Software Interface Elements
10
Save
No Fault |
Clear Fault
CANopen
Objects Table
Info
Drive in Use
Help
About
Sidebar
Task Screen
Status Bar
Faults
Warnings
Saves the parameter values currently in the drive
RAM to the drive's non-volatile memory. These
values will be loaded to drive RAM at power-up.
Use Save after configuring parameters to keep
values in non-volatile memory.
Indicates whether a fault exists. When lit, click to
send a clear faults command to the drive.
Opens a screen that allows you to access and
modify the values of the CAN objects.
Refer to CANopen Objects
Shows the drive detected (online), or the drive
defined for offline use.
Online help for ServoStudio software. Also
includes help for drive hardware and VarCom. In
addition, use F1 or the right-click shortcut menu
to activate Help for the currently selected field.
Software version information.
Contains a navigation menu to the various
ServoStudio screens.
The sidebar can be hidden or displayed using the
Arrow button.
Displays various interactive screens for viewing,
setting and testing parameters and drive
configurations.
These screens are described in detail in other
sections throughout this manual.
Displays the status of the drive.
This segment of the status bar is green as long
as no faults exist; it is red whenever a fault
exists.
Hovering the mouse over Faults displays the
fault/s.
Click Faults to open the Enable & Faults screen.
Right-click to clear faults.
This segment of the status bar is green as long
as no warnings exist; it is yellow whenever a
warning exists.
Click Warnings to open the Enable & Faults
screen.
Right-click to clear fault/s.
Table.
