Programming Level

[Input Group]

Name Address
RESERVED 000Dh
aItyp
aIlo
000Eh
aIhi
000Fh
pVdp
0010h
lOsc
0011h
hIsc
0012h
pVzro
0013h
pVspn
0014h
ZSrst
0015h
dsply
0016h
lOcut
0017h
avg
0018h
Dfilt
0019h
Pcode
001Ah
Flock
001Bh

[Relay Group]

Name Address
rYsb
001Ch
rYsd
001Dh
ry!md
001Eh
ry!hy
001Fh
ry!rd
0020h
ry!fd
0021h
ry@md
0022h
ry@hy
0023h
Range
No use unless CS2-PR
The address is for CS2-PR only
0~5
Analogue Input Type
0:0~10V
4:4~20mA 5:0~10mA
0.00~100.00%
Input Low
0.00~100.00%
Input High
0~4
PV Decimal Point
0: 00000 1: 0000.0 2: 000.00 3: 00.000
4: 0.0000
-19999~29999
Low Scale
-19999~29999
High Scale
-19999~29999
PV ZERO
-19999~29999
PV SPAN
0~3 The clear of PV_ZERO and PV_SPAN
0:None
3: Both
0~3 Display Mode
0:PV 1: Minimum Hold 2: Maximum Hold
3: RS485
-19999~19999
Low Cut
1~99
Average
0~99
Digital Filter
0000~9999
Pass Code
0~3 Function Lock
0: none 1: User Level
3: All
Range
0000~9999
Start Band of Relay
0000~5999
Start Delay Time of Relay
(0.1second)
0~5 Relay1 Energized Mode
0: oFF(no use);
1: Lo(Low Energized);
2: Hi(High Energized)
3: Lo Hold(Low Energized Hold)
4: High Hold(High Energized Hold)
5: DO(Digital Output);
0000~5000
Hysteresis of Relay1
0000~5999
Energized Delay Time of Relay1
(0.1second)
0000~5999
De-Energized Delay Time of Relay1
(0.1second)
0~5 Relay2 Energized Mode
0: oFF(no use);
1: Lo(Low Energized);
2: Hi(High Energized)
3: Lo Hold(Low Energized Hold)
4: High Hold(High Energized Hold)
5: DO(Digital Output);
0000~5000
Hysteresis of Relay2
CS2 SERIES –OPERATION MANUAL(EN)-A-2017-11-16
Explain
1:0~5V 2:1~5V 3:0~20mA
1:PV_ZERO 2:PV_SPAN
2: Engineer Level
Explain
Initial Write/Read Note
0 R/W
0.00% R/W
100.0% R/W
0 R/W
0 R/W
19999 R/W
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
5 R/W
0 R/W
1000 R/W
0 R/W
Initial Write/Read Note
0 R/W
0 R/W
2 R/W
0 R/W
0 R/W
0 R/W
2 R/W
0 R/W
