Icom IC-F620 Programming Software Manual page 24

Group Field
TG Group ID
Start
MIN
ASID
HSID
Frequency Home ch
(MHz)
Frequency Backup
(MHz) Home ch
Digital Color Code
Digital Fixed DCC
W/N
Prefer Last-
site
CS-F620TR Programming Software Manual
Description
Enter from 1 to 65519. Sets the split point
where all group/alias numbers at or above this
number are considered groups and all numbers
below this number are considered MINs. This
should be set before entering the PassPort Talk
Group Setting programming sub-screen.
Enter from 1 to 65519. Enter the MIN you wish
to use for this system here.
Enter from 1 to 127. Enter the ASID (Affiliated
System ID) for the system you wish to use
here.
Enter from 1 to 65535. Enter the HSID (Home
System ID) for the system you wish to use
here.
Enter from 1.000000 to 520.000000 (though, of
course, the radio will only function for
frequencies it is designed for). This is the home
channel of your home site and this is the
channel the radio will look to for idle messages,
go-to messages etc. (when registered to your
home system).
Enter from 1.000000 to 520.000000 (though, of
course, the radio will only function for
frequencies it is designed for). This is the
backup home channel that your radio will
search for and use in case of failure of the
primary home channel. This is not supported in
NTS Firmware from at least 2.4 earlier.
Select "0," "1," "2" or "3". It is unimportant
what this is set to if Fixed DCC is set disable.
Select "Enable" or "Disable". When this is
enabled, the radio will only attempt to register
to sites utilizing the color code entered in the
Color Code column. This setting is primarily
used to distinguish between different systems
that utilize the same frequency (most
commonly in geographically dissimilar areas).
Select "Wide" or "Narrow". Specify if the
PassPort system you are attempting to utilize is
using wide or narrow band channels.
Select "Enable" or "Disable". This sets the
search behavior of the radio when it is first
turned on or a new system has been selected. If
this field is set to "Disable" the radio will
always search for its home site first. If set to
"Enable," the radio will always search first for
the site it was registered to when the radio was
shut off or the system was changed. "Disable"
may help the PassPort system operator reduce
network traffic; "Enable" will probably ensure
quicker end-user registrations.
Default
32000
1
1
1
Blank
3
Disabled
(Blank)
Wide
(Blank)
Disabled
(Blank)
PassPort Programming Screen
(rev 1.0) -
Suggested
Settings
System
operator
provided.
System
operator
provided.
System
operator
provided.
System
operator
provided.
Mandatory
field - system
operator
provided.
Currently not
supported in
PassPort – do
not use.
System
operator
provided.
System
operator
provided.
System
operator
provided.
System
operator
provided.
21
