stepIM
Clear Chart
Clears the displayed chart.
Chart Properties
Set Background
Color
Grid
Show Legend
Legend Position
Freeze Scale
Reset All Trace
Offsets
Grid Color by Trace
Hide Right Y Scale
Copy Image to
Clipboard
Show All (Hidden) Traces
Displays all traces on the chart that were hidden by the Hide Trace option.
The Show/Hide status of a trace can be toggled by right-clicking on the variable
in the Record Variables pane.
ServoStudio Reference Manual
Opens the Colors dialog box, and allows you to modify
the background color of the chart.
Toggles the grid display on and off.
Also allows you to modify the grid:
X Axis. Toggles the X-axis grid line on/off.
Y Axis. Toggles the Y-axis grid line on/off.
Dot | Line. Uses either dotted lines or solid lines for
the grid.
Toggles the legend display on and off.
Top right or bottom left
Sets the Y-axis to a fixed scale. Normally the Y-axis is
scaled dynamically as the amplitude of the signals
changes.
When Scale is frozen, the letter F is displayed next to
the Chart Options button on the toolbar.
When Scale is frozen, the letter O is also displayed if
part of the trace is out of view.
Resets the value of all offset (+) values in the Record
Variables list to 1.
Whenever an offset is in effect, a plus sign + is
displayed next to the variable name in the legend.
If two grids are used (right and left axis), different
colors can be defined to improve the readability of the
chart.
Hides the Y-axis scale on the right side of the chart, if
displayed.
Copies the chart to a graphic image, which can be
pasted into other application.
Scope Dashboard
