Toolbar - Icom IC-F620 Programming Software Manual

TOOLBAR

The Toolbar provides quick access to commonly used functions. Note: if you let your
mouse "hover" over a Toolbar button for about one second a tool tip will be displayed,
briefly describing the function of that button.
New Button: Create new radio configuration file.
Open Button: Access configuration data stored in a file on the programming
computer's hard drive. When selected, use the dialog box to navigate to the correct data
file (usually with a ".icf" extension).
Save Button: Used to save configuration data to a file. When selected, use the dialog
box that opens to name the file and store it in the folder of your choice.
Clone Read: Used to read configuration information in an attached radio. If you get a
"No answer from transceiver" dialog box follow the onscreen recommendations.
Clone Write: Used to write configuration information to an attached radio. If you get
a "No answer from transceiver" dialog box follow the onscreen recommendations.
Clone Info: Read basic information concerning the attached radio including ESN,
serial number, transceiver model, revision, comments and any installed option(s).
CS-F620TR Programming Software Manual Toolbar
(rev 1.0) -
11
