Icom IC-F620 Programming Software Manual page 63

Group Row
Trunking Number of
Parameters Preamble Bits
Trunking Number of
Parameters Hang Bits
Option TX Low
Power for all
modes
Option Odometer
Write
Option Display
Sequencing
Option PassPort
CRC LOS
Tone
Option PassPort
RSSI LOS
Tone
Scrambler Type
Scrambler Group Code
CS-F620TR Programming Software Manual
Description
Select "0" through "7". Selects number of initial bits sent
out with low speed data records to ready the decoder.
Used for both PassPort and LTR systems.
Select "0" through "7". Selects number of bits sent out at
the end of the low speed data record to aid the decoder.
Used for both PassPort and LTR systems.
Select "Enable" or "Disable". Selecting "Enable" forces
to radio to start in low power. The "RF Pwr" field in the
"Conv." programming screen or the Repeater Setting
programming sub-screen over-rides this. Programming
and activating a TX Power key will over-ride this also.
Select "Enable" or "Disable". Selecting "Enable" allows
certain key radio "accounting" information (such as run
time) to be periodically recorded to the radio's memory.
To use the run time fields in the Field Data programming
screen you must enable this. Enabling this also activates
the Total Radio Runtime field in the Field Data
programming screen.
Select "Enable" or "Disable". Selecting "Enable" forces
the radio on start up to continuously scroll detailed
information about the current PassPort, LTR or
Conventional system you have selected. This can be
over-ridden by toggling the Mode Display Type key
(though if power is cycled, the display will revert to
"Scroll").
Select "Enable" or "Disable". Selecting "Enable" causes
the radio to emit a short tone whenever it goes into search
mode (roam) because CRC is not sufficient.
Select "Enable" or "Disable". Selecting "Enable" causes
the radio to emit a short tone whenever it goes into search
mode (roam) because RSSI is not sufficient.
Select "Rolling" or "Non-Rolling". The optional UT-109
(#02) or UT-110 (#02) voice scramble unit is required for
this functionality (remove the UT-108 DTMF decoder
unit to install). The UT-109 is a "Non-Rolling" type
scrambler so select "Non-Rolling" in this field if
installing a UT-109. The UT-109 will work with
Conventional, LTR or PassPort. The UT-110 is a
"Rolling" type scrambler so select "Rolling" in this field
if installing a UT-110. The UT-110 can be used with
LTR or PassPort, but only if the Synchronous Capture
field is set to "Continuous". If the Synchronous Capture
field is set to "Standard" the scrambler can only be used
in Conventional mode.
Select 1 through 4. Selects group code. This setting is for
the UT-110 only as the UT-109 does not utilize group
codes.
(rev 1.0) -
Common Programming Screen
Default
2
2
Disable
Disable
Disable
Disable
Disable
Rolling
1
60
