50 Watt Fibermark - Epilog Laser FiberMark Fusion 13000 Owner's Manual

Section 12: Speed and Power

50 Watt FiberMark

Anodized Aluminum
Stainless Steel
Brass
Laserable Plastic
Bare Aluminum
Titanium
Stainless Steel
Titanium
Notes on Annealing: Producing an annealed mark is very dependent on the material
being out of focus. Run the laser at slow speed and full power then adjust the focus
while the machine is running until you achieve the annealed mark you need.
Notes on settings: Don't be afraid to experiment with Speed, Power and Frequency
settings. Many materials can be marked over the entire range of settings! Start with
the recommended settings and change one variable at a time to produce a mark that
best suits your needs. Most users start with the highest speed setting listed and work
their way faster or slower.
Recommendations
Marking/Etching
SPEED
40-80%
15-60%
15-60%
50-100%
5-50%
15-60%
Annealing
SPEED
12-17%
12-17%
148
POWER FREQUENCY
50-100% 50-100%
100% 1-20%
100% 1-10%
40 -80% 50-100%
100% 1–20%
100% 1–15%
POWER FREQUENCY
100% 1-10%
100% 1-100%
FOCUS
-0.03 to +0.03
-0.01 to +0.01
0.00
-0.02 to +0.02
-0.01 to +0.01
-0.02 to +0.02
FOCUS
-0.08 to -0.1
+0.05 to +0.08
-0.08 to -0.1
+0.05 to +0.08
