjustment of the head- light aim. 2Maintenance and service For GT and OUTBACK models –...
  • Page 467 2Maintenance and service 1) Low beam light bulb 2) High beam light bulb Remove the headlight bulb cover, by turning it coun- terclockwise. 11-66 Low beam light bulbs UBB040BB 1) Electrical connector 2) Red cable 3) Black cable 1. Disconnect the electrical connector for the black cable.
  • Page 468 2Maintenance and service High beam light bulbs UBB042BA UBB043BA 2. Remove the retainer spring. 3. Replace the bulb, then set the retainer spring se- curely. 4. Reconnect the electrical connector for black cable. 5. Install the headlight bulb cover. – CONTINUED – 11-67...
  • Page 469 2Maintenance and service 1) Push 1. Disconnect the electrical connector from the bulb. 2. Remove the bulb from the headlight assembly by turning it counterclockwise. 3. Replace the bulb with new one. 4. Reconnect the electrical connector. At this time, use care not to touch the bulb surface.

  • Page 470: Front Fog Light (If Equipped)

    After a bulb has been replaced, it is recommended that the head- light aiming adjustment be made at a SUBARU dealer. UBB046BA 1. Remove the headlight assembly mounting screws...
  • Page 471 2Maintenance and service 2. Move the headlight assembly forward. 1) Front turn signal light bulb 2) Front turn signal light bulb/parking and front side marker light bulb 3. Remove the bulb socket from the headlight assem- bly by turning it counterclockwise. 11-70 UBB039CB 4.

  • Page 472: Rear Combination Lights

    Rear combination lights Sedan 1. Open the trunk lid. 2. Open the rear combination light cover. For covers on the trunk lid: 1) Back-up light bulb 2) Brake/tail light bulb Unlatch the cover by pushing the knob and open the UBF014DA cover.
  • Page 473 Brake/tail and rear turn signal light bulbs It may be difficult to replace the bulbs. It is recom- mended that you have the bulbs replaced by your SUBARU dealer. UBB035BB 1) Service holes 1. Remove the light bulb replacement service hole covers at two places by prying the edge of the cover with a regular screwdriver.
  • Page 474 1) Nuts 2. Remove the upper and lower nuts. Then, slide the rear combination lamp assembly to the rear and re- move it from the vehicle. 3. Using a Phillips screwdriver, remove the upper and lower screws that secure the side cover of the rear combination light assembly.
  • Page 475 2Maintenance and service Turn signal light bulb 11-74 UBB048BA Brake/tail light bulb 5. Remove the bulb from the socket. Turn signal light: Pull the bulb out of the socket. Brake/tail light: Remove the bulb from the socket by pushing it and turning it counterclockwise. 6.
  • Page 476 10.Reinstall the light bulb replacement service hole covers. Back-up and brake/tail light bulbs 1) Back-up light bulb 2) Brake/tail light bulb 1. Unlatch the rear finisher light cover by moving the knob upward. Open the cover up. 2. Remove the bulb socket from the rear finisher light assembly by turning it counterclockwise.

  • Page 477: License Plate Light

    2Maintenance and service License plate light 11-76 1. Remove the mounting screws using a phillips screwdriver. 2. Remove the cover and lens. 3. Pull the bulb out of the socket. Install a new bulb. 4. Reinstall the lens and cover. 5.
  • Page 478 2Maintenance and service UBB068BA HSB088BA Map light (with moonroof model) Dome light – CONTINUED – 11-77...
  • Page 479 2Maintenance and service Luggage compartment light 1) Bulb 11-78 UBB067BB Door step light 1. Remove the lens by prying the edge of the lens with a regular screwdriver. 2. Pull the bulb out of the socket. Install a new bulb. 3.

  • Page 480: Trunk Light

    Trunk light 1. Remove the cover by squeezing its sides and pull- ing it. 2. Pull the bulb out of the socket. Install a new bulb. 3. Reinstall the cover. High mount stop light Sedan UBF014FA 1. Remove the high mount stop light cover by prying on the edge with a screwdriver.
  • Page 481 3. Pull the bulb out of the socket. Install a new bulb. 4. Reinstall the cover. 5. Tighten the mounting screws then reinstall the cov- ers. NOTE Other bulbs may be difficult to replace. Have your SUBARU dealer replace these bulbs if necessary. 11-80...

