DTMF DECODE PROGRAMMING SCREEN

DTMF D P
ECODE
This programming screen allows the programmer to create, read, edit and delete all
global DTMF Decode entries. This is a global screen and all system programming
screens will refer to this list in the "Decode ch" field.
Note that to delete a row, you can right click on almost any field in the programming
screen and select "Delete" from the menu that appears.
DTMF D
ECODE
Group Field
No.
Text
Primary Code
Primary Response
Secondary Code
Secondary Response
Dead Beat Enable
Code
CS-F620TR Programming Software Manual
S
ROGRAMMING CREEN
P
ROGRAMMING
Description
The line number of the DTMF Decode entry.
You can have up to 10 entries here before
getting an overflow error.
Double click here to enter a text description for
this system (as described on page 13). You can
enter up to 10 characters for this field.
Enter up to 10 numbers here. This is the
sequence of DTMF digits that is the primary
decode for this row.
Select "None" or any listed entry (you must
have entries in the DTMF Encode
programming screen to see a list of selections
here). This is the DTMF response given upon
the proper decode of the digits in the Primary
Code field.
Enter up to 10 numbers here. This is the
sequence of DTMF digits that is the secondary
decode for this row.
Select "None" or any listed entry (you must
have entries in the DTMF Encode
programming screen to see a list of selections
here). This is the DTMF response given upon
the proper decode of the digits in the Secondary
Code field.
Enter up to 10 numbers here. This is the
sequence of DTMF digits that will restore the
radio from DTMF "stun" mode.
I : Located in DTMF Autodial Folder
CON
S F D
CREEN IELD ESCRIPTION
DTMF Decode Programming Screen
(rev 1.0) -
T
ABLE
Default Suggested
Settings
No user No user
entry. entry.
Blank Set as
needed.
Blank Set as
needed.
None Set as
needed.
Blank Set as
needed.
None Set as
needed.
Blank Set as
needed.
49
