Section 8: Using the Front Control Panel
your new or temporary Table Home position and want the table to move back
to its default Home position so you can start using auto focus again.
Note – an alternative method of setting a new Table Home position is to just center
click once. There is no visual indicator on the display, but a single center click after
you have focused your table eliminates double center clicking to access the sub-
menu.
JOG
With Jog highlighted, use the Joystick to move the lens carriage over the table. Turn
on the red dot pointer for a visual indicator of where the carriage is moving. The
carriage can be moved in X, Y or diagonally. The display will show a digital readout
of the carriage position. The imagine below shows the lens carriage is at +0.500 in the
X axis and +1.234 in the Y axis.
Set a New or Temporary Home:
The Jog function is most useful for setting a new or temporary Home position when
working on odd shaped items or if it's just more convenient to designate somewhere
other than the upper left corner of the table as your starting point. To set a new Home
position, use the following instructions:
1. Go to the Jog function on the keyboard
2. Use the Joystick to move the carriage to a new position. Use the red dot pointer
as a visual indicator of the carriage location. The display will also show a
digital readout of the X and Y position.
3. Double center click to access the sub-menu.
4. Tilt the joystick to the left (SET 0) to set a new Home position.
Note – an alternative method of setting a new Home position is to just center click
once. There is no visual indicator on the display, but a single center click takes the
place of steps 3 and 4 above.
5. Once your new Home position is set, use the cursor keys to go to the Job
function. Press the Go key to run your job. Your job will use this new Home
position as it's starting reference point.
6. When you are finished with the new Home position, go back to the Jog mode
and double center click to bring up the sub-menu.
7. Tilt the joystick to the right (RESTORE) to restore the lens carriage to its
default zero, zero Home position in the upper left corner.