  • Page 482: Specifications

    Specifications Specifications ... Dimensions ... Engine ... Electrical system ... Capacities ... Tires ... Wheel alignment ... Fuses and circuits ... Fuse panel located behind the coin tray ... Fuse panel located in the engine compartment ... Bulb chart ... 12-12 Vehicle identification ...
  • Page 483 Specifications Specifications Specifications These specifications are subject to change without notice. Dimensions Item Sedan Overall length 184.4 (4,685 ) 187.4 (4,760) Overall width 68.7 (1,745) Overall height 55.7 (1,415) Wheel base 104.3 (2,650) Tread Front 57.5 (1,460) Rear 57.5 (1,460) Ground clearance 6.1 (155) *: With roof rail...

  • Page 484: Engine

    Engine Engine model Engine type Horizontally opposed, liquid cooled 4 cyl- Displacement cc (cu-in) Bore × Stroke in (mm) Compression ratio Firing order Electrical system Battery type and capacity Alternator Spark plugs *: CALIFORNIA spec models EJ251, EJ259 (2.5 liter) Horizontally opposed, liquid cooled 6 cyl- inder, 4 stroke gasoline engine inder, 4 stroke gasoline engine...

  • Page 485: Capacities

    Specifications Capacities Fuel tank Engine oil Transmission oil (MT) Transmission fluid (AT) AT differential gear oil Rear differential gear oil Power steering gear fluid Engine coolant 12-4 2.5 liter 3.0 liter L-S (AT), L (AT) Others 2.5 liter 3.0 liter 16.9 US gal (64 liters, 14.1 Imp gal) 4.2 US qt (4.0 liters, 3.5 Imp qt) 5.6 US qt (5.3 liters, 4.6 Imp qt)

  • Page 486: Tires

    Tires Tire size P205/60R15 90H Wheel size 15 x 6JJ Pressure Front Rear Rear at trailer towing Temporary Size T135/70R16 spare tire Pressure Wheel alignment Item Sedan Front Rear Camber Front Rear –0°30’ P205/55R16 89H 16 x 6 32 psi (220 kPa, 2.2 kg/cm 30 psi (210 kPa, 2.1 kg/cm –...

  • Page 487: Fuses And Circuits

    Specifications Fuses and circuits Fuse panel located behind the coin tray 2.5 liter models 12-6 Fuse panel HBC001DB Fuse rating Circuit Heater fan Heater fan Power door lock Keyless entry Mirror heater Cigarette lighter Remote controlled rear view mirrors Tail light Parking light SRS airbag Front fog light...
  • Page 488 Fuse panel Fuse rating Circuit Illumination brightness control Fuel pump Rear window wiper and washer Windshield wiper and washer Brake light Air conditioner Backup light Cruise control ABS control Wiper deicer Accessory power sock- Seat heater Ignition coil and ignitor (CALIFORNIA spec vehicle only) Specifications...
  • Page 489 Specifications Fuse panel Fuse rating Heater fan Power door lock Keyless entry Cigarette lighter Remote controlled rear view mirrors Mirror heater Tail light Parking light SRS airbag Front fog light ABS (VDC) solenoid Radio Clock Trailer Engine ignition system SRS airbag Illumination brightness control 12-8...

  • Page 490: Fuse Panel Located In The Engine Compartment

    Fuse panel located in the engine com- partment 2.5 liter models A) FWD socket (without SPORTSHIFT mode) B) Main fuse Fuse panel Fuse rating UBC003BB Specifications Circuit Radiator cooling fan (Main) Radiator cooling fan (Sub) ABS motor Rear window defogger Hazard warning flasher Horn Meter...
  • Page 491 Specifications Fuse panel Fuse rating Clock Interior light 12-10 3.0 liter models Circuit A) FWD socket (without VDC model) B) Main fuse UBC004BC...
  • Page 492 Fuse panel Fuse rating Circuit Radiator cooling fan (Main) Radiator cooling fan (Sub) ABS motor VDC motor McIntosh audio amp (if equipped) Rear window defogger Hazard warning flasher Horn Meter SRS airbag system warning light Automatic transmis- sion control unit ABS UNIT Alternator Headlight (right side)

  • Page 493: Bulb Chart

    Specifications Bulb chart Description Wattage Headlight GT and OUTBACK Low beam 12V-55W High beam 12V-60W Except GT and OUT- 12V-65/55W 9007 (HB5) BACK Front turn signal 12V-27W Spot light 12V-8W Dome light 12V-8W Door step light 12V-3.4W Parking and front side 12V-27/8W marker light Front fog light...

  • Page 494: Vehicle Identification

    Vehicle identification Emission control label Vehicle identification number Radio noise label (Canada mod- Tire inflation pressure label Certification and bar code label Vehicle identification number plate Model number plate UBC009BB Specifications – CONTINUED – 12-13...
  • Page 496 Consumer information and Reporting safety defects Tire information ... Tire labeling ... Recommended tire inflation pressure ... Glossary of tire terminology ... Tire care – maintenance and safety practices ... Vehicle load limit – how to determine ... Determining compatibility of tire and vehicle load capacities ...

