Section 6: Using the Epilog Dashboard
Any time the focus setting is a negative number it means the table is being moved
Closer to the focus lens. In other words, a negative number indicates that the gap
between the table and the focus lens is getting smaller (decreasing).
The Focus slider has a range of -500 to +3000. This range allows the user to move
the table closer to the lens by as much as 0.500 inch (-500), or move the table
away from the lens by as much as 3.000 inches (3000).
Changing the focus setting by typing a value is discouraged.
With this box checked, all raster objects will be processed at the color
Raster –
mapped settings. However, this function will not allow a thin vector line to raster.
With this box checked, all vector objects will be processed at the color
Vector –
mapped settings. However, this function will not allow a raster object to be
processed as a vector.
With this box checked, all objects will be processed with Air
Air Assist -
Assist at the color mapped settings.
For most jobs Color Mapping is a powerful and easy tool to use and understand.
Please keep in mind that because you can control seven different variables and 17
different colors doesn't mean that you should. With so many different settings
available in a single setup it has the potential to get overly complicated.
Sometimes it's easier to scale back on how complicated a job should be.
