[Ao Group]; [Rs485 Group]; Disclaims; Trademark - ADTEK CS2-VA Operation Manual

ecI3
0032h
debnc
0033h

[AO Group]

Name Address
aOtyp
0034h
aOls
0035h
aOhs
0036h
aOlmt
0037h
ZSrst
0038h

[RS485 Group]

Name Address
adres
0039h
baud
003Ah
prity
003Bh
sQrot
003Ch
Amend 2009/11/14, Add Square root function

DISCLAIMS

■
The information in this manual has been carefully checked and is believed to be accurate.
ADtek Instruments Co., Ltd. assumes no responsibility for any infringements of patents or other
rights of third parties, which may result from its use.
ADtek assumes no responsibility for any inaccuracies that may be contained in this document,
and make no commitment to update or to keep current the information contained in this manual.
ADtek reserves the right to make improvements to this document and/or product at any time
without notice.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in
any form of or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of ADtek Instruments Co., Ltd.
■

TRADEMARK

The names used for identification only maybe registered trademark of their respective
companies.
Copyright © 2006 ADtek Instruments Co., Ltd. All rights reserved.
Printed in Taiwan.
Welcome to visit our web-site:
www.adtek.com.tw
0~5 External Control Input 1
0:nonE (None);
1:rEL.PV(Relative PV);
2:PV.HLd(PV Hold);
3: M.rSt(Reset for Maximum & Minimum);
4:rY.rSt(Reset for Relay Hold);
5:di(Digital Input);
5~255 ECI debouncing
5~255 *8mSec
Range
0~5 Analog Output Type
0: 0~10V
3: 0~20mA
-19999~29999 Analogue Output Low Scale
-19999~29999 Analogue Output High Scale
00.00%~110.00% Analogue Output High Limit
0~3 The clear of AO_ZERO and AO_SPAN
0: None
3: Both
Range
1~255 RS485 address
0~5 RS485 baud rate
0:1200
4:19200 5:38400
0~3 RS485 parity
0: n-8-1 1: n-8-2, 2: odd,
0~1 Square root function
0: no 1: yes
www.csec.com.tw
CS2 SERIES –OPERATION MANUAL(EN)-A-2017-11-16
Explain
1: 0~5V 2:1~5V
4: 4~20mA 5: 0~10mA
1: AO_ZERO 2: AO_SPAN
Explain
1:2400 2:4800 3:9600
3: even,
3 R/W
12 R/W
Initial Write/Read Note
4 R/W
0 R/W
19999 R/W
110.00% R/W
0 R/W
Initial Write/Read Note
1 R/W
3 R/W
1 R/W
0 R/W