  • Page 497: Tire Information

    Consumer information and Reporting safety defects For U.S.A. Consumer information and Reporting safety defects The following information has been compiled accord- ing to Code of Federal Regulations “Title 49, Part 575”. Tire information Tire labeling Many markings (e.g. Tire size, Tire Identification Number or TIN) are placed on the sidewall of a tire by tire manufacturers.

  • Page 498: Consumer Information And Reporting Safety Defects

    Example: 225 / 60 R 16 97 H Size designation (6) (7) (6) Load Index: A numerical code which specifies the maximum load a tire can carry at the speed indicated by its speed symbol, at maximum infla- tion pressure. For example, “97”...
  • Page 499 Consumer information and Reporting safety defects (2) Tire Size (3) Tire Type Code (4) Date of Manufacture The first two figures identify the week, starting with “01” to represent the first full week of the cal- endar year; the second two figures represent the year.

  • Page 500: Recommended Tire Inflation Pressure

    Recommended tire inflation pressure Recommended cold tire inflation pressure Recommended cold tire inflation pressure for your vehicle’s tires is as follows, Tire size P205/60R15 90H Wheel size Pressure Front Rear Rear at trailer towing Temporary Size spare tire Pressure Consumer information and Reporting safety defects P205/55R16 89H 15 x 6JJ 32 psi (220 kpa, 2.2 kg/cm...
  • Page 501 Consumer information and Reporting safety defects Vehicle placard The vehicle placard is affixed to the driver’s side B-pillar. 13-6 Example: TIRE AND LOADING INFORMATION SEATING CAPACITY The combined weight of occupants and cargo should never exceed 386kg or 850 lbs. ORIGINAL TIRE SIZE P225/60R16 COMPACT SPARE TIRE...

  • Page 502: Glossary Of Tire Terminology

    hicle control could lead to an accident. Measuring and adjusting air pressure to achieve proper inflation Check and, if necessary, adjust the pressure of each tire (including the spare) at least once a month and before any long journey. Check the tire pressures when the tires are cold.

  • Page 503: Tire Care - Maintenance And Safety Practices

    Consumer information and Reporting safety defects Maximum loaded vehicle weight The sum of curb weight, accessory weight, vehi- cle capacity weight and production options weight. Normal occupant weight 150 lbs (68 kg) times the number of occupants (3 occupants). Occupant distribution Distribution of occupants in a vehicle, 2 in front, 1 in rear seat.

  • Page 504: Vehicle Load Limit - How To Determine

    left-hand side of the vehicle. (Each tire must be kept on its original side of the vehicle.) Replace any damaged or unevenly worn tire at the time of rotation. After tire rotation, adjust the tire pres- sures and make sure the wheel nuts are correct- ly tightened.
  • Page 505 Consumer information and Reporting safety defects Vehicle capacity weight of the vehicle is 800 lbs (363 kg), which is indicated on the vehicle plac- ard with the statement “The combined weight of occupants and cargo should never exceed 363 kg or 800 lbs”. For example, if the vehicle has one occupant weighing 154 lbs (70 kg) plus cargo weighing 551 lbs (250 kg).
  • Page 506 number of occupants to two), the calculations are as follows: 1. Calculate the total weight. Total weight = 154 lbs (70 kg) + 176 lbs (80 kg) (Occupant) + 551 lbs (250 kg) (Cargo) = 881 lbs (400 kg) 2. Calculate the available load capacity. Available Load Capacity = 800 lbs (363 kg) –...
  • Page 507 Consumer information and Reporting safety defects the trailer tongue (i.e. Tongue load = 176 lbs (80 kg)). 1. Calculate the total weight. Total weight = 165 lbs (75 kg) + 265 lbs (120 kg) (Occupant) (Cargo) + 22 lbs (10 kg) + 176 lbs (80 kg) (Tongue load) (Trailer hitch) = 628 lbs (285 kg)

  • Page 508: Determining Compatibility Of Tire And Vehicle Load Capacities

    Total weight = 165 lbs (75 kg) + 143 lbs (65 kg) + 40 lbs (18 kg) (Occupant) + 11 lbs (5 kg) + 265 lbs (120 kg) (Child restraint) (Cargo) + 22 lbs (10 kg) + 176 lbs (80 kg) (Trailer hitch) (Tongue load) = 822 lbs (373 kg)

  • Page 509: Adverse Safety Consequences Of Overloading On Handling And Stopping And On Tires

    Consumer information and Reporting safety defects Adverse safety consequences of over- loading on handling and stopping and on tires Overloading could affect vehicle handling, stop- ping distance, vehicle and tire as shown bellow. This could lead to an accident and possibly result in severe personal injury.

