Section 8: Using the Front Control Panel
17. Stamp Match – This sets the left-right raster line alignment in Stamp mode.
This setting is normally a factory only setting and will not need to be adjusted
by the user.
18. ♦ Set XY Home – This sets a new Home Position. Most users find it is easier to
make this setting from the sub-menu in Jog mode.
19. ♦ Set Table Home – This sets a new Table Home Position. Most users find it is
easier to make this setting from the sub-menu in Focus mode.
20. ♦ Go XY Home – This restores the carriage lens to its default Home position in
the upper left corner of the machine. Most users find it is easier to make this
setting from the sub-menu in Jog mode.
21. ♦ Go Table Home – This restores the table to its default Home position.
22. X Scale Adjust – This setting calibrates the accuracy in the X-axis. This setting
is normally a factory only setting and will not need to be adjusted by the user.
23. Y Scale Adjust – This setting calibrates the accuracy in the Y-axis. This setting
is normally a factory only setting and will not need to be adjusted by the user.
24. Laser TI – This sets the Tickle of the laser tube. This setting is normally a
factory only setting and will not need to be adjusted by the user.
25. Bed Size – This indicates the bed size. This setting is normally a factory only
setting and will not need to be adjusted by the user.
26. Sys Unit – Sets the units of the machine to inches or CM.
27. Fiber Laser PWR – Sets the correct parameters for the specific power output of
your machine.
28. ♦ Full Table Home – This setting is normally a factory only setting.
29. Calibrate Joystick – This setting is normally a factory only setting. It
reestablishes the feel of the Joystick.
30. System Version – This displays the Firmware version that is installed.