  • Page 510: Uniform Tire Quality Grading Standards

    Uniform tire quality grading stan- dards This information indicates the relative perfor- mance of passenger car tires in the area of treadwear, traction, and temperature resistance. This is to aid the consumer in making an in- formed choice in the purchase of tires. Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width.

  • Page 511: Temperature A, B, C

    Consumer information and Reporting safety defects tests, and does not include acceleration, cornering, hydroplaning, or peak traction characteristics. Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.

  • Page 512: Reporting Safety Defects (Usa)

    However, NHTSA cannot become involved in individual problems between you, your dealer, or Subaru of America, Inc. To con- tact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 366-0123 in the Washington D.C. area) or write to: NHTSA, U.S.

  • Page 514: Index

    Index 14-1...
  • Page 515 Index ABS (Anti-lock Brake System) Warning light Accessories Accessory power outlet Air cleaner element Air conditioner operation Air filtration system Air flow selection Aluminum wheels Antenna system Anti-lock Brake System (ABS) Arming the system Armrest Ashtray AT OIL TEMPerature warning light Audio set Auto-dimming mirror/compass Automatic/Emergency Locking Retractor...
  • Page 516 Center Console Ventilators Changing Flat tire Oil and oil filter Charge warning light CHECK ENGINE warning light/ Malfunction indicator lamp Checking Brake pedal free play Brake pedal reserve distance Clutch function Clutch pedal free play Engine oil level Fluid level 11-28, 11-35, 11-36, 11-38 Gear oil level 11-27, 11-30, 11-32...
  • Page 517 Index Disc brake pad wear warning indicators Dome light Door locks Door open warning lights Drive belts Driving Drinking Drugs Foreign countries Car/Mobile phone Pets Tips 7-14, 7-19, 7-28, 8-6 Tired or sleepy Snowy and icy roads Electrical system Emergency Locking Retractor (ELR) Engine Compartment overview Coolant...
  • Page 518 GAWR (Gross Axle Weight Rating) Glove box GVWR (Gross Vehicle Weight Rating ) Hazard warning flasher Headlights Headrest adjustment (Wagon) Head restraint adjustment (Front) Heater operation High beam indicator light High mount stop light Horn Hose and connections Ignition switch Illuminated entry Illumination brightness control Indicator light...
  • Page 519 Index Manual heating and air conditioning system Manual transmission Manual transmission oil Map light Maximum load limits Meters and gauges Mirrors Moonroof New vehicle break-in driving – the first 1,000 miles (1,600 km) Odometer/Trip meter Off road driving Oil pressure warning light Oil filter Oil level Engine...
  • Page 520 Recommended Automatic transmission fluid Brake fluid Clutch fluid OIL grade and viscosity 11-15, 11-16, 11-27 Power steering fluid Spark plugs Remote keyless entry system Replacement Brake pad and lining Wiper blades Replacing Air cleaner element Battery (remote keyless entry system) Lost transmitters (keyless entry system) Replacing bulbs Dome light...
  • Page 521 Index SRS side airbag Starting the engine State emission testing (U.S. only) Stopping the engine Storage compartments Subfloor storage Sun visors Sun shades Supplemental Restraint System airbag (SRS) Synthetic leather upholstery Tachometer Temperature gauge Temporary spare tire Tie-down hooks Tilt steering wheel Tire Chains Inspection...
  • Page 522 Vehicle Dynamics Control (VDC) system Ventilator Warning and indicator lights Warning lights Anti-lock Brake system AT OIL TEMPerature Brake system Charge CHECK ENGINE Door open Front-wheel drive Oil pressure Seatbelt SRS airbag system Warranties and maintenance Washing Waxing and polishing Wear indicators Wheel Alignment...
  • Page 524 HSF028AA...

  • Page 525: Fuel Octane Rating

    Fuel: 2.5 Liter models Use only unleaded gasoline with an octane rating of 87 AKI or higher. 3.0 Liter models Use premium unleaded gasoline with an octane rat- ing of 91 AKI or higher. Regular unleaded gasoline with an octane rating of 87 AKI may be used if nec- essary.

This manual is also suitable for:

2004 outbackLegacy outback 20042004 legacy sedan2004 outback sedan2004 legacy station wagon2004 outback station wagon

Table of Contents
